OFM ORO300 User manual

Assembly Notes:
During assembly, hand tighten screws only. When all screws
are in place, you may then tighten all screws completely.
CAUTION:
1. Do not use this chair as a step ladder.
2. Check for loose screws and tighten them every 6 months.
Model ORO300 Designer High-Back Multi-Task Chair
WEIGHT CAPACITY: 300 lbs.
Parts Listing
919-362-4765 (fax)
www.ofminc.com
161 Tradition Trail, Holly Springs, NC, 27540
800-520-7471 (voice)
919-303-6389 (voice)
[email protected]
05.29.2013
A
Chair Back
1 Unit
B
Chair Seat
1 Unit
C
Chair Base
1 Unit
D
Casters
5 Units
E
Chair Arms
2 Units
F
Seat Mechanism
1 Unit
G
Gas Lift
1 Unit
H
Telescopic Bellows
1 Unit
I J
0.75” Screws
10 Units
Arm Caps
8 Units
Allen Wrench
1 Unit
K
1.25” Screws
2 Units
L
STOP
Assembly Instructions
Tools Needed: Allen Wrench - included
Please read all instructions before assembly.
Step 1: Insert Casters (D) into Chair Base (C). Insert Gas Lift (G) into Chair
Base (C) and cover with Telescopic Bellows (H).
Step 2: Attach Seat Mechanism (F) to the Chair Seat (B) with .75” Screws (I) at
back of seat and 1.25” Screws (J) at front of seat, using the Allen
Wrench (K) that is provided. Tension control knob should face front.
Step 3: Attach Chair Seat (B) to Chair Base (C) by inserting the top of the Gas Lift (G)
into the center hole of the Seat Mechanism (F), and press down firmly to secure.
Step 4: Attach Chair Arms (E) to Chair Seat (B) using .75” Screws (I) and Allen Wrench (K).
The tablet arm goes on the right side.
Step 5: Attach Chair Back (A) to Chair Arms (E) using .75” Screws (I) and Allen Wrench (K).
Step 6: Cover screw holes with Arm Caps (L).
1
H
G
2
B
3
I
front
J
K
B
F
D
C
4
B
E
I
6
A
5
L
E
I
E
Product Web Page & Video

Pull tablet outward 180° from it’s Tucked Position at side of chair until it stops. Tablet is now
straight out and ready to be rotated.
180O
With right hand on Bottom Edge/Shelf Edge of
tablet, lift up and over counter clockwise 270°
until it stops.
270
O
Tablet
Lock/Release
Button
Bottom Edge/
Shelf Edge
Bottom Edge/
Shelf Edge
Connection
Magnet
2
1
Tablet
Lock/Release
Button
Place right hand under tablet mechanism at the
bottom right corner and push the in the Tablet
Lock/Release Button. This will allow the tablet
to be rotated from this position.
Tablet
Lock/Release
Button
3
Distance
Adjustment
Channels
Connection
Magnet
Tablet
Lock/Release
Button
With left hand on Tablet Shelf Edge, pull
tablet towards you counter clockwise 90° until
it stops. Let go of Tablet Lock/Release Button
when tablet begins to rotate. Tablet is now
in nal position. At this time, Tablet Distance
from body can be adjusted.
4
90
O
90
O
Notice the Tablet Lock/Release
Button, The Distance Adjustment
Channels and the Connection
Magnet underneath the tablet.
NOTE:
5-2013OFM • 161 Tradition Trail • Holly Springs, NC • 27540
ORO Chair Tablet Arm Operating Instructions — OPEN Tablet
