NUTRICHEF PKOPR15 User manual

OIL PRESS
User Manual
Don't connect this machine to a power source before you read this manual
completely. Keep this manual for future reference.
Picture is for reference only; there may be slight changes to the actual product.
Continuous improvement made to the product is subject to change without being
informed.
PKOPR15

Safety Instructions
Warning: Possible accidents could occur if you operate this machine without reading the
instructions.
Notice: If you operate this product with disregard to the instructions, your product,
property, or yourself could be endangered.
Please read the operation instruction of the manual in detail while using this
machine, and keep this book for future reference.
In order to prevent accidents or danger, the power cord or plug must be replaced
by the manufacturer or the maintenance department designated by the
manufacturer.
N o tic e
Please read the each
instruction of the directions in
detail before using the product.
The power supply used shall be 0V
of voltage and more than 10A of
current.
Please don't use the product
beyond the functional scope.
Be sure not to operate the product by
the children.
Please stop using the product when
the power line and plug are damaged
and failed in function.
The product must be operated on the
stable and reliable work surface.
Please don’t use the product outdoors.
Please don't contact the power line to
the sharp corners or high temperature
surfaces.
Please hold the plug while pull out the
plug, and please don’t pull the power
line.
Clean the product when it is cooled fully
after using, so as to avoid from scalding.
Please don’t immerse the product in
the water or any other liquids.
To ensure the safety, please don’t dismantle the product arbitrarily, and please send to the each
service center or agency of company to maintain by the qualified maintenance personnel, if any
abnormal.
11

Product Scope
This product is able to squeeze: peanuts, sesame seeds, vegetable seeds, tea seeds,
soybeans (shell and grind to about 5mm before the extracting the oil), sunflower
kernels and walnuts (shell and crumb to about 5mm before the extracting the oil).
This product does not apply to grains or seeds where the oil content is low and cannot
be shelled (such as corn).
*Note: The product is designed for family indoor use, and is not applicable to
commercial purpose; otherwise, the product longevity may be shortened.
Notice
Before using this product, please read the instructions in detail and use this machine
with regard to the instructions.
1. Please do not share the power source of this product with other high-powered
electrical equipment.
2. To prevent the electric surge and any possible danger, please use this machine
according to the instructions.
3. This machine is strictly prohibited from being immersed in water. This includes the
power line and the plug as well.
4. Please attention while you or someone else is operating this machine as to avoid
possible accidents or danger.
5. If you have discovered any damaged parts or damage to the product structure,
please do not use this product. You should also never attempt to perform maintenance
to the machine by yourself; maintenance should be done by a professional so as to
avoid possible accidents or danger.
6. Children or disabled people should never operate this machine without parental
guidance or supervision.
7. Please do not use this product on or near high-temperature areas or appliances.
8. Please be careful while moving the machine or oil cup after the completion of the
extraction of oil, so as to avoid the splashing or spilling of oil.
9. Please do not touch or move any moving parts while the oil press is operating.
10. Please don't insert any foreign or metal objects into the oil press so as to prevent
any accidents, fire or short circuiting.
11. Please don't start the machine while the squeezing chamber is not completely in
place.
12. Before cleaning this machine, please switch off the power supply and pull the plug
out while the machine is idle or being moved.
13. Be sure not to place the machine near any flammable material or objects.
14. In order to prevent danger, have the damaged power line or plug replaced by the

manufacturer or the maintenance department.
15. While pulling out the plug, make sure to not pull the actual cord, but the plug
itself. You are also prohibited from handling the plug or power cord with wet hands.
16. Before using the machine, please ensure that the oil press is placed on a firm, flat,
table-top surface.
17. Please don't place the machine in an area where it is in the arm’s reach of children.
18. Please be sure to pull the plug out of its power supply when you are done using it.
Components
(Components above are subject to actual product.)
2
3
1
4
7
5
68
9
10 11
12
13
15
16
14
17
18
19 20
1. Pan
2. Cover
3. Upper main body
4. Operation panel
5. Protection cover
6. Squeezing chamber componen
7. Heater
8. Fastening nut
9. Squeezing chamber assembly
10. Nut
11. Filter
12. Lower main body
13. Oil receiving cup
14. Drawer ( for small parts)
15. Slag receiving box
16. Small push rod
17. Screw driver
18. Small brush
19. Big brush
20. Glove

Installation Instructions
Check if the silicon ring is put on the hex head side of the screw
1. Put the lower main body on a smooth, flat table; insert the screw in the motor output bearing
hole from the hex head side.
2. Insert the squeezing chamber into the squeezing chamber component the same way that you
installed the screw.
3. Tighten the squeezing chamber component by tightening the nut in a clockwise direction.
Silicon ring

4. Put the protection cover onto the upper main body as shown in the above picture (arrow).
5. Attach the upper body to the lower body; fasten the screw to make both parts stable and firmly
connected
6. Place the oil receiving container directly in front of the machine (underneath the nozzle) so as to
catch the oil that is being extracted while the machine is in use.
7. Take out the small push rod, the screwdriver, and small from manual package, pull out the
drawer located on the bottom of the machine and place them inside.

Assembling the Waste Box
1. Insert the two “Board B” pieces into the card slot on Board A from the bottom up, (Picture 1
and Picture 2)
2. Insert the Board A card slots into the two Board B slots from top to bottom. (Picture 3)
3. Fold the bottoms of Board B toward the inside. (Picture 4)
4. Fold the bottoms of Board A toward the inside. (Picture 5)
Board A Board B
Picture 1 Picture 2
Picture 3
Picture 4
Picture 5

5. Tighten the 4 buckles on Board A to Board B (Picture 6)
Picture 6

Operating the Panel
In the process of the oil extraction, the LCD panel will flash and show the operation status and
running time of the current stage.
Explanation of Functions
1. Power Button: While plugged in, the buzzer will sound with a beep; only the power button is
workable at this time. Touch the " " button with the power connected; now the time screen
should show "00:00". The default settings will have "Peanut" and “Well Done" (baking level)
selected. Touch the " " button again to switch it off.
2. Function Button: touch the “ ” button; there is a “Well Done”, “Medium”, “Mild” and
“Raw” option. It is recommended that certain plants/seeds/grains only use two of these options.
3. Start Button: Once you are finished selecting the correct settings, press “ ”to begin the oil
extraction.
4. Reverse Function: press the “ ” button for 3 seconds; the machine will reverse the gear
so that the plant/grains will be pushed upward; once the plant/grains are loosened, it will stop.
5. Stop Function: while operating this machine, if the "Stop" button is touched, the machine will
stop. It will return to the next step when the “ ” button is touched (If you press and hold
“”for 3 seconds, the machine stops and all the settings are canceled).
Peanut Black
Sesame White Sesame
Rapeseed Sunflower
Seed Flaxseed
Walnut Soybean Others
W e ll
D o n e
M edium M ild R a w
