O.S. engine MAX-61LX Setup guide

It is of vital importance, before attempting to
operate your engine, to read the general
'SAFETY INSTRUCTIONS AND WARNINGS'
section on pages 2-5 of this booklet and to strictly
adhere to the advice contained therein.
●Also, please study the entire contents of this
instruction manual, so as to familiarize yourself
with the controls and other features of the
engine.
Keep these instructions in a safe place so that
you may readily refer to them whenever
necessary.
It is suggested that any instructions supplied
with the model, radio control equipment, etc.,
are accessible for checking at the same time.
●
●
MAX-61LX-HRING SERIES

SAFETY INSTRUCTIONSAND WARNINGS
ABOUT YOUR O.S. ENGINE
INTRODUCTION
BASIC ENGINE PARTS,
INSTALLATION
BEFORE STARTING
FACTS ABOUT GLOW PLUGS
FUEL
CARBURETTOR CONTROLS
STARTING
RUNNING-IN, SETTING UP,
STARTING AND ADJUSTMENT
SUBSEQUENT READJUSTMENTS
CARBURETTOR CLEANLINESS
ADJUSTING CHART
INSTALLATION OF THROTTLE SERVO
CARE AND MAINTENANCE
ENGINE EXPLODED VIEW &
PARTS LIST
CARBURETTOR EXPLODED
VIEW & PARTS LIST
THREE VIEW DRAWING
O.S. GENUINE PARTS & ACCESSORIES
CONTENTS
2 ~ 5
6
7
~ 8
8
~ 10
10
~ 11
12
13
~ 14
18
18
20
22 ~ 23
24
25
15
~ 17
19
26
21
1

Remember that your engine is not a "toy", but a highly efficient internal-
combustion machine whose power is capable of harming you, or others, if it is
misused.
As owner, you, alone, are responsible for the safe operation of your engine, so act
with discretion and care at all times.
If at some future date, your O.S. engine is acquired by another person, we would
respectfully request that these instructions are also passed on to its new owner.
SAFETY INSTRUCTIONS AND WARNINGS ABOUT YOUR O.S. ENGINE
The advice which follows is grouped under two headings according to the
degree of damage or danger which might arise through misuse or neglect.
WARNINGS NOTES
These cover events which
might involve serious (in
extreme circumstances, even
fatal) injury.
These cover the many other
possibilities, generally less obvious
sources of danger, but which, under
certain circumstances, may also
cause damage or injury.
2

WARNINGS
••
•
•
•
Never touch, or allow any
object to come into contact
with, the rotating parts.
Model engine fuel is poison-
ous. Do not allow it to come
into contact with the eyes or
mouth. Always store it in a
clearly marked container and
out of the reach of children.
Model engine fuel is also
highly flammable. Keep it
away from open flame,
excessive heat, sources of
sparks,oranythingelsewhich
might ignite it. Do not smoke
orallowanyoneelsetosmoke,
near to it.
Model engines generate
considerable heat. Do not
touch any part of your
engine until it has cooled.
Contact with the muffler
(silencer), cylinder head or
exhaust header pipe, in
particular, may result in a
serious burn.
Never operate your engine in an en-
closed space. Model engines, like auto-
mobile engines, exhaust deadly carbon-
monoxide. Run your engine only in an
open area.
3

NOTES
•
•
•
•
•
These engine were designed for model
helicopters. Do not attempt to use it for any
other purpose.
Mount the engine in your model securely, fol-
lowing the manufacturers' recommendations,
using appropriate screws and locknuts.
Install an effective silencer (muffler). Frequent
close exposure to a noisy exhaust (especially
in the case of the more powerful high-speed
engines) may eventually impair your hearing
and such noise is also likely to cause
annoyance to others over a wide area.
Check the linkage to the throttle arm before
each flight.
Avoid sudden high r.p.m. immediately after the
engine is started, as the clutch will engage and
you may be struck by the rotor.
•
•
After starting the engine, carry out any needle-
valve readjustments after stopping the rotor by
closing the throttle to the lowest r.p.m..
Stop the engine before attempting to make
other adjustments to the carburetor.
Use an electric starter. The wearing of safety
glasses is also strongly recommended.
Press the rotor head down securely.
Take care that the glow plug clip or battery
leads do not come into contact with rotating
parts.
Adjust the throttle linkage so that the engine
stops when the throttle stick and trim lever on
the transmitter are fully retarded. Alternatively,
the engine may be stopped by cutting off the
fuel supply. Never try to stop the engine
physically.
•
•
4

NOTES
•
•
•
Take care that loose clothing (ties, shirt sleeves,
scarves etc.) do not come into contact with the
rotor. Do not carry loose objects (such as pen-
cils, screwdrivers, etc.) in a shirt pocket from
where they could fall through the rotor disc.
For their safety, keep all onlookers (especially
small children) well back (at least 20 feet or 6
metres) when preparing your model for flight. If
you have to carry the model to the take-off point
with the engine running, be especially cautious.
Hold the rotor securely and keep well clear of
spectators.
Warning! lmmediately after a glowplug-ignition
engine has been run and is still warm,
conditions sometimes exist whereby it is just
possible for the engine to restart when turned
over WITHOUT the glowplug battery being
reconnected. Remember this if you wish to
avoid the risk of accidents.
5

Because of this initial tightness, a
standard electric starter may have
difficulty in rotating the engine when
cold, before it has been adequately
run-in. In this case, use a high-torque
type starter.
DO NOT, however, confuse tightness
with the symptoms of hydraulic lock
caused by an excess of fuel within the
cylinder - often the result of over-
priming.
Attempting to force the engine to turn
over in this condition may cause
internal damage. Instead, remove the
glowplug, invert the engine and eject
surplus fuel from the combustion-
chamber.
Note:
The ringed-piston MAX-61LX-H, MAX-
61LX-HG(R) and MAX-61LX-HGL are high-
performance, high-quality engines that
have been developed specifically for
radio-controlled 60 class helicopters.
They are ideal for scale and sport flyers,
for newcomers to 60 class helicopters and
for contest flyers' first-line or reserve
models.
These motors are produced by the world's
oldest and largest model engine design
and manufacturing company, a company
that has built more helicopter engines
than any other manufacturer worldwide.
INTRODUCTION
6

BASIC ENGINE PARTS
Heatsink Head
Carburettor
Crankshaft
Propeller nut
Crankcase
Glowplug
Mounting Lugs
INSTALLING THE GLOWPLUG
Install the washer on the
glowplug and screw
carefully into cylinder-
head, making sure that it
is not cross-threaded
before tightening firmly. Glow plug
Washer
INSTALLATION OF THE ENGINE
The under-surfaces of all O.S. engine beam
mounting lugs are precision machined flat and
exactyly parallel to the engine's horizontal axis. It is
essential that the engine mounts in the model are
also accurately made and aligned. If they are not,
they will cause stress and distortion within the engine
itself, probably resulting in loss of performance and
internal damage.
The recommended screws for securing the engine to
the engine mounts in the model are 4mm or 6-32 NC
steel Allen type. It is also advisable to use lock
washers or LOCTITE to prevent nuts from loosening.
Cover Plate
7

Front view
CORRECT
Side view
Top surfaces are in the same plane.
Re-align the surfaces as necessary
INCORRECT
Top surfaces are not
in the same plane. Top surfaces are not in the
same plane.
Engine does not rest firmly.
BEFORE STARTING
Tools, accessories, etc.
The following items are necessary for operating the
engine.
1 Fuel
Model glowplug engine fuel of good quality, preferably
containing a small percentage of nitromethane.
Make sure that only the under-surfaces
of the engine’s mounting lugs are in
contact with the engine mount.
If the crankcase body touches the
mount, chamfer the edges of the mount.
As delivered, the engine has its carburetor lightly
fitted into its intake boss. Secure it as follows.
INSTALLATION OF THE CARBURETOR
Retainer
nut Carburetor Rubber
Gasket
0.2mm gap
Loosen the retainer nut, rotate the carburetor to its
correct position and press it well down into the
intake boss, compressing the rubber gasket as
shown in the sketch, before re-tightening screw.
Rotate the retainer nut gently until it stops, then
tighten a further 90-120 degrees.
1.
2.
8

3 Glowplug battery
The power source for heating the glowplug may be
either a large heavy-duty 1.5volt dry cell, or preferably,
a 2-volt rechargeable lead-acid cell .
1.5 volt heavy-duty
dry battery or 2 volt rechargeable lead-acid cell (at least 5Ah)
If a 2-volt cell is employed,
use a resistance wire, as
shown, to reduce applied
voltage, otherwise element
will overheat and burn out.
Resistance coil
(nichrome wire)
Adjust applied voltage by changing the position of clip on
resistance coil until glowplug element is glowing bright red.
Battery leads
Raise
voltage to
increase
brightness.
Lower voltage to
reduce brightness.
Warning (Very hot)
Never touch the nichrome
wire while the battery is
connected.
4 Plug wrench
Used for tightening glowplug. The
O.S. long plug wrench is available
as an optional accessory.
5 Battery leads
These are used to conduct current
from the battery to the glowplug.
Basically, two leads, with clips, are
required, but, for greater conve-
nience, twin leads with special
glowplug connectors, as shown on
the right, are commercially
available.
6 Fuel bottle or pump
For filling the fuel tank, a simple,
polyethylene"squeeze"bottle,with
a suitable spout,is all that is
required. Alternatively, one of the
purpose-made manual or electric
fuelpumpsmaybeusedto transfer
fuel directly from your fuel
container to the fuel tank.
For tightening
glowplug
Fuel bulb
Battery leads
Manual
Electric
Fuel pumps
2 Glowplug
O.S. No.8 glowplug is installed in the engine.
9

Fuel Can Filter
12V Battery Starter
7 Fuel container filter
Fit a filter to the outlet tube of
your refuelling container to
prevent entry of foreign matter
into the fuel tank
8 Silicone tubing
This is required for the
connection between the fuel
tank and engine.
9 Hexagon starting shaft
This shaft mounted on an
electric starting motor is driven
into the main body of a
helicopter to turn the engine.
Silicone tube
10 Electric starter and starter
battery
An electric starter is recom-
mended for starting.
FACTS ABOUT GLOWPLUGS
The role of the glowplug
Glowplug life
Particularly in the case of very high performance
engines,
glowplugs must be regarded as expendable
With a glowplug engine, ignition is initiated by the
application of a 1.5-volt power source. When the
battery is disconnected, the heat retained within the
combustion chamber remains sufficient to keep the
plug filament glowing, thereby continuing to keep the
engine running. Ignition timing is 'automatic' : under
reduced load, allowing higher rpm, the plug becomes
hotter and, appropriately, fires the fuel/air charge
earlier; conversely, at reduced rpm, the plug become
cooler and ignition is retarded.
Since the compatibility of glowplug and fuel may have
a marked effect on performance and reliability, it may
be worthwhile to choose the R/C type plug found
most suitable after tests. Recommended O.S. plugs
are No.8, A5 and A3. Carefully install plug finger-tight,
before final tightening with the correct size plug
wrench.
10

Install a plug suitable for the engine.
Use fuel containing a moderate percentage of
nitromethane.
Do not run the engine too lean and do not leave the
battery connected while adjusting the needle.
However, plug life can be extended and engine
performance maintained by careful use, i.e.:
Apart from when actually burned out, a plug may
need to be replaced because it no longer delivers its
best performance, such as when:
When to replace the glowplug
Filament surface has roughened and turned white.
Filament coil has become distorted.
Foreign matter has adhered to filament or plug
body has corroded.
Engine tends to cut out when idling.
Starting qualities deteriorate.
•
•
•
•
•
•
•
•
FUEL
Select, the most suitable fuel from among the best
quality fuels available in your country for helicopter
use. For the best throttle response, a fuel containing
5% to 30% nitromethane for the 60G carburetor is
preferable. The 60H carburetor is designed to use
less than 10% nitromethane fuel. Lubricants may be
either castor-oil or a suitable synthetic oil (or a blend
of both) provided that they are always of top quality.
For consistent performance and long engine life, it is
essential to use fuel containing AT LEAST 18%
lubricant by volume. Some fuels containing coloring
additives tend to deterriorate and may adversely
affect running qualities. Select by practical tests when
experimenting such fuels.
Modelenginefuelispoisonous.Donotallow
it to come into contact with the eyes or
mouth. Always store it in a clearly marked
container and out of the reach of children.
Model engine fuel is also highly flammable.
Keep it away from open flame, excessive
heat, sources of sparks, or anything else
whichmightigniteit.Do not smoke,orallow
anyone else to smoke, near to it.
Reminder!
11

CARBURETOR CONTROLS
With a fixed-wing model, power failure is rarely a
serious threat to the safety of the aircraft since it can
usually glide down to a safe landing. In a helicopter,
on the other hand, it is vitally imporant that the engine
keeps running and that there is a quick and reliable
response to the throttle in order to ensure safe ascent
and descent of the model.
The Needle Valve:
When set to produce maximum power at full throttle,
this establishes the basic fuel/air mixture strength.
This is then maintained by the carburetor's
automatic mixture control system to cover the
engine's requirements at reduced throttle settings.
The Mixture Control Valve (Mixture ControlScrew):
For adjusting the mixture strength at part-throttle
and idling speeds, to obtain steady idling and
smooth acceleration to medium speeds. The Mixture
Control Valve has been factory set for the
approximate best result. First, run the engine as
received, and re-adjust the Mixture Control Valve
only when necessary.
Two adjustable controls are provided on this carburetor.
Needle Valve
Throttle Lever
Mixture Control Valve
(MIxture Control Screw)
•
•
BASIC POSITION OF MIXTURE CONTROL VALVE
(Mixture Control Screw)
Thick
Mixture Control Valve
MIxture Control Screw
Lean
As delivered, the Mixture Control Screw is positioned
at around the center as shown in the sketch.
Mixture gets lean when the Mixture Control Screw is
turned right, while mixture gets rich when the Mixture
Control Screw is turned left. With a model helicopter,
adjustments vary with combined various factors such
as climatic conditions, fuel, muffler, main rotor,
weight of the model, gear ratio, etc. Therefore,
Mixture Control Screw position varies with each
model and set- up, and it is normal if the Mixture
Control Screw position is off the center.
This carburetor is not fitted with a throttle stop
screw.Instead,idlingspeedisadjustedbymeans
of the throttle trim lever on the transmitter.
12

STARTING
Close
Open
Be sure to use a muffler pressurized fuel feed. Use
the same fuel as you intend to employ for actual
operation of your model.
1.
2.
3.
Opening and closing of the Needle-Valve
Turn the needle clockwise to
close the needle-valve, and turn
the needle counter-clockwise to
open the needle-valve as shown
in the sketch.
Opening the needle-valve
Firstly, turn the needle clockwise slowly until it
stops. The position it stops is the fully closed
position of the needle-valve. Make note this
position for reference..
Open the needle-valve 1 turns.
Preparation of the starter
Install the starting shaft to the
starter securely. Poor installation
swings the starting shaft, which is
dangerous.
12
4.
5.
6.
Checking the rotating direction of the starter
Make sure that the starter rotates
to the direction shown in the
sketch. If the direction is reverse,
reverse the leads on battery.
Inserting the starter shaft
Insert the starting shaft into the
shaft cup securely.
Priming
Without heating the glowplug, open
the throttle a little from the idling
position. Turn the engine using the
starter until the fuel is seen to reach
carburetor.
Preparation of starting
Make sure that the transmitter
throttle stick is at the fully closed
position and the throttle trim at
center position, and make sure that
idle-up switch on the transmitter is
off. Hold the rotor head by hand so
that rotor cannot rotate when the
engine is Started. Also, steady the
model with a foot on the landing-
gear skid.
7.
13

In case the engine does not stop.
Hold the rotor head, and pinch the silicone tube to
stop the fuel supply. If it still does not stop, pull off the
fuel tubing from the carburetor.
It is necessary to readjust the throttle linkage so that
the carburetor rotor is fully closed when the throttle
stick and throttle trim on the transmitter are fully
pulled Down.
Stopping the engine
Fully pull down the throttle trim on the transmitter.
Starting
Connect the battery to the glowplug and start the
engine by applying the starter. When started,
switch off the starter and withdraw the starting
shaft after making sure the rotation of the starter
shaft stops.
8.
9.
NOTE:
If the throttle response is poor or the engine
stops due to a temporarily over-rich mixture im-
mediately after the engine is started, pinch the
fuel line for one or two seconds until the engine
r.p.m. increase and the engine runs steadily.
Reminder!
Never touch, or allow any object to
come into contact with, the rotating ro-
tor.
14

Fit a conventional exhaust-pressurized fuel system
and select the same fuel as you intend to use for
flying the model.
All internal-combustion engines benefit, to some
degree, from extra care when they are run for the first
few times known as running-in or breaking-in.
This is allows the working parts to mate together
under load at operating temperature.
However, because O.S. engines are made with the
aid of the finest modern precision machinely and from
the best and most suitable materrials, only a very
short and simple running-in procedure is required and
can be carried out with the engine installed in the
modle. For the first few flights with a new engine (i.e.
while the engine is being run-in) set the needle-valve
for a slightly rich mixture not excessively rich as this
may result in poor throttle response and cause the
engine to stope. About 1 turn open from the nomal
setting will usually suffice.
Close the needle-valve, then reopen it 1 turns.
Open the throttle fully and rotate the crankshaft
with an electric starter until fuel is seen to reach
the carburetor inlet nipple.
Warm the engine by allowing it to idle for about 30
seconds. If it stops, advance the throttle trim lever
slightly to increase idling speed and restart.
A
SETTING UP, STARTING AND ADJUSTMENT
RUNNING-IN ("Breaking-in")
12
12
Re-set the throttle stick to the closed position,
keeping the throttle trim lever in the advanced(i.e.
idle) position. Hold the rotor firmly against rotation
and start the engine.
B
C
Reminder!
Do not touch, or allow any object to
come into contact with, the spinning tail
rotor.
15

lf, at this stage, the engine is slow to pick up and
produces an excess of exhaust smoke, the mixture
is too rich. Correct this condition by turning the
Mixture Control Screw clockwise. lf the mixture is
extremely rich, engine rpm will become unstable :
opening the throttle will produce a great deal of
smoke and rpm may drop suddenly or the engine
may stop. This condition may also be initiated by
an excessively prolonged warming-up period.
lf, on the other hand, the mixture is too Iean, this
wiIl be indicated by a marked lack of exhaust
smoke and a tendency for the engine to cut out
when the throttle is opened. ln this case, turn the
Mixture Control Screw counter-clockwise to enrich
the mixture.
Turn the Mixture Control Screw a few degrees at a
time.
D
E
F
G
NOTE:
If throttle response is poor, or the engine stops on
restarting, due to a temporarily over-rich mixture,
firsttrypinchingthefueldeliverytubeforoneortwo
seconds when the engine is restarted, in the
expectation that the engine will pick up and run
steadily.
Having provisionally set the idle mixture, the next
step is to adjust the mixture for hovering flight.
Hover the model and actuate the throttle to
observe response over the medium speed range.
lf the engine smokes excessiveIy and throttle
response is poor, the mixture is too rich ; in which
case, land the model and turn the Needle Valve
clockwise. Do not close the NeedIe Valve too
much, keeping it a little on the rich side at this
stage.
lf, on the other hand, hovering is not stable and
response to the throttIe is over-sensitive, or if the
engine tends to overheat, this indicates that the
mixture is too lean and should be corrected by
turning the Needle Valve counter-clockwise.
When satisfactory hovering flight has been
achieved, land the modeI again and re-check the
engine's idlling qualities.
After about 10 seconds of idling, open the throttle
to 'float' the model. lf the transition is smooth, the
idle mixture is O.K. If the symptoms of either rich
or Iean running are
observed, readjust the Mixture
Control Screw accordingly.
H
I
J
K
16

Now adjust the Needle Valve to achieve the best
performance when the model is flying at full throttle.
lf, at full throttle, acceleration is poor, theexhaust
unduly smoky and the model fails to reach expected
straight line speed, the mixture is too rich and the
Needle Valve setting will need to be reduced.
lf, however, after smoothly acceIerating to
satisfactory high-speed straight and level flight,
power is lost when the model is puIled up into a
climb, the mixture is too lean. ln this case, land the
model immediately and readjust the Needle Valve
to a richer setting.
Now re-check hovering performance and, if
necessary, fine-tune the mixture for hovering flight.
For helicopters, good throttle response at medium
r.p.m. (e.g.hovering speeds) is most important,
since this is a power range widely used in
helicopter flight. The optimum fuel/air mixture
strength at medium speeds is dependent on
obtaining balanced adjustment of both the Needle
Valve and the Mixture Controlof both the Needle
Valve and the Mixture Control Valve. lf both
controls are already at their optimum setting, some
modification to these settings may be necessary to
L
M
N
achieve satisfactory mid-range throttle response,
but such readjustments should onIy be made
within the range where idling reliability and high-
speed performance are not unduly compromised.
OReadjustments should therefore be carried out as
follows:
lf the mid-range throttle response is not rapid and
positive (indicating a rich mid-range mixture), turn
the Needle Valve 2 or 3 clicks clockwise, or turn the
Mixture Control Screw 2-3 degrees cIockwise.
lf, on the other hand, the response to mid-range
throttle movement is too sensitive (indicating a lean
mid-range mixture), turn the Needle Valve 2 or 3
clicks counter-clockwise or turn the Mixture Control
Screw 2-3 degrees counter-clockwise.
Throttle response at hovering speeds is aIso
affected by the reIationship of the main rotor pitch
angle to throttle opening. If the optimum mid-range
throttle response cannot be obtained by the
carburettor adjustments described above, try
adjusting the helicopter's pitch control
characteristics.
Q
P
17

SUBSEQUENT READJUSTMENTS
Once the engine has been run-in and the carburetor
controls properly set up, it should be unnecessary to
alter the mixture settings, except to make minor
adjustments to the Needle Valve occasionally, to take
account of variations in climatic condisitions.
The use of a different fuel, however, particularly one
containing more, or less, nitromethane and / or a
different type or proportion of lubricating oil, is likely to
call for some readjustment of the Needle-Valve.
Remember that, as a safety measure, it is advisable
to increase the Needle Valve opening by an extra
half-turn counter-clockwise, prior to establishing a
new setting. The same applies if the silencer type is
changed. A different silencer may alter the exhaust
pressure applied to the fuel feed and call for a revised
Needle-Valve setting.
The use of a different glowplug, or changes to the
mainrotor and its pitch angles may also require
compensating carburettor readjustments.
CARBURETOR CLEANLINESS
The correct functioning of the carburetor depends on
its small fuel orifices remaining clear. The minute
particles of foreign matter that are present in any fuel
can easily partially obstruct these orifices and upset
mixture strength so that engine performance
becomes erratic and unreliable. It is recommended
that fuel is passed through a filter when the tank is
filled and that a good in-line filter is installed between
the fuel tank and carburettor and, furthermore, that
this filter is frequently cleaned to remove dirt and lint
that accumulates on the filter screen. Finally,
occasionally remove the needle-valve holder from the
carburetor as shown in Sketch and extract any
remaining foreign matter that may have lodged in the
location shown in Sketch.
Remove this with
an 8mm spanner
Dirt and fbrous matter
mostly accumulate here
18

ADJUSTING CHART
Open the Needle Valve11/2 turns from the fully closed position.
Make sure that the Mixture Control Valve is at the factory setting.
A
Start the engine
Warm up the engine
B
C
Observe the mixture condition while "floating" the model
Turn the Mixture
Control Screw
counter-clockwise Idling OK
Turn the Mixture
Control Screw
clockwise
Lean mixture Rich mixture
DE
F
E
Observe the hovering mixture condition
Open the
Needle Valve
(Turn counter-clockwise)
Hovering OK
Lean mixture Rich mixture
J
H
I
G
Close the
Needle Valve
(Turn clockwise)
Land the model
Idle for approx: 10 seconds, then reopen throttle to
observe transition ("Float" the model)
Turn the Mixture
Control Screw
counter-clockwise Idling OK
Turn the Mixture
Control Screw
clockwise
Lean mixture Rich mixture
High Speed Flight
Open the
Needle Valve
(Turn counter-clockwise)
Lean mixture Rich mixture
L
M
Close the
Needle Valve
(Turn clockwise)
High Speed Flight OK
Fine tuning of hovering mixture
Turn the Needle Valve
2 or 3 clicks counter-
clockwise, or turn the
Mixture Control Screw
2-3 degrees counter-
clockwise. Adjust pitch
control characteristics.
Hovering OK
Response too sensitive
N
Response too slow
Adjustment completed
PQOQ
Turn the Needle Valve
2 or 3 clicks clockwise,
or turn the Mixture
Control Screw 2-3
degrees clockwise.
Adjust pitch control
characteristics.
K
19
