OGK Urban Iki User manual

1
www.urbaniki.com
no°6
included
Ø
21 to 28
mm
Ø
21 to 28
mm
9 to
22 kg
9 months
to 6 years
Front seat
with Compact Adapter
Fietszitje voor met Compact Adapter
スリム取付けタイプ自転車用フロントシート
Scan for
instruction video
Bike away
in just a few
minutes

2
ENG
Hello
You have chosen the Urban Iki Front seat, the child bicycle
seat for your child’s first trips on the bike.
Urban Iki by OGK is developed by Dutch and Japanese de-
signers. The best of both worlds come together in Urban
Iki products. OGK has been making innovative products
for the cycling consumer for 80 years, and is the bike seat
expert of choice in Japan, where the bicycle is king. Tech-
nology and safety at the highest level. Dutch design is well
known the whole world over. And your Urban Iki bike seat
brings combines these factors.
In addition to the Urban Iki Front seat, a fitted windshield
is also available as an accessory for greater protection from
wind, weather and insects and against stones from the
road. An extra mounting block for a second bike is available
as a separate accessory too. Is your child now over 15 kg?
Then the Urban Iki Front seat is no longer suitable for carry-
ing your child on the bike. For children from 15 kg to 22 kg,
there is the Urban Iki Rear seat for carrying kids on the back
of your bike. Go to www.urbaniki.com for the full range and
all accessories.

21mm
25-28mm
2x
25-28mm
2x
21mm
2x
3
ENG
Urban Iki
Front seat
Foot support (L) Foot support (R)
mounting block
user manual
insert 25-28 mminsert 21 mm
Allen wrench
No° 6
In the box
User manual
The Urban Iki Front seat is easy to put together and attach to your bike. This user
manual explains how to do this yourself quickly and easily. So you can get on the
road straight away and enjoy cycling with your child. Read the user manual care-
fully before using the Urban Iki Front seat, and follow closely the instructions for
safe use. That’s the best way to ensure a great deal of biking fun.
Keep plastic packaging materials out of reach of babies and children
due to the risk of suffocation. Throw the packaging away immediately.
What makes the Urban Iki Front seat unique
Safe 5-point
seatbelt
Easy-to-adjust
Seatbelt
Seatbelt lock
Soft shoulder
padding
Adjustable footrests
Adjustable foot
straps
Soft rubber water-
repellent seat
cushion
Integrated water
drainage points
Ergonomically
shaped seat
Easy-to-fit mounting
block
Click & Go fastening for
easy attachment and
removal of the seat

4
ENG
How to assemble the Urban Iki Front seat
Your Urban Iki Front seat is easy to put together. All you have to do is slide the foot
supports onto the left and right mounting tubes.
How to mount the Urban Iki Front seat to the bike
Mounting left and right foot supports
Scan for
instruction video
Scan for
instruction video
Step 1: Unscrew
The Urban Iki Front seat is suitable for carrying children
with a maximum weight of 15 kg in the age range of 9
months to about 3 years. Check whether you are legally
permitted to use the Urban Iki Front seat in the country
in which you intend to use it. The bike seat is mounted to
the front of a bike on handlebar stems with a diameters
ranging between 21-28 mm. Only use the Urban Iki Front
seat on bikes built for a heavier load. Where necessary, con-
sult the bicycle manual or enquire from the manufacturer.
If your bike is technically up to the job, then mount your
Urban Iki bike seat as follows.

max 5Nm
5
ENG
21-24 mm | standard
25-28 mm | standard
Ø25-28mm
21mm
2x
Ø21-24mm
21mm
25-28mm 2x
Step 2: Fit block to handlebars
Remove 21mm insert
Step 3: Screw tight to max 5Nm

min 19 mm
Ø21-24mm
21mm
2x
min 19 mm
Ø21-24mm
25-28mm
2x
6
ENG
consult
the bicycle
manual
consult
the bicycle
manual
step 2: disassemble the
handlebar / remove spacers
step 2: disassemble the
handlebar / remove spacers
step 4: remove
insert
step 4: remove
insert
step 5: mount
21 mm insert
step 5: mount
25-28 mm insert
step 3: mount handlebar
step 3: mount handlebar
21-24 mm | compact
25-28 mm | compact

max 5Nm
7
ENG
Step 6: Fit block to handlebars Step 7: Screw tight to max 5Nm
Fasten bike seat to the mounting block
Always check whether the handlebars can still be turned properly both left and
right after fitting the bike seat. If the angle of rotation is less than 45° left or right,
then we recommend fitting different handlebars.
The bike seat is also easy to remove when not in use.
Step 1: Press button
Step 2: Turn handle
to the rear
Step 3: Remove
seat from mounting
block

OK
8
ENG
How to use the Urban Iki Front seat
When you use the Urban Iki Front seat, always check
whether the seat is properly fitted and take a brief test
ride without your child. If everything is working properly
and you are not restricted when cycling, then you are now
ready top set off with your child. Place your child in the
seat and fasten the safety belt firmly, but not too tightly.
Adjust the foot supports to the required height and ensure
the feet stay in place by fastening the foot straps. Always
check whether there are any sharp bike parts within reach
of your child and that the clothing your child is wearing
cannot come into contact with rotating or moving parts of
your bike.
Adjust foot supports
Adjusting foot straps
Step 1: Unlock Step 2: Slide
Step 3: Lock
Step 1: Insert foot strap Step 2: Adjust
Step 3: Loosen
Scan for
instruction video

CLICK!CLICK!
1
1
3
22
3
9
ENG
Close seatbelt
Opening and closing the seatbelt
Adjusting seatbelt strap
Open seatbelt
1. Press
2. Press
3. Pull upwards
Tilt seatbelt upwards
Tightening seatbelt
Tilt seatbelt upwards

10
ENG
Safe use; a few warnings:
•Only take your child of 9 months or older, with a weight of 9 kg or more, if he
or she can sit upright unaided for the duration of the planned bike ride. Regu-
larly check to ensure your growing child is not too tall or heavy (maximum 22
kg) for the seat you are using.
•Always cloth your child warmly enough and with protection from wind and
rain. Your child does not move and thus cools off quickly.
•Never leave your child sitting alone in the bike seat without holding the bike
firmly. Ensure your bike is fitted with a stable (two-legged) stand.
•Check that the bike seat is not too hot in the sun during nice weather before
putting your child in the seat.
•In the event of any defects, never change anything on your bike seat yourself,
but contact either the store where you bought your seat or Urban Iki customer
service. Do not use the bike seat if a component is defective.
•Taking your bike with the car on the bicycle carrier; always remove the bike
seat. Turbulence can damage the seat or its mounting. This makes the seat
unsafe to use.
•Lock the seatbelts on the bike seat even when your child is not sitting in it; this
prevents the straps from getting snagged or entangled.
•Only use the bike seat for transporting your child on the bike. Bags or other
baggage is best carried on the bike in the opposite place to your child. This
helps to spread the weight on the bike.
•Do not lift your bicycle using the bike seat.
•Urban Iki recommends using a well-fitting helmet for your child.
•Your Urban Iki children’s bike seat is intended for taking your child on the
bike in the daily setting. This bike seat is not suitable for cycling off-road and
ATB courses.
•Cycling with a child in a bike seat can influence the characteristics of your
bike when cycling, especially when steering in bends, or braking or setting off.
•You must be 16 years or older to carry a child in the Urban Iki bike seat. Legisla-
tion may differ per country.

11
ENG
Maintenance, warranty and service
Maintain your Urban Iki bike seat properly, as it will then give you many years of
pleasure. It is sufficient to clean it occasionally with a cloth, lukewarm water and
a mild cleaning agent.
Urban Iki products are developed and manufactured on the basis of the highest
quality standards. The Urban Iki Front seat is tested to the most stringent appli-
cable European norm, EN 14344. A certificate from the leading TUV institute has
been awarded as proof of compliance to this standard.
We give a two-year warranty on your Urban Iki Front seat. This warranty period
starts on the date that you bought the seat as stated on the purchase receipt.
Always save this receipt if you ever need to make a claim on this warranty.
The warranty does not apply in the following cases:
•When using the product in a way other than prescribed in the user manual.
•A claim is made against the product warranty without the original receipt
outside the applicable warranty term.
•Repairs to the Urban Iki child seat are carried out by third parties.
•The defect is the result of improper, careless use or maintenance, by neglect
or accident.
•Normal wear and tear of parts that may be expected with daily use of the
product.
The warranty issued complies with European Directive 99/44/EG dated 25 May
1999.
In the event of a complaint or defect related to your Urban Iki child seat, contact
the store where you bought your Urban Iki child seat or our customer service.
11
Urban Iki customer service
OGK Europe B.V.
Energiestraat 13
7442 DA Nijverdal
The Netherlands
www.urbaniki.com
E: [email protected]

58
For you to discover
Osaka - Amsterdam
2018 - version 1
