UNPACKING
After unpacking the unit, inspect carefully for any damage that
may have occurred during transit. Check for loose, missing,
or damaged parts. If any damage is observed, a shipping
damage claim must be filed with the carrier. DO NOT use
the OEMTOOLS™24897 12" Cylinder Blower Fan if broken,
bent, cracked or damaged parts (including labels) are noted.
Any Blower Fan that appears damaged in any way, operates
abnormally or is missing parts should be removed from
service immediately. If you suspect that the Blower Fan was
subjected to shock load (a load that was dropped suddenly,
unexpectedly, etc.), immediately discontinue use until it has
been checked by a factory authorized service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself
and others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in
personal injury and/or damage to product or property. Please retain instructions for future reference.
Operating Instructions and Parts Manual 24897
9/17
2017 OEMTOOLS™
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
12" Cylinder Blower Fan
Thank you very much for choosing an OEMTOOLS™Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS™cannot be responsible for issues arising
from modification. We strongly recommend this product is not modified and/or used for any application other than that for which it was
designed. If you have any questions relative to a particular application, DO NOT use the product until you have first contacted customer
service to determine if it can or should be performed on the product.
The following safety information is provided as a guideline to help you operate your Blower Fan under the safest possible conditions. Any tool or
piece of equipment can be potentially dangerous to use when safety or safe handling instructions are not known or not followed. The following
safety instructions are to provide the user with the information necessary for safe use and operation. Please read and retain these instructions
for the continued safe use of your Blower Fan. Failure to follow instructions listed below may result in serious injury. In addition, make sure that
anyone who uses the equipment understands and follows these safety instructions as well.
WARNING
Explanation of Safety Signal Words
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION: Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
NOTES: Provide clarity and helpful information.

2
Operating Instructions and Parts Manual 24897
9/17
2017 OEMTOOLS™
12" Cylinder Blower Fan
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your product. Read this manual carefully.
Learn the product’s applications and limitations
as well as potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or
dark work areas invite accidents.
3. Keep children away. All children should be kept
away from the work area. Never let a child handle
tools or equipment without strict adult supervision.
4. DO NOT operate this product if under the
influence of alcohol or drugs. Read warning labels
on prescriptions to determine if your judgment or
reflexes are impaired while taking drugs. If there is
any doubt, DO NOT attempt to operate.
5. Use safety equipment. Eye protection should be
worn at all times when operating this tool. Use ANSI
approved safety glasses. Everyday eyeglasses are
NOT safety glasses. Dust mask, non-skid safety
shoes, hard hat or hearing protection should be
used in appropriate conditions.
6. Wear proper apparel. Loose clothing, gloves,
neck-ties, rings, bracelets or other jewelry may
present a potential hazard when operating this
product. Keep all apparel clear of the product.
7. DO NOT overreach. Keep proper footing
and balance at all times when operating
this product.
8. Check for damage. Check equipment regularly.
If part of the product is damaged, it should be
carefully inspected to make sure that it can
perform its intended function correctly. If in doubt,
discontinue use of product.
9. Keep away from flammables. DO NOT attempt
to operate this product near flammable materials
or combustibles. Failure to comply may cause
serious injury or death.
10. Store this product out of the reach of children
and untrained persons. This product may be
dangerous in the hands of untrained users.
11. Keep this product dry and clean.
12. Use only accessories that are recommended by
the manufacturer for your model. Accessories
that may be suitable for one product may become
hazardous when used on another product.
13. Service must be performed only by qualified
repair personnel. Service or maintenance
performed by unqualified personnel could result in
a risk of injury.
14. When servicing a product, use only identical
replacement parts. Use of unauthorized parts or
failure to follow maintenance instructions may
create a risk of injury.
15. Maintain a safe working environment. Keep the
work area well lit. Make sure there is adequate
surrounding workspace. Keep the work area free of
obstructions, grease, oil, trash, and other debris.
DO NOT use this product in a damp or wet location.
16. Maintain labels and nameplates on this product.
These carry important information. If unreadable
or missing, contact OEMTOOLS™ for a
replacement.
17. Keep this product dry, clean, and free from brake
fluid, oil, and grease.
18. Avoid accidental fire. DO NOT smoke near this
product.
19. The warnings, precautions, and instructions
discussed in this manual cannot cover all possible
conditions and situations that may occur. The
operator must understand that common sense and
caution are factors which cannot be built into this
product, but must be supplied by the operator.
20. We believe the information contained herein to be
reliable. However, general technical information
is given by us without charge and the user shall
employ such information at their own discretion
and risk. We assume no responsibility for results
or damages incurred from the use of such
information in whole or in part.
21. The manufacturer declines any and all
responsibility for property damage or injury if said
damage is the result of unskillful handling by the
operator or of failure to observe the basic safety
rules set forth in the instruction manual.
22. The procedures documented in this manual are to
serve as guidelines for the use of this equipment.
23. The use of this equipment is simple and
straightforward if you follow the instructions.
When operating this equipment, use common
sense, and only use this equipment for its
intended purpose.
PRODUCT DESCRIPTION
The OEMTOOLS™12" Cylinder Blower Fan is designed
to extract or ventilate air in garages, workshops and
other workspaces.
PRODUCT SPECIFICATIONS
Fan Blade Size (Diameter) 12"
Cylinder Dimensions 13.5" (Diameter) x
13.63" (Depth)
Weight 21.2 Lbs.
Speeds 2
Output Power 1/3 HP
Voltage 120V / 60Hz
Current 4.2A
CFM 3100
RPM 3000
Sound Pressure Level (dB) 85
Ingress Protection (IP) Rating IP44
UL Listed E302275

3
Operating Instructions and Parts Manual 24897
9/17
2017 OEMTOOLS™
12" Cylinder Blower Fan
CONTENTS
(1) 12" Cylinder Blower Fan, (1) Instruction Manual
SPECIFIC SAFETY INSTRUCTIONS
AND WARNINGS
WARNING: Thoroughly read and understand the
provided product manual before attempting to use
this product.
WARNING: DO NOT attempt to disassemble, repair or
modify this fan.
WARNING: DO NOT insert your hand or other objects
into the fan guard or near moving parts.
WARNING: DO NOT submerge this fan in liquids.
WARNING: DO NOT touch this fan with wet hands.
WARNING: DO NOT use this fan if the cord or plug
has been damaged.
1. DO NOT unplug this fan by holding the cord.
Unplug this fan by holding the plug.
2. DO NOT plug this fan into an extension cord.
3. DO NOT operate near an open flame.
4. DO NOT use this fan in conjunction with a solid-
state speed control device.
5. DO NOT leave this fan plugged in while unattended.
Always unplug the fan when not in use.
6. DO NOT move or attempt to perform maintenance
while this fan is plugged in.
OPERATION INSTRUCTIONS
1. Place the fan onto a clean, protected surface that
can support the weight of the fan. Ensure the fan
is placed at a distance that does not overextend
the cord or place tension on the plug.
2. Position the fan to extract or ventilate air:
a. Extraction: Direct the air flow away from the
targeted room or workspace.
b. Ventilation: Direct the air flow toward the
targeted room or workspace.
3. Plug the fan into a grounded 120V / 60 Hz outlet.
4. Test GFCI (Ground Fault Circuit Interrupter) before
each use.
a. Press the RESET button. Indicator should
turn red.
b. Press the TEST button. Indicator should
turn off.
c. Press the RESET button again before
attempting to use.
d. DO NOT ATTEMPT TO USE IF GFCI TEST
FAILS. Call customer service for assistance.
5. Adjust to the desired speed with the toggle
switch:
0 – OFF
1 – Low
2 – High
6. Turn the fan to OFF before unplugging from the
electrical outlet.
Available Attachments: OEMTOOLS™24898 16' Duct
Attachment for 12" Blower Fans.
STORAGE
Store the Blower Fan in an upright position and in a
clean, dry area. DO NOT store near flammable items or
open flames.
PRODUCT MAINTENANCE
WARNING: Unplug the fan before performing product
maintenance.
WARNING: DO NOT use water to clean the fan.
Use a vacuum cleaner to remove dust from the
protective fan guard and blades. If desired, remove the
front protective fan guard to access the fan blades.
Ensure the protective guard is securely reattached
prior to use.
DISPOSAL
At the end of the useful life of the OEMTOOLS™12"
Cylinder Bower Fan, dispose of the components in
accordance with all federal, state and local regulations.

4
Operating Instructions and Parts Manual 24897
9/17
2017 OEMTOOLS™
12" Cylinder Blower Fan
OEMTOOLS™90 DAY LIMITED WARRANTY
For 90 days from the original purchase of this product, OEMTOOLS™will warranty this item. If you find any defect in material
or workmanship, through normal usage, return it to the place of purchase or to OEMTOOLS™for repair or replacement at
our discretion. In order to obtain this service, send your tool and proof of purchase, transportation pre-paid, to OEMTOOLS™
Q.A. Dept., 3850 Raines Road #3, Memphis, TN 38118. We will not be responsible for lost or damaged goods during
transportation; please insure your package. If our inspection verifies the defect, we will either repair or replace the product at
our election, or we may elect to refund the purchase price if we cannot readily and quickly provide you with a replacement.
We will return repaired products at our expense, but if we determine there is no defect, or that the defect resulted from
causes not within the scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS™does not provide warranty for products labeled other than OEM®or OEMTOOLS™. OEMTOOLS™will not
provide any warranty for products subjected to abnormal use. Abnormal use includes, but is not limited to, abuse, accident,
alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not cover bits, blades, files,
batteries, or calibration. We recommend that you maintain your tools and sharpen or replace blades, bits, files, and batteries
as necessary. OEMTOOLS™reserves the right to make any changes in construction or design at any time without any
obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS™makes every effort to ensure that its products meet high quality and durability standards, and warrants to
the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from
the date of purchase. This warranty does not apply to damage due directly or indirectly to misuse, abuse, negligence or
accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear or to lack of
maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or consequential
damages arising from the use of our product. Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN
LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND
FITNESS. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state.
Don’t forget to register your new OEMTOOLS™product at www.oem-tools.com.
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
Item Description Quantity
A Front Guard 1
B GFCI Power Cord 1
C Handle 1
D Cylinder Body 1
E Motor 1
F Rear Guard 1
G Fan Blade 1
H Rubber Base Supports 4
PARTS DESCRIPTIONPRODUCT LAYOUT
ABC
H G F
ED
