Nuu Garden SRD001-01 User manual

NUUGARDEN USA
INSTRUCTION MANUAL
Nuu Garden Corp.
Add: 6366 Corley Road, Norcross GA 30071.
Tel: [phone]
Web: http://www.nuugarden.com
E-mail: [email protected]
SRD001-01

1 8
Thanks for purchasing and trusting NUUGARDEN with your home deco-
rating plans. This product is a furniture designed and made by
NUUGARDEN Corp.
We are committed to R&D innovation and to create the most refined,
diverse choice of outdoor collection.
After unpacking and before every use, check whether the item shows
any damages. In addition, check that you have all parts and hardwares
before assembly. If there is any damage, please do not use and just call
customer service at [phone] or send an email to service@nu-
ugarden.com. If you do not have all the parts lists, have your dealer
contact us and they will be sent to you immediately.
This furniture is intended for indoor and outdoor use. Please take time to
read and follow the instruction below. Use the item as described in this
operating manual.We accept no liability for damages caused by improp-
er use.
INTRODUCTION
Thanks for purchasing this NUUGARDEN furniture. We are here to help you
maximize your enjoyment and appreciation of it.
Please do not hesitate to contact our customer service when you have any
questions regarding assembly or accessories.
Add: 6366 Corley Road, Norcross GA 30071.
Tel: [phone]
Web:http://www.nuugarden.com
E-mail: [email protected]
Service time: Mon-Fri, 8:30 AM-5:30 PM, EST
CUSTOMER SERVICE
CARE AND MAINTENANCE
Follow the instruction for the material of your special product to make
sure that it stays in the best shape for as long as possible.The informa-
tion below is only intended as a general guideline. For more information,
please contact us.
• Only need to rinse it thoroughly with clean water to wash away dirt and
grime. Never use abrasive cleansers on the furniture, since it can attack
the surfaces and leave behind scratch marks.
• For the stubborn grime and stains, just use a soft sponge and mild
soapy water and then dry it with a cloth or paper towel.
• Check the stability of the screws, nuts and nut caps prior to each use.
Tighten up them after one to two month’s use whenever required.
• Avoid improper use, and be careful not to scratch or damage the
surface with sharp objects.
• When you move your furniture, make sure you lift it rather than pulling
or pushing it to avoid damaging the foor, legs and mounting.

Step1: Attach chair frame(B) to 2 back legs(C) using 4 bolts(F) and
4 washers(G). Attention to the back legs' direction. Do not over
tight.
Step2: Attach the step1 components to base(A) using 4 bolts(E)
and 4 washers(G). Do not over tight.
Step3: Attach base(A) to foreleg(D) using 4 bolts(F) and 4 wash-
ers(G). Do not over tight.
Step4: Upon completion of full assembly and bolted up-all screws
can be tightened down.
7 2
Note:Please do not tighten any bolt until all bolts have been put
into right place.
If you tighten one bolt, it maybe cause other bolts out of position.
1
Part
Number
Images
Sizes
Qty.
and
A
B
C
D
E
2
2
12
12
M6*20
M6*ø15
A
B
C
B
C
E

3 6
1 1
B
C
E
D
↓
E
D
↓

5 4
Step1：Assemble the 2 front legs （B）and the 2 behind
legs（C）to the seat （A）by 3 washers（D）and 3 bolts
（E) respectively.
Step2: Secure and tighten all the components and attched
cushions.
Note:Please do not tighten any bolt until all bolts have
been put into right place.
If you tighten one bolt, it maybe cause other bolts out of
position.
1
Part
Number
Images
Sizes
Qty.
and
A
B
C
D
E
4
1
8
8
M6*15
M6*ø15
ASSEMBLY INSTRUCTIONS
