Nuvico Xcel NCT-8ML-E21AF User manual

1
2
Package
Overview
Installation
1
2
3
4
►Connecting Network Cable
Warning and Caution
■If the product does not work properly, please contact your dealer or
the nearest service center. Never attempt to disassemble the camera
yourself. (We shall not be responsible for any problems caused by
unauthorized repair or maintenance.)
■Do not allow water or liquid intrusion into the camera.
■In the use of the product, you must be in strict compliance with the
electrical safety regulations of the nation and region. When the product is
mounted on wall or ceiling, the device shall be firmly fixed.
■Do not use camera b eyond specified voltage range.
■Do not drop the camera or subject it to physical shock.
■Avoid touching the camera lens.
■If cleaning is necessary, please use clean cloth to wipe it gently.
■Do not aim the camera at the sun or extra bright place.
■Do not place the camera in extremely hot, cold (the operating
temperature shall be -22˚F~140˚F), dusty or damp locations, and do not
expose it to high electromagnetic radiation.
■To avoid heat accumulation, good ventilation is required for operating
environment.
Camera Quick start guide
CD Plastic plug ×4 Drill template
Screwdriver
Tapping screw ×4
Please make sure that the wall or ceiling is strong enough to
withstand 3 times the weight of the camera.
① Loosen the fixed screw to disassemble the camera.
②
the drill template.
Drill the screw holes and the cable hole on the wall according to
■Please read these instructions carefully before operating the unit
and keep it for further reference.
■All the examples and pictures used here are for reference only.
■The contents of this manual are subject to change without notice.
* 1 It is recommended to install the security cap for outdoor installation.
* 2 If the PoE switch is used to power the camera, DC12V power supply is not
required.
Security Cap
2
13
Fixed Screw
Cover (only available for
manual zoom camera)
Mounting Base
Enclosure
Dome
DC12V
3
41
2
3
4
Ethernet connector
Mounting base
Fixed screw
Power connector
Ø4.24 in
Ø5.0 mm
Ø3.13 in
2.21in
2.21 in
③Route and connect the cables. T
ceiling or wall with the screws provided.
hen secure the mounting base to the
(in)
NCT-8ML-E21AF Eyeball Camera
Quick Start Guide
①Loosen the nut from the main element.
②Run the network cable (without RJ 45 connector) through both
elements. Then crimp the cable with RJ 45 connector.
③Connect the cable to the hermetic connector. Then tighten the
nut and the main cover.

Network Connection
5
MENU
MENU
IPC
IPC
Network Cable Network Cable
Network Cable
Switch
Router Computer
Computer
•Access Through Xcel IP Utility
In LAN, there are two ways to access the camera. 1. Access Through
Xcel IP Utility; 2. Direct Access Through Web Browser
①Make sure that the camera and the PC are connected to the local
network.
②Install Xcel IP Utility from the CD and run it after installation.
Device Network Search
Immediate Refresh
name
name
name
IPC
IPC
IPC
unknown
unknown
unknown
192.168.2 26.201
192.168.1 .2
192.168.1 .3
80
80
80
9008
9008
9008
255.255.
255.255.
255.255.
Modify Netw ork Parame ter
Mac Address
IP Address
Modify
CE :98 :23 :75 :3 5 :22
192 . 168 . 226 . 201
255 . 255 . 255 . 0
192 . 168 . 226 . 1
i
Tip: Enter the administrator passwor d, and
then modify t he network parameters.
Total Device: 3 Local IP Address:192.168.1.4Subnet Mask:255.255.255.0 Gateway: 19 2.168.1.1 DNS：21 0.21.196.6
Device Name Device Type IP Address Http Port Data Port Subnet Product Mod el
About
Subnet Mask
Gateway
Restore IPC Default Configuration
③MModify the IP address. The default IP address of this camera is
192.168.226.201. Click the information of the camera listed in the
above table to show the network information on the right hand. Modify
the IP address and gateway of the camera and make sure the network
address is in the same local network segment as the computer. Please
modify the IP address of your device according to the practical situation.
Mac Address
IP Address
Modify Network Parameter
Modify
CE :98 :23 :75 :35 :22
192 .168 . 1 . 201
255 . 255 . 255 . 0
192 .168 . 1 . 1
Subnet Mask
Gateway
The default password of the administrator is “123456”.
④Double-click the IP address and then the system will pop up the web
browser to connect the IP camera. Follow directions to download and run the
plugin in the computer. Then enter the user name and password in the login
interface.
•Direct Access Through Web Browser
The default network settings are as shown below:
IP address: 192.168.226.201 HTTP:80
Subnet Mask: 255.255.255.0 Data Port:9008
Gateway: 192.168.226.1
You may use the above default settings when you log in the camera
for the first time.
①Set the IP address of the PC and make sure the network segment is
the same as the default settings of the IP Camera. Open the network and
share center. Click “Local Area Connection” to pop up the following
window. Select “Properties” and then select Internet protocol according
to the actual situation (for example: IPv4). Next, click
“Properties” button to set the network of the PC.
For example, the IP address of your computer is 192.168.1.4. So the
IP address of the camera shall be changed to 192.168.1.X. After
modification, please enter the password of the administrator and click
“Modify” button to modify the setting.
②Open a browser and enter the default address of IP Camera and
confirm.
③Download and run the plugin in the computer.
④Enter the default username and password in the login interface to
log in.
NCT-8ML-E21AF450043001155 A0
The default username is admin; the default password is 123456.
④
ceiling or wall with the screws provided.
Route and connect the cables. T hen secure the mounting base to the
⑥
the dome to obtain an optimum view angle. Finally, fix the camera with
the fixed screw.
Install the dome and enclosure to the mounting base and then adjust
After that, open the cover of the camera to adjust Zoom or Focus to
obtain an optimum image. Then install the cover back and fix it firmly
with the screws. Note that the cover shall not be installed unevenly.
Before adjustment, view the image of the camera on a monitor.
**If the model you get is motorized zoom lens, please skip this step.
⑤
Zoom
Focus
