odd-i N700D User manual

User’s Manual
odd-i N700D

Introductions
2
odd-i N700D User Guide
Thank you for purchasing an odd-i N700D.
Odd-i is a brand for people who believe in realizing their dreams and who have a different way of looking at
things.
Our starting point is the belief that your way of seeing is special - “You see the world differently.”
This manual is written to help you to use the various convenient features of theproduct.
We recommand that you read this manual before using the product.

odd-i N700D User Guide
3
Content
s
Contents
Introduction
Safety Precautions
Before Using the Product
Features 6
Accessories 8
Description of Components 10
Using the Product
Installing the Product 13
Connecting the Product 15
Turning On/Off the Product 18
Using Navigation 19
Using the Overlay Function 20
Firmware Update 22
Using the Menu Functions
Movie Player 23
Music Player 30
PhotoAlbum 40
File Management 43
Environment Settings 47
External Inputs 55
Rear Monitoring Camera 59
Vehicle Management 62
Appendix
Specifications 70
FAQ 75
Warranty Card

Safety Precautions
4
odd-i N700D User Guide
➲ To use the product safely, follow these instructions.
Install the product sothat it
does not obstruct your field
of vision.
You may have a problem
receiving GPS signals when
you are driving between
high rise buildings.
Do not remove the SD card
or hard disk drive when the
product is turned on.
It is recommended to exit all
programs before shutting
the product down.
Operating or looking at the
product while driving is
extremely dangerous. Be
sure to operate or look at the
product only after stopping
the vehicle.
Be sure to start the vehicle
before turning the product
on, and turn it off before
switching the car ignition off,
in order to avoid a potentially
damaging voltage surge.

odd-i N700D User Guide
5
Safety Precaution
s
➲ To use the product safely, follow these instructions.
Do not attempt to repair or
disassemble the product
yourself. It may damage the
product or cause a
malfunction.After-sales
service may not be provided
when damage has been
caused by unauthorized
tampering with the product.
Avoid excessive impact to
the product.
Do not leave the product in a
vehicle. There is a risk of
theft, and the productmay
malfunction due to a sudden
change in temperature.
Asudden increase in the
internal temperature of the
vehicle in cold weather may
cause moisture formation. If
this happens, wait for a
while before using the
product.
Keep the product away from
moisture, and do not touch
the product with wet hands.
If the volume is too loud you
may not be able to hear
other vehicles, which is
potentially dangerous.
Maintain the volume at a
moderate level.

6
odd-i N700D User Guide
Features
① 7 Inch Wide LCDAdopted
The 7 inch (480X234) 16:9 wide LCD screen of the odd-i N700D enables you to
enjoy perfect and realistic picture quality. In addition, it enables you to play various
content formats by providing a variety of video codec (MPEG1, MPEG4 SP, XVID,
MP43, DivX 3.x/4.x/5.x, WMV 7/8/9).
② Ergonomic UI Design Emphasizing Luxury and Convenience
The odd-i N700D employs an easy-to-use UI design with intuitive and fun graphics
for easier access to all menus.
③ The Best GPS Navigation Software in Korea, MappyAdopted
The odd-i N700D has adopted the Mappy for searching and providing Korean
nationwide road information. It receives information about your current location from
GPS satellites in real-time, and provides audio and graphics information on routes t
o
your destination.
④ Multitasking Support
The odd-i N700D supportsthe overlay of one video source ontop of a second vide
o
source, so that you can view them simultaneously. For example, Navigation+DMB,
Navigation+Movie Player and Movie Player+DMB are supported.
⑤ Vehicle Management
The odd-i N700D provides a Car MaintenanceAccount Book function foreasier cos
t
management for vehicle maintenance, which includes oil consumption, servicing,
and other expenditure.
Features in odd-i N700D

odd-i N700D User Guide
7
Feature
s
⑦ Rear Monitoring Camera Input Support
The odd-i N700D supportsa Rear Monitoring Camera Input Port so that you can
view the rear of your vehicle using the camera installed in the vehicle.
⑧ External Video In/Out Support
The odd-i N700D has a built-in TV output system so that you can view photos or
video on a TV monitor. You can also save video images from the CVBS Video IN
port of the odd-i N700D in MPEG4 format and watch it later.
⑨ MP3 Player and Easy-to-Use FM Radio Support
The odd-i N700D supportsthe MP3, WAV OGG and WMAformats. In addition, it
allows you to listen to FM radio through the FM tuner speakers in your vehicle.
⑩ File Navigation Support
The odd-i N700D provides functions that enable you to navigate folders and files
exactly as in Windows Explorer.
⑪ USB Host Function
The odd-i N700D has adopted the USB 1.1 Host function so that you can exchange
data with a USB device such as a digital camera or MP3 player.
⑫ Removable Disk Support
The odd-i N700D also supports the USB 2.0Device function that enables quick file
downloads.
Features in odd-i N700D

8
odd-i N700D User Guide
Accessories
➲ The following parts are included in the product packaging.
(Parts included may be changed without any advance notice to improve the performance or quality of the
product.)
Basic Package Contents for the odd-i N700D
Main body Vehicle Cradle
Cigar Jack Adapter SD Card (2GB)
SD Card Reader
User Manual
Mando Mappy User Manual

odd-i N700D User Guide
9
Accessorie
s
➲ The following parts are included in the product packaging.
(Parts included may be changed without any advance notice to improve the performance or quality of the
product.)
Cable for AV, USB DevicesWireless Remote Control Case

Description of Components
10
odd-i N700D User Guide
Rear
Top / Bottom
24-Pin Connector
GPSAntenna
Speaker
Support
HDD Operation LEDHDD COVER
Power Jack:

odd-i N700D User Guide
11
Description of Component
s
Front
Sides
Power On / Off Key
Volume Key
LED ILLUMINATION
Main LCD
Earphone Jack
SD Card Slot
AV/OUT Jack
AV/IN Jack
CAMERAIN Jack
USB DevicePort
USB HOSTPort
Remote Control
Sensor MODE NAVI MENU Joystick Key Key Key

Description of Components
12
odd-i N700D User Guide
Wireless Remote Control (Optional)
Power Key
MODE
Cancel
Mute Ke
y
Up/Down Control (same as withthe joystick
)
NAVI
Left/Right Control (same aswith the joystick)
OK Key
MENU
Volume Up
Movie Ke
y
File Manager Ke
y
Music Key
PIN Key
Volume Down
Setup Key

odd-i N700D User Guide
13
Installing the Produc
t
1. Turn the main body power off completely and remove theAC power adapter.
2. Pull the HDD Cover out while pressing the catch down.
3. Assemble the hard disk drive and the HDD Cover and fasten the screw.
Make sure that the hard disk drive is installed the right way round.
4. Slide the hard disk drive in and close the HDD Cover.
Insert the disk drive smoothly. If you press it in with excessive force, it can get caught.
5. If you have difficulty inserting the hard disk drive, try pressing lightly on the bottom ofthe rear
side of the product.
※
Note.
- If it cannot be comected in properly, do not insert it forcibly. Try sliding it into the main body
again.
- Be sure to check the direction of the hard disk drive before inserting it.
- Do not touch the hard disk drive with wet hands, and beware of static electricity when
handling it.
- Run the anti-virus program and checkdisk, and defragment the hard disk drive as you would
for a computer.
- It is recommended to use a hard disk drive designed forvehicles when you are using it in a
vehicle.
- Take care not to lose the screw fastening the hard disk drive, or let it fall into the product.
- Be sure to format the hard disk drive in FAT32.
Installing the Hard Disk Drive

14
odd-i N700D User Guide
Installing the Product
1. Wash the inner surface of your windscreen with a wet towelor tissue.
2. Assemble the product to the cradle by fastening the cradle screw.
3. To install on the windscreen, push the housing onto the windshield and pullthe lever down.
4. If the installation position is notquite right, pull the lever up, adjust the position, and then pull it
down again.
※
For your safety, use the product above the dashboard.
Installing the Cradle
1. To Remove: Push the edge of the card slightly inwards. It will then pop up. Pull it out with your
fingers.
2. To Insert: Insert the SD card and push it in until it clicks.
Installing and Removing an SD Card

odd-i N700D User Guide
15
Connecting the Produc
t
Turn the power on and connect the end ofthe USB cable to the USB port on the right-hand
side of the product, and connect the otherend to the USB port of the computer. The device
driver is automatically installed and you can check it through Windows Explorer on the
computer. (For Windows 98, however, you should download the device driver from the odd-i
web site and install it manually.)
- Please exit all programs before connecting or removing a USB host or device, if possible, and select
Connect or Remove from the Main Menu to connect or remove a USB host or device.
- Make sure to run the ‘Safely Remove Hardware’ before disconnecting the USB Device cable,
otherwise you may lose data.
※
Safely Remove Hardware: If you click the icon from the Taskbar of your computer, ‘USB Mass
Storage Device’ appears in the Safely Remove Hardware window. Select it and click ‘Stop’. The
Stop a Hardware device pop-up window appears. Select ‘OK’. Then you can remove thehardware
safely.
Connecting a USB Device-This is available only when a hard disk drive is installed.
Connect the power cable jack to the Power port of the product.
Connectin
g
the Power
Cigar Jack Adapter
USB Cable

16
odd-i N700D User Guide
Connecting the Product
You can connect the product to a TV, to watch or record video from a TV.
You can not only connect a TV but also any device supporting CVBS such as a VCR,
Camcorder, etc.
Connect the cable and select ‘External IN’ from the Main Menu.
(Refer to ‘External Input’on page 52)
Connecting a TV IN
A
V Cable
Yellow: Video
White: Sound L
Red: Sound R

odd-i N700D User Guide
17
Connecting the Produc
t
You can connect the product to a TV, to watch video from the product on aTV.
To view a video from the product on a TV, you have to select the appropriate ‘TV OUT’ in the
Environment Settings.
(Refer to ‘Environment Settings’on page 47)
●To Connect through the CVBS Port
●To Connect through the S-Video Port
※
You should purchase a 24-pin cable separately.
Connecting a TV OUT
CVBS TV Port
Connect the Black Connector to the S-Video
Port of the TV.
Yellow: Video
White: Sound L
Red: Sound R
Yellow: Sound (Connect to
an audio device)
Black: Video (Connect to a
TV)

18
odd-i N700D User Guide
Turning On/Off the Product
1. Exit all running programs.
2. Press and hold the Power button for approximately 1 second.
Turnin
g
of
f
th
e
Product
1. Check the power connection status.
2. Fold out the GPS antenna on the rear side of the product so that it faces upwards.
3. Press and hold the Power button for approximately 1 second.
4. The booting screen appears and the MainMenu appears aftera while.
5. Navigation runs automatically.
You can set it so that Navigation is not launched automatically. (Refer to ‘Environment
Settings‘ on page 50.)
Turning on the Product

odd-i N700D User Guide
19
Using Navigation
Number Name Function
1 OK Key Registers Safe Driving Points
2 Up/Down/Left/Right Key Move over the map.
3 NAVI Key Moves to the current position of the vehicle.
4 Cancel (Wireless Remote
Control) Registers the current location (Registers My Point)
Navigation Key Map
1. Fold out the GPS antenna on the rear side of the product so that it faces upwards.
2. Press the ‘Navigation’button from the Main Menu or press the ‘NAVI’ key on the body.
3. Navigation is launched.
4. For procedures on using Mappy, refer to the Mappy MXC User’s Manual.
Starting Navigation

Using the Overlay Function
20
odd-i N700D User Guide
●
Movie Player + navigation
1Launch the Movie Player.
2Touch the screen. The Control Barappears.
3Press the ‘NAVI’ button on the Control Bar.
4The Movie Player screen is decreased and displayed together with
Navigation.
5When you touch the Movie Player screen, the Movie Player screen size is
adjusted in 3 steps.
