ObboMed MW-4500 User manual

1
Your healthy living center
www.obbomed.com
Foldable Rollator
with Lock Brakes
Model No. MW-4500
Please carefully read through this manual before first use, and store it in safe place.
If you pass the product to another person, hand over this manual along with it!
IMPORTANT SAFETY INSTRUCTION
Failure to follow the above instrucons may result serious bodily injuries.
ObboMed assumes no responsibility for any damage or injuries caused by wrongful installaon, assembly, or use of
this product.
- Consult your physicians or doctors before use.
- Ensure the rollator is at the proper height before use.
- Always check the rubber p for signs of tears, cracks, or wears before use. If any of these signs is present, replace the
rubber p immediately. Stop using if there is any sign of damage.
- All leg extensions must be at the same height. When using the wheeled aachments on the front legs, adjust the rear
legs so the side frames are level.
- The maximum capacity of this walker is 120 kg/ 260 lbs.
- Ensure the snap buon fully protrudes through the adjustment hole when adjusng the walker. Always test the snap
buons are secured before use.
- Do not install any accessories that are not recommended/ provided by Obbomed. Use of other manufacturer’s
accessories may result improper fit or bodily injuries.
- Ensure the handles do not twist or move. The handles must be ght and secure.
- The wheels should always be in contact with the ground.
- Do not use on stairs and escalators.
- Operate the rollator with both hands.
CAUTION: • Beware of the following when using the rollator:
» Electrical cords in way
» Liquid/ ice on floor
» Rugs
» Toys or debris
» Furniture
» Door steps
» Gaps on the floor
• The wheeled aachment can ONLY be used on the front legs of the rollator
unless rear wheels are equipped with brakes.
All below informaon serves to ensure the safety of user, read before use.
Please follow the instrucons below.

2
Handle
Lock Brake
Brake Wire
Tightening Knob
8” Solid Caster
Padded Backrest
Padded Seat
Basket
Seat Supporng Bars
Folding Hinge
OVERVIEW
PROPER ROLLATOR HEIGHT
ASSEMBLY
Always make sure the rollator is at the proper height before use.
1. Stand upright on a firm and flat surface and let your arm hang down naturally and
comfortably on your side.
2. The handle of the rollator should be at the height of your wrist, and your elbow
should be flexed 20 to 30 degree when using the rollator.
3. Adjust the handles of the rollator ll the handles are at the ideal height.
Seng Up the Rollator:
1. Remove all contents from the carton: backrest, handle with tube, rollator frame and basket.
2. Open the rollator frame and make sure the folding hinge is in fully open posion.
3. Slide padded backrest into frame brackets making sure snap buons protrude through holes.
4. Unscrew the ghtening knob from handle and insert handle tube into frame at desired height.
Lining up holes appropriately and slide the bolts through holes from the inside and screw on ghtening knob unl
secure.
Installing the basket:
The basket can be installed under the seat, or at the front of the rollator:
1. Flip up the padded seat, and put the basket in between the seat supporng bars.
2. Use the hanger on the basket to hang at the front of rollator.
Hanger

3
LOCK BRAKE OPERATION
Operaon:
Note: Always engage and disengage the lock brakes on both sides simultaneously.
- To slow down or come to a temporary stop, pull up the brake handles. Make sure to pull with four fingers unl the
rollator slows down or comes to a temporary stop, Fig. 1.
- To lock the wheels in posion, press down both brake handles. An audible “click” will be heard when the lock is
secured, Fig. 2.
- To release the lock brakes, push up both brake handles to the original posion, Fig. 3.
Pull & Hold
“Click”
Fig. 1 Fig. 2 Fig. 3
Model No.: MW-4500
Name: Foldable Rollator with Lock Brakes
Frame: Aluminum
Wheel: 8” caster wheels
Seat: PU
Backrest: EVA foam
Size: Seat Width: 44 cm/ 17.3 inches
Seat Height: 54 cm/ 21.25 inches
Total Height: 79-90cm/ 31-35.5 inches
Total Width: 61 cm/ 24 inches
Folding size: 22cm/ 8.66 inches
Weight: 8.2 kg/ 18 lbs
Max. Capacity: 120 kg/ 260 lbs
SPECIFICATION
CARE AND STORAGE INSTRUCTION
- Inspect the wheels and lock brakes for wear and damage regularly.
- Inspect the snap buons on the padded backrest can be pressed and protrude properly on regular bases.
- Replace any broken, damaged, worn parts immediately.
- Store in cool and dry place if not in use. Long exposure to direct sunlight and heat may damage the rubber accessories.
- Wipe the rollator with so cloth regularly.
Technical specificaons are subject to change without noce.

4
Distribuon by ObboMed Group:
Webshop: www.obbomed.com
Europe:
Morseweg 11, 8503 Ah Joure
The Netherlands
Mail: [email protected]
United States:
1210 E Lexington Ave,
Pomona, CA 91766, U.S.A.
Mail: [email protected]
Australia:
39/3 Kelso Crescent Moorebank,
NSW 2170, Australia
Mail: [email protected]
ObboMed® is registered Trademark of ObboMed Group.
LIMITED LIFETIME WARRANTY
This warranty is extended only to the original purchaser/ user of our product.
ObboMed warrants the frame to be free of defects in materials and workmanship for the lifeme of the product. In the
event of a defect covered by this warranty, we will, at our opon, repair or replace the device.
This warranty does not cover device failure due to owner misuse or negligence, or normal wear.
The warranty does not extend to non-durable components, such as rubber accessories, casters, and grips, which are
subject to normal wear and need periodic replacement. No guarantee is provided when the product is not installed/
operated according to this manual, used for other purposes or careless use of the product.
For repair and warranty processing, please include the following documents when you send in
the product:
• A copy of the receipt with purchasing date.
• A reason for the claim or descripon of the fault.
DISTRIBUTION & SERVICE
DISPOSAL
Disposal of packing and product aer end of lifeme.
Deliver all packing materials at a collecon point or in the appropriate bins for recycling. For further queson please
contact local recycling office.
