OasisSpace 9125A User manual

9125A Knee Walker
Instruction Manual

Thank you for choosing OasisSpace.
PRODUCT INTRODUCTION
The OasisSpace Knee Walker with Basket is a sturdy, dur
able,and comfortable 4-wheel mobility aid that offers patients
suffering from a foot or ankle injury a smooth-
rolling alternative to crutches during their recovery
Features
•
Sleek, compact design
Detachable features foreasy installation,
carrying, and storage
Adjustable handlebar height
Ad justable knee pad height
Foldable steering column
Attachable basket for personal storage
Front steering wheels
Easily controllable dual back wheel brak
es
Washable, plush knee pad cover
•
•
•
•
•
•
•
•
Product Components
•
Padded Contoured Knee Pad
Handlebar with Anti-Slide Grips and Hand Brak
es Height Adjustable Steering Column, 33"- 41'
Height Adjustable Knee Pad Column, 19"- 23"
Front and Back Wheels, 7.8" Diameter
Dual Back Wheel Brakes
Sturdy Dual Bar Frame
Attachable Basket
Washable Knee Pad Cover
•
•
•
•
•
•
•
•
2

Height Adjustable
Steering Column
33" to 41"Basket
Anti Slip Grips
Attached
Basket
Height
Adjustable
Seat 19" to23"
Double
Back Brakes
/
7.8"
Wheels
Sturdy
Dual Bar Frame
Product Specifications
•
Knee Pad Adjustable Height : 19"-
Handlebar Adjustable Height: 33"-
Max. Weight Capacity: 300 lb. [136 kg)
24" [48.8 cm- 61.3 cm)
42" [84 cm- 106.8 cm)
•
•
3

INSTALLATION
To assemble the knee walker, the following components
are required:
1.
Front frame with Front Wheels
Rear Frame with Back Wheels
Handlebar Attachment
Padded Contour Knee Pad Attachment
2.
3.
4.
5.Attachable Basket with Mounting Hardware
[Two Screws, Mounting Bar ,and Allen Wrench]
6. Washable Knee Pad Cover
7. Three [3] Knobs and Pins
。
。
。
。
。
。
4
。

Frame Assembly
1. Insert the dual rods of the front frame into the dual rods of the
rear frame.
2.
Ensure the spring pin on the bottom rod of the front frame
locks into the matching hole in the bottom rod of the rear
frame.
3. Then attach one of the three knobs with a pin into the
available hole through the top rods.
4. Tighten the knob to secure.
5

Knee Pad Assembly and Height Adjustment
1.
Insert the knee pad into the knee pad column.
2.
Select the height, then attach the second of the three knobs
with a pin into the correct hole, locking the height in plac
e.
3. Tighten the knob to secure .
6

Steering Column Assembly and Disassem
bly
1. From
the folded position, straighten the steering
column vertically
2.
Lock it in place by tightening the lever down at the base of
the column
3 To fold the steering column,release the lever, and push the column downwa
rd.
7

1. Insert the handlebar into the steering column.
2. Adjust to the correct height,
then attach the final knob with a pin into the correct hole,
locking the height in place.
3.Tighten the knob in secure.
Handlebar Assembly and Height Adjustment
8

Basket Attachment
1.
To
install the basket, align the holes in the front anchor
plate located on the steering column with the holes in
the anchorsection of the basket
2. Tighten until the basket is secure.
9

Brakes Test
Grip the hand brake levers on the handlebars tightly, and test
to ensure the brakes are working on the back wheels.
Setting The Parking Brake
1. To set the parking brake, locate the spring pins on each
hand brake lever
2. Grip
then
each hand brake to activate the back-wheel brakes
,
push the spring pins down to lock the brakes in place
3. To release the parking brake , grip each handbrake again
causing the spring pins to
position .
How To Use
1. Before use, set the
parking brake
2. Place your hands on the
handlebars.
3. Position the knee of your
injured foot or ankle on
the center of the knee pa
d.Your lower leg will rest
on
the rear portion
of the pad .
