O-Two 01FC User manual

FLOW CONTROLLERS
FOR USE WITH MEDICAL GASES
INTENDED USE:
The O-Two Medical Technologies “Therapy Flow Controller” is intended for the delivery of adjustable
therapy flow rates (medical oxygen or medical air) to a patient.
DESCRIPTION:
The O-Two “Therapy Flow Controller” is a therapy flow administration device which is capable of
delivering a controllable continuous flow of medical gas (oxygen or air) within the specified range.
Connected to medical gas supply system, O-Two “Therapy Flow Controller” can deliver the desired
therapy flow by adjusting flow-selecting control.
Rev. 7 Feb 2020
O-TWO MEDICAL TECHNOLOGIES INC.
45A Armthorpe Road, Brampton, Ontario, Canada L6T 5M4
Tel. [phone] Fax [phone]
www.otwo.com
REF 01FC
SAFETY WARNINGS
1. It is imperative that the O-Two Therapy Flow Controller only be operated in accordance with the
instructions as described in this manual by clinically trained and authorized personnel. Do not use the
Flow Controller for driving any medical equipment.
2. Using oil, grease or other petroleum-based substances with oxygen and oxygen mixtures may cause
fire or explosion. Never handle Flow Controllers with oily or greasy hands or gloves. Do not use or store
oxygen equipment near excessive heat or open flame.
3. Make sure that the inlet fittings on flow controllers are properly mated for the gas intended. Never
attempt to force an incompatible connection or change the connectors. Never interchange flow
controllers, hoses, or other equipment with similar equipment intended for use with other gases.
4. Disconnect the flow controller from a pressure source and release all gas from the flow controller
after each use.
5. Do not stand in front of a flow controller outlet when opening the pressure source in case foreign
particles are present which could cause a hazardous malfunction of the flow controller. Never occlude
the outlet to test for the presence of pressure.
6. The flow controller doesn’t indicate that a flow is occurring.
7. Setting the flow-selecting knob between adjacent settings may cause the output flow to cease!
8. Varying inlet pressure outside the specified operating inlet pressure has significant impact on the
accuracy of output therapy flow rate!
9. Presence of outlet resistance may result in decrease of the flow rates delivered.
10. Ambient temperature variations within the specified operating temperature range have no eect
on the accuracy of flow rate.
11. Oxygen therapy may be critical treatment. The application of oxygen therapy using this flow
controller should be made in strict accordance with the prescription and instructions of a physician.
12. Never disassemble a flow controller under pressure! Disassembly and assembly of flow controllers shall
be performed only by O-Two authorized and trained personnel. Unauthorized disassembly will void the
warranty. Lubricant, if used in the maintenance of the flow controller, shall be compatible with the intended
medical gases. Use of lubricants not recommended by the manufacturer may cause fire or explosion.
SPECIFICATIONS:
GAS Medical Oxygen, Medical Air
OPERATING INLET PRESSURE 50 to 55 PSI
THERAPY FLOWRATE RANGE 0 – 6 l/min, 0 – 8 l/min, 0 – 15 l/min, 0 – 25 l/min
STORAGE TEMPERATURE From -28°C to +60°C
OPERATING TEMPERATURE From -18°C to +50°C
WARRANTY:
The O-Two Therapy Flow Controllers for Use with Medical Gases are manufactured from the
finest quality materials. Each individual part is subject to strict quality control tests to ensure
exceptionally high standards. The manufacturer warrants to the purchaser of the O-Two
Flow Controller that its component parts are free from defects in material and workmanship
for a period of five (5) years from the date of purchase. The manufacturer will replace and/
or repair all parts of the Flow Controller at its option for five years from the date of purchase
at no cost to the purchaser, upon the notification of the defects, in writing by the purchaser
and confirmation of said defect by the manufacturer. All shipping costs shall be borne by
the purchaser. The manufacturer shall be liable under this warranty only if the Flow Controller
and its parts have been used and serviced in the normal manner described in the instruction
manual. This warranty does not cover failure resulting from alterations, accidental damage,
misuse or operation not in accordance with the instructions provided. Wear items are not
covered hereunder. This warranty is null and void if unauthorized repairs are attempted or
performed. There are no other expressed or implied warranties. This warranty gives no
specific legal rights.

OPERATING INSTRUCTIONS:
A. PRE-USE CHECK:
1. Visually inspect the flow controller for any signs of grease or oil. Do not use the device if grease
or oil is suspected or found.
2. Visually inspect the intended gas symbol which is marked on the flow controller label. It shall
match the contents of the pressure source to be used.
3. Visually inspect the inlet and outlet connectors of the flow controller for damage and to ensure
compatibility with the pressure source.
4. Connect the flow controller to a pressure source and turn the flow knob to “OFF” position.
5. If required, slowly and gradually turn on the pressure source.
6. Confirm that the contents of the pressure source are sucient for the intended use.
7. Apply a compatible leak test solution to fittings and threads of the inlet and outlet of the flow
controller to check for leakage.
8. If leakage occurs between the flow controller and the pressure source, close the pressure source
and tighten fittings as required to eliminate all external leaks. DO NOT over tighten threaded
connections. Never tighten fittings when under pressure.
B. OPERATION:
1. Ensure that the Flow Controller knob is in the “OFF” position.
2. Connect the flow controller to a pressure source and tighten the connection if applicable.
3. Connect the flow controller to a patient through therapy tubing and mask.
4. If required, gradually open the pressure source.
5. Rotate the flow-selecting knob anti-clockwise to the required flow setting.
C. PREVENTATIVE MAINTENANCE:
The flow controller can be cleaned with a clean, soft and damp cloth after each use.
The user shall also test the flow controller (therapy flow and leak) periodically to ensure proper
performance and safety. The frequency of such testing should be established according to usage, but
it is recommended that it be performed at least every 6 months.
O-Two Medical recommends that the flow controller be returned to the manufacturer or its authorized
agents for evaluation for damage, contamination, wear and function every 5 years. The maximum
service life for the flow controller is 15 years providing the above maintenance recommendations are
followed.
THERAPY FLOW CONTROLLER FOR USE WITH MEDICAL GASES:
INTENDED
MEDICAL GASES
O – Oxygen (O
2
)
A – Medical Air
INLET CONFIGURATION
1 - DISS Inlet- Male
2 - NIST Inlet
3 - Schrader Female quick disconnect
4 - Hansen Female quick disconnect
5 - British Female quick disconnect
6 - Schrader male probe
7 – British Probe
8 – DISS Inlet- Female
9 – UNIFOR Probe
10- AFNOR Probe
11- DIN Probe
12- AGA Probe
13- DISS Inlet- Hand tight
14- DISS Inlet- Hand tight (US version)
PRESSURE OUTLETS
D – 9/16 DISS outlet
B – Therapy barbed outlet
01FC
THERAPY
06 – 0- 6 L/min (± 20%)
08 – 0- 8 L/min (± 20%)
15 – 0-15 L/min (± 20%)
25 – 0-25 L/min (± 20%)
*(± 30% for flows 1.5 l/min or less)
6. When medical gas is no longer required, turn o the gas cylinder or disconnect the flow controller
from hospital pipeline system and vent any trapped pressure inside the flow controller.
7. Turn the flow-selecting clockwise back to the “OFF” position and then remove the flow controller
from the pressure source.
8. Store the flow controller in a clean and dry place.
WARNING
Setting the flow-selecting knob between adjacent settings may cause the output flow to cease!
