NUTRICHEF PKBRTP99 User manual

www.NutriChefKitchen.com
1
3
2
45
10
11
8
6
9
7
12
HomebrewDoubleWallMiniKeg
BeerDispenser
PKBRTP99-PKBRTP299
UNIT OPERATION INSTRUCTION
1. Mini keg Growler
2. Cap Spear Body
3. Gas In Connection Tube
4. Pressure Relieving Valve 30PSI.
5. Cross-bar
6. Regulator Base
7. 30 PSI Pressure Gauge
8. CO2 Regulator Knob
9. CO2 Regulator Aluminium Body
10. Black Plastic Tap Handle.
11. Chrome Plated Faucet Body
12. Beer Tube
NOTE: DON’T stop turning if you hear a slight gas leak
swish, nish turning it in all the way it seal properly.
PART TWO: TAPPING
1. Connect the regulator with capsule to the spear.
2. Install faucet into spear body, make sure the connection
is proper and tight.
Remark: Improper combination would cause leakage of
beer.
3. Pull on pressure relieving ring for a couple of seconds.
If the keg was shaken in transit or warmed, it may
contain excessive pressure which must be relieved
before tapping. A hissing noise is expected.
4. Slowly turn the regulator knob in clockwise direction
to 5 PSI, and stop for 2 seconds ad turn o regulator.
PART ONE: SPEAR ACCEMBLY
1. Please clean mini keg, cap, spear
body, faucet and beer hose with
warm water and mild soap before
use.
2. Fill your mini keg at your favourite
craft brewery, or with your own
homebrew.
3. Cut beer hose according to keg
height and insert into spear, make sure hose can touch
bottom of keg without overlong or over short.
Remark: If hose is too short, beer would not be tapped
completely. But if hose is too long, it may crimp inside the
keg, also cause incomplete tapping.
4. Fit tube on to spear, and screw spear into mini keg.
5. Check whether the regulator knob is in OFF position. If
not, please follow arrow mark instruction to turn the
regulator knob counter clockwise to the OFF position.
6. Turn in a new 16g CO2 capsule with thread type of
3/8-24UNF, turn clockwise rmly into the regulator base.

www.NutriChefKitchen.com
Wait for 2 mins, then pull on the pressure relieving ring
for a couple of seconds. This is for adjusting pressure of
keg beer.
5. Put a glass or pitcher under
the faucet spout, with the
faucet knob pulled forward
(ON), slowly turn the regulator
knob on in clockwise direction,
until beer starts to ow out.
Don’t continue adding
pressure, suggest tapping 5-8
PSI (Max pressure 30 PSI), so
please stop turning the regulator knob when the
pressure is enough to tap beer out with perfect foam.
Too much pressure would cause over foam. When the
beer stopped or ow slower, try turning the regulator
knob on slowly, to get bigger pressure.
6. When you nish tapping, please turn regulator knob to
OFF position.
7. If there is no beer owing out, then the CO2 capsule
needs to be replaced, unless no beer is remained
(Normally, 16g capsule can tap 4-5 liters of beer).
Caution: Removing a punctured capsule from regulator
should be done slowly. Swish is expected if pressure
remains.
8. Turn the regulator knob o and install a new capsule
into the regulator by following above steps.
TROUBLE SHOOTING GUIDE
1. Faucet Leakage
Solution: Screw out and remove the faucet, then install
again, make sure the faucet can match the connection
of spear tightly.
A 35x3.1 MM (1pcs)
B 13x10x2 MM (1pcs)
C 8x1.5 MM. (1pcs)
D11x1.5 MM (2pcs)
E8x2.5 MM (3pcs)
(Out Diamter* Thickness)
O RING ASSEMBLY:
2. Too much Foam
Solution: Decrease the pressure properly.
3. Leakage of CO2
CO2 capsule should be installed properly and tightly.
In case there is CO2 leakage, please observe the position
of leakage and continue with the tightening process, but
never screw out if gas remains.
PART FOUR: WARNING
1. Keep away from children under 18.
2. Never point cylinder towards someone’s face.
3. Do not heat over140°F as rupture may occur!
4. Discontinue using of this equipment if unsolvable
leakage or visible damage is found.
5. Capsule end become punctured when turned into
regulator base. Unscrewing before it’s empty can result
in loss of high pressure gas. Please remember, never
unscrew the CO2 capsule before gas used up, liquid CO2
spray onto unprotected skin may cause freezing burns.
6. Exterior of capsule may become frozen when in use,
this is normal. But don’t touch with bare hands, your
ngers could stick to the frozen surface and cause
frostbite.
7. Please ship via land or sea shipment, never bring CO2
capsule when you travel by air.
O RING INFORMATION:
Questions? Issues?
We are here to help!
Phone: [phone]
Email: [email protected]
This product can expose you to a chemical or group of checmicals, which
may include ”Chromium” which is known in the state of California to cause
cancer, birth defects, or other reproductive harm. For more info, go to
https://www.p65warnings.ca.gov/.
A
E
B
D
C
