Lathe
Model 2019
Owner’s Manual
For Models Manufactured Since 05/2023
Oliver Machinery
1-800-559-5065
921 Thomas Ave SW
Renton, WA 98057
[e-mail]
WWW.OLIVERMACHINERY.NET
For Stock Number:
2019.001
Manual Version: 1.0.0

READ AND UNDERSTAND ALL INSTRUCTIONS IN THIS MANUAL BEFORE
ATTEMPTING TO ASSEMBLE OR OPERATE THE MACHINE.
FOLLOW THE INSTRUCTIONS AND THINK SAFETY!
THE OWNER OF THIS MACHINE IS SOLELY RESPONSIBLE FOR THE SAFETY OF ANYONE USING
THIS MACHINE. SUCH RESPONSIBILITIES INCLUDE BUT ARE NOT LIMITED TO:
•PROPER ASSEMBLY, OPERATION, INSPECTION, MAINTENANCE, AND RELOCATION OF
THE MACHINE.
•PROPER TRAINING FOR THE OPERATORS AND ENSURES THIS MANUAL IS AVAILABLE
AT ALL TIMES.
•USAGE AUTHORIZATION.
•USAGE OF SAFETY AND PROTECTION DEVICES.
OLIVER MACHINERY DISCLAIMS ANY LIABILITY FOR MACHINES THAT HAVE BEEN ALTERED OR
ABUSED. OLIVER MACHINERY RESERVES THE RIGHT TO EFFECT AT ANY TIME, WITHOUT PRIOR
NOTICE, THOSE ALTERATIONS TO PARTS, FITTINGS, AND ACCESSORY EQUIPMENT WHICH THEY
MAY DEEM NECESSARY FOR ANY REASON WHATSOEVER.
** SAVE THIS MANUAL FOR FUTURE REFERENCE. **
PROP 65 NOTICE
WARNING: Drilling, sawing, sanding, or machining wood products can expose you to wood dust
and/or other chemicals that are known to the State of California to cause cancer, birth defects,
or other reproductive harm.
Some examples of these chemicals are:
•Lead from lead-based paints.
•Crystalline silica from bricks, cement, and other masonry products.
•Arsenic and chromium from chemically treated lumber.
Avoid inhaling wood dust and other harmful chemicals. Use a dust mask and/or other safety
devices for personal protection.
For more information, visit http://www.P65Warnings.ca.gov/wood

Table of Contents
Introduction ..................................................5
Specifications.................................................6
Identification .................................................9
Safety..........................................................10
General Safety Guidelines............................10
Safety Guidelines Specific to Woodturning .11
Electricals ....................................................13
Minimum Circuit Size Required for Model
2019 Lathe ...................................................13
Grounding ....................................................13
Electrical Wiring...........................................13
Setup...........................................................14
Shop Preparation .........................................14
Receiving......................................................15
Cleaning .......................................................17
Assembly ......................................................18
Unloading the Lathe ................................18
Install Auxiliary Power Switch..................18
Dust Collection System Usage .....................19
Accessories..................................................20
Controls and Components ............................21
Main Control Panel ......................................21
Auxiliary Power Switch ................................22
Indexer and Spindle Lock .............................22
Extension Bed ..............................................23
Test Run .......................................................24
Wood 101....................................................25
Why do we have this section? .....................25
Structure of Wood .......................................25
Different Types of Wood Grain....................25
Wood Defects ..............................................25
Check and Shake......................................25
Bug Infestation.........................................26
Spalted/Rotted Wood..............................26
Bark Inclusion...........................................26
Knotty Wood............................................26
Operation....................................................27
Before Turning .............................................27
Material Selection....................................27
Workpiece Inspection ..............................27
Setting Spindle Speed Range ...................28
Basic Spindle Turning Setup Steps ...............29
Basic Face Grain Turning Setup Steps ..........31
Basic Outboard Turning Setup Steps............33
Other Techniques and Procedures...............34
Filling Cracks and Gaps.............................34
Sanding.....................................................34
Common Woodturning Errors......................35
Tearouts and Chipping .............................35
Warp and Cracks ......................................35
Fuzzy Grain ...............................................35
Tool Marks................................................36
Catch ........................................................36
Using Wrong Cutting Tools ......................36
Maintenance ...............................................37
Maintenance Schedule.................................37
Cleaning & Lubrication.................................38
Tool Rest...................................................38
Bedways & Underside of Tailstock/Banjo38
Tailstock & Banjo Cam Lock Adjustment......39
Troubleshooting...........................................40
Wiring Diagram............................................42
Parts List......................................................43
Headstock, Bed, and Tailstock .....................43
Motor and Lathe Stand ................................44
Banjo (Sold Separately) ................................45
Maintenance Record....................................52
Notes...........................................................53
Warranty and Service...................................54
Appendix.....................................................55
Suggested Lathe Speed Limits for Turning...55
Useful Links ..................................................55
Tool Sharpening: ......................................55
List of Woodturning Clubs, Craft Schools,
and Symposiums: .....................................55

2019 Lathe OLIVERMACHINERY.NET 5|Page
Introduction
Thank you for choosing Oliver! This manual contains important information on how to set up, operate,
and maintain this machine safely. Please take the time to read this manual and ensure you understand all
the instructions.
While this manual may provide tips on optimizing the result of your workpiece, the manual is not a
substitute for formal woodworking training. Please consult qualified training resources if you need to
know how to complete a woodworking task safely.
We made every effort to keep this manual up to date. Instructions, specifications, drawings, and
photographs in this manual should match the machine delivered. If you find any discrepancies or anything
that seems confusing in this manual, or if some instructions are not available, please check our website
for an updated version:
WWW.OLIVERMACHINERY.NET/MANUALS
Alternatively, you can contact our technical support for help:
1-800-559-5065
Before calling, please note down the production date and the machine’s
serial number on the nameplate located on the cabinet behind the tools rack.
This information is needed to provide proper technical support and to
determine if an updated manual is available for your machine.
Please let us know how well this manual serves you. If you have any
suggestions, please call the number above or email us at:
[email protected]
We love to hear from our customers and make improvements.

6 | Page Oliver Machinery 2019 Lathe
Specifications
Quick View
Model
2019 Lathe
Stock Number
2019.001
Swing Over Bed
18”
Outboard Swing
35-1/2”
Distance Between Centers with
Extension Bed Installed
41”
Index Positions
36
Motor Horsepower
2 HP
Input Power
230V, 1Ph, 15A
Dimensions
61-3/4" (L) x 19-1/2" (D) x 49-1/4" (H)
Footprint
46-1/2"(L) x 16-1/4" (D)
Fully Assembled Weight
415 lbs.
Warranty
1 Year (Motor and electronics)
2 Years (All other parts)
Shipment Info
Package 1
Lathe and accessories
Type
Wood crate with pallet
Dimensions
52" (L) x 29-3/4" (D) x 54" (H)
Weight
520 lbs.
Package 2
Outboard turning banjo (sold separately)
Type
Wood crate
Dimensions
26-3/4” (L) x 19-1/4” (D) x 9-3/4” (H)
Weight
57 lbs.
Product Dimensions
Dimensions
61-3/4" (L) x 19-1/2" (D) x 49-1/4" (H)
(With extension bed installed)
46-1/2” (L) x 19-1/2” (D) x 49-1/4” (H)
(Without extension bed)
Footprint
46-1/2" (L) x 16-1/4" (D)
Fully Assembled Weight
415 lbs.

2019 Lathe OLIVERMACHINERY.NET 7|Page
Electricals
Input Power
230V, 1Ph, 60Hz
Full Load Current Rating
15A
Recommended Circuit Size
20A
Power Switch Type
Button Switch
Plug Type
NEMA 6-20
Cord Length & Type
6-1/2’ SJT 12AWG Power cord
Variable Frequency Drive Type
Delta ME300
Variable Frequency Drive Size
2.2kW / 3HP Output
Motor
Motor Type
Three-phase variable speed TEFC induction motor
Horsepower
2 HP
Max Speed
3450 RPM
Efficiency
81.7%
Power Factor
80%
Power Transfer Mechanism
Poly-V belt and pulleys
Bearing type
Permanently sealed ball bearing
Lathe Capacity
Swing Over Bed
18”
Swing Over Banjo Base
14”
Outboard Swing
35-1/2”
Distance Between Centers
-Without Extension Bed
-With Extension Bed
26”
41”
Headstock and Spindle
Spindle Taper
MT #2
Spindle Speed Range
50-950 (Low range)
170-3200 (High range)
Spindle Speed Indicator
LCD
Spindle Direction
Forward / Reverse
Floor to Spindle Center Height
41-1/2”
Inboard Spindle Thread Size
1-1/4 x 8 TPI
Inboard Spindle Thread Direction
Right Hand
Outboard Spindle Thread Size
1-1/4 x 8 TPI
Outboard Spindle Thread Direction
Right hand
Drive Spindle Through Hole Size
5/8”
Spindle Bearings Type
Permanently sealed bearings
Index Positions
36

8 | Page Oliver Machinery 2019 Lathe
Tailstock
Tailstock Taper
MT #2
Tailstock Quill Travel
4-3/8”
Tailstock Quill Through Hole Size
3/8”
Tailstock Quill Thread
ACME 2920-8teeth/INCH (Left-handed)
Lathe Bed
Main Bed Length
33-7/8”
Extension Bed Length
15”
Bed Gap Size
1-3/4”
Tool Rest and Banjo
Include Tool Rest Type
Cast Iron
Tool Rest Width
12”
Tool Rest Post Diameter
1”
Tool Rest Post Length
2-3/8”
Banjo Usable Length
11-3/4”
Banjo Base Height
2”
Banjo Overall Height
5-3/4”
Outboard Banjo Usable Length
16-3/4”
Outboard Banjo Base Height
3”
Outboard Banjo Overall Height
14-1/2”
Accessories
Spindle Center
Four-Prong Spur Center
Tailstock Center
Live Center
Faceplate
Two 6” Steel Faceplates
Safety
Sound Rating
74 dB (2’Distance and Max RPM)
Others
Serial Number Location
On the lathe cabinet behind the tool rack.
Country of Origin
Taiwan

2019 Lathe OLIVERMACHINERY.NET 9|Page
Identification

10 | Page Oliver Machinery 2019 Lathe
Safety
Oliver Machinery has made every attempt to provide a safe, reliable, easy-to-use piece of machinery.
Safety, however, is ultimately depending on the individual machine operator. Before operating this
machine, please become familiar with the following safety labels and guidelines.
DANGER
This indicates an imminently hazardous situation that must avoid, or it WILL cause
death or severe injury.
WARNING
This means if the warning is not taken seriously, it CAN cause death or severe injury.
CAUTION
This means if the precaution is not taken, it MAY cause injury.
IMPORTANT
This is a tip for properly operating the machine to avoid machine damage.
General Safety Guidelines
1. FAMILIARIZE yourself with all safety instructions found in this manual. Know the limitations and
hazards associated with this machine. Do not operate or service this machine until you are properly
trained.
2. ELECTRICAL GROUNDING, when done correctly, reduces the risk of electrocution, shocks, and fire.
Make certain that the machine frame is electrically grounded and that a ground lead is included in the
incoming electrical service. In cases where a cord and a plug are used, ensure that the grounding plug
connects to a suitable ground. Follow the grounding procedure indicated in the electrical code of your
area.
3. DISCONNECT the machine from power before performing any service, maintenance, or adjustments.
A machine under repair should be RED TAGGED to show it should not be used until the repair is
complete.
4. GUARDS: Keep machine guards in place for all applicable operations. If any guards are removed for
maintenance, DO NOT OPERATE the machine until all guards are reinstalled. Check clearance between
the guards and the cutter before starting the machine.
5. ACCESS DOORS/PANELS: If a machine is equipped with access doors and panels for maintenance and
service purposes, the access doors and panels must be closed before starting the machine.
6. WORKPLACE SAFETY: Keep the floor around the machine clean. Scrap material, sawdust, oil, and
other liquids increase the risk of tripping or slipping. Be sure to clean up the table before starting the
machine. Ensure the work area is well-lighted, and a proper exhaust system is used to minimize dust.
Use anti-skid floor strips on the floor area where the operator typically stands and mark off the
machine work area. Provide adequate workspace around the machine.
7. REPLACEMENT PARTS: Use only genuine Oliver Machinery replacement parts and accessories
recommended for this machine. Generic parts made by other manufacturers may create a safety
hazard and WILL void the factory warranty and other guarantees.
8. PROPER USE: Do not use this machine for anything other than its intended use. If used for other
purposes, Oliver Machinery disclaims any real or implied warranty and holds itself harmless for any
injury or damage which may result from that use.

2019 Lathe OLIVERMACHINERY.NET 11 |Page
Safety Guidelines Specific to Woodturning
Preparation Guidelines
1. USE EYE AND HEAD PROTECTION: Always wear a safety face shield and goggles that comply with ANSI
Z87.1 and CSA Z94.3 standards. Common eyeglasses are not safety glasses and may not provide
adequate protection.
2. REDUCE DUST EXPOSURE. Always wear a dust mask when turning wood. If a dust collection system is
available, place a dust hood close to the workpiece to extract the dust produced.
3. USE HEARING PROTECTION. Wear noise-reduction earplugs or earmuffs when the noise level in the
work area exceeds the level of exposure allowed in Section 1910.95 of the OSHA Regulations. When
in doubt, use the ear production device.
4. OTHER PERSONAL PROTECTION ADVISORIES: Before starting the lathe, remove tie, rings, watch, and
other jewelry. Roll up sleeves above elbows. Remove all loose clothing and confine long hair.
Protective footwear should be used. Do not wear gloves unless it is instructed to perform specific
steps in the manual.
5. ONLY USE MATERIALS THAT CAN TURN SAFELY ON A WOOD LATHE. Avoid turning blanks that can
disintegrate during operation. Avoid blanks with cracks or loose parts that can break up or cause a
catch while turning. Do not turn treated lumber or anything that contains harmful chemicals. This
wood lathe operates at a higher speed than a typical metal lathe, and it is not suitable for turning or
spinning metals.
6. Glued Up TURNING. Use high-quality adhesive to attach segmented/laminated pieces. Make certain
that the adhesive is completely cured before turning. A workpiece containing any decorating materials
weaker than the wood itself can significantly impact the structural integrity of the workpiece.
7. USE PROPER LIFTING METHODS. For mounting heavy blanks, use proper lifting techniques and
machinery to lift them and securely mount them on the lathe.
8. REMOVE LARGE ROUGH EDGES AND CORNERS. Before roughing a large workpiece, remove the
corners along the length of the blank.
9. SECURE ALL PARTS. Secure the workpiece, tool rest, banjo, tailstock, chuck, faceplate, drive/live
centers, extension bed, and other parts that may come loose while turning. Failure to do so may cause
the workpiece to dislodge at high speed or a severe catch.
10. FACEPLATE. The faceplate must be at least 1/3 of the diameter of the workpiece. Use strong, epoxy-
coated fasteners for a secure mount and easy removal. Predrill the mounting holes for hardwood to
avoid breaking the fastener and destroying the workpiece.
11. ADJUST TOOL REST. Adjust the tool rest so that the cutting tool can be safely presented to the
workpiece without excessive overhanging. At the same time, the tool rest must stay far enough from
the workpiece, so the tool is not only supported by its bevel. Before starting the motor, rotate the
blank for one full resolution to ensure the tool rest is not impeding the rotation of the blank.
12. REMOVE ADJUSTMENT TOOLS: Remove the tools for setting up the workpiece for turning. Chuck keys,
wrenches, and other tools for setting the workpiece must be removed before starting the lathe.
13. CHECK CLEARANCE: Hand rotate the mounted workpiece on the lathe for at least one full revolution
to ensure it does not catch on any parts of that lathe.

12 | Page Oliver Machinery 2019 Lathe
Operation Guidelines
1. STAY ALERT at all times. Do not operate this machine while under the influence of drugs/alcohol or
when not feeling well.
2. ALWAYS START WITH THE LOWEST SPEED AND CORRECT ROTATION DIRECTION. Before starting the
lathe, set the speed to the lowest and check the rotation direction.
3. SET PROPER SPEED. Stand on the side of the lathe and gradually increase speed to the desired
operating speed. Begin work only when the workpiece is spinning on the lathe without excessive
vibration. Use low speed for roughing. Also, use low speed when turning large, heavy, or irregular-
shaped workpieces.
4. USE CORRECT TOOLS. Never use tools that are not designed for specific type of turning. For instance,
using a spindle roughing gouge for bowl turning.
5. PROPERLY PRESENT TOOL TO WORKPIECE. Gouges, skews, scrapers, and other tools require different
techniques to operate. To avoid severe catches and injuries, please read the user manual of the
turning tools and consult accredited training resources to use the tool properly.
6. ROUGHING. Use low speed and take light cuts to remove the rough edges and corners of a workpiece.
Support the tool firmly and keep the tool close to the center of the tool rest.
7. KEEP TOOLS SHARP. Turning tools can become dull quickly after minutes of use. Make sure the tools
are resharpened frequently. Sharp tools can cut with less resistance, reducing the risk of catching and
breaking the workpiece.
8. MEASURE THE WORKPIECE SAFELY. Do not measure the diameter, thickness, or depth of a workpiece
while it is spinning on the lathe. The measurement tool can catch the workpiece and get pulled from
the woodturner’s hand.
9. MEASURE WORKPIECE THICKNESS FREQUENTLY. Pay attention to the change of thickness of the
workpiece when turning. Turning a workpiece too thin can cause it to disintegrate and eject from the
lathe.
10. SANDING AND POLISHING. To reduce the risk of entanglement, avoid using a large piece of sandpaper
that can wrap around the workpiece. Do not reach inside deep cavities of a workpiece with a bare
hand for sanding.
11. DUST COLLECTION SYSTEM is recommended. Install a screen in front of the dust port to avoid large
pieces of debris entering the dust collection system and jamming it.
12. DEBRIS REMOVAL. When debris is stuck on or inside a workpiece, turn off the lathe and wait for the
workpiece to come to a complete stop, then remove the debris with compressed air or a brush.
13. STOP THE LATHE when leaving the lathe unattended for any reason. Always set the speed to the
lowest before pressing the stop button. Doing so prevents the lathe from starting at an unexpected
speed in the future. Wait until the machine comes to a complete stop before leaving the machine.
Never attempt to stop the lathe by hand or using another object.
After Operation
1. CLEAN UP the work area at least once a day after turning. Woodturning creates a lot of loose chips
and debris. Removing the debris reduces the risk of fire, pest infestation, and rusting of tools.
2. LOCK UP. Unplug the lathe and lock the workshop to prevent children and unexpected guests from
accidentally starting the lathe.

2019 Lathe OLIVERMACHINERY.NET 13 |Page
Electricals
WARNING
Faulty electrical work can cause electrocution and is a fire hazard.
All electrical work must be completed by a licensed electrician and must meet
the local electrical code in your area, or the warranty is void.
Minimum Circuit Size Required for Model 2019 Lathe
Stock Number
Operation Voltage
Minimum Circuit Size Required
2019.001
230V
20A
Please ensure the electrical circuit for this machine meets the minimum circuit size requirement. The
minimum circuit size requirement applies to a dedicated circuit that provides power to one 2019 Lathe. If
more machines share the same circuit, consult a licensed electrician to ensure the designated circuit is
correctly sized for safe operation.
If a circuit is available but not meeting the minimum circuit size requirement, a new circuit must be
installed for this machine.
Grounding
WARNING
Improper grounding can cause electric shock, fire, and equipment damage.
Proper grounding reduces the risk to the operator in the event of electrical malfunction or breakdown.
This machine must connect to a grounding conductor, and all grounding connections must meet or exceed
the electrical code requirements in your area. Furthermore, all grounds must be verified and meet or
exceed the electrical requirement of the machine. If grounding is unavailable, consider using a GFCI
protection device as an alternative if this complies with the electric code in your area. When in doubt,
consult a licensed electrician in your area.
Electrical Wiring
This machine is wired for 230V with a cord and a NEMA 6-20 plug. Avoid using an extension by placing the
machine near the power outlet. If you need an extension cord to connect to a power source, select a
durable cord type with high-temperature rating (90C° or above). Use the minimum amount of extension
cord as needed.
Minimum cord size (AWG) required based on amperage draw and length of the cord:
Amps
Power Cord Length
25 feet
50 feet
75 feet
100 feet
> 100 feet
15 to 20
10
10
10
NR
NR
*NR: Not Recommended
WARNING
Use properly sized wires that meet or exceed the power requirement of your
machine. Using undersized wires may cause overheating and increase the risk of
fire and machine damage.

14 | Page Oliver Machinery 2019 Lathe
Setup
Shop Preparation
Space Requirement
The dimensions of this machine are 61-3/4" (L) x 19-1/2"
(D). You need additional space for manipulating your
workpiece and accessing the back of the lathe.
Load Limits
This machine has a shipping weight of 520 lbs. and a net
weight of 415 lbs. The optional outboard turning banjo adds
additional weight. Please ensure all lifting tools and building
structures have adequate load capacity for transporting and
supporting the total weight of this machine, the operator,
and related items.
Electricals
Ensure a properly sized circuit and an electrical terminal are available near the machine. If the machine is
to be hardwired, there must be a readily accessible power disconnect nearby so that the machine can be
disconnected from the power source for service and adjustments. If the machine is to be connected with
a cord and a plug, please ensure a matching outlet is installed near the machine.
Please refer to the “Electricals”section in this manual for details regarding electrical requirements.
Lighting
Operate this machine with adequate overhead non-glare lighting. Use supplemental lighting to illuminate
portions of the workpiece not reachable by overhead lighting.
Safety Labels
If this machine introduces new safety hazards to your workplace, display proper warning signs in highly
visible locations.
Dust Exposure Reduction
Turning and sanding wood on a lathe can produce a lot of wood dust and shavings. Wood dust created by
this lathe is a health hazard. Use a dust collection system to reduce wood dust entering the environment.
Adding a screen on the dust hood can prevent large shavings from entering and jamming the dust
collection system. Check air suction regularly to ensure the dust collection system is working effectively.
Dust masks should be available for using the lathe.
Humidity Control
If the machine is to be placed in a high-humidity area, install a dehumidifier to keep the humidity low.
Unpainted parts of machines can rust and bind with other parts in a high-humidity environment. Having
a humidity control workspace also prevents wood from getting mold, rot, and bug infestation.

2019 Lathe OLIVERMACHINERY.NET 15 |Page
Receiving
Your shipment should come with one wood crate. The outboard turning banjo that is sold separately is
shipped in a separate package. Upon receiving your shipment, check for significant damages before
signing the delivery confirmation.
IMPORTANT
If items are damaged, please call us immediately at 1-800-559-5065
CAUTION
You may need to remove the straps on your package. The straps may spring back
violently when released and cause injury. Always wear safety goggles and gloves
when removing the straps.
Moving the Shipment into the Shop
Your machine will be delivered by freight service, and it will be left outside of your workshop by default.
On the day of delivery, please be sure help is available to move the machine to its final location.
WARNING
This lathe has a gross weight of 520 lbs. and a net weight of 415 lbs. Safe moving
techniques and proper lifting equipment are required, or serious personal injury
may occur.
WARNING
Your shipment may be secured by the straps. Do not lift your shipment by the strap.
They are not designed to hold the total weight of your shipment. They may snap
without warning and cause severe injury and machine damage.
Unboxing
The crate contains a mostly assembled lathe and three paper boxes
with loose parts and accessories.

16 | Page Oliver Machinery 2019 Lathe
Inventory
Carefully unwrap the packaging and ensure all components are included in the shipment. Put items in
groups for the final assembly.
Group 1: Auxiliary Switch
Item
Description
QTY
1
Aux. Power Switch
1
2
Socket Head Cap Screws and
Washers
2
3
6mm Hex Wrench
1
Note: Please keep the switch in the box so it is
protected when unloading the lathe from the
pallet.
Group 2: Extension Bed
Item
Description
QTY
4
Extension Bed
1
5
Socket Head Cap Screws
4
6
Flat Washer
4
7
Spring Washer
4
8
8mm Hex Wrench
1
Group 3: Accessories
Item
Description
QTY
9
Live Center
1
10
Spur Center
1
11
Knockout Rod
1
12
Faceplate Wrench
1
13
3mm Hex Wrench
1

2019 Lathe OLIVERMACHINERY.NET 17 |Page
Group 5: Outboard Turning Banjo (Optional)
Item
Description
QTY
14
Clamping Lever
1
15
Outboard Turning Banjo
1
NOTICE: If you cannot find an item in the list
above, please check if it is still attached to the
packaging or inside the cabinet. Occasionally, the
item may have been pre-installed at the factory.
Please refer to the parts list section in this
manual to ensure you have all the components
to set up this machine.
NOTICE: This machine comes with various
standard-sized, non-proprietary parts. If any of
these parts are missing, we are happy to deliver
them to you. To have the machine up and
running as soon as possible, you can also find
these parts at your local hardware store.
Additional Items Recommended for Assembly
Item
Purpose
Safety Glasses
Protection
Disposable Gloves
Cleaning
Paper Towel / Rags
Cleaning
Rust Inhibitor
Rust protection.
Lifting Straps / Crane
Lathe installation.
Cleaning
The cast iron lathe beds are covered with
machine oil and plastic film to prevent rusting.
Remove the plastic film, then wipe off the
machine oil with paper towels or rags.
After cleaning, routinely apply rust preventive
such as Boeshield® T-9 or paste wax. Do not use
rust preventives that contain silicone, which is
known to interfere with certain wood finishes
and glues.

18 | Page Oliver Machinery 2019 Lathe
Assembly
This lathe is mostly assembled in the factory. When all items are ready for the final assembly, lift the lathe
from the pallet. A few more items are to be set up before the machine is ready for a test run.
It takes approximately 45 minutes to clean and set up the lathe.
Unloading the Lathe
1. This lathe weighs 415 lbs. and requires
several people and proper gear to set up.
2. The lathe can be lifted with a crane and
lifting straps. To make the lathe less top-
heavy and easier to lift, remove the tailstock
and banjo, then install the extension bed
(see page 23 for details).
3. Wrap the lifting straps under the main lathe
bed and the extension bed, and slowly lift
the lathe from overhead. The lathe is much
heavier on the headstock side. Adjust the
straps to ensure the lathe is balanced when
lifted.
Note: The auxiliary switch is packed in a box
and is attached to the lathe with a cord.
Secure the box when lifting the lathe.
4. Lower the lathe gently to the floor to
prevent damage.
5. To minimize vibration while turning, ensure
the lathe is evenly supported by all six
leveling feet. Adjust the leveling feet with a
3/4” wrench as necessary.
WARNING
2019 Lathe has a net weight of 415 lbs.
All lifting devices must be capable of
handling the load, or serious personal
injury and machine damage may
occur.
Install Auxiliary Power Switch
Remount the tailstock. Open the box of the auxiliary switch
and mount the switch on the back of the tailstock.

2019 Lathe OLIVERMACHINERY.NET 19 |Page
Dust Collection System Usage
Turning wood can generate a lot of wood shavings and dust. When a
dust collection system is available, place a dust hood close to the
workpiece to extract the dust from the source. Installing a screen in
front of the dust hood can prevent large shavings from clogging the
dust collection system. Check air suction before using the dust
collection system, as blockage of the hose and air leakage can reduce
the system’s dust removal effectiveness.

20 | Page Oliver Machinery 2019 Lathe
Accessories
Outboard Turning Banjo
This extra tall banjo can support the tool rest with an 1” post for
outboard turning.
Parts number: A-2019.A001
Touchup Paint
A good coat of paint keeps the machine rust-free. We have pre-mixed
spray paint available in Oliver-Blue for purchase.
Accessories are available on our website: OLIVERMACHINERY.NET
To order by phone, please call us at 1-800-559-5065.We are available Monday through Friday, 7:30 AM -
4 PM Pacific Time. You can also email us at [e-mail] to purchase accessories.
Please visit our website at OLIVERMACHINERY.NET for additional recommended accessories.
WARNING
Unapproved accessories may cause the machine to malfunction, resulting in
severe injury and machine damage. Only use accessories recommended for this
machine.
