OCENCO M-20.2 EEBD (Type”D”)
EMERGENCY ESCAPE BREATHING DEVICE
CE 0194/EN 13794:2002
ISO 23269-1:2008
INSTRUCTION
BOOKLET
P/N 340059, DWG C16141, Rev. B, ECN 3450
The Ocenco M-20.2 EEBD is a belt worn or stored,
compressed-oxygen, self-contained self-rescuer.
The M-20.2 EEBD instantly provides breathable
air, independent of the surrounding atmosphere,
to a person escaping from any area of toxic gas
or oxygen deficiency.
DONNING P OCEDU E
The following are the donning steps for the belt
worn configuration of the M-20.2 EEBD. If the
M-20.2 EEBD is wall mounted, first remove the
orange Secondary Container from the wall and
the M-20.2 EEBD from the orange Secondary
Container case. These five steps must be
practiced numerous times until they become
second nature.
1. Lift yellow lever and discard cover.
2. Remove unit by pulling yellow neck strap
upwards.
3. Insert yellow mouthpiece.
4. Fit yellow nose clip.
5. Inhale through mouth and escape.
To fit the neck strap, simply place the neck strap
over the head and pull upward on the o-ring to
shorten the neck strap.
To fit the face shield, simply pull the face shield
over the head and pull outward on the o-rings to
tighten the face shield around neck.
In the unlikely event that moisture on the inside
of the face shield distorts your vision, simply
press or rub face shield against the face with
your hand.
SE VICE LIFE
Service Life: the M-20.2 EEBD may remain in
service for fifteen years from the date of
manufacture, provided the conditions of use are
E N G L I S H
1
320980_320980 4/27/12 7:01 AM Page 1

observed. The M-20.2 EEBD must be either
stored or belt worn, according to the conditions
of use, throughout its service life. If the M-20.2
EEBD is belt worn, after five years it must be
placed in stored position or returned for factory
service. If the M-20.2 EEBD is stored it may
remain in service without factory service.
The M-20.2 EEBD should be removed when it
exceeds the mandatory factory service date.
Conditions of Use: (1) the visual inspections
described in this booklet must be performed,
(2) proper care described in this booklet must
be performed, (3) when stored, the M-20.2 EEBD
must be contained in an Ocenco Incorporated
Secondary Container and then placed in a rigid
bracket securely fastened to a wall or other
substantial structure and (4) if worn, the M-20.2
EEBD must be belt worn on the person.
HOW TO INSPECT
THE M-20.2 EEBD
M-20.2 EEBD inspections are visual. DO NOT
open the clear case to inspect the M-20.2 EEBD.
If belt worn, the following visual inspection
should be conducted at the beginning of each
work shift that the unit is worn:
1. Read the pressure gauge.
The tip of the white needle on the gauge
is normally in the green. If the needle is in
the red or on the white zero pressure mark,
remove the M-20.2 EEBD from service. If the
view of the gauge is obstructed, the M-20.2
EEBD must be removed from service. If the
surrounding air temperature is above 38°C
and the needle is above the green zone, allow
the unit to cool down to 18° to 24°C.
The needle should read within the green
zone. If belt worn or stored, the following
visual inspections should be conducted every
two years:
1. Read the pressure gauge.
2. Visually inspect the apparatus for indications
of abuse. Indications of abuse are listed
below. If any of these signs are present the
M-20.2 EEBD must be removed from service:
a) Case cracked, burned, deformed or
excessively worn.
b) Excessive gap between cover and base.
c) Damaged latch or cover band.
d) Dirt, debris or moisture visible
through case.
ENGLISH
2
p
d
o
e
e
272464_booklet 11/19/07 11:19 AM Page 2

So
em
1.
2.
3.
4.
5.
6.
7.
8.
9.
In t
M-
hel
e) Belt loops broken
f) Missing tamper indicating ball from yellow
lever on band assembly.
If the M-20.2 EEBD fails any of the listed
inspections or if at any time during its life the
pressure gauge is out of the green zone or the
indications of abuse are observed, the unit should
be removed from service.
HOW TO CARE FOR
THE M-20.2 EEBD
The M-20.2 EEBD is designed to be belt worn or
stored in a confined space environment.
However, like all escape breathing devices it is
not indestructible.
Abusing your M-20.2 EEBD is risking your life in
the event of an emergency.
Abusing someone else’s M-20.2 EEBD should be
considered a criminal offense.
Your life may depend on the care you give your
M-20.2 EEBD. Avoid the most common abuses:
1. If the M-20.2 EEBD is accidentally opened,
DO NOT close it, remove it from service.
2. DO NOT drop the M-20.2 EEBD, particularly
when taking off the belt to which it is
attached.
3. DO NOT clean the M-20.2 EEBD with anything
other than a soft brush.
4. DO NOT immerse the M-20.2 EEBD in water.
5. DO NOT sit on the M-20.2 EEBD.
6. DO NOT drag the M-20.2 EEBD on the ground.
7. DO NOT place the M-20.2 EEBD near heat
greater than 70°C.
8. DO NOT put tape or stickers on the
M-20.2 EEBD that would impede its opening
or the reading of the gauge.
WHEN TO USE THE M-20.2 EEBD
The M-20.2 EEBD should be used immediately at
the first indication of fire or explosion, even if
smoke is not visible. Carbon monoxide is odorless
and colorless. You could breathe a fatal amount of
carbon monoxide before smoke is present. If you
suspect an oxygen deficient atmosphere, put on
the M-20.2 EEBD, don’t wait!
ENGLISH
3
272464_booklet 11/19/07 11:19 AM Page 3

Some of the possible indications of an
emergency are:
1. Sight of smoke
2. Smell of smoke
3. Sight of fire
4. Fire or toxic gas alarm
5. Sudden increase of air temperature
6. Sound of explosion
7. Vibrations of an explosion
8. Interruption of air flow
9. Someone around you has difficulty
breathing or passes out
In the event of an emergency, always don your
M-20.2 EEBD before attempting to escape or
help others.
ADDITIONAL USER INSTRUCTIONS
1. Failure to properly use and maintain this
product could result in injury or death.
2. Never substitute, modify, add or omit parts.
3. Approved for use at temperatures
above -15°C.
4. The maximum recorded surface temperature
of the M-20.2 EEBD during use is 55°C.
5. The minimum purity of the oxygen supply
is 99.5%.
6. CE mark issued through:
INSPEC International Ltd
56 Leslie Hough Way
Salford, M6 6AJ, United Kingdom
