Oeuf PERCH NEST 1PNB01 User manual

Korea
J2 International Inc.
(주) 제이투인터내셔날
서울시 강남구 도산대로 506
재정빌딩 304호
Tel: [phone]
[e-mail]
China
Arketype Limited
7F Metro Loft, 38 Kwai Hei St.
Kwai Chung, N.T.,
Hong Kong
[phone]
www.arketype.com
Australia
Kido Agencies
Postal: PO Box 6039
Alexandria NSW 2015
Australia
Tel: [phone]
[email protected]om
Canada
Monte Distribution Inc.
270 Belfield Rd
Toronto, Ontario
M9W 1H5
Canada
Tel: [phone]
[e-mail]
UK
Kids At Home Distrb.
Newick Business Centre
Church Road
Newick, BN8 4NA
England
Tel: [phone]
[e-mail]
EU
Suede Import
20 Bis Rue des Champs
92600 Asnières-sur-Sein
France
Tel: [phone]
[e-mail]
Distributed internationally by:
Made in Latvia
Oeuf LLC 234 Underhill Ave | Brooklyn, NY 11238 | USA [phone] | www.oeufnyc.com
ek73074
PERCH NEST
ITEM #
USA • CANADA • KOREA
1PNB01

US & Canadian Safety Warnings
Follow the information on the warnings appearing on the upper bunk end
structure and on the carton. Do not remove warning label from bed.
•Use only mattress which is 75” (190 cm) long and 39” (99 cm) wide with a
thickness not greater than 6” (15 cm) on upper bunk. (use a standard
Twin-size Mattress without a box spring)
•Always use the recommended size mattress or mattress support, or both, to
help prevent the likelihood of entrapment or falls.
•Surface of mattress must be at least 5 in. (127 mm) below the upper edge of
guardrails.
•Do not allow children under 6 years of age to use the upper bunk.
•Prohibit more than one person on upper bunk.
•Periodically check and ensure that the guardrail, ladder, and other
components are in their proper position, free from damage, and that all
connectors are tight.
•Do not allow horseplay on or under the bed and prohibit jumping on the bed.
•Always use the ladder for entering and leaving the upper bunk.
•Do not use substitute parts. Contact the manufacturer or dealer for
replacement parts.
•Use of a night light may provide added safety precaution for a child using the
upper bunk.
•Always use guardrails on both long sides of the upper bunk. If the bunk bed
will be placed next to the wall, the guardrail that runs the full length of the bed
should be placed against the wall to prevent entrapment between the bed and
wall.
•The use of water or sleep flotation mattresses is prohibited.
STRANGULATION HAZARD
Never attach or hang items to any part of the bunk bed that are not designed for
use with the bed; for example, but not limited to, hooks, belts and jump ropes.
Keep these instructions for future reference.
Replacement Parts:
Replacement parts are available by contacting your local Oeuf retailer.

Informations importantes concernant la sécurité
IMPORTANT - À LIRE ATTENTIVEMENT - À
CONSERVER POUR CONSULTATION
ULTÉRIEURE
•Utiliser exclusivement un matelas de 75” (190cm) sur 39” (99cm), d’une épaisseur
maximale de 15 cm.
•Toujours utiliser un matelas aux dimensions recommandées afin d’éviter tout risque
de coincement ou de chute.
•La surface supérieure du matelas doit se situer 160 mm au moins en dessous du bord
supérieur des barrières de protection. L’épaisseur du matelas ne doit pas dépasser la
ligne tracée sur la barrière latérale du lit superposé supérieur.
•Lors de l’assemblage, tous les points d’attache doivent être correctement fixés.
S’assurer qu’il n’y a pas de jeu entre les éléments.
•Vérifier régulièrement la position de la barrière de sécurité, de l’échelle et des autres
éléments afin de s’assurer qu’ils ne sont pas endommagés et que tous les points de
raccord sont correctement fixés.
•Ne pas utiliser ce lit superposé si l’un des éléments est défectueux ou manquant. Ne
pas remplacer les éléments. Contacter le fabricant ou le revendeur pour obtenir des
pièces de rechange.
•Le lit superposé supérieur n’est pas conçu pour supporter le poids de plus d’une
personne.
•Ne pas chahuter sur et sous le lit ; ne pas sauter sur le lit.
•Toujours utiliser l’échelle pour monter ou descendre du lit supérieur.
•Laisser une veilleuse allumée permet d’augmenter la sécurité des enfants dormant
sur le lit supérieur.
•Toujours utiliser la barrière de sécurité latérale sur le lit supérieur.
ATTENTION: Risque de coincement entre le lit et le mur. Pour éviter tout risque de
blessure grave, la distance entre la barrière de sécurité supérieure et le mur ne doit pas
dépasser 75 mm, ou doit être supérieure à 230 mm.
ATTENTION: En raison du risque de chute, le lit superposé supérieur ne convient
pas aux enfants de moins de 6 ans.
RISQUE DE STRANGULATION:
Certains objets tels que des cordes, fils, ficelles, harnais et ceintures attachés ou
pendus à un lit superposé représentent un risque de strangulation pour les enfants. Ne
jamais attacher ou pendre au lit superposé, à quelque partie que ce soit, des objets non
destinés à être utilisés avec le lit (crochets, cordes, ceintures ou cordes à sauter par
exemple ; liste non exhaustive).
Conserver ces instructions pour toute consultation ultérieure.!

Australian Safety Warnings
MATTRESS SIZE 920 mm X 1880 mm
Maximum thickness of 150 mm
WARNING: TOP BUNKS AND ELEVATED BEDS ARE DANGEROUS AND
ARE NOT RECOMMENDED FOR CHILDREN UNDER THE AGE OF 9
Falls from elevated beds can be fatal and deaths have occurred where
children have fallen from elevated beds. This is relevant for all ages. The
risk is greater for younger children.
The risk of injury or death from a fall from an elevated bed compared to a
non-elevated bed is:
10 x greater for 7-8 year olds
7 x greater for 9-10 year olds
3 x greater for 11-12 year olds
Children should be discouraged from playing on the bunk bed.
The bunk bed should be checked periodically to ensure that the guardrail,
access device and other components are maintained in the correct position and
state of repair and that all connectors are tight.
WARNING: The upper bunk must be more than 2 m from
any ceiling fan.
STRANGULATION HAZARD – Never attach or
hang items to any part of the bunk bed that are not designed for use with the
bed; for example, but not limited to, hooks, belts and jump ropes.
Keep these instructions for future reference.
Replacement Parts:
Replacement parts are available by contacting your local Oeuf retailer.

KO - Korean - 대한민국 안전 주의사항
주의: 퍼치 이층침대를 안전하고 올바르게 사용함으로 사고나 위험을 막기 위한 안내서이므로 끝까지
읽어 주십시오. 그림을 참고하시면 도움이 됩니다.
침대에 부착된 라벨을 제거하지 마십시오.
•상단 침대에 맞는 매트리스의 크기는 길이 188 cm - 190 cm, 넓이 95.5 cm - 98 cm, 최대높이 15 cm
가 넘지 않아야 합니다. (박스 스프링을 제외한 평 균 규격 트윈 매트리스를 사용하시면 됩니다.)
•어린이의 낙상방지를 위해 항상 권장된 사이즈의 매트리스 혹은 매트리스 지지대를 사용하십시오.
•매트리스의 상단면이 가드레일의 상단부에서 아래쪽으로 최소한 127 mm 아래에 위치해야 합니다.
•만 6세 미만의 어린이는 상단 침대를 사용할 수 없습니다.
•상단 침대는 한 사람만 사용할 수 있습니다.
•가드레일, 사다리 및 기타 부품들이 적절한 위치에 있는지, 손상된 곳은 없 는지, 나사와 볼트가 느슨해진
건 아닌지 정기적으로 확인하십시오.
•어린이들이 침대아래에서 장난을 치거나 혹은 침대위에서 뛰어 놀지 않게 하십시오.
•상단 침대에서 내려올때에는 항상 사다리를 사용하십시오.
•대체 부품을 절대 사용하지 마십시오. 필요시에는 우프 수입판매업체 및 구입하신 소매점에 부품 교체를
문 의 하십시오.
•야간에 어린이들이 침대에서 안전하게 내려올수 있도록 작은 야간용 전등 을 사용하시면 도움이 됩니다.
•상단침대에는 양쪽부분 모두 가드레일을 설치하여 사용하십시오. 이층침 대를 벽 옆으로 배치시킬 경우
도 아이들이 벽과 침대사이로 떨어질수 있 는 사고를 예방하기 위하여 항상 가드레일을 설치해야 합니다.
•물이나 공기를 이용한 매트리스의 사용을 금합니다.
질식위험
절대 침대에 장난감을 부착하거나 물건을 걸어 놓지
마십시오. 이층침대는 물건을 걸어 놓는 용도로 디자인된 침대가 아닙니다. 예를 들
어, 벨트, 각종 줄, 끈, 고리 등을 침대에 연결하거나 부착하지 마십시 오. 나중에 참고
할 수 있도록 이 설명서를 잘 보관하십시오.
부품교체:
부품을 교체를 원하실 경우, 우프 수입판매업체 및 구입하신 소매점으로 연
락하시기 바랍니다.

Fittings List
02:00 h
Z1
(×1)
Z2
(×1)
G
(×24)
Ø35x14
A
(×16)
Ø8x40
C
(×56)
D
(×22)
M6x30 M6x50
B
(×16)
Ø10x40
E
(×24)
M6x65
F
(×46)
M6x10x14
Q
(×4)
P
(×2)
J
(×4)
H
(×12)
Ø7x50 Ø4x35
K
(×68)
Ø20
L
(×4)
M6x14
M
(×4)
M6x30
N
(×6)
2-18
73074

WARNINGlabelforPERCH NEST Bed
Tobeplacedon inside of Top Headboard (part 16)– CENTER HORIZONTALLY & 20mm From TOP EDGE
7/4/22 9:58 AM
234UnderhillAve
Brooklyn,NY11238 USA
[phone]
STRANGULATIONHAZARD- Never attach or hang items to any part of the bunk bed that are
notdesignedfor use with the bed; for example, but not limited to, hooks, belts, and jump ropes.
DONOTREMOVE THIS LABEL
WARNING
Tohelp prevent serious or fatal injuries from entrapment or falls:
• Neverallowa child under 6 years on the upper bunk.
• Useonlymattress which is 74”-75” (188-190cm) long
and38”-39”(97-99cm) wide on upper bunk.
• Ensurethicknessof mattress does not exceed 6” (15cm)
andmattressis at least 5” (12.7cm) below upper edge of
guardrails.
• Useguardrailson both sides of upper bunk.
• Prohibitmorethan one person on upper bunk.
• Prohibithorseplayon or under beds.
• Useladderfor entering and leaving upper
bunk.
Labelwith:
ARTICLE# / DATE
Item#/Date of Manufacture
15
15
3
3
4
11
11
8
8
4
21
21
21
19
2
1
6
5
1
2
6
5
7
7
20
17
14
16
13
3-18
73074
BOX 1
BOX 3
BOX 2
BOX 4

2
1
B
B
E
E
E
E
A
A
A
A
A
A
A
F
F
F
F
F
F
F
F
F
F
F
F
A
A
A
A
A
B
A
F
F
E
B
Ø10x40
A
Ø8x40
FF
A
(×24)
B
(×8)
E
(×8)
F
(×24)
2x
!
!
4-18
73074
1

A
(×8)
B
B
E
E
E
E
F
F
F
F
A
A
A
A
A
A!B
F
E
!
B
Ø10x40
A
Ø8x40
FF
B
(×8)
E
(×8)
F
(×12)
2x
5
6
5-18
73074
2

GG
G
CC
G
G
(×8)
G
Z1
Z1
E
8x
C
8x
2x Z1
(×1)
2
4
3
1
CC
D
M6x50
C
M6x30
C
(×4)
6-18
73074
3

C
G
(×8)
8x
Z1
(×1)
G
G
G
Z1
Z1
E
8x
2x
G
G
6
8
7
5
CC
CC
D
M6x50
C
M6x30
C
(×4)
7-18
73074
4

WARNINGlabelforPERCH NEST Bed
Tobeplacedon inside of Top Headboard (part 16)– CENTER HORIZONTALLY & 20mm From TOP EDGE
7/4/22 9:58 AM
234UnderhillAve
Brooklyn,NY11238 USA
[phone]
STRANGULATIONHAZARD- Never attach or hang items to any part of the bunk bed that are
notdesignedfor use with the bed; for example, but not limited to, hooks, belts, and jump ropes.
DONOTREMOVE THIS LABEL
WARNING
Tohelp prevent serious or fatal injuries from entrapment or falls:
• Neverallowa child under 6 years on the upper bunk.
• Useonlymattress which is 74”-75” (188-190cm) long
and38”-39”(97-99cm) wide on upper bunk.
• Ensurethicknessof mattress does not exceed 6” (15cm)
andmattressis at least 5” (12.7cm) below upper edge of
guardrails.
• Useguardrailson both sides of upper bunk.
• Prohibitmorethan one person on upper bunk.
• Prohibithorseplayon or under beds.
• Useladderfor entering and leaving upper
bunk.
Labelwith:
ARTICLE# / DATE
Item#/Date of Manufacture
5
page 9-18
WARNINGlabelforPERCHNEST Bed
Tobeplacedoninside of Top Headboard (part 16)– CENTER HORIZONTALLY & 20mm From TOP EDGE
7/4/22 9:58 AM
234UnderhillAve
Brooklyn,NY11238 USA
[phone]
STRANGULATIONHAZARD-Never attach or hang items to any part of the bunk bed that are
notdesignedforuse with the bed; for example, but not limited to, hooks, belts, and jump ropes.
DONOTREMOVE THIS LABEL
WARNING
Tohelpprevent serious or fatal injuries from entrapment or falls:
• Neverallowachild under 6 years on the upper bunk.
• Useonlymattresswhich is 74”-75” (188-190cm) long
and38”-39”(97-99cm)wide on upper bunk.
• Ensurethicknessofmattress does not exceed 6” (15cm)
andmattressisat least 5” (12.7cm) below upper edge of
guardrails.
• Useguardrailsonboth sides of upper bunk.
• Prohibitmorethanone person on upper bunk.
• Prohibithorseplayonor under beds.
• Useladderforentering and leaving upper
bunk.
Labelwith:
ARTICLE#/ DATE
Item#/Date of Manufacture
8-18
73074
15
page 15-18
LOFT BED
go to go to
BED

N
N
LOFT BED
2x
N
(×4)
4x
N
2
4
3
1
WARNINGlabelfor PERCH NEST Bed
Tobeplaced on inside of Top Headboard (part 16)– CENTER HORIZONTALLY & 20mm From TOP EDGE
7/4/22 9:58 AM
234UnderhillAve
Brooklyn,NY11238 USA
[phone]
STRANGULATIONHAZARD- Never attach or hang items to any part of the bunk bed that are
notdesignedfor use with the bed; for example, but not limited to, hooks, belts, and jump ropes.
DONOTREMOVE THIS LABEL
WARNING
Tohelp prevent serious or fatal injuries from entrapment or falls:
• Neverallowa child under 6 years on the upper bunk.
• Useonlymattress which is 74”-75” (188-190cm) long
and38”-39”(97-99cm) wide on upper bunk.
• Ensurethicknessof mattress does not exceed 6” (15cm)
andmattressis at least 5” (12.7cm) below upper edge of
guardrails.
• Useguardrailson both sides of upper bunk.
• Prohibitmorethan one person on upper bunk.
• Prohibithorseplayon or under beds.
• Useladderfor entering and leaving upper
bunk.
Labelwith:
ARTICLE# / DATE
Item#/ Date of Manufacture
9-18
73074
5

Z1
(×1)
D
(×16)
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
Z1 D
M6x50
C
M6x30
8
7
2
6
3
7
4
4
3
1
8
6
52
1
10-18
73074
6

K
(×4)
C
(×5)
Z1
(×1)
K
C
K
Z1
Z2
(×1)
J
(×4)
P
(×2)
2x
2x
!
J
N
N N
N
P
P
P
J
J
J
J
J
Z2
D
M6x50
C
M6x30
20
19
13
N
(×2)
C
CC
K
K
11-18
73074
7
8

Z1
(×1)
D
Z1
F
F
(×6)
D
(×6)
D
D
D
F
F
F
F
F
F
D
D
D
D
M6x50
C
M6x30
21
20
19
21
21
12-18
73074
9
10

K
(×12)
C
(×15)
Z1
(×1)
K
C
K
Z1
K
(×16)
C
(×12)
Z1
(×1)
K
K
C
Z1
D
M6x50
C
M6x30
D
M6x50
C
M6x30
11
16
11
14
K
C
C
C
C
C
K
C
C
C
K
K
K
K
C
C
CK
K
K
C
CK
K
KK
K
K
C
C
C
C
C
Y
X>Y
X
13-18
73074
11
12

K
(×12)
Z1
(×1)
K
K
Q
M
L
Q
Q
C
C
C
K
K
K
C
K
K
K
C
Z1
H
H
H
H
H
H
HH
H
H
H
H
H
H
(×12)
12x
4x
D
M6x50
C
M6x30
15
15
17
Q
(×4)
L
(×4) M
(×4)
C
(×8)
14-18
73074
13
14

N
N
BED
2x
N
(×4)
4x
N
2
4
3
1
WARNINGlabelforPERCH NEST Bed
Tobeplacedon inside of Top Headboard (part 16)– CENTER HORIZONTALLY & 20mm From TOP EDGE
7/4/22 9:58 AM
234UnderhillAve
Brooklyn,NY11238 USA
[phone]
STRANGULATIONHAZARD- Never attach or hang items to any part of the bunk bed that are
notdesignedfor use with the bed; for example, but not limited to, hooks, belts, and jump ropes.
DONOTREMOVE THIS LABEL
WARNING
Tohelp prevent serious or fatal injuries from entrapment or falls:
• Neverallowa child under 6 years on the upper bunk.
• Useonlymattress which is 74”-75” (188-190cm) long
and38”-39”(97-99cm) wide on upper bunk.
• Ensurethicknessof mattress does not exceed 6” (15cm)
andmattressis at least 5” (12.7cm) below upper edge of
guardrails.
• Useguardrailson both sides of upper bunk.
• Prohibitmorethan one person on upper bunk.
• Prohibithorseplayon or under beds.
• Useladderfor entering and leaving upper
bunk.
Labelwith:
ARTICLE# / DATE
Item#/Date of Manufacture
15-18
73074
15

Z1
(×1)
D
(×16)
D
Z1 D
M6x50
C
M6x30
D
D
DD
D
D
D
D
D
D
D
D
D
D
D
D
6
1
5
3
7
7
4
4
3
2
8
8
5
6
1
2
16-18
73074
16
