OdinLake Ergo PRO A633-1 User manual

Note: Thanks for purchasing from OdinLake. This manual contains
important information so please keep it for further possible uses. If you
have any questions that can not be solved by this manual, contact us:
[email protected]
www.odinlake.com
Ergonomic Chair
Health & Stylish
OdinLake
OdinLake Ergo PRO
USER GUIDE
MODEL:A633-1

01
02Tips
Warranty Rules 10
03Tools List
07Functions
11Office Ergonomic Guide
12Disclaimer
04Parts List
05-06Assembly Instructions
08Frequent Questions Answers
09Frequent Assembling Malfunction
Contents

Tips
Ax5
Ex1
Ix3
Mx5 Nx5 Ox1
Jx5 Kx11 Lx5
Fx1 Gx2 Hx1
Bx1 Cx1 Dx1
1. Please make sure that all bolts and screws have been tightened properly
before actually using the chair. Check all levers, adjust knobs and buttons
before everyday use.
P.S: If the cylinder doesn't match the seat plate appropriately, the height
adjuster may stop functioning.
2. Please inspect the chair twice a year. Daily use can wear down the screws
and bolts, so regular inspections are important in order to keep you safe.
3. No standing on the chair.
4. Please do not press the height adjuster down while adjusting, you only have to
lift it slightly to raise or lower the seat. Hard pushing might break the adjuster.
5.If you are giving this chair to a third person/party, please attach this manual
with the chair.
6. Installation tips: follow the instructions carefully. Please do not tighten
the screws until all screws are lined up at once. This helps you make changes
easier if some steps go wrong. Over-tightening one screw can make other
screws hard to tighten.
7. Please tighten all screws again after the set-up process is complete.
Casters
Headrest Seat
Bolts
M6*40mm
Bolts
M8*40mm Lock Washers Allen Wrench
M6*16mm
Bolts
M6*50mm Lock Washers
M6*16mm
Bolts
M6*75mm
Armrests Seat Plate
Base Cylinder Backrest
* Each type of bolt and washer has one extra as a spare. 0302
Tools List

E
D
G
H
F
C
B
A
ITEM
A
B
C
D
E
F
G
H
DESCRIPTION
Casters x5
x1
x1
x1
x1
x1
x2
x1
Base
Cylinder
Backrest
Headrest
Seat
Step 1
Take the Casters(A) and push them
into the 5-star Base(B）.Install the
Cylinder(C) into the Base(B).
Step 2
Fix the Armrests(G) to the Seat(F)
with 6pcs Lock Washers(K), 4pcs
Bolts(J) & 2pcs Bolts(l). Please
notice that the Shorter Bolts ( l )
are for the inner bolt holes.
Step 3
Fix the Backrest(D) to the Seat
Plate（H) with 4pcs Lock Washers(N)
& Bolts(M).
Step 4
Fix the Seat Plate(H) to the Seat(F)
with 4pcs Lock Washers(K) & Bolts(L).
Armrests
Seat Plate
QUANTITY
0504
Parts List Assembly Instructions
A
B
C
M
N
D
KI
KJF
L
K
L
K
H

Scan the code to watch the
installation video.
E
Install the Headrest(E) to the Backres
(D), then place the upper part onto
the cylinder.
Step 5
Completed!
Step 6
Functions
Adjustable Seat Depth
Adjustable Seat Height
Swiveling and Lifting
Extended forward Foot
Pedal
Tilt Lock
Adjustable Rocking Tension
ERGONOMIC DESIGN
STYLISH ARMRESTS
Curved design offers adequate high-back with twisting left and right function and
headrest angle adjustment and lifting adjustment functions, which can effectively
reduce the pain and pressure of the neck and back caused by long time sitting.
The stylish PP+PU material 3D armrests can be multi-functionally adjusted, the armrest
can be adjusted up and down, and the armrest pad can be adjusted forward and
backward + rotated left and right, making the chair more modern and less monotonous.
Pull up the adjustment lever to adjust the seat depth to suit people of
different sizes and heights.
Switch the tilt lock lever to start rocking or lock at certain position. The tension knob
(under the seat) can adjust the tilt tension of the backrest.
Pull up the adjustment lever then you can raise or lower the seat.
0706
Assembly Instructions
ADJUSTABLE SEAT DEPTH
ADJUSTABLE HEIGHT
DCKING FUNCTION

1. How much weight can this chair hold?
The maximum weight capacity is 300 lbs. In general, you will feel very
comfortable if you weigh about 260 lbs. But if you feel any discomfort,
please contact us for technical assistance at c[email protected].
2. What if my lumbar cannot fit on the backrest closely?
The fitness of the lumbar and backrest varies with different users' heights.
Tucking a cushion between the user's lower back and the chair can improve
fitness if it isn't snug.
3. How to clean the mesh office chairs?
Use a vacuum cleaner weekly to keep the mesh breathing easily. Odinlake
ergonomic chairs can be washed with warm water and mild detergent. Use a
soft brush and be careful when scrubbing or the mesh fiber may break.
Apply cleaning solutions and cover the dirty area with a wet cloth for 30
minutes to remove the stubborn dirt.
4. How to clean the office chair wheels?
Pull off the wheels by hand or detach with a screwdriver when cleaning.
Remove dirt and debris with a spray cleaner. And be sure to dry all
components thoroughly. After finishing cleaning, wheels need to be
polished by greaseless lubricant to keep them operating smoothly.
Rocking spring too
loose
Malfunction Reason How to Fix
1Abnormal noise Loose or untightened
bolt Retighten all bolts
2
Loosen the bolts,
adjust component to
correct position and
retighten
3 Seat can not be raised
chair
4Seat can not be
lowered
person not sitting on
properly
5Not rocking
6Uncomfortable rocking
- strong tension
until you find the best
tension that fits your
back to backrest closely
7Uncomfortable
rocking-weak tension
Adjust spring to the
right until you find the
best tension
The lift valve is closed,
the chair or not sitting
Rocking function is
locked
The lift valve is closed
or person sitting on the
during assembling
Crooked components Crooked backrest or
armrest
Open the lift valve, do
not sit on the seat
while adjusting
Open the lift valve,
make sure to sit in the
center of the chair
Adjust spring to the left
Pull out the adjustment
lever
Rocking spring too tight,
user's back is not close
to the backrest
09
08
Frequent Questions Answers Frequent Assembling Malfunction

Warranty Rules
1. Warranty Range
We provide free replacement parts for buyers/users. Warranty only covers
the parts of the chair. Please note that free tools ( allen wrench ) are not
covered in the warranty.
2. Warranty conditions
Parts will be covered if used normally in reference to the instructions in
the manual. Warranty will not include damages caused by not following
the manual.
3. No warranty covered
1) No proof of damaged parts ( need clear original picture or video to
show the defective parts of chair ).
2) Failure parts caused by improper operation after purchase. For
example, sitting on the armrest may break it.
3) The parts fail due to modification, disassembly or repair of the product
by a third party or customer not following the instructions.
4) Other reasons found that cannot prove damaged parts. We shall not be
responsible for any intended damages or accidental damages by
detrimental weather, etc.
4. Attention
Please keep the original package box for 14 days in case you need to
return the chair to the seller.
Office Ergonomic Guide
A comfortable working space can help you feel better. Give your
sitting and working area a makeover with this visual guideline to
office ergonomics.
Wrists straight,
hands at or below
elbows level
Adjust chair height
so knees are about
same level with hips
Keep an arm away
Enjoy your daily life with Odinlake Chairs! 1110

12 13
Disclaimer
Attention: Ignoring the contents described herein may
result in death or injury to the user, or there is a risk of
property damage.
Please do not use or store the product in
high temperature, high humidity or direct
sunlight for a long time.
Please do not repair, modify or disassemble yourself
unless you follow the instructions in this manual.
It could cause a malfunction.
Do not use this product for infants.
Never sit on the armrest
OdinLake owns the copyright of this file.
Unauthorized reproduction/reprinting of all parts of this manual is
prohibited.
Due to product improvement, the specifications and appearance of this
product are subject to change without prior notice.
Please note that we are not responsible for any failure of other
products caused by using this product.
OdinLake is a registered trademark in the USA, Europe and Japan.
Any Quality Issue
Please send email to [email protected],
take picture and offer your Order No. for OdinLake's easy checking.
OdinLake will provide free replacement parts, send a new
chair or refund accordingly.
