Ogawa Activo TREK PRO T8.3 User manual

30
35
28
26
24
18
09
06
05
03

it’s
Activo

Activo

OAGWA
OAGWA
T8.3
OAGWA
Activo

x 6
Washer m8 x 6
Bolt m8*55 x 4
OAGWA
Activo

Activo
7

Activo
1 Base 1 40 Rear end cap left 1
2 Inclineframe 1 41 Rear end cap right 1
3 Main frame 1 42 Base cover(left&right) 2
4 Left upright 1 43 Base cover board 2
5 Right upright 1 44 Side rail cover 2
6 Handrailrack 1 45 Side rail 2
7 Bolt M10*55 1 46 End cap supportboard 1
8 Bolt M10*45 5 47 Handrailfoam 2
9 Bolt M8*55 2 48 Motorbelt210J-6 1
10 Screw￠4*20 8 49 Cushion￠25*33*M8 8
11 Bolt M8*25 1 50 Base foot 4
12 Bolt M8*30 4 51 Base movingwheel 2
13 Bolt M8*35 4 52 Frame movingwheel 2
14 Bolt M8*40 3 53 Magnetringfoam 1
15 Screw ￠4*12 2 54 Runningboard1220*605*T15 1
16 Bolt M8*65 3 55 Running belt460*2870*T1.6 1
17 Bolt M8*20 8 56 U socket 1
18 Bolt M5*28 8 57 Cable grommet￠24*￠15*6 1
19 Screw￠4*15 7 58 Power cord 1
20 Screw￠4*12 30 59 DC Motor 1
21 Screw￠3*10 4 60 Inclinemotor 1
22 Screw￠4*12 22 61 Power switch 1
23 Nut M10 6 62 Magneticring￠28*￠16*13 1
24 Nut M8 11 63 Circuit breaker 1
25 Washer ￠11*￠22*2.0 6 64 Air cyclinder 1
26 Washer ￠9*￠16*T1.6 12 65 Upper controller 1
27 Spring washer M8 4 66 Controller 1
28 Spring washer M10 4 67 Safety key 1
29 Front rollerdia 1 68 Upper cables 1
30 Rear rollerdia 1 69 Middlecables 1
31 Console upperbox 1 70 Under cables 1
32 Console underbox 1 71 Audilcables 1
33 Console PCB uppercover 1 A Bolt M8*55 6
34 Console PCB undercover 1 B Bolt M8*15 4
35 Front handrailbar uppercover 1 C Screw￠4*15 6
36 Front handrailbar undercover 1 D Washer￠9*￠16*T1.6 10
37 Handrailcap 2 E Wrench S13.15 1
38 Front motorcover 1 F WrenchS5 1
39 Motorcover 1 G WrenchS6 1
8

Activo
9

Activo
NOTICE
●Read this manualbeforeassembly
●Recognize the spare parts first
●Check the hardware
●Ensure thatyou have the righttool
●Prepare an area to assemble
●Followthe instructionaccordingly
●Never force the joints
●Periodicallytightenthe joints
●Keep this manual withyou
10

Activo
11

Activo
12

Activo
13

Activo
14

Activo
15

Activo
16

Activo
WARNING
17

I. Display function
1:LCD Display readout：
1、“SPEED ”：（Referred to as: window1 ）
1.1 display speed
2、“INCLINE/ DIS/CAL”：（Referred to as: window2）
2.1 When“INCLINE”flashes, display the accumulatedtotalworkoutincline
2.2 When“DIS ”flashes, display the accumulatedtotalworkoutdistance in kilometers
2.3 When“CAL”flashes, display the accumulatedcalories burn duringworkout
2.4 When you enter intoprogramsports, it willdisplay programnumber
3、“TIME/PULSE ”：（Referred to as: window3）
Activo
18

3.1 When“TIME”flashes, display the accumulatedtotalworkouttimein minute
3.2 When“PULSE”flashes, display the currentpulse readingin beats per minutewhen the pulse is detectedby
placingBoth palm on the stainless steel handrailpulse kit
3.3 When the value displayed, the countdownenterinto3 seconds
4、Dot matrixwindow：
4.1 display graphics program
5、Volumeicon: display volume
6、“MANUAL/TIME/DISTANCE/CALORIES/PROGRAM ”display manual mode/timemetermode/distancemetermode/
Calories metermode
2: Keyboard function:
PROG. ：Program selection key. In the order: manual mode—P1-P15 —U1-U3- FAT
MODE ：Time mode selection key. In the order: manual mode-time mode-distance mode-calories mode. Fat
measurements mode for lipidmeasurementparameterselection key.
START/STOP ：Press the START buttonand wait 3 seconds for belt begin to move. Press STOP buttonthen the
equipmentwillresume to ready mode.
SPEED ：Speed add and subtract adjustment.Movement speed can be adjusted. Stop can be used to adjust the
parameters.
SPEED （3 6 9 12） ：Speed quick adjustmentbutton
INCLINE ：Incline up and down adjustment. Movement incline can be adjusted. Stop can be used to adjust the
parameters.
INCLINE （2 4 6 8）： Incline quick adjustmentbutton
Left handrailkey: Incline adjustmentbutton
Right handrailkey: Speed adjustmentbutton
Volume+/volume-/inthe song/thenext song/startstop button：Volume adjustmentbutton、in the song/thenext song、
start/stopbutton
3. Main function:
Attachthe safety key to wake up console in 2 seconds, and then the equipmentis on manual mode.
3．1 Manual mode：
Plug in power cord and switch on the equipment, press PROGRAM button can be settled in circle: Program
P1-P15-U1-U3-FAT,press start button,window3 will display:3333－2222－1111,andeach minus one buzzer chirping,
then start the motorizedtreadmillfrom minimumspeed. Press speed +/- and incline +/- buttoncan adjust speed and
incline, also can be adjusted by the quick speed on the displayer or handrailbutton.Press STOP buttonor move safety
key thenthe equipmentwillresume to ready mode.
