ODA EX Series User manual

Brochure & Operating Manual
P t N ODA T h l i EX S i i l t t h l
Part No : ODA Technologies EX Series single output channel
January 2009.
For safety information, warranties, and regulatory information,
see the pages behind the Index.
© Copyright ODA Technologies, Co,. Ltd. All Rights Reserved.
Head
q
uarter
Headquarter
A-708B, Woorim Lions Valley, #435, Bupyung-gu,
Incheon Metropolitan City, Republic Of Korea.
TEL : [phone] FAX : [phone]
[email protected]
Research Center
Research Center
A-607, Woorim Lions Valley, #435, Bupyung-gu,
Incheon Metropolitan City, Republic Of Korea.
TEL : [phone]
ODA Technologies EX□□□-□□□ Series
Switching Type Programmable DC Power Supply

Le
g
al Notices
Legal Notices
© ODA Technologies Co., Ltd. 2008
No part of this document may be photocopied, reproduced, or translated to another language without
the prior agreement and written consent of ODA Technologies Co., Ltd. as governed by Republic of
Korea and international copyright laws.
Warranty Certification
The material contained in this document is provided “as is,” and is subject to being changed, without
notice, in future editions. Further, to the maximum extent permitted by applicable law, ODA disclaims
all warranties, either express or implied, with regard to this manual and any information contained
h i i l di b t t li it d t th i li d ti f h t bilit d fit f ti l
herein, including but not limited to the im
p
lied warranties of merchantability and fitness for a
p
articular
purpose. ODA shall not be liable for errors or for incidental or be liable for errors or for incidental or
consequential damages in connection with the furnishing, use, or performance of this document or of
any information contained herein. Should ODA and the user have a separate written agreement with
warranty terms covering the material in this document that conflict with these terms, the warranty terms
in the separate agreement shall control.
Assistance
This product comes with the standard product warranty. Warranty options, extended support contacts,
product maintenance agreements and customer assistance agreements are also available.
Contact your nearest ODA Technologies Sales and Service office for further information on ODA
Technolo
g
ies' full line of Su
pp
ort Pro
g
rams. Refer to below information.
Technologies
full
line
of
Support
Programs.
Refer
to
below
information.
www.odacore.com
[email protected]
[phone]
Waste Electrical and Electronic Equipment
Waste Electrical and Electronic Equipment
The affixed product label (see right) indicates that you must not discard
this electrical/electronic product in domestic household waste. Do not
dispose in domestic household waste. To return unwanted products,
contact our local ODA distributors, or call us for more information.
Manual Editions
Manual Part Number: 011EX-2.1 Edition 1, June, 2009 Printed in ROK
Reprints of this manual containing minor corrections and updates may have the same printing date.
Revised editions are identified by a new printing date.
- 3 -

Safet
y
Notices
Safety Notices
The following general safety precautions must be observed during all phases of operation of this
instrument. Failure to comply with these precautions or with specific warnings or instructions elsewhere
in this manual violates safety standards of design, manufacture, and intended use of the instrument.
ODA Technologies assumes no liability for the customer's failure to comply with these requirements.
General
Do Not Modify the Instrument
In Case of Dama
g
e
for service and repair to ensure that safety
Ground the Instrumen
t
specified by the manufacturer. The protective
General
Do not use this product in any manner not
used in a manner not specified in the operation
Do
Not
Modify
the
Instrument
features are maintained.
Do not install substitute parts or perform any
unauthorized modification to the product. Return
the product to an ODA Sales and Service Office features of this product may be impaired if it is
instructions.
In
Case
of
Damage
Instruments that appear damaged or defective
chassis and cover must be connected to an qualified service personnel.
connected to the ac power mains through
a
g
rounded
p
ower cable, with the
g
round CAUTION
electrical ground. The instrument must be
Ground
the
Instrument
This product is a Safety Class 1 instrument
To minimize shock hazard, the instrument unintended o
p
eration until they can be re
p
aired b
y
(provided with a protective earth terminal). should be made inoperative and secured against
earth terminal will cause a potential shock of important data. Do not proceed beyond a
hazard that could result in personal injury. CAUTION notice until the indicated conditions
wire firmly connected to an electrical ground A CAUTION notice denotes a hazard. It calls
are fully understood and met.
(safety ground) at the power outlet. Any attention to an operating procedure, practice, or
interruption of the protective (grounding) the like that, if not correctly
p
erformed or adhere
d
Before Applying Power
conductor or disconnection of the protective to, could result in damage to the product or loss
a
grounded
power
cable,
with
the
ground
CAUTION
Verify that all safety precautions are taken.
WARNING
applying power. Note the instrument's A WARNING notice denotes a hazard. It calls
external markings described under
"Safety Symbols" or the like that, if not correctly performed or
adhered to, could result in personal injury or
Fuses death. Do not proceed beyond a WARNING
Make all connections to the unit before
attention to an operating procedure, practice,
are
fully
understood
and
met.
Before
Applying
Power
of flammable gases or fumes.
Do not operate the instrument in the presence
is not customer accessible.
Do Not Operate in an Explosive Atmosphere
py
The instrument contains an internal fuse, which notice until the indicated conditions are fully
understood and met.
are aware of the hazards involved should
Only qualified, service-trained personnel who
removing the instrument cover.
the power cable and any external circuits before
remove instrument covers. Always disconnect
Do Not Remove the Instrument Cover
- 4 -

Safet
y
S
y
mbol
Safety Symbol
Direct current Alternating current
Earth (ground) terminal Protective earth ground terminal.
Both direct and alternating current Three phase alternating current
Neutral conductor on
p
ermanentl
y
installed
Terminal is at earth potential.
Line conductor on
tl i t ll d i t
Frame or chassis terminal
On supply Off supply
Standby supply Unit is not
permanently
installed
equipment
p
ermanently installed e
q
ui
p
ment.
Out position of a bi-stable
push switch Caution, risk of electric shock
Standby
supply
.
Unit
is
not
completely disconnected
from ac mains when switch
is off
In position of a bi-stable push
switch
Caution, hot surface Caution, refer to accompanying
documents
- 5 -

EX Series Operating Manual
CONTENTS
1. General Information -------------------------------
-
10
1-1. Feature ------------------------------------------
-
10
General Feature
Remote Interface Characteristics
R
emo
t
e
I
n
t
er
f
ace
Ch
arac
t
er
i
s
ti
cs
Calibration
Factory Function
Self Test Characteristics
Applications
1-2. Accessories and Options ----------------------------
-
11
Accessories
Oti
O
p
tions
Homepage and Reference(www.odacore.com)
1-3. Inspecting the Unit -------------------------------
-
12
Instrument Check
Electrical Check
1-4. Installation and Operating Conditions -----------------
-
12
1
-
5 Check Before Power On
----------------------------
-
13
15
.
Check
Before
Power
On
13
Output Terminal Check
Power Cord Check
Input AC Power Line Check
1-6. Check After Power On ----------------------------
-
15
Display Procedure on the LCD
Default Setting Values
1 7 Installation
16
1
-
7
.
I
ns
t
a
ll
a
ti
on ---------------------------------------
-
16
Cooling
Bench Operation
Rack Mounting
2. Front Panel, Rear Panel Com
p
osition & Functio
n
-------
-
18
2. Front Panel, Rear Panel Composition & Function
2-1. Front-Panel Setting 21
2-2. Rear Panel Composition -------------------------------
-
22
2-3. Output Check ---------------------------------------
-
24
Voltage Output Check
Current Output Check
----------------------------------
3. Front-Panel Operating ---------------------------------- 25
Overview 25
3-1. Constant Voltage Operating(CV) -----------------------
-
26
3-2. Constant Current Operating(CC) -----------------------
-
27
--------------------------------------------------
-
- 6 -

EX Series Operating Manual
3-3. Programming Over Voltage Protection(OVP) ------------
-
28
3-4. Programming Over Current Protection(OCP) ------------
-
31
3-5. Programming Under Voltage Limit(UVL) -----------------
-
33
3-6. Programming Over Voltage Limit(OVL) -----------------
-
34
3-7. Pro
g
rammin
g
Under Current Limit(UCL
)
-----------------
-
35
37.
Programming
Under
Current
Limit(UCL)
3-8. Programming Over Current Limit(OCL) -----------------
-
36
------------------------------------------
-
37
------------------------------------------
-
38
RS232C Setting
RS232C Configuration
RS485 Setting
3-10. IO/Local
3-9. Key Lock
g
RS485 Connection Drawing
RS485 Configuration
USB Setting
TCP/IP Setting(Option)
Delimiter
Response
3
-
11 Limit Display
---------------------------------------
-
47
311
.
Limit
Display
47
3-12. Store 48
3-13. Recall 49
3-14. Output ON/OFF ------------------------------------
-
50
3-15. Error Message Display -------------------------------
-
51
-----------------------------------------------
-
-----------------------------------------------
-
4. Rear-Panel Operating ------------------------------------
-
52
Overview 52
4-1. Remote Voltage Sensing ----------------------------
-
53
CV Regulation
Output Rating
Output Noise
--------------------------------------------------
-
Output Noise
Stability
Remote Voltage Sensing Connection
4-2. Analog Control Connector ----------------------------
-
55
4-3. Remote Programming Control ----------------------------
-
56
4-4. Remote Monitoring ----------------------------
-
58
4-5. Remote ON/OFF Control ----------------------------
-
59
4-6. Parallel Operating ------------------------------------
-
61
4-7. Fuse --------------------------------------------------
-
64
- 7 -

EX Series Operating Manual
5. Calibration 65
5-1. Characteristics ---------------------------------------
-
65
5-2. Preparation for Calibration ----------------------------
-
65
5-3. Equipment required for Calibration --------------------
-
66
5
-
4 Technic of Calibration
-------------------------------
-
66
-----------------------------------------------
-
54
.
Technic
of
Calibration
66
Instruments Connection Drawing
Electronic Load
Current-Monitoring Resistor(shunt)
DVM(Digital Volt Meter)
Programming
Measuring
Point
Measuring
Point
5-5. Using Front Panel Calibration --------------------------
-
68
Calibration Key Structure
Voltage Calibraton
Current Calibration
5-6. Remote Interface Calibration --------------------------
-
72
Instruments Connection
Remote Calibration Command Procedure
R
emo
t
e
C
a
lib
ra
ti
on
C
omman
d
P
roce
d
ure
Voltage Calibraton
Current Calibration
6. Factory 74
6-1. Characteristi
c
---------------------------------------
-
74
--------------------------------------------------
-
61
.
Characteristic
74
6-2. Factory Key Structure -------------------------------
-
74
6-3. User-Mem Clear 75
User-Memory Clear Operating
6-4. Last State 75
Last State Operating
6
-
5. Auto Cursor MV
76
------------------------------------------
-
---------------------------------------
-
-
---------------------------------------
-
65
.
Auto
Cursor
MV
76
AUTO CURSOR MV(Moving) Operating
6-6. Auto Key Lock ---------------------------------------
-
77
Auto Key Lock Operating
6-7. OVP Use --------------------------------------------- 78
OVP Use
6-8. OCP Use --------------------------------------------- 79
OCP Use
6-9. ADC Sampling ---------------------------------------
-
80
ADC Sampling
6-10. CAL-RESTORE ---------------------------------------
-
81
CAL-RESTORE Operating
- 8 -

EX Series Operating Manual
6-11. CAL-BACKUP ------------------------------------
-
82
CAL-BACKUP Operating
6-12. CAL-DEFAULT ------------------------------------
-
83
CAL-DEFAULT Operating
6-13. LOAD DEFAULT ------------------------------------
-
83
LOAD DEFAULT O ti
LOAD DEFAULT O
p
erating
7. SCPI Command ------------------------------------------
-
84
------------------------------------
-
84
7-2. Commands ------------------------------------------
-
84
Output Setting Commands
Measurement Commands
7-1. Commands Syntax
Measurement
Commands
Calibration Commands
Factory Commands
System Commands
7-3. Apply Commands ---------------------------------------
-
86
7-4. Output V/I Setting & Oprating Commands ---------------
-
86
7-5. Measure Commands ------------------------------------
-
91
7-6. Remote Connector Commands --------------------------
-
91
7-7. Calibration Commands ---------------------------------- 93
7-8. Factory Commands ------------------------------------
-
93
7-9. System Commands ------------------------------------
-
95
8. Error Messa
g
e
s
------------------------------------------
-
98
8.
Error
Messages
8-1. Operating Error ---------------------------------------
-
98
8-2. Hardware Error ---------------------------------------
-
98
8-3. Remote Calibration Error -------------------------------
-
98
8-4. Calibration Error ---------------------------------------
-
100
8-5. Nonvolatile Memory Check Error -----------------------
-
100
8
-
6 Interface Commands Error
----------------------------
-
101
8
-
6
.
Interface
Commands
Error
----------------------------
-
101
9. Specifications 102
9-1. Outside Dimension ------------------------------------
-
105
10. Preventive Maintenance -------------------------------
-
108
---------------------------------------------
11. Warranty --------------------------------------------------
-
109
12. Cautions --------------------------------------------------
-
110
13. ODA Technologies Other Products -----------------
-
111
- 9 -

EX Series Operating Manual
1. General Information
1-1. Feature
EX Series Single Output products are high-performance and high-efficiency programmable DC power
supply with RS232C, RS485, USB, TCP/IP(option) interface based on SCPI (Standard Commands for
Programmable Instruments) protocol and the combination of bench
-
top and system features in these
Programmable
Instruments)
protocol
and
the
combination
of
bench-top
and
system
features
in
these
power supplies provides versatile solutions for your design and test requirements in the industiral fields,
R&D institute center and education fields.
General Feature
▌Easy-to-use knob control settings.
▌1-Line * big size 16Character LCD Display. `
▌Output ON/OFF key.
▌F t l k l k f ti
▌
Front panel key lock function.
▌Alarm beep when events occure.
▌Excellent precision and high resolution.
▌Built-in Remote Sensing for Load Voltage(V-Sensing)
▌O.V.P(Over Voltage Protection) / O.C.P(Over Current Protection) mode supplied.
▌U.V.L(Voltage under level)/O.V.L(Voltage over level) level value setting function.
▌U.C.L(Current under level)/O.C.L(Current over level) level value setting function.
▌E ll t l d d li l ti
▌
Excellent load and line regulation.
▌Memory(operating state of voltage, current, OVP,OCP) store and recall available up to 10
▌Save and confirm up to 10 error messages.
▌19inch Rack Compact Size(600~2.5KW-1U, 2.5~5KW-2U, 5~10KW-4U)
▌High-efficient output of 80%~90%.
Remote Interface characteristics
▌Supply various interface.(RS232C, RS485, USB, TCP/IP(option))
▌Supply
various
interface.(RS232C,
RS485,
USB,
TCP/IP(option))
▌adoptend SCPI(Standard Commands for Programmable Instruments) command.
▌High speed setting & measurement
▌Programmed in abundant commands in the instrument.
▌Easy interface setting by front panel key of "I/O config".
▌Technical realization of products insulation & Floating Logic.
▌Buint-in the checking of SCPI programming grammer error.
Calibration
Calibration
▌No need of opening cover of instrument in other to calibrate and adopted software calibration
(by manual and PC).
▌Easy calibration operating by using independence or PC interface.
Factory Function
▌Initial function of 10 user memory.
▌Last state(before turn off the power) memory store and recall function.(state of output ON/OFF,
voltage & current value and etc)
▌The function of "Auto Key Lock & Auto Cursor Move" that prevents operator's mistake.
▌OVP & OCP disable or disable setting function.
▌LCD display speed control function of V/I value by using "ADC(Analog to Digital Conversion)
Sampling" function.
▌Calibration restore function.
▌Calibration backup function.
- 10 -

EX Series Operating Manual
Applications
▌DC source for automobile parts(wiper motor, meter panel, audio set, air blower fan and etc.)
▌DC source for LED, LD, PD, LED package, back light unit and etc.
▌DC source for electric devices.(braker, circuit protector and etc)
▌(,p)
▌DC source for electronic devices.(home appliances, MP3 player and etc.)
▌DC source for subway train parts.
▌DC source for electric and electronic parts.(capacitor, condensor, IC, regulator and etc.)
▌DC source for battery charge, recharge and test.
▌DC source for chemical test, physical test and etc.
▌DC source for test lab.(high school and university of electric, electronic department and etc.)
▌DC source for reliability, durability, lifetime test system and etc.
▌y,y,y
Self Test Characteristics
▌Front panel test
▌Remote interface test
▌Memory date verification test
▌ADC H/W error test
▌Unregulated state test
▌g
▌ADC/DAC calibration verification test
1-2. Accessories and Options
Accessories
▌Operationg Manual 1pc.
▌()()
▌Output Cable.(+, -) 1set.(1.5meter) : Usually provide when the current is below 100A.
▌AC input cord 1pc.(1.5meter)
▌Fuse 1pc.
Options
▌TCP/IP communication module
▌RS232C Cross cable 1M, 2M, 4M, 10M
▌RS485 Cable 2/4/8
-
Channel 1M, 2M, 4M, 10M
▌RS485
Cable
2/4/8 Channel
1M
,
2M
,
4M
,
10M
▌USB Cable 1.8M/5M
▌Remote Analog Controller and Parallel Operation Board
▌AC Input Cable (Special order type)
▌Output Cable (Special order type)
▌380V ± 10% , 50~60Hz Input AC power.
▌Booster Function
▌Single or three phase Input AC power.
▌Single
or
three
phase
Input
AC
power
.
Homepage and Reference(www.odacore.com)
▌http://www.odacore.com
▌E-mail : [email protected](representative)
- 11 -

EX Series Operating Manual
1-3. Inspecting the Unit.
When you receive your power supply, inspect it for any obvious damage that may have
occurred during shipment. If any damage is found, notify the carrier and the nearest ODA
Sales Office immediately. Warranty information is shown in the front of this manual. Keep
the original packing materials in case the power supply has to be returned to ODA
Technologies in the future. If you return the power supply for service, attach a tag
identifying the owner and model number. Also include a brief description of the problem.
Mechanical Check
▌Check the broken key, encoder switch, power switch.
▌Check the panel surfaces are free of dents and scratches.
▌Ch kth b k t tt i l
▌
Check the broken rear out
p
ut terminals.
▌Check the cabinet is free of scratches.
▌Check the LDC display is not scratched or cracked.
Electrical Check
▌When turning on the power, check the alarm sound.
If the alarm sounds, the instrument has the error during self-testing itself.
Error checking, press the error key and conform error code.
More information about error code, refer to “7.Error Messages”.
About Self-test, refer to 『1-6. Check after Power On』.
▌Check the model Number is matched with displayed model number.
▌Aft it h w "**OUTPUT OFF**" v ifi t hi h l v l f fid
▌Af
ter,
i
t s
h
ows
"
**
OUTPUT
OFF
**
"
message, ver
ifi
es to a
hi
g
h
l
eve
l
o
f
con
fid
ence
that the power supply is operating in accordance with its specifications.
Service Center : 82-32-623-5454
Home page : www.odacore.com
Note
pg
1-4. Installation and Operating Conditions
This instrument is designed for following environmental conditions in other to use
optimized condition
▌E i t l T t 0
40℃
▌
Environmental Tem
p
erature : 0 ∼ 40℃
▌Relative Humidity : ≦80﹪RH
▌Operating altitude : <2000m.pollution degree Ⅱ
▌No vibration.
▌Avoid the electricmagnetic field.
- 12 -

EX Series Operating Manual
1-5. Check Before Power On
Output Terminal Check
▌Check the rear panel outputs for voltage sensing and rear main outputs.
<Figure 1-1>
Floating the power supply output more than ±60 Vdc from the chassis presents an
electric shock hazard to the operator Do not float the outputs more than ±60 Vdc
WARNING
electric
shock
hazard
to
the
operator
.
Do
not
float
the
outputs
more
than
±60
Vdc
when metal shorting material or wire without insulation are used to connect
the (+) output to the (+) sense and the (-) output to the (-) sense terminals.
Outputs can be floated to maximum of ±240 Vdc provided that the metal shorting wire
without insulation are either replaced with insulated conductors or they are removed
WARNING
without
insulation
are
either
replaced
with
insulated
conductors
or
they
are
removed
from the terminals so there is no operator access to the output conductors without
insulation. All field wiring insulation must be adequate for the voltage present.
<Figure 1-2>
- 13 -

EX Series Operating Manual
Power Cord Check
▌Your power supply is equipped with a 3-wire grounding type power cord; the third
conductor being the ground. The power supply is grounded only when the power-
line cord is plugged into an appropriate receptacle. Do not operate your power
supply without adequate cabinet ground connection.
Input AC Power Line Check
▌You can operate your power supply from a nominal 198~242 V single phase AC
power source at 47 to 63 Hz. AC100V, 110V, 115V, 230V input power is optional.
Refer to chapter "1-2. Accessories & Options"
▌In other to prevent the instrument severe damage from overload fuse is built
-
in
▌In
other
to
prevent
the
instrument
severe
damage
from
overload
,
fuse
is
built in
(1U, 2U products) or braker(3U products) is installed rear side. If fuse also is
broken or braker is turned down repeatedly when power turns on, check the
input power line or broken braker and then call to nearest ODA Technologies A/S
Center
If products maximum output capacity is over 5KW, fuse will be replaced to Breaker.
<Figure 1-3>
- 14 -

EX Series Operating Manual
1-6. Check After Power On.
The power-on test includes an automatic self-test that checks the internal microprocessors
and allows the user visually to check the display. You will observe the following sequence
on the display after pressing the front panel power switch to on. And also keep the
ex-remote and voltage value is zero and current value is max value.OVP & OCP level are
g
set to maximum output value of instrument capacity and it is under the vigilance.
Display Procedure on the LCD
▌Displa
y
"ODA Technolo
g
ies".
▌Displa
y
"EX-Series Ver1.3"의 제품명이 Display됩니다.
▌Annunciators of ERR,LMT,RMT,LOCK on front side are lit and go off clockwise from
th l ft
the left.
CV & CC annunciators are not applied.
▌During displaying above procedure, the instrument is initialized by stored in non-
volatile memory.
▌Also the instrument runs automatic self-test below mentioned.
Connection test between front panel and connector.
Remote interface test
Check remote interface for PC communication.
Front panel test
Remote
interface
test
Check
remote
interface
for
PC
communication
.
Memory data confirm test Check product information and related setting.
ADC H/W error test Check error on ADC control condition.
Unregulated state test Check output voltage floating state.
ADC/DAC calibration test check ADC & DAC Calibration data state.
If the error occurs, alarm beeps and the error code is saved to volatile memory
automatically. You can read the error code by pressing error key.
About error code ex
p
lanation
,
refer to “7. Error Messa
g
es”.
About
error
code
explanation
,
refer
to
7
.
Error
Messages
.
Default Settin
g
Values (Last state Mode is under the Disable state
)
▌OVP : OVP value is max, state is ON. ▌Remote Interface : RS-232C
▌OCP : OCP value is max, state is ON. ▌State after self-test : "**OUTPUT OFF**"
▌UVL : 0V ▌Cursor location : Default voltage select
▌OVL : Limit setting maximum value. Voltage : 1V
▌UCL : 0A Current : 100mA if current is under 5A.
▌OCL Li i i i l
Ifd0A1A
▌OCL : Limit setting maximum value. In case of under 50A : 1A
▌Output Voltage : 0V In case of under 100A : 10A
▌Output Current : Limit setting maximum value. ▌KEY LOCK : OFF
Remote Interface default is RS232C and the rate is set to 9600 baud when the power supply is
shipped from the factory. TCP/IP Module is optional and bulit in type.When ordering, please request.
Note1
In case of "Last State", it is disable when the power supply is shipped from the factory. If you want to
use this function, it is able to use in "Factory Mode". Refer to "5-4. Last State"
If attached the option of remote analog controll board, output is set by setting value.
Note2
Note3
- 15 -

nj EX Series Operating Manual
1-7. Installation.
Cooling
▌The power supply can operate without loss of performance within the temperature range
of 0 °C to 40 °C, and with derated output current from 40 °C to 55 °C. A fan cools the
power supply by drawing air through the rear panel and exhausting it out the sides
p
ower su
ppl
y
b
y
d
raw
i
ng a
i
r t
h
roug
h
t
h
e rear
p
ane
l
an
d
ex
h
aust
i
ng
i
t out t
h
e s
id
es.
Using an ODA rack mount will not impede the flow of air.
<Figure. 1-4 Bottom view>
Bench Operation
▌Your power supply must be installed in a location that allows sufficient space
at the sides and rear of the power supply for adequate air circulation.
Rack Mounting
Rack
Mounting
▌Our products dimension is based on 1U * 19inch full rack size and we provide front rack
bracket basically when you purchase our goods.
<Figure. 1-5>
- 16 -

EX Series Operating Manual
▌Fasten between rack bracket and rack case by using fastener.
<Figure. 1-6>
▌To install instruments in a sliding support shelf, order support shelf and slide kit
and it is very east to install.
<Figure. 1-8>
- 17 -

EX Series Operating Manual
2. Front Panel, Rear Panel Composition & Function.
113
214
315
416
517
618
7
19
Remote Interface Lamp
Store or Calibration Key
Volt/Curr Setting Limit Display Key
Output ON/OFF Key
Limit Display Lamp
Error Lamp
Key Lock Lamp
Curr Cursor or Menu Change Key
Recall or Factory Key
Protection Setting and Front-panel Lock Key
POWER switch
16Character, one line LCD Display
Ventilation slit
IO/Local Setting and Error Display Key
7
19
8
9
10
11
12
Remote
Interface
Lamp
Volt Cursor or Menu Change Key
CV Mode Lamp
Current Encoder Knob
CC Mode Lamp
Recall
or
Factory
Key
Voltage Encoder Knob
- 18 -

EX Series Operating Manual
1. POWER switch.
The power supply is turned on or off by this switch. It is adopted by following power supply's
capacity.
2. Ventilation slit.
Air flow flows from front ventilation slit to rear ventilation slit compulsorily.
3. 16Character, one line LCD Display.
Voltage/current and , all kinds menu/message displayed.
4. Error Lamp.
Error occurs, LED is lit. After checked all errors, LED is turned off.
5. Limit Display Lamp.
When the instrument is under the setting of Volt/Curr, LED is lit. If the device is output on state,
LED is turned off.
6. Key Lock Lamp.
If Key lock lamp is turned on, front panel keys are not working.
7. Remote Interface Lamp.
When received the remote control signal from PC, PLC and etc, it lights and automatically,
front panel keys are under "Key Lock" state.
8. CV Mode Lamp.
The power supply is in constant voltage mode.
9. CC Mode Lamp.
The power supply is in constant current mode.
10. Voltage Encoder Knob.
Adjusts the output voltage, the over-voltage protection level, the under-voltage limit
and numeric value changing of other menu.
11. Current Encoder Knob.
Adjusts the output current, the over-current protection level, the under-current limit
and numeric value changing of other menu.
12. Volt Cursor or Menu Change Key.
Move the under bar digit to the left about voltage. It also is used to move to next menu
hld d
when selected menu mode.
13. Curr Cursor or Menu Change Key.
Move the under bar digit to the right about current. It also is used to move to next menu
when selected menu mode.
- 19 -

EX Series Operating Manual
14. Output ON/OFF Key.
Enables or disables the power supply output. This key toggles between on and off.
15. IO/Local Setting and Error Display Key
Configures the power supply for remote interfaces(Choose RS232C, RS485, USB or TCP/IP)
This key can be used to change to Local Mode from Remote Interface state.
yg
Displays error codes generated during operation and self-test.
16. Protection Setting and Front-panel Lock Key
Enables or disables the OVP/OCP/UVL/OVL/UCL/OCL protection function, sets trip voltage
level, and clears the overvoltage condition. Also during 1 sec press this key, you can lock
pront panel operating with lighting LOCK lamp. One more press this key during 1 sec,
pp p g gg p p y g
clear the lock key.
17. Volt/Curr Setting Limit Display Key.
Shows voltage and current limit values on the display and allows knob adjustment for setting
limit values with lighting LMT lamp. One more press this key during 1 sec, return to previous
state. You only see the setting value not just real output value.
18. Store or Calibration Key.
Stores an operating state(voltage, current, OVP, OCP and other state) in location ‘‘1’’, ‘‘2’’,
‘‘3’’ or another number / enables calibration mode with pressing this key and put the AC power
on.
19. Recall or Factory Key.
Recalls an operating state(voltage, current, OVP, OCP and other state) in location ‘‘1’’, ‘‘2’’,
‘‘3’’ or another number / enables factory mode(Memory Initializing, ,Auto Cursor Move, Auto
Key Lock, OVP Disable, OCP Disable, ADC Sampling, Calibration Restore, Calibration
Backup, Calibration Factory Default Recover and etc) with pressing this key and put the AC
power on.
- 20 -
