OFM Mesa Series User manual

H
10x35mm Screw
4 Units
B
Side Panel Legs
2 Units
C
Pedestal
1 Unit
D
Privacy Panel
1 Unit
F
Drawer
1 Unit
J
Allen Wrench
1 Unit
L
Corner
Leg Bracket
4 Units
G
6x55mm Screw
4 Units
I
6x16mm Screw
12 Units
Assembly Notes:
During assembly, hand tighten screws only. When all screws
are in place, you may then tighten all screws completely.
CAUTION:
1. Do not use this desk as a step ladder.
2. Check for loose screws and tighten them every 6 months.
Model 66366 Mesa Series Single Pedestal Desk
Parts Listing
919-362-4765 (fax)
www.ofminc.com
161 Tradition Trail, Holly Springs, NC, 27540
800-520-7471 (voice)
919-303-6389 (voice)
[email protected]
01.16.2014
STOP
Assembly Instructions
Tools Needed: Phillips Head Screwdriver
Please read all instructions before assembly. Assembly will require 2 people.
The following instructions result in a 66366L-ready desk. For a 66366R, please
assemble Pedestal on opposite side.
Step 1: Align Side Panel Legs (B) with the support rail on the underside of the Desk Top (A).
Place Corner Leg Bracket (L) in holes on support rail, and insert 10x35mm Screw (H)
through bracket and into legs. Tighten using Allen Wrench (J). Align Drawer
Runners (E) with holes in underside of the Desk Top (A). Attach using 6x16mm
Screws (I) and Phillips Head Screw Bit (K).
Step 2: Attach Pedestal (C) to underside of Desk Top (A) by aligning screw holes in
Pedestal with holes in Desk Top, and inserting 6x55mm Screws (G) to secure.
Tighten using Phillips Head Screw Bit (K) or screwdriver.
STOP
If you have Model 66366R or 66366L, please proceed to next
page for Return assembly.
Step 3: Attach Pedestal (C) to Side Panel Legs (B) by inserting
6x16mm Screws (I) through pedestal wall and into legs.
Tighten using Phillips Head Screw Bit (K) or screwdriver.
Step 4: Attach Privacy Panel (D) to Pedestal (C) by inserting 6x16mm
Screws (I) through side of Privacy Panel (D) and into the side of
Pedestal (C). Attach Privacy Panel (D) to Side Panel Legs (B)
by inserting 6x16mm Screws (I) through other side of Privacy
Panel (D) and into the corresponding hole on the inside of the
Side Panel Leg (B). Tighten using Phillips Head Screw Bit (K).
Step 5: Flip the desk right side up using at least two people. Insert the
Drawer (F) backwards, as shown, aligning it with the
Drawer Runners (E). Push Drawer (F) all the way in to secure.
A
Desk Top
1 Unit
E
Drawer Runners
2 Units
K
Phillips Head
Screw Bit
1 Unit
3
I
4
C
D
I
K
5
F
A
EE
J
L
H
B
I
1
G
B
A
2
C

E
Return Privacy Panel
1 Unit
F
Return Support Bracket
1 Unit
C
Corner Leg
1 Unit
B
Side Panel Leg
1 Unit
D
Pedestal
1 Unit
Assembly Notes:
During assembly, hand tighten screws only. When all screws
are in place, you may then tighten all screws completely.
CAUTION:
1. Do not use this desk as a step ladder.
2. Check for loose screws and tighten them every 6 months.
Model 66366L / 66366R Mesa Series L-Shaped Pedestal Desk Return
Parts Listing
919-362-4765 (fax)
www.ofminc.com
161 Tradition Trail, Holly Springs, NC, 27540
800-520-7471 (voice)
919-303-6389 (voice)
[email protected]
01.16.2014
STOP
Assembly Instructions
Tools Needed: Allen Wrench and Phillips Head Screw Bit
Please read all instructions before assembly. Assembly will require 2 people.
The following instructions should only be used following the assembly of a 66366 desk.
Step 1: Align Side Panel Legs (B) with the support rail on the underside of
the Return Top (A). Place Corner Leg Bracket (L) in holes on support
rail, and insert 10x35mm Screw (H) through bracket and into legs.
Tighten using Allen Wrench (J). Align Corner Leg (C) with the support
rail on the underside of the Return Top (A). Place Corner Leg
Bracket (L) in holes on support rail, and insert 10x35mm Screw (H)
through bracket and into legs. Tighten using Allen Wrench (J).
Step 2: Attach Pedestal (D) to underside of Return Top (A) by aligning screw
holes in Pedestal with holes in Return Top (A), and inserting 6x55mm
Screws (G) to secure.
Step 3: Attach Pedestal (D) to Side Panel Leg (B) by inserting 6x16mm Screws (I) through
pedestal wall and into legs. Tighten using Phillips Head Screw Bit (K) or screwdriver.
Step 4: Attach Privacy Panel (E) to Pedestal (D) by inserting 6x16mm Screws (I) through
side of Privacy Panel (E) and into the side of Pedestal (D). Attach Privacy Panel (E)
to Corner Leg (C) by inserting 6x16mm Screws (I) through other side of Privacy
Panel (E) and into the corresponding hole on the inside of the Corner Leg (C).
Step 5: Flip the return right side up using at least two people. Line up with the appropriate
position on 66366 Desk. Attach by inserting 6x16mm Screws (I) up through Return
Support Bracket (F) to secure to both the Return Top (A) and the 66366 Desk Top.
A
Return Top
1 Unit
3
I
C
BA
D
5
A
IF
66366 Desk Top
4
D
E
IC
K
A
L
J
H
C
B
1
G
B
A
2
D
H
10x35mm Screw
4 Units
J
Allen Wrench
1 Unit
L
Corner
Leg Bracket
3 Units
G
6x55mm Screw
4 Units
I
6x16mm Screw
12 Units
K
Phillips Head
Screw Bit
1 Unit
