UNPACKING
After unpacking the unit, inspect carefully for any
damage that may have occurred during transit. Check
for loose, missing, or damaged parts. If any damage
is observed, a shipping damage claim must be filed
with the carrier. DO NOT use the OEMTOOLS™1500W
120V Shop Heater if broken, bent, cracked or damaged
parts (including labels) are noted. Any Shop Heater that
appears damaged in any way, operates abnormally
or is missing parts should be removed from service
immediately. If you suspect that the Shop Heater was
subjected to shock load (a load that was dropped
suddenly, unexpectedly, etc.), immediately discontinue
use until it has been checked by a factory authorized
service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect yourself and
others by observing all safety information, warnings, and cautions. Failure to comply with instructions could result in personal
injury and/or damage to product or property. Please retain instructions for future reference.
The following safety information is provided as a guideline to help you operate your Shop Heater under the safest possible
conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling instructions are
not known or not followed. The following safety instructions are to provide the user with the information necessary for safe use
and operation. Please read and retain these instructions for the continued safe use of your heater. Failure to follow instructions
listed below may result in serious injury. In addition, make sure that anyone who uses the equipment understands and follows
these safety instructions as well.
Operating Instructions and Parts Manual 24823
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]
1500W 120V
SHOP HEATER
Thank you very much for choosing an OEMTOOLS™Product!
For future reference, please register your new tool at www.oem-tools.com and complete the owner’s record below:
Model: _______________ Purchase Date: ___________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product
before you begin using it. This product is designed for certain applications only. OEMTOOLS™cannot be responsible for issues
arising from modification. We strongly recommend that this product is not modified and/or used for any application other than that
for which it was designed. If you have any questions relative to a particular application, DO NOT use the product until you have first
contacted customer service to determine if it can or should be performed on the product.
Explanation of Safety Signal Words
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION:Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result
in property damage.
WARNING
1
7/17
2017 OEMTOOLS™

2
Operating Instructions and Parts Manual 24823
1500W 120V
SHOP HEATER
7/17
2017 OEMTOOLS™
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your product. Read this manual carefully. Learn
the product’s applications and limitations, as well as
potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark
work areas invite accidents.
3. Keep children away. All children should be kept away
from the work area. Never let a child handle tools or
equipment without strict adult supervision.
4. DO NOT operate this product if under the influence of
alcohol or drugs. Read warning labels on prescriptions
to determine if your judgment or reflexes are impaired
while taking drugs. If there is any doubt, DO NOT
attempt to operate.
5. Use safety equipment. Eye protection should be
worn at all times when operating this tool. Use ANSI
approved safety glasses. Everyday eyeglasses are NOT
safety glasses. Dust mask, non-skid safety shoes, hard
hat or hearing protection should be used in appropriate
conditions.
6. Wear proper apparel. Loose clothing, gloves, neck-ties,
rings, bracelets or other jewelry may present a potential
hazard when operating this product. Keep all apparel
clear of the product.
7. DO NOT overreach. Keep proper footing and balance
at all times when operating this product.
8. Check for damage. Check your heater regularly. If
part of the heater is damaged, it should be carefully
inspected to make sure that it can perform its intended
function correctly. If in doubt, discontinue use of
product.
9. Keep away from flammables. DO NOT attempt to
operate this product near flammable materials or
combustibles. Failure to comply may cause serious
injury or death.
10. Store this product out of the reach of children and
untrained persons. This product may be dangerous in
the hands of untrained users.
11. Keep this product dry and clean.
12. Use only accessories that are recommended by the
manufacturer for your model. Accessories that may be
suitable for one product may become hazardous when
used on another product.
13. Service must be performed only by qualified repair
personnel. Service or maintenance performed by
unqualified personnel could result in a risk of injury.
14. When servicing a product, use only identical
replacement parts. Use of unauthorized parts or failure
to follow maintenance instructions may create a risk of
injury.
15. Maintain a safe working environment. Keep the work
area well lit. Make sure there is adequate surrounding
workspace. Keep the work area free of obstructions,
grease, oil, trash, and other debris. DO NOT use this
product in a damp or wet location.
16. Maintain labels and nameplates on this product. These
carry important information. If unreadable or missing,
contact OEMTOOLS™ for a replacement.
17. Keep this product dry, clean, and free from brake fluid,
oil, and grease.
18. Avoid accidental fire and/or explosion. DO NOT smoke
near this product.
19. The warnings, precautions, and instructions discussed
in this manual cannot cover all possible conditions
and situations that may occur. The operator must
understand that common sense and caution are factors
which cannot be built into this product, but must be
supplied by the operator.
20. We believe the information contained herein to be
reliable. However, general technical information is given
by us without charge and the user shall employ such
information at their own discretion and risk. We assume
no responsibility for results or damages incurred from
the use of such information in whole or in part.
21. The manufacturer declines any and all responsibility
for property damage or injury if said damage is the
result of unskillful handling by the operator or of
failure to observe the basic safety rules set forth in the
instruction manual.
22. The procedures documented in this manual are to
serve as guidelines for the use of this equipment.
23. The use of this equipment is simple and straightforward
if you follow the instructions. When operating this
equipment, use common sense, and only use this
heater for its intended purpose.
PRODUCT DESCRIPTION
The OEMTOOLS™ 24823 1500W 120V Shop Heater is a
convenient way to heat work areas safely and effectively.
PRODUCT SPECIFICATIONS
Input Voltage 120V
Output Wattage 1500W
Amperage 15A
Plug Type Nema 1-15P
Heating Area 250 Sq. Ft.
Dimensions 10.25" (Base W) x 9.25" (Base L)
x 13.25" (Height)
CONTENTS
1500W Shop Heater
SPECIFIC SAFETY INSTRUCTIONS AND WARNINGS
WARNING: DO NOT store or use gasoline or other
flammable vapors / liquids in the vicinity of this heater.
WARNING: Extreme caution should be exercised
when using heaters near children or pets.
1. To avoid burns, DO NOT let bare skin touch hot
surfaces. Use the handle when moving this heater.
Keep combustible materials, such as furniture, pillows,
bedding, papers, clothes and curtains at least 3 feet
(0.9 m) from the Shop Heater to avoid fire. Never block
the air intake.
2. Always operate on a clean, flat surface capable of
supporting the weight of the Shop Heater. Failure
to stabilize may cause the Shop Heater to fall or
malfunction during operation, leading to injury and
property damage.

3
Operating Instructions and Parts Manual 24823
1500W 120V
SHOP HEATER
7/17
2017 OEMTOOLS™
3. Always unplug this appliance when not in use.
4. Always turn the controls off prior to unplugging the
Shop Heater.
5. Always connect directly to a properly grounded
outlet. This appliance must be electrically grounded
in accordance with local codes, with the current CSA
C22.0 Canadian Electrical codes for US installations,
follow US codes, and the National Electric Code ANSI/
NFPA No. 70.
6. Always use 110-120V AC, 60 Hz power supply.
7. DO NOT operate the heater with a damaged cord or
plug, or after the Shop Heater has malfunctioned or has
been dropped.
8. DO NOT attempt to repair or modify the Shop Heater.
9. DO NOT operate on wet surfaces or allow moisture/
liquids to contact the Shop Heater. This heater is not
intended for use in bathrooms, laundry areas or similar
locations. DO NOT use near sinks, swimming pools or
other areas where this heater may contact water.
10. DO NOT use outdoors.
11. DO NOT use this Shop Heater in elevated locations,
such as on shelves, raised platforms, etc.
12. DO NOT cover the power cord with rugs, runners or
any other materials.
13. DO NOT run the power cord through a high traffic area.
14. DO NOT insert foreign objects to enter the ventilation,
this may cause fire.
15. DO NOT leave heater operating unattended.
16. Not intended for commercial or industrial use.
OPERATION
WARNING: Follow the information in this manual exactly;
a fire may result causing property damage, personal injury or
loss of life.
WARNING: Electrical outlet wiring must comply with
local building codes and other applicable regulations to
reduce risk of fire, electrical shock and operator injury.
Note: When operating this heater for the first time, you
may notice a slight emission of smoke. This is normal and
will stop after a short time. The heating element is made
of steel and is coated with layer of protective oil during
production.
1. Position the Shop Heater on a level, dry surface
capable of supporting the shop heater’s weight.
Ensure the Shop Heater is separated from flammable
materials.
2. Connect the Shop Heater to a 110-120V AC grounded
electrical power source.
3. For the fan function, turn the left function dial (G)
clockwise to the 2nd position.
4. For the heating function, turn the left function dial (G)
clockwise to the 3rd position.
5. Rotate the thermostat dial clockwise (I) to set the
thermostat to the maximum temperature.
6. Once the workspace reaches the desired temperature,
turn the thermostat dial (I) counterclockwise until
the heating element (D) turns off. The heater will
automatically cycle around the set room temperature.
7. To increase room temperature, turn the thermostat dial
(I) clockwise. To decrease room temperature, turn the
thermostat dial (I) counterclockwise.
8. To turn the Shop Heater off, turn the thermostat dial (I)
counterclockwise to the lowest temperature setting.
Then turn the function dial (G) counterclockwise to the
1st position “Off”.
9. By grasping the plug, not the cord, remove from the
electrical power source.
10. Once the heating element (D) and metal casing cools,
store in a clean, dry place.
ADJUSTING ANGLE OF OUTPUT
1. The Shop Heater (C) should tilt within the frame
(B). If unable to tilt, turn the frame fasteners (D)
counterclockwise on each side of the heater.
2. Tilt the Shop Heater to the desired angle.
3. Tighten the frame fasteners (E) by turning clockwise.
MOVING THE SHOP HEATER
1. Turn the Shop Heater off and allow to cool (reference
operation above).
2. Grasp the handle (A) on the Shop Heater frame (B)
located above the operation dials, and lift.
AUTOMATIC OVERHEAT SAFETY CONTROL
1. This heater is equipped with an internal heat-limiting
thermostat and an overheat protection circuit.
When the heater’s internal temperature is at risk of
overheating, the heat-limiting thermostat and overheat
protection circuit will automatically shut the heater off.
2. If the system shuts off, unplug the heater and allow the
heater to cool for at least 10 minutes before attempting
to restart.
MAINTENANCE
Remove all dust or grease residue before each use. Wipe
off any debris/residue with a clean cloth.
WARNING: DO NOT attempt to clean the Shop
Heater while it is in operation.
WARNING: No Serviceable Parts
WARNING: DO NOT open the unit or attempt to
repair.
STORAGE
Store the Shop Heater in an upright position and in a
clean, dry area. Do Not store near flammable items or
open flames.

4
Operating Instructions and Parts Manual 24823
1500W 120V
SHOP HEATER
7/17
2017 OEMTOOLS™
OEMTOOLS™ONE YEAR WARRANTY
If for up to one year from the date of purchase of this OEMTOOLS™product you find any defect in material or workmanship, through normal
usage, return it to the place of purchase, or to OEMTOOLS™for repair or replacement at our discretion. In order to obtain this service, send
the product and proof of purchase, transportation pre-paid, to OEMTOOLS™Q.A. Dept, 3580 E. Raines Road #3, Memphis, TN 38118. We
will not be responsible for lost or damaged goods during transportation; please insure your package. If our inspection verifies the defect, we
will either repair or replace the product at our election, or we may elect to refund the purchase price if we cannot readily and quickly provide
you with a replacement. We will return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
OEMTOOLS™does not provide warranty for products labeled other than OEM or OEMTOOLS™. OEMTOOLS™will not provide any warranty
for products subjected to abnormal use. Abnormal use includes, but is not limited to, abuse, accident, alteration, neglect, and unauthorized
or unreasonable use or repairs. This warranty does not cover bits, blades, files, batteries, or calibration. We recommend that you maintain
your tools and sharpen or replace blades, bits, files, and batteries as necessary. OEMTOOLS™reserves the right to make any changes in
construction or design at any time without any obligation in incorporating such changes to tools or equipment previously sold.
OEMTOOLS™makes every effort to ensure that its products meet high quality and durability standards, and warrants to the original
purchaser that this product is free from defects in materials and workmanship for the period of one year from the date of purchase. This
warranty does not apply to damage due directly or indirectly to misuse, abuse, negligence or accidents, repairs or alterations outside our
facilities, criminal activity, improper installation, normal wear and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state.
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
Figure Description
A Handle
B Frame
C Shop Heater
D Heating Element and Output
E Frame Fastener
F Air Intake
G Function Dial
H Power Indicator
I Thermostat Dial
J Power Cord (Not Pictured)
COMPONENT LIST COMPONENT DIAGRAM
TROUBLESHOOTING
Note: Not all components of the 1500W 120V Shop Heater are
replacement items, but are illustrated as a convenient reference for
location and position in the assembly sequence. The manufacturer
and/or distributor have provided the parts list and assembly diagram
in this manual as a reference tool only. Neither the manufacturer nor
distributor makes any representation or warranty of any kind to the
buyer that he or she is qualified to make any repairs to the product,
or that he or she is qualified to replace any parts of the product. In
fact, the manufacturer and/or distributor expressly states that all
repairs and parts replacements should be undertaken by certified
and licensed technicians, and not by the buyer. The buyer assumes
all risk and liability arising out of his or her repairs to the original
product or replacement parts thereto, or arising out of his or her
installation of replacement parts thereto.
A BH
G
F
I
E
C
D
This symbol designates that this tool is listed with
U.S. requirements by ETL Testing Laboratories, Inc.
Conforms to UL Std. 1278, CSA Std. C22.2 No.46.
4003787
PROBLEM CAUSE SOLUTION
The heating element does
not glow red
Stainless steel does not glow red to
produce heat The heater is operating correctly
Do not feel heat
or air flow
No power to heater Check the power connection
Desired room temperature is reached Thermostat automatically will shut off once the temperature is reached
Auto-reset has tripped Unplug the heater and allow to cool for at least 10 minutes, then restart
Heater only has fan only setting Rotate to the third setting on the function dial for heating
C
Intertek
US
