OKUtools EP-12 User manual

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
1
EN
Stud Gun
Automatic Stud Gun EP-12, EP-15, EP-16
Operating instructions
(ID-No. 00035103)
00100264
EP-12
00100265
EP-15

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
2
EN
Table of contents
Table of contents................................................................................................................... 2
1 Preface and general information......................................................................................... 3
1.1 General........................................................................................................................ 3
1.2 Scope of supply........................................................................................................... 3
1.3 Intended use................................................................................................................ 3
1.4 Liability......................................................................................................................... 3
1.5 Warranty...................................................................................................................... 4
2 Safety information .............................................................................................................. 4
2.1 Personnel responsible for safety.................................................................................. 4
2.1.1 Operator................................................................................................................ 4
2.1.2 Qualified personnel................................................................................................ 4
2.2 General safety instructions........................................................................................... 4
2.3 Layout of the safety instructions................................................................................... 5
3 Technical Data ................................................................................................................... 6
3.1 Stud types.................................................................................................................... 6
3.2 Dimensions and weight................................................................................................ 6
3.3 Noise emission ............................................................................................................ 6
3.4 Ambient conditions....................................................................................................... 6
4 Commissioning................................................................................................................... 6
4.1 Pneumatic connection.................................................................................................. 6
5 Operation of the gun........................................................................................................... 7
5.1 Insertion of studs.......................................................................................................... 7
5.2 Faults during insertion.............................................................................................. 7
5.2.1 Studs inserted to deep........................................................................................... 7
5.2.2 Studs jut out off the tire.......................................................................................... 7
6 Faults and troubleshooting ................................................................................................. 8
7 Lubrication and maintenance.............................................................................................. 9
7.1 Lubrication................................................................................................................... 9
7.1.1 Lubricating oil........................................................................................................ 9
7.1.2 Lubricating grease................................................................................................. 9
7.2 Greasing points............................................................................................................ 9
7.3 Maintenance...............................................................................................................10
8 Shutdown and dismounting...............................................................................................10
9 Spear and wear parts........................................................................................................11
9.1 Requirements .............................................................................................................11
9.2 Handling of order ........................................................................................................11
9.3 Explanation of spare parts list.....................................................................................11
9.4 Spare parts-set...........................................................................................................11
9.5 Exploded drawing EP-12, EP-15.................................................................................12
9.6 Spare parts list EP-12, EP-15 .....................................................................................13
10 Appendix.........................................................................................................................15
10.1 CE-Declaration of Conformity....................................................................................15
10.2 Copyright ..................................................................................................................16
10.3 Manufacturer and contact person..............................................................................16

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
3
EN
1 Preface and general information
1.1 General
The operating instructions is used for safe operation of the Stud Guns (in the follow-
ing referred to as “gun“) type Automatic Stud Gun EP-12 and EP-15 (ID-No. 100264,
100265)). The safety instructions included hereinafter must be observed.
The operating instructions must be available for anybody who is working with the gun
and the included instructions must be carefully attended to.
The operating instructions must always be complete and perfectly readable.
1.2 Scope of supply
The delivery normally consists of a stud gun, the operating instruction and 1 separat-
ing finger for multi-flange studs fingers (only EP-8 and EP-9). The parts included in
your delivery are stated in the accompanying papers.
These papers shall be checked for conformity, immediately after receipt of the goods.
OKU Tools GmbH does not provide any guarantee and/or accept any liability for de-
fects complained belatedly. Therefore:
•Contact the forwarder immediately to complain visible transit damages.
•Contact OKU Tools GmbH immediately to complain visible defects and/or incom-
pleteness of delivery.
1.3 Intended use
The gun is intended to be used only for the insertion of single and multi-flange spikes
into tyres of trucks.
Any other use shall be deemed to be inappropriate!
1.4 Liability
The information, data and notes of this operating instruction were up-to-date when
passing for press. The specifications, illustrations and descriptions included hereinaf-
ter do not apply for any previously supplied guns.
We do not accept liability for damages and operating troubles caused by:
•inappropriate use.
•unauthorized modification of gun.
•improper operation of the gun.
•operating errors.
•disregard of this operating instructions.

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
4
EN
1.5 Warranty
Conditions of warranty: see Standard Terms and Conditions of OKU Tools GmbH.
Assert warranty claims against OKU Tools GmbH immediately after detection of the
defect.
Warranty claims expire in each case in which liability claims cannot be made.
2 Safety information
2.1 Personnel responsible for safety
2.1.1 Operator
Operator is called any natural or legal person who is using the gun and/or on behalf of
whom the gun is used.
The operator and/or his safety officer must ensure,
•observance of the relevant regulations, instructions and laws.
•only qualified personnel is working with the gun.
•personnel having the operating instructions available at any time.
•to prohibit non-qualified personnel from working with the gun.
2.1.2 Qualified personnel
As qualified personnel are to be considered persons who were authorised by the
safety officer of the plant to perform the necessary activities and who are able to rec-
ognise and avoid potential hazards because of their education, experience, instruc-
tions and their knowledge about corresponding standards and rules for the prevention
of accidents as well as operating conditions(see IEC 364, definition for qualified per-
sonnel).
2.2 General safety instructions
These safety instructions do not claim to be exhaustive. In case of any questions,
please, contact OKU Tools.
At the time of delivery the gun is state of the art and reliable.
The gun is a source of danger for persons, for the gun itself and for other material as-
sets of the operator, if
•it is operated by unqualified personnel.
•it is used inappropriately.
Operate the gun only when it is in good condition.
Any upgrade, modification or redesign of the gun is basically prohibited. In this case,
please confer with OKU Tools.

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
5
EN
2.3 Layout of the safety instructions
The safety instructions described hereinafter are arranged consistently.
Beware of personal injury
Pictogram
Meaning
Signal words
Notes
Warning for hazardous
electrical voltage
Danger!
Warns of imminent danger.
Consequences of disregarding:
Death or very severe injuries
Warning for general dan-
ger
Warning!
Warns of a potential, very hazardous
situation.
Consequences if disregarded:
Death or very severe injuries
Warning for a general dan-
ger
Caution!
Warns of a potential hazardous situa-
tion.
Consequences if disregarded:
Light or minor injuries
Warning of material damage
Icons used
Meaning
Signal words
Notes
Warning of material dam-
age
Stop!
Warns of potential material damage.
Consequences if disregarded:
Ambient damage or damage of the
gun.
Other information
Icons used
Meaning
Signal words
Notes
General note
Note!
Designates a general, useful note.
Adherence hereof will ease the use of
the gun.

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
6
EN
3 Technical Data
3.1 Stud types
The gun can be used for the insertion of single-flange and multi-flange studs into car
tires. Factory setting is for the insertion of single-flange studs.
Type
ID.-No.
Stud sizes
EP-12
00100264
Ø12, 15-25 mm length
EP-15
00100265
Ø15, 18-25 mm length
3.2 Dimensions and weight
The following values are valid for the gun without any accessories and can differ ac-
cording to the respective extra equipment.
Length
ca. 310 mm
Width
ca. 70 mm
Height
ca. 182 mm
Weight
ca. 2,6 kg
3.3 Noise emission
The sound pressure level at the work station of the operator can reach up to 83
dB(A). Provide suitable ear protection for the operator.
3.4 Ambient conditions
Use the gun only in closed and dry rooms.
The permissible ambient temperature during operation is from 10 °C to 40 °C.
4 Commissioning
Precautions to be taken before start working with the gun
•Check gun for proper condition.
•Do never operate a damaged gun.
4.1 Pneumatic connection
The pneumatic connection is to be made by qualified per-
sonnel with extensive knowledge in handling of pneumatic
systems.

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
7
EN
Screw provided coupling (1) onto the hand grip. Plug compressed air hose into
coupling. The gun requires compressed air with approx. 7-8 bar working pres-
sure. The maximum operating pressure amounts to 10 bar.
5 Operation of the gun
5.1 Insertion of studs
Without feeding unit: fill the feeding pipe (13) with approx. 10 studs (flange leading).
With feeding unit: connect the gun with the feeding hose of the studs until feeding
pipe (13) is filled with studs (flange leading).
Moisten tire with low surface tension water. To get this, mix normal tap water with
some drops of usual dish liquid.
Use only less dish liquid to avoid that the inserted stud is pulled out
again when extracting the gun.
Insert spreader fingers (34) into one of the moistened tyre holes. Operate the trigger
(17) and keep it pressed. The stud is pressed into the tire. Release trigger; the gun is
now loosen from the tire and the stud is inserted.
Put some pressure onto the gun when inserting the studs. With some
practice and skill you’ll soon find the respective pressure which shall
be applied to reach a steady result.
5.2 Faults during insertion
5.2.1 Studs inserted to deep
Reduce the pressure applied on the gun during insertion.
5.2.2 Studs jut out off the tire
Put more pressure onto the gun when inserting the studs.
Coupling (1) for com-
pressed air connection

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
8
EN
6 Faults and troubleshooting
When unscrewing the intermediate piece (21), it must be
held tight, because of the strong compression spring which
is in the gun. If not, it can be ejected and pose great danger.
No.
Cause
Trouble shooting
6.1
Deformed or dirty stud jammed in feeding
pipe (13) or gun head.
Unscrew union nut (33) and take the head
(25) off the gun. Now remove the jammed
stud.
6.2
Stud in feeding pipe (13) in wrong position
(with shank leading)
Remove feeding tube and shake out stud
6.3
Trigger (17) get caught
Remove O-Ring (19) and dowel pin (18) and
then trigger (17). Clean and lubricate trigger
slightly with oil.
Check if compression spring (3) broken, if so
replace compression spring.
6.4
Worn spreader fingers (34)
Unscrew union nut (33) and take the head
(25) off the gun. Remove O-Ring (31) and
replace spreader finger (34)
6.5
Worn push rod (22)
Unscrew union nut (33) and take the head
(25) off the gun. Unscrew both hexagon
head cap screws (16) (Caution!), press
intermediate piece (21) against hand grip
(back-pressure of inner springs). Remove
intermediate part and circlip (15). Extract
push rod (22) together with the springs (10,
11), retaining ring (14) piston disk (6) lip seal
(7) and bushing (23). Unscrew hexagon nut
(8) and replace worn push rod. Assemble
the gun in reversed order and replace hexa-
gon nut if necessary.
6.6
Worn centring finger (32)
Unscrew union nut (33) and take the head
(25) off the gun. Remove O-Ring (31) and
replace centring finger (32).
6.7
Worn separating pin (27)
Unscrew union nut (33) and take the head
(25) off the gun. Remove separating flap
(26) from dowel pin (29). The compression
spring (28) may not jump out. The separat-
ing pin (27) is riveted with the separating flap
(26). Grind off closing head and drive off
separating pin with a drift punch. Replace
and rivet separating pin. Assemble the gun
in reversed order.

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
9
EN
7 Lubrication and maintenance
7.1 Lubrication
Observe the effective directions for the use and safety of the applied
lubricants!
7.1.1 Lubricating oil
Distinguishing
mark acc. to
DIN 51502
Designation
ISO-Viscosity
Index
DIN 51519
Manufacturer
AN 22
Normal lubri-
cating oil
ISO VG 22
AVIA (AVILUB RS 22)
BP (BP Energol CS 22)
ESSO (Coray 22)
SHELL (SHELL Carnea Oel 22)
7.1.2 Lubricating grease
Designation
acc. to
DIN 51825
Designation
Consistency
Index
NLGI Class as per
DIN 51818
Worked pene-
tration as per
DIN ISO 2137
Manufacturer
KP2K-20
Lubricating
grease for
bearing
NLGI-2
265-295
AVIA (AVIALITH 2)
BP (Energrease L2)
ESSO (Beacon 2)
KLÜBER (CENTOPLEX 2 EP)
MOBIL (Mobilux 2)
SHELL (Alvania R 2)
7.2 Greasing points
The following points of the gun need to be greased regularly. You will find a mainte-
nance-set including grease and corrosion preventive-oil-spray in the spare parts list in
chapter 9.6.
To grease the gun it must be partially dismounted (see hereto chapter 6 “Faults and
trouble shooting”. We recommend taking the opportunity and greasing the gun when
replacing the wear parts.
No.
Designation
Service to be
done
Consumables
Measured values
Frequency
Notes
1
Trigger
Lubricate with
oil
Lubricating oil
DIN 51501-L-AN 22
quarterly
Oil trigger slightly
2
Piston disk
Lip seal
Lubricate with
grease
Lubricating grease
DIN 51825-KP2K-20
yearly
Grease piston surface
slightly
3
Separating
flap
Lubricate with
grease
Lubricating grease
DIN 51825-KP2K-20
quarterly
Grease dowel pin and
frontal contact surface
of head gun slightly

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
10
EN
7.3 Maintenance
We are working with water to insert the studs, therefore the head of the gun shall be
sprayed regularly with anticorrosive material to avoid corrosion and extend lifetime of
the gun.
8 Shutdown and dismounting
OKU Tools takes back your gun. We recommend you have OKU Tools professionally
dismantle the gun and dispose of it.
Be part of the environmental protection by recycling valuable materials.
What?
Where?
Transport material
Pallets
Return to the manufacturer or forwarder
Packing material
Cardboard boxes to waste paper
plastic to plastic recycling or waste material
reuse wood-wool or waste material
Lubricants
Oil, grease
Dispose according to the valid regulations
Components
Used materials:
aluminium
aluminium cast
grey cast iron
steel
brass
plastic
Separate valuable substances and dispose
1
2
3

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
11
EN
9 Spear and wear parts
9.1 Requirements
Spare and wear parts must be in accordance with the technical re-
quirements stipulated by the manufacturer.
9.2 Handling of order
To ensure punctual handling of orders, please state always the OKU-ID.-No. of the
spare part you need when ordering. You’ll find the OKU-Id.-No. on the drawing of the
gun and the spare parts list.
9.3 Explanation of spare parts list
The numbers on the exploded drawing correspond to the item numbers of the spare
parts list.
9.4 Spare parts-set
To the gun there is available a spare parts-set including the most important wear
parts. It contains all in the spare parts list with marked parts inclusive grease and
corrosion preventive-oil-spray.
OKU-Id.-No. spare parts-set EP-12: 20015508
OKU-Id.-No. spare parts-set EP-15: 20015509

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
12
EN
9.5 Exploded drawing EP-12, EP-15

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
13
EN
9.6 Spare parts list EP-12, EP-15
Item
OKU part No.
Qty
Designation
1
00031539
1
Coupling
2
00003463
1
O-Ring
3
00350297
1
Compression spring
4
00350728
1
Bushing
5
00470942
1
Hand grip
6
00350664
1
Piston disk
7
00003507
1
Lip seal
8
00004082
1
Hexagon nut M8
9
00000613
1
Eyebolt
10
00000627
1
Hexagon nut M6
11
00350670
1
Compression spring,
inner
12
00350669
1
Compression spring,
outer
13
00350659
1
Feeding pipe 12
00350660
1
Feeding pipe 15
14
00350666
1
Retaining ring
15
00000796
1
Circlip
16
00004099
2
Hexagon socket head
cup screw
17
00470092
1
Trigger
18
00000536
1
Dowel pin
19
00003464
1
O-Ring 
20
00003404
1
O-Ring
21
00470238
1
Intermediate piece
22
00250053
1
Push rod 12 
00250049
1
Push rod 15 
23
00350710
1
Sleeve
24
00000300
1
Set screw
25
00470221
1
Gun head EP-12
00470222
1
Gun head EP-15
26
00350991
1
Separating flap
27
00403148
1
Separating pin
28
00350665
1
Compression spring
29
00350806
1
Dowel pin
30
00004083
1
Spring dowel pin
31
00003467
1
O-ring 
32
00353731
3
Centering finger 
33
00350923
1
Union nut

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
14
EN
Item
OKU part No.
Qty
Designation
34
00470946
3
Spreader finger for
truck 
00885027
1
corrosion preventive-oil, aerosol can 100 ml (single) 
00885028
1
grease, tube 20 g (single) 
20015510
1
1 aerosol can corrosion preventive-oil (100 ml) and
1 tube grease (20 g) as maintenance-set
= included in the spare parts-set

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
15
EN
10 Appendix
10.1 CE-Declaration of Conformity
(CE Machine Directive 2006/42/EC, Appendix II A)
The manufacturer: OKU Tools GmbH
Rosenstraße 15
73650 WINTERBACH, GERMANY
herewith declares that the machine
designation: Studding gun models:
AS-8, AS-9, EP-8, EP-9, EP-10, EP-12, EP-15, EPK-6,5, EPK-8
as delivered complies all the relevant regulations of the CE Machine Directive 2006/42/EC.
Harmonized standards applied:
EN ISO 12100 Safety of machinery –General principles for design
–Risk assessment and risk reduction
Stuttgart, 01.03.2019
OKU Tools GmbH
Karin Klingel
Geschäftsführer

English Stud Gun EP-12, EP-15
OKU Tools GmbH, 70374 Stuttgart, Germany
16
EN
10.2 Copyright
© 03/2019
This documentation is protected by copyright which covers the exclusive rights to re-
produce and distribute the documentation, as well as all translation rights. No material
published in this documentation may reproduce photographically or stored on micro-
film, in electronic data bases, video disks, etc. Technical modifications reserved.
10.3 Manufacturer and contact person
OKU Tools GmbH
Sommestrasse 6
70374 Stuttgart
Telefon: [phone]
Telefax: [phone]
Internet: www.okutools.com
Ihr Ansprechpartner ist:
Karin Klingel
Abteilung Verkauf Spikes
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]m
