Okina USA SIV7-T54AI922 Quick start guide

R201110-V251
Operational Manual
Die-Cast Top Open Fully-Cable Managed Housing & Bracket
With Infrared Day & Night Camera
IR on/off sensor is fully integrated with IR Cut Filter Removable (ICR)
* UL certification only refers to the power converter and the power module
z1/3” Sony Interline Transfer Super HAD CCD, 540 TV Lines
z7 Super Power IR LED, 4pc x 25o/ 3pc x 45o
z9.0mm~22.0mm Auto Iris Manual Vari-Focal ED-IR Lens
z0.1 Lux @ F1.2
zIR Distance 200~250ft / 60~80m c
zEven Distribution of IR Light (No IR Halo)
zUser Adjustable IR LED Intensity (VR), Factory Default 80% ¡
zBuilt-in IR Cut Filter Removable (ICR)
zBuilt-in Heater & Blower
zFully-Cable Managed Bracket
zUses professional rust-proof stainless steel screws
zIP66 Rating
z24V AC, 60VA
FEATURES
Please read the Operational Manual
before attem
p
tin
g
to use this
p
roduct.
c¡Please see page 7
SIV7-T54AI922
SIV7-T54AI922P

R201110-V252
PART DESCRIPTION

R201110-V253
1. Lens Cap with Heater
2. Temper Glass
3. IR LED: 7pcs Super Power IR LED with Refractor
4. IR Board and IR Board Bracket
5. Camera Board and Camera Board Bracket
6. IR Control Board
7. Power Supply Unit: 24V AC Power Input, 60VA, 12V DC Output
8. Blower and Blower Bracket
9. Live (L): Brown Wire
10. Earth (E): Yellow/Green Wire
11. Neutral (N): Blue Wire
12. Video Output BNC Female Connector: Use the connector to connect with the video in connector of a monitor
13. Heater Thermostat Switch: Turns on at 18oC / 64oF and turns off at 28oC / 82oF
14. IVR: IRIS Level Control. Turn clockwise to L to get darker picture. Turn counterclockwise to H to get brighter picture.
15. VR: Adjust VR to set Infrared LED activation level
FACTORY DEFAULT 80% -- If there is not enough IR light, adjust the level to maximum 100%
16. Blower Thermostat Switch: Turns on at 35oC / 95oF and turns off at 25oC / 77oF
17. Terminal Block: 24V AC External Power Input
18. Fuse Holder: With 250V/3.15A fuse
19. Terminal Block: To power supply unit
20. Ground Wire: To top cover
21. RCA Jack Monitor Output
22. Monitor Out for Angle & Focusing: When setting up the camera, connect a monitor to this video output connector
using enclosed BNC female cable, then adjust the image displayed on the hand-held monitor, set the surveillance
angle.

R201110-V254
How to install cables through the mounting bracket:
1.
2.
INSTALLATION
Head of Fully-Cable Mana
g
ed Bracket

R201110-V255
3.
N
L
E
9.0mm~22.0mm Auto Iris Manual Vari-Focal ED-IR Lens
Zoom & Focus Adjustments
1. Focus Ring
2. Zoom Ring

R201110-V256
SIV7-T54AI922 / SIV7-T54AI922P:
Fully-Cable Managed Bracket:
zMax Load: 3500g
zMaterial: Die-cast aluminum alloy with light ivory powder coated
and stove finish
zScan Angle: 180°
zTilt Angle: 90°
zNet Weight: 900g
zFixing: 3 Screws with bushings
Model SIV7-T54AI922 SIV7-T54AI922P
TV System NTSC PAL
LED Quantity 7 Super Power IR LED
IR LED Beam Angle 4pc x 25o/ 3pc x 45o
Filter IR Cut Filter removable for auto iris lens
IR Wave Length 850nm
IR Distance Up to 200~250ft / 60~80m c
IR Light On/Off Photo Diode Sensor Control
Heater Control 18oC / 64oF (on); 28oC / 82oF (off)
Blower Control 35oC / 95oF (on); 25oC / 77oF (off)
IP Rating IP66
Temper Glass Thickness 4mm
Mounting Bracket Full-Cable Management
Construction Die-Cast Aluminum Alloy
Coating Ivory Powder Stove
Required Power Supply /
Transformer * 24V AC (+/-10%), 60VA
Power Consumption 11W
Dimension 8.46”(L) x 4.72”(W) x 4.53”(H); 215mm(L) x 120mm(W) x 115mm(H)
W
eight 4.63 lbs / 2100g (w/out bracket); 7.72 lbs / 3350g (with bracket)
* Power supply / transformer not included
GENERAL SPECIFICATIONS
DIMENSIONS
(
mm
)

R201110-V257
Model SIV7-T54AI922 SIV7-T54AI922P
TV System NTSC PAL
Image Sensor 1/3” Sony Interline Transfer Super HAD CCD
Total Pixels 768(H) x 494(V) 752(H) x 582(V)
Video Output 1.0 Vp-p Composite, 75 ohms (BNC Connector)
Resolution 540 TV Lines
Minimum Illumination 0.1 Lux @ F1.2 (30 IRE, AGC on) 0.001 Lux @ F1.2 (B/W mode, AGC on, Sense-up on)
0 Lux under infrared illumination
Lens 9.0mm~22.0mm Auto Iris Manual Vari-Focal
ED-IR Lens (ED-IR lens avoids focus shift)
Auto Iris Lens Type Accepts DC Servo Iris Lens
Filter Built-in IR Cut Filter (ICR)
Color/Mono Switching Synchronized with IR on/off
Frame Integration 4x Factory Default
IR Accuracy No Focus Shift in Nighttime
S/N Ratio Better than 50dB
Electronic Shutter
Speed 1/60~1/120,000sec 1/50~1/120,000sec
White Balance ATW (2500oK ~ 9200oK) / AWB
Auto Gain Control Auto Gain 36db
Digital Noise
Reduction Auto
Gamma Correction 0.45
Day/Night Control On/Off Switchable
Day/Night OLPF
Switch Delay Time 5~8sec
Sense-up On(4x)/Off Switchable
Power
Consumption 90mA (AE) / 110mA (Auto Iris)
Operation
Temperature -40°C ~ +50°C / -40°F ~ 122°F
cNOTE 1: IR light distances are entirely dependant upon environmental site conditions and the location at which the unit is
situated. The type of camera being used is also very important.
¡NOTE 2: Factory default for the IR LED activation level is 80%. If there is not enough IR light, adjust the VR level to maximum 100%.
Please see #17 in the Part Description section on page 1.
zOne (1) SIV7-T54AI922 or SIV7-T54AI922P Camera with video/power cable
zOne (1) Fully-Cable Managed Bracket
zOne (1) Video Output Cable Wire
zOne (1) Operational Manual
zOne (1) Main Accessories Pack
Three (3) Rust-proof Stainless Steel Wall Screws
Three (3) Rust-proof Stainless Steel Mounting Screws
Three (3) Stainless Steel Washers
Three (3) Plastic Washers
One (1) Allen Wrench
zOne (1) Secondary Accessories Pack
Three (3) Screw-on Connectors
*For any returns, please include all components listed above with original packaging in Resalable Condition. Absolutely No Returns will be
accepted if any component is missing/damaged or if any cable is cut or tampered with.
PACKAGE CONTENTS
CAMERA SPECIFICATIONS

R201110-V258
OKINA USA Products are covered under warranty for one year from the date of purchase. The warranty will
automatically be voided if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any information regarding when and where the
product was purchased. We have no other way to verify the purchase record without the serial number on the camera
sticker; therefore, it should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not described in this manual, the warranty will be
voided immediately. It is the customer’s responsibility to keep the camera in good condition.
3. Video or power cable is cut
The video cable, the power cable, and any other cable should not be tampered with. Cutting or modifying of the
cables will result in termination of the warranty.
1. Read and follow instructions
All operating and user instructions should be read and followed before the unit is to be operated.
2. Secure all screws
Please make sure all rust-proof stainless steel screws are installed securely to ensure a waterproof seal.
3. Electrical connections
Only a qualified electrician should be allowed to make electrical connections.
4. Do not disassemble the product
Do not disassemble the product as it is dangerous and may cause damage to the product. Refer all servicing to
qualified service personnel.
5. Handle the product with care
Be careful when handling the product. Do not drop it or subject it to strong shock or vibrations in order to prevent
any damage to the product. Do not handle the product in a wet environment or when your hands are wet.
6. Do not install the product near electric or magnetic fields
Install the product away from TV sets, radio transmitters, magnets, electric motors, transformers, and audio
speakers, because the magnetic fields generated from the above devices will distort the video image of the product.
7. Cleaning
Use a soft cloth to remove dirt from the unit. Use lens tissue or a cotton tipped applicator with ethanol to clean the
product lens.
8. Never face the product toward the sun directly
Direct sunlight may damage the product.
9. Reducing risk
To reduce risk of fire or electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to
qualified service personnel.
10. Unpacking
Unpack carefully. Electronic components can be damaged if improperly handled or dropped. If an item appears to
have been damaged during shipment, please place it properly in its carton and notify the shipper.
11. Installation notice
Tropical, coastal salt water environment: If you plan to install this product into a tropical, sea, coastal salt water or
corrosive industrial water/mist environment, please seal each stainless screw and fitting with a silicon grease
compound. This will help prevent electrolysis corrosion occurring and extend the lifespan of the product and housing
and prevent premature deterioration.
WARRANTY
IMPORTANT NOTE
