Okina USA 3-AXIS SHDX-755AIDN-VD Quick start guide

SHDX-755AIDN-VD_SSDX-742AI-VD_rev031209
Operational Manual
3-AXIS Day & Night Vandal Proof Dome Camera
SHDX-755AIDN-VD
SHDX-755AIDN-VDP
z1/3” Sony Super HAD CCD II
z550 TV Lines, HQ-1 DSP
z2.9mm~10.0mm Aspherical Auto Iris Lens
MadeinJapan
zHigh Gain/Low Noise Amplifier - DNR
z0.15 Lux @ F1.2
zIP66 Rating
z12V DC
SHDX-755AIDN-VD
SSDX-742AI-VD
SHDX-755AIDN-VDP
SSDX-742AI-VDP
FEATURES
Please read the Operational Manual
before attempting to use this product.
SSDX-742AI-VD
SSDX-742AI-VDP
z1/3” Sony Super HAD CCD
z420 TV Lines
z2.9mm~10.0mm Aspherical Auto Iris Len
s
MadeinJapan
z0.15 Lux @ F1.2
zIP66 Rating
z12V DC
DIMENSIONS (Unit: mm)
* Day & Night Feature Available Only for SHDX-755AIDN-VD/SHDX-755AIDN-VDP
3-AXIS

SHDX-755AIDN-VD_SSDX-742AI-VD_rev031209
1. FAR/NEAR
2. WIDE/TELE
1. FAR / NEAR
2. WIDE / TELE
3. DC LEVEL
The VR for adjusting the IRIS level of Auto Iris lens.
4. CONTROL SWITCHES
Switch 1. Color / D&N (SHDX Model)
Color: Color mode. (Normal position)
D&N: Day and Night Switch. Color mode automatically switches to B/W mode under 2.0 Lux.
Switch 1. AES: Automatic Electronic Shutter (SSDX Model)
AES / OFF switch.
The range of shutter speed from 1/60 (1/50sec.) to 1/100,000 sec.. This mode is employed for using a manual iris lens.
OFF: AES OFF.
The shutter speed is 1/60sec. (1/50sec.).
When an auto iris lens is applied, AES should be off.
Switch 2. BLC: Backlight Compensation.
BLC / OFF switch.
When the object is dark by strong light (sunlight etc….) as (Fig.2-1), please turn on BLC to make object become bright as
(Fig.2-2).
OFF: BLC OFF.
Switch 3. AGC: Automatic Gain Control.
AGC / OFF switch.
AGC level of gain varies from 0 to 26dB.
OFF: AGC OFF. The level of gain is fixed at 0dB.
Switch 4. FL: Flickerless.
F. L / N O M s w i t c h .
In FL mode, the shutter speed is 1/100sec. (NTSC system) / 1/120sec. (PAL).
If choose FL mode, [AES] switch should be off.
NOM: Normal position.
PARTS
A
ND FUNCTIONS

SHDX-755AIDN-VD_SSDX-742AI-VD_rev031209
5. Video connector
This is an output for connection to a video monitor, etc (75Ω).
6. Power input terminal
Connect to 12V DC power supply.
*Specifications are subject to change without notice
zOne (1) SHDX-755AIDN-VD/SHDX-755AIDN-VDP or SSDX-742AI-VD/SSDX-742AI-VDP Camera with video/power cable
zOne (1) L-type Star Wrench
zOne (1) L-type Hexagon Wrench
zThree (3) Wall Anchors
zThree (3) Mounting Screws
zOne (1) Operational Manual
*For any returns, please include all components listed above with original packaging in Resalable Condition.
Absolutely No Returns will be accepted if any component is missing/damaged or if any cable is cut or tampered with.
Model SHDX-755AIDN-VD SHDX-755AIDN-VDP SSDX-742AI-VD SSDX-742AI-VDP
TV System NTSC PAL NTSC PAL
Image Sensor 1/3” Sony Super HAD CCD II 1/3” Sony Super HAD CCD
DSP Sony HQ-1 Sony
Total Pixels 811(H) x 508(V) 795(H) x 596(V) 537(H) x 505(V) 537(H) x 557(V)
Synchronizing System Internal
Resolution 550 TV Lines 420 TV Lines
Minimum Illumination 0.15 Lux @ F1.2
Color mode automatically switches to
B/W mode under 2.0 Lux 0.15 Lux @ F1.2
S/N Ratio More than 48dB (AGC OFF)
Auto Gain Control ON/OFF (Switchable)
Flickerless ON/OFF (Switchable)
BLC ON/OFF (Switchable)
AES ON/OFF (Switchable)
DC Level The VR for adjusting the IRIS level of auto Iris lens
White Balance AWB / 2500°K ~ 9200°K
Video Output 1Vp-p composite / 75 Ω
Lens / Angle of View 2.9mm~10.0mm / F1.2
Aspherical Auto Iris Lens, 94.6°~28.8° (Made in Japan)
DNR / Sens-up High Gain/Low Noise Amplifier N/A
Max Breaking Strength 656.1 Kgf
Waterproof Level IP66
Lead Free Yes
Power Supply 12V DC
Power Consumption 145mA / 1.7W 85mA / 1.0W
Operating
Temperature 14°F ~ 122°F / -10°C ~ +50°C
Dimension 4.42”(dia) x 5.51”(H) / 112.2(dia) x 140(H) mm
Weight 2.09 lbs / 950g
SPECIFICATIONS
PACKAGE CONTENTS

SHDX-755AIDN-VD_SSDX-742AI-VD_rev031209
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling could damage the camera.
3. Requires a proper operating environment
This camera is designed for outdoor or indoor use. The allowable temperature range for operation of this camera is between
14°F ~ 122°F / -10°C ~ +50°C and the allowable humidity is 85%RH maximum.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned before lens installation or whenever the lens is changed. Cleaning
should be done by using a chamois, a very fine soft cloth, lens tissue, or cotton tipped applicator and ethanol to carefully remove
any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range. (Camera must meet the specifications). Camera must be
connected to a surge protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may touch dangerous voltage points of short out parts that could result in
a fire or electric shock. Never spill any kind of liquid on the video product.
7. Servicing
Do not attempt to service this video product by yourself as opening or removing covers may expose you to dangerous voltage or
other hazards. Refer all service to qualified servicing personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer service to qualified servicing personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been dropped or the cabinet has been damaged.
d. When the video product exhibits a distinct change in performance.
OKINA USA Products are covered under warranty for one year from the date of purchase. The warranty will automatically be voided
if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any information regarding when and where the product was
purchased. We have no other way to verify the purchase record without the serial number on the camera sticker; therefore, it
should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not described in this manual, the warranty will be voided
immediately. It is the customer’s responsibility to keep the camera in good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered with. Cutting or modifying of the cables will result in termination of
the warranty.
