Oh!FX SANIFYER User manual

INSTRUCTION MANUAL
SANIFYER / SANIFYER PLUS
C/ Indústria, 4 | Industrial zone | 08592 Sant Martí de Centelles | Barcelona | Spain
[phone] | [email protected]
EN

INSTRUCTION MANUAL
SANIFYER / SANIFYER PLUS
* Measures taken with 1,0020cP at 20ºC viscosity  uid. Real consumption may vary depending on  uid viscosity.
SANIFYERTECHNICAL SPECIFICATIONS SANIFYER PLUS
SANIFPLUS9
615g.
9
15 x 23 x 5,8 cm
3/8 BAR
200 l/min
120 ml/min at 3 BAR *
8-10 meters
>pH5 / <pH9
SANIF
560g.
3
15 x 23 x 5,8 cm
3/8 BAR
100 l/min
40 ml/min at 3 BAR *
4-6 meters
>pH5 / <pH9
REF.
WEIGHT
NO. NOZZLES
MEASURES (without hose and bottle)
MAX/MIN WORKING PRESSURE
MIN AIR WORKING CONSUMPTION
FLUID CONSUMPTION
REACH
MAX/MIN PH (fl uid)
PARTS
AIR INLET CONNECTOR
HANDLE
TRIGGER
SAFETY LOCK
NOZZLES
FLUID BOTTLE
ABSORPTION TUBE
FILTER
COMPRESSED AIR HOSE
FEMALE CONNECTOR (hose)
MALE CONNECTOR (hose)
SANIFYER is an atomizer gun specially designed for pulverising disinfectant liquids on di erent
surfaces. It is made with high quality components and with a quick connection system.
Atomization, unlike other spray systems, creates much smaller droplets that allow the application
of disinfectant on large surfaces with very little  uid consumption and without wetting.
Its design and power allows to cover large spaces with microdrops in a very short time and creates
a layer of disinfectant so thin that it does not require subsequent rinsing or drying.
There are currently 2 models of guns. SANIFYER, equipped with 3 nozzles, and SANIFYER PLUS with
9 nozzles, much more powerful and designed to cover larger spaces and save application time.

INSTRUCTION MANUAL
1. Make sure the safety lock in the SANIFYER / SANIFYER PLUS gun’s handle is locked to avoid the
accidental actioning of the trigger during assembly.
2. Connect the compressed air hose to your air compressor. (This air hose may be not included).
3. Connect the other end of the hose - female quick connect to the air inlet connector of the
SANIFYER / SANIFYER PLUS gun.
4. Fill the bottle with the uid and screw it carefully onto the SANIFYER / SANIFYER PLUS gun so that
the absorption tube and the lter are inside the container and in its bottom.
ASSEMBLY
1. Start the compressor.
2. Hold the SANIFYER/SANIFYER PLUS pistol rmly with one hand on the handle and with the
other hand unlock the safety lock .
3. Pull the trigger to spray the uid by pointing the nozzles towards the surface you want
to disinfect from a distance of approximately 1-2m with the SANIFYER, and 3-4m with the
SANIFYER PLUS.
4. If you need to rell the uid bottle make sure to set the safety lock to avoid accidental trigger.
OPERATION
In case you are not using the disinfecting uid supplied by SANIFYER SOLUTIONS, we recommend
to rinse the gun after each use. When you have nished using the SANIFYER / SANIFYER PLUS
gun, ll the uid bottle with water and operate the SANIFYER/SANIFYER PLUS gun for at least
10 seconds to clean the inside of the gun. Then, empty the excess water from the bottle before
storing the SANIFYER gun.
For disassembly, the air hose must be empty of air pressure. Turn o the compressor and pull
the trigger on the SANIFYER gun until air stops coming out before disconnecting the hose.
CLEANING AND DISMANTLING
• Use non-aggressive liquids (i.e hydroalcohols) with a pH between 5 and 9. Very acidic or alkaline
substances (quaternary ammonium, bleach,…) could damage the aluminium inside of the
SANIFYER/SANIFYER PLUS gun and its nozzles.
• For an optimal result, use a compressor that oers a minimum air ow rate of 100L of air per minute
at 3 Bar for SANIFYER GUN, and 200l per minute at 3 Bar for SANIFYER PLUS.
• If you pulverise on a surface from less than 1 meter or repeatedly treat the same surface, it is
possible that the liquid moisture accumulates on the treated surface and requires manual drying.
• If you need the droplets sprayed by the SANIFYER / SANIFYER PLUS gun to be larger and more
moist, you can lower the compressor pressure below the optimum operating pressure. If, on the
contrary, you prefer the particles to be smaller, you will achieve this by increasing the pressure
of the compressor.
• The surfaces in which the disinfectant is applied must be clean and dry so that the disinfectant
does not lose eectiveness.
REMARKS

INSTRUCTION MANUAL
GENERAL CAUTION
• Do not inhale the fumes coming out of the gun.
• Do not pulverise over people or animals.
• Read carefully the label instructions of the disinfecting liquid you are using, before
starting to use the gun. Pay particular attention to the sections WARNING and USING
INSTRUCTIONS.
• Do not pulverise inammable liquids close to ame or heating sources.
• Use non-aggressive liquids (i.e hydroalcohols) with a pH between 5 and 9. Very acidic
or alkaline substances (quaternary ammonium, bleach,…) could damage the aluminium
inside of the SANIFYER/SANIFYER PLUS gun and its nozzles.
• The SANIFYER/ SANIFYER PLUS gun has been designed for the described eect. Any other
use will exclude SANYFYER SOLUTIONS S.L. from all liability and guarantee.
• Use only the accessories supplied by your distributor provided for this use and duly certied.
• In case of air leak or malfunction, do not attempt to disassemble the machine or any
accessory. Disconnect the air compressor and contact your dealer.
• Any unauthorized manipulation will invalidate the warranty.
• Use only the consummables conceived for the described use and duly certied.
• Only an adult and qualied person must handle the machine.
08/2020
