OfficeSource PLTCRKB36WF24 User manual

®
®www.ocesourcefurniture.com
PLTCRKB36WF24
ASSEMBLY INSTRUCTIONS
®
®www.ocesourcefurniture.com
PLTCRKB60WF30
ASSEMBLY INSTRUCTIONS
HARDWARE LISTS AND TOOLS REQUIRED
Item Number Drawing QTY Tool
M6 x 8 A 16 PCS 4mm Allen Wrench
6X14 Bolt
(Wood Top) B
4 PCS Cross-Head screw driver
5x16 Screw
(Wood Top) C
16 PCS Cross-Head screw driver
M8x37
(Foots) D
8 PCS 5mm Allen Wrench
Connect Bar -
1. 24"D Top (Short)
2. 30"D Top (Long)
E 2 PCS N/A
Crank Box F 1 PCS N/A
Pull Holder G 1 PCS N/A
Pull Handle H 1 PCS N/A
Leveler I 4 PCS N/A

®
®www.ocesourcefurniture.com
PLTCRKB36WF24
ASSEMBLY INSTRUCTIONS
®
®www.ocesourcefurniture.com
PLTCRKB60WF30
ASSEMBLY INSTRUCTIONS
INSTALLATION INSTRUCTION
Step 1
Take both leg and the middle support out of the box , attach both legs to the main frame
Step 2
Attach both legs to the frame
Important: Make sure the red dots are on the same side

®
®www.ocesourcefurniture.com
PLTCRKB36WF24
ASSEMBLY INSTRUCTIONS
®
®www.ocesourcefurniture.com
PLTCRKB60WF30
ASSEMBLY INSTRUCTIONS
Step 3
install (Screw A, 12 PCS) on both legs
A
Tools
Step 4
Install the side frame to the main frame with ( Screw A , 4 PCS )
A
Tools

®
®www.ocesourcefurniture.com
PLTCRKB36WF24
ASSEMBLY INSTRUCTIONS
®
®www.ocesourcefurniture.com
PLTCRKB60WF30
ASSEMBLY INSTRUCTIONS
Step 5
Flip over the table base and put it on the back of the wood top
Step 6
Install (Screw B, 4 PCS) and (Screw C , 10 PCS)
B
C
Tools
Step 7
Install the connect bar (Part F) and the Crank Box (Part G), use (screw C, 4 PCS) to secure the crank box
Note : 24”D Wood Top uses the short connect bar, 30”D Wood Top uses the long connect bar
C
Tools
C
C
C
C
C
C
C
C
C
C

®
®www.ocesourcefurniture.com
PLTCRKB36WF24
ASSEMBLY INSTRUCTIONS
®
®www.ocesourcefurniture.com
PLTCRKB60WF30
ASSEMBLY INSTRUCTIONS
Step 8
Install the Pull Holder (Part H) using (Screw C, 2 PCS)
C
Tools
Step 9
Install the feet with (Screw D, 8 PCS), then install the glides (Part I, 4 PCS)
D
Tools

®
®www.ocesourcefurniture.com
PLTCRKB36WF24
ASSEMBLY INSTRUCTIONS
®
®www.ocesourcefurniture.com
PLTCRKB60WF30
ASSEMBLY INSTRUCTIONS
Step 10
Flip over the table
