SPECIFICATION SHEET
80F HRV90H.indd
FEATURES
•20% smaller than comparable units / Designed for
applications where space is critical, such as closet
and utility rooms in condominiums, apartments, and
pre-fabricated homes. Also has compact footprint
design for an easy t in mechanical rooms, closets,
and other tight-t applications. A versatile solution for
the most demanding applications.
• State-of-the-art ventilation technology / Performance
sized for new ventilation standards and will not
over-dry the house. The most exible Heat Recovery
Ventilator (HRV) on the market.
•Bottom door opening / Design allows easy access
from any angle.
•Side (HRV90HS) and top (HRV90HT) port
conguration / Versatile design allows for vertical or
horizontal conguration, facilitating installation and
maintenance (factory-congured).
• Removable electric drawer / Easy maintenance of
major sub-components.
•Interchangeable core / Allows unit to be changed from
HRV to ERV in the summer.
• Convenient three-mode wall control (VT4W)
(Optional) (Min/Max Intermittent: 20-min. On / 40-min.
Off).
HRV90H
FRESH AIR SYSTEM
GENERAL SPECIFICATIONS
•For houses up to 3,000 sq. ft.
•45 to 96 cfm (0.4 in. w.g.)
• Voltage: 120 VAC
• Frequency: 60 Hz
• Dimensions: 12.81” x 22.56” x 19.81”
• Weight: 39 lbs
• Shipping Weight: 42 lbs
• Warranty: 2 years on parts - 10 years on core
• HVI Rated of air ow: 106 cfm
• Power Consumed (max): 150 Watts
• Supply air duct connections: 5” diameter
• Exhaust air duct connections: 5” diameter
• Filter: 30 ppi washable reticulated foam
• Cabinet: 20 ga. Pre-painted steel
• Mounting: Suspension by chains and springs
• Wall control modes: Low/High Speeds
• Power: 150 Watts
• Current: 1.3 Amps
•Continuous duty, permanently lubricated motors
• 36” power cord
ERV90HC
HRV90H

Broan-NuTone LLC Hartford, Wisconsin www.broan.com 800-558-1711
MODEL HRV90H
PERFORMANCE SPECIFICATIONS
INSTALLATION OPTIONS
Energy Performance
Supply Temperature Net Airflow Average
Power
Sensible
Recovery
Efficiency
Apparent
Sensible
Effectiveness
Latent
Recovery
Moisture
Transfer
Heating C F L/s cfm Watts % %
0 32 23 48 68 66 78 0.07
0 32 30 63 82 65 76 0.04
0 32 44 93 116 59 68 0.04
-25 -13 30 63 110 55 81 0.08
Total Recovery Efficiency
Cooling 35 95 Not Tested
Ventilation Performance
External
Static Pressure Net Supply Airflow Gross Airflow
Supply Exhaust
Pa In. W.g. L/s cfm L/s cfm L/s cfm
25 0.1 52 110 52 110 57 122
50 0.2 50 106 50 106 55 116
75 0.3 48 101 48 102 53 113
100 0.4 45 96 46 97 50 107
125 0.5 43 92 43 92 48 103
150 0.6 41 87 41 87 45 96
175 0.7 38 81 38 81 43 91
Return-Return
Connection
Bulkhead Installation
(Mechanical Room) Direct Exhaust - Return Connection
Warm
Cold
Cold
Cold
Cold
Warm
Warm
Warm
Cold
Cold
Cold
Cold
Warm
Warm
