nvent ERICO System 1000 User manual

1m
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
nVent, nVent CADDY, nVent E ICO Cadweld, nVent E ICO Critec, nVent E ICO, nVent E IFLEX, and nVent LENTON are owned by
specifications without prior notice.
www.nVent.com
IP8504_A 1 OF 7
System 1000 Cantilevered 3 meters above building
INSTRUCTION SHEET
nVent or its global affiliates. All other trademarks are the property of their respective owners. nVent reserves the right to change
TECHNICAL SUPPO T
WA NING:
nVent products shall be installed and used only as indicated in nVent product instruction sheets and training materials. Instruction sheets are available at 1.
www.nVent.com and from your nVent customer service representative.
nVent products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.2.
All instructions must be completely followed to ensure proper and safe installation and performance. 3.
Improper installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause product malfunction, property 4.
damage, serious bodily injury and/or death, and void your warranty.
SAFETY INST UCTIONS:
All governing codes and regulations and those required by the job site must be observed.
© 2019 nVent All ights eserved
Three every 1m
ITEM PART No. QTY. DESCRIPTION
1 SIXXI 1 ESE Terminal
2 SIM28A2 1 SIM STAINLESS STEEL MAST
3 SIM33B2 1 SIM STAINLESS STEEL MAST
TMCSS (702165) 2 PIPE CLAMP
5 ALOF1GS (702175) 2 MAST SUPPORT
6 CABTIESS (701 20) 9 CABLE TIE
7 DOWN CONDUCTOR CLIP 3 PER METER
8 COPPER TAPE/CABLE DOWN CONDUCTOR
2
3
8
8
5
3
1
To bend down conductor:
ollow chapter 5.3.3 rom
NFC 17-102 standard
4
8
1
grounding system
Connect to
7
8
2
6
8
Connect to
grounding system
5
3
1m

1 m
Connect to
grounding system
85
3
1
2
8
8
5
To bend down conductor:
ollow chapter 5.3.3 rom
NFC 17-102 standard
3
8
2
6
8
Connect to
grounding system
7
4
1
8
ITEM PART No. QTY. DESCRIPTION
1 SIXXI 1 ESE Terminal
2 SIM28A2 1 SIM STAINLESS STEEL MAST
3 SIM33B3 1SIM STAINLESS STEEL MAST
TMCSS (702165) 2 PIPE CLAMP
5 ALOF1GS (702175) 2 MAST SUPPORT
6 CABTIESS (701 20) 12 CABLE TIE
7 DOWN CONDUCTOR CLIP 3 PER METER
8 COPPER TAPE/CABLE DOWN CONDUCTOR
Three every 1m
TECHNICAL SUPPO T
www.nVent.com
IP8504_A 2 OF 7
INSTRUCTION SHEET
nVent, nVent CADDY, nVent E ICO Cadweld, nVent E ICO Critec, nVent E ICO, nVent E IFLEX, and nVent LENTON are owned by
nVent or its global affiliates. All other trademarks are the property of their respective owners. nVent reserves the right to change
specifications without prior notice.
WA NING:
nVent products shall be installed and used only as indicated in nVent product instruction sheets and training materials. Instruction sheets are available at 1.
www.nVent.com and from your nVent customer service representative.
nVent products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.2.
All instructions must be completely followed to ensure proper and safe installation and performance. 3.
Improper installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause product malfunction, property 4.
damage, serious bodily injury and/or death, and void your warranty.
SAFETY INST UCTIONS:
All governing codes and regulations and those required by the job site must be observed.
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
System 1000 Cantilevered 4 meters above building
© 2019 nVent All ights eserved
1 m

1 m
1 m
Connect to
grounding system
96
4
9
9
6
3
To bend down conductor:
ollow chapter 5.3.3 rom
NFC 17-102 standard
1
2
4
9
2
7
5
1
9
9
Connect to
grounding
system
8
TECHNICAL SUPPO T
www.nVent.com
IP8504_A 3 OF 7
INSTRUCTION SHEET
nVent, nVent CADDY, nVent E ICO Cadweld, nVent E ICO Critec, nVent E ICO, nVent E IFLEX, and nVent LENTON are owned by
nVent or its global affiliates. All other trademarks are the property of their respective owners. nVent reserves the right to change
specifications without prior notice.
WA NING:
nVent products shall be installed and used only as indicated in nVent product instruction sheets and training materials. Instruction sheets are available at 1.
www.nVent.com and from your nVent customer service representative.
nVent products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.2.
All instructions must be completely followed to ensure proper and safe installation and performance. 3.
Improper installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause product malfunction, property 4.
damage, serious bodily injury and/or death, and void your warranty.
SAFETY INST UCTIONS:
All governing codes and regulations and those required by the job site must be observed.
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
System 1000 Cantilevered 5 meters above building
© 2019 nVent All ights eserved
ITEM PART No. QTY. DESCRIPTION
1 SIXXI 1 ESE Terminal
2 SIM28A2 1 SIM STAINLESS STEEL MAST
3 SIM33B3 1SIM STAINLESS STEEL MAST
SIM 0C2 1 SIM STAINLESS STEEL MAST
5 TMCSS (702165) 2 PIPE CLAMP
6 ALOF1GS 3 MAST SUPPORT
7 CABTIESS (701 20) 1 CABLE TIE
8 DOWN CONDUCTOR CLIP 3 PER METER
9 COPPER TAPE/CABLE DOWN CONDUCTOR
Three every 1m
1 m
1 m

1 m 1 m
Connect to
grounding system
9
6
4
5
1
9
1
9
9
6
3
To bend down conductor:
ollow chapter 5.3.3 rom
NFC 17-102 standard
4
227
9
Connect to
grounding system
8
ITEM PART No. QTY. DESCRIPTION
1 SIXXI 1 ESE Terminal
2 SIM28A2 1 SIM STAINLESS STEEL MAST
3 SIM33B3 1 SIM STAINLESS STEEL MAST
SIM 0C3 1 SIM STAINLESS STEEL MAST
5 TMCSS (702165) 2 PIPE CLAMP
6 ALOF1GS 3 MAST SUPPORT
7 CABTIESS (701 20) 17 CABLE TIE
8 DOWN CONDUCTOR CLIP 3 PER METER
9 COPPER TAPE/CABLE DOWN CONDUCTOR
Three every 1m
TECHNICAL SUPPO T
www.nVent.com
IP8504_A 4 OF 7
INSTRUCTION SHEET
nVent, nVent CADDY, nVent E ICO Cadweld, nVent E ICO Critec, nVent E ICO, nVent E IFLEX, and nVent LENTON are owned by
nVent or its global affiliates. All other trademarks are the property of their respective owners. nVent reserves the right to change
specifications without prior notice.
WA NING:
nVent products shall be installed and used only as indicated in nVent product instruction sheets and training materials. Instruction sheets are available at 1.
www.nVent.com and from your nVent customer service representative.
nVent products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.2.
All instructions must be completely followed to ensure proper and safe installation and performance. 3.
Improper installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause product malfunction, property 4.
damage, serious bodily injury and/or death, and void your warranty.
SAFETY INST UCTIONS:
All governing codes and regulations and those required by the job site must be observed.
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
System 1000 Cantilevered 6 meters above building
© 2019 nVent All ights eserved
1 m 1 m

Crow's oot
DOWN CONDUCTOR CLIP
3 every 1 m
Connect to
lightning
protection
system
Digital Lightning Counter
LECV
Earth testing clamp
CCJ70CA
To be installed in a accessible area
IP900C
103450
Down conductor
Crow's oot
Grounding busbar
Conductor protection
Install earth pit 1 meter away
rom the building acade
Building
Ground
Ground
Enhancement
Material
GEM25A (163670)
Quick ill (QF25)
Around grounding system
TECHNICAL SUPPO T
www.nVent.com
IP8504_A 5 OF 7
INSTRUCTION SHEET
nVent, nVent CADDY, nVent E ICO Cadweld, nVent E ICO Critec, nVent E ICO, nVent E IFLEX, and nVent LENTON are owned by
nVent or its global affiliates. All other trademarks are the property of their respective owners. nVent reserves the right to change
specifications without prior notice.
WA NING:
nVent products shall be installed and used only as indicated in nVent product instruction sheets and training materials. Instruction sheets are available at 1.
www.nVent.com and from your nVent customer service representative.
nVent products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.2.
All instructions must be completely followed to ensure proper and safe installation and performance. 3.
Improper installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause product malfunction, property 4.
damage, serious bodily injury and/or death, and void your warranty.
SAFETY INST UCTIONS:
All governing codes and regulations and those required by the job site must be observed.
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
© 2019 nVent All ights eserved
GROUNDING SYSTEM
Ground rod
connector
RTCxxxx
Copper bonded
ground rod
Down conductor

LIGHTNING SYSTEM
EARLY STREAMER EMISSION TERMINAL
-SI25I
-SI40I
-SI60I
SIM STAINLESS STEEL MAST
-SIM28A2
-SIM33B2
-SIM33B3
-SIM40C2
-SIM40C3
PIPE CLAMP
-TMCSS (702165)
MAST SUPPORT
-ALOF1GS (702175)
-ACF2GS (103100)
CABLE TIE
-CABTIESS (701420)
CONDUCTORS
-TAPE
-ROUND SOLID CONDUCTOR
-STRANDED CONDUCTOR
FASTENERS
GROUNDING SYSTEM
GROUND ROD
GROUND ROD TO CONDUCTOR
INSPECTION HOUSINGS
CROWS FOOT
GF302 (503900)
QUICKFILL (QF25)
GEM25A (163670)
DIGITAL LIGHTNING
EVENT COUNTER
LECV
LECIV (702050)
EARTH TESTING CLAMP
CCJ70CA (102700)
CONDUCTOR PROTECTORS
Copper, Tinned copper and Aluminium
TECHNICAL SUPPO T
www.nVent.com
IP8504_A 6 OF 7
INSTRUCTION SHEET
nVent, nVent CADDY, nVent E ICO Cadweld, nVent E ICO Critec, nVent E ICO, nVent E IFLEX, and nVent LENTON are owned by
nVent or its global affiliates. All other trademarks are the property of their respective owners. nVent reserves the right to change
specifications without prior notice.
WA NING:
nVent products shall be installed and used only as indicated in nVent product instruction sheets and training materials. Instruction sheets are available at 1.
www.nVent.com and from your nVent customer service representative.
nVent products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.2.
All instructions must be completely followed to ensure proper and safe installation and performance. 3.
Improper installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause product malfunction, property 4.
damage, serious bodily injury and/or death, and void your warranty.
SAFETY INST UCTIONS:
All governing codes and regulations and those required by the job site must be observed.
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
System 1000 Cantilevered parts and accessories
© 2019 nVent All ights eserved

TECHNICAL SUPPO T
www.nVent.com
IP8504_A 7 OF 7
INSTRUCTION SHEET
nVent, nVent CADDY, nVent E ICO Cadweld, nVent E ICO Critec, nVent E ICO, nVent E IFLEX, and nVent LENTON are owned by
nVent or its global affiliates. All other trademarks are the property of their respective owners. nVent reserves the right to change
specifications without prior notice.
WA NING:
nVent products shall be installed and used only as indicated in nVent product instruction sheets and training materials. Instruction sheets are available at 1.
www.nVent.com and from your nVent customer service representative.
nVent products must never be used for a purpose other than the purpose for which they were designed or in a manner that exceeds specified load ratings.2.
All instructions must be completely followed to ensure proper and safe installation and performance. 3.
Improper installation, misuse, misapplication or other failure to completely follow nVent's instructions and warnings may cause product malfunction, property 4.
damage, serious bodily injury and/or death, and void your warranty.
SAFETY INST UCTIONS:
All governing codes and regulations and those required by the job site must be observed.
Always use appropriate safety equipment such as eye protection, hard hat, and gloves as appropriate to the application.
System 1000 Cantilevered
© 2019 nVent All ights eserved
.
.
.
.
This manual is a guide to the installation, operation and maintenance o the nVent
ERICO SYSTEM 1000 Lightning Protection System. It assumes that the system to
be installed has been designed by an authorized nVent representative. The system
design will include:
• Grounding systems design – a con iguration should be designed as a result o
soil resistivity analysis.
• Downconductor routes - chosen to avoid other services maintain minimum
bending radius o 20 cm (8 inches) or greater and minimize downconductor run
length.
• Downconductor securing requirements.
• LPSD - CAD analysis design so tware which determines terminal placement,
mast & height requirements as well as protection level calculation.
All o the above are recommended or a success ul installation. I there is any doubt
about any o the points mentioned, please contact nVent or its nearest
representative or clari ication.
For additional details on installing your nVent ERICO SYSTEM 1000, please re er
to nVent’s technical notes and the French standard NFC17-102. It is also
recommended to adhere to local standards or relevant local downconductor and
grounding requirements.
Warning - Do not attempt to install the nVent
ERICO SYSTEM 1000 d ring periods of
lightning activity.
Installation
The recommended order o installation is as ollows:
1. Full installation o the grounding system.
2. Full installation o the downconductor(s).
3. Termination o the downconductor(s) to the grounding system.
4. Terminate the top o the downconductor(s) to the nVent ERICO SYSTEM 1000
mast.
5. Attach the terminal to the top o the mast.
6. Raise the mast into position and secure.
7. The nVent ERICO SYSTEM 1000 must be at least two meters higher than any
point on the structure it is intended to protect.
8. The resistance o the lightning protection grounding system must be less than 10
ohms. This should be measured without downconductor(s) connected and without
interconnection to other grounding systems.
Operation
The nVent ERICO SYSTEM 1000 lightning protection system requires no user
operation: it is completely automatic in operation.
1. The nVent ERICO SYSTEM 1000 becomes active only during storm activity.
2. The system does not require any external power requirements or replacement
components or normal operation.
Maintenance
It is essential that the nVent ERICO SYSTEM 1000 Lightning Protection System be
regularly maintained. Maintenance should be undertaken a ter each known strike to
the nVent ERICO SYSTEM 1000 or at least once per year or i any changes or
additions have been made to the structure.
Do not attempt maintenance d ring
potential lightning activity.
Maintenance should be undertaken as ollows:
1. Check that the building is the same physical shape and that no additional
structures such as antennae, advertising signs, satellite dishes, building maintenance
units or similar have been installed within 2 m (80 in.) height o the nVent ERICO
SYSTEM 1000.
2. Inspect the nVent ERICO SYSTEM 1000 terminal to ensure that it is not dented or
physically damaged in any way.
3. Inspect the inial tip on top o the nVent ERICO SYSTEM 1000 to ensure that it is
not excessively burnt, de ormed or missing.
4. Check that the mast is securely attached to the structure. Check that the guys are
secure and undamaged. Replace i necessary. Check that all astenings are secure
and tight.
5. Look or signs o damage to the downconductor (whether by lightning, careless
handling, vandalism or other causes).
6. Check that the Lightning Event Counter is secured and i the display is registering
a reading, then record the reading and date.
7. Ensure the grounding resistance is less than 10 ohms.
8. Check the continuity o all bonding conductors.
WARNING
1. nVent ERICO products shall be installed and used only as indicated in nVent
ERICO product instruction sheets and training materials. Instruction sheets are
available at www.erico.com and rom your nVent ERICO customer service
representative.
2. nVent ERICO products must never be used or a purpose other than the purpose
or which they were designed or in a manner that exceeds speci ied load ratings.
3. All instructions must be completely ollowed to ensure proper and sa e installation
and per ormance.
4. Improper installation, misuse, misapplication or other ailure to completely ollow
nVent’s instructions and warnings may cause product mal unction, property damage,
serious bodily injury and death.
SAFETY INSTRUCTIONS: All governing codes and regulations and those required
by the job site must be observed. Always use appropriate sa ety equipment such as
eye protection, hard hat, and gloves as appropriate to the application.
Installation G idelines
