Clarke Woodworker CWL1000 Installation and operation manual

OPERATING & MAINTENANCE
INSTRUCTIONS 0408
40”WOODLATHE
40”WOODLATHE
Model No. CWL1000
Part No. 6500685

Lathe Specifications ................................................................................................... 3
General Safety Instructions ........................................................................................ 4
Wood Lathe Safety Instructions ................................................................................. 5
Electrical Connections and Motor Specifications................................................... 6
Unpacking And Checking Contents ........................................................................ 7
Optional Accessories ................................................................................................. 7
Main Component ID ................................................................................................... 8
Assembly ..................................................................................................................... 8
Spindle Speeds and Belt Tensioning ....................................................................... 10
Basic Techniques ...................................................................................................... 11
Using Woodworking Chisels ..................................................................................... 13
Making Standard Cuts ............................................................................................. 18
SpindleTurnings ........................................................................................................ 21
Face Plate And Chuck Turnings .............................................................................. 23
Fancy Face Plate Turnings ....................................................................................... 23
Turning Plastics .......................................................................................................... 27
Sanding, Buffin8g And Polishing ............................................................................. 28
Maintenance............................................................................................................. 29
Lubrication ................................................................................................................. 29
Spares And Servicing Contacts .............................................................................. 30
Parts List ...................................................................................................................... 30
Parts Diagram ............................................................................................................ 31
CONTENTS Page
2
When disposing of this product, do not dispose of with general waste. It must be disposed of according to
the laws governing Waste Electrical and Electronic equipment, at a recognised disposal facility.
DECARATION OF CONFORMITY
We declare that this product conforms to the followinhg EC Directive:
• 98/37/EC
signed
D. Kemp
Engineering Manager

3
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the
date of purchase. Please keep your receipt as it will be required as proof of purchase. This guarantee
is invalid if the product is found to have been abused or tampered with in any way, or not used for
the purpose for which it was intended.
Faulty goods should be returned to their place of purchase, no product can be returned to us without
prior permission. This guarantee does not effect your statutory rights.
Thank you for purchasing this CLARKE 40 inch Wood lathe.
Before assembling this machine, please read this manual thoroughly and follow all instructions
carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can
look forward to the wood lathe giving you long and satisfactory service.
WARNING:
THIS MACHINE MUST NOT BE MODIFIED, OR USED FOR ANY PURPOSE
OTHER THAN THAT FOR WHICH IT IS DESIGNED.
SPECIFICATIONS
Motor.............................................................................................. 230V 50Hz 1Ph
Power Rating ................................................ 370W
Input Current ................................................ 1.65A
Fuse rating ..................................................... 13A
Switch Type ................................................... No Volt Release
Turning Capacity .......................................................................... 350mm
(Between Centres)....................................... 1016mm
Spindle Speeds 1. .................................................................... 850rpm
2. .................................................................... 1250rpm
3. .................................................................... 1750rpm
4. .................................................................... 2510rpm
Headstock Thread ........................................................................ 3/4” x 16TPI (UNF)
Tailstock .......................................................................................... Rotating Centre
Tailstock Spindle Advance........................................................... 60mm via hand wheel
Overall Dimensions (LxWxH)......................................................... 1425x213x346mm
Weight unpacked......................................................................... 27kg

GENERAL SAFETY RULES FOR OPERATING MACHINERY
1. KNOW YOUR MACHINE.
Read the manual carefully. Learn the
machines applications and limitations, as
well as the specific potential hazards
peculiar to it.
2. KEEP GUARDS IN PLACE
and in working order.
3. EARTH ALL MACHINES.
If the machine is equipped with three-pin
plug, it should be plugged into a three-pin
electrical socket. Never remove the earth
pin.
4. REMOVE ADJUSTING KEYS AND WRENCHES.
5. KEEP WORK AREA CLEAN.
Cluttered areas and benches invite
accidents.
6. DON’T USE IN DANGEROUS ENVIRONMENT.
Don’t use machinery in damp or wet
locations, or expose them to rain. Keep
work area well lit.
7. KEEP CHILDREN AND VISITORS AWAY.
All children and visitors should be kept a
safe distance from work area.
8. MAKE WORKSHOP CHILDPROOF
Use padlocks, master switches or remove
starter keys etc.
9. DON’T FORCE THE MACHINE.
It will do the job better and safer, at the rate
for which it was designed.
10. USE RIGHT TOOL.
Don’t force a tool or attachment to do a
job for which it was not designed.
11. WEAR PROPER APPAREL.
Loose clothing, gloves, neckties, rings,
bracelets, or other jewellery may get
caught in moving parts. Nonslip footwear is
recommended. Long hair should be
contained.
12. USESAFETYGLASSES.
Also use face or dust mask if cutting
operation is dusty. Everyday eyeglasses
only have impact resistant lenses, they are
NOT safety glasses.
13. USEEARDEFENDERS.
14. DON’T OVERREACH.
Keep proper footing and balance at all
times.
15. MAINTAIN TOOLS IN TOP CONDITION.
Keep tools sharp and clean for best and
safest performance. Follow instructions for
lubricating and changing accessories.
16. ALWAYS DISCONNECT THE MACHINE
before servicing or changing accessories.
17. AVOID ACCIDENTAL STARTING.
Ensure the machine is switched OFF before
plugging in.
18. CHECK FOR DAMAGE.
If part of the machine (eg. A cover or
guard), is damaged, it should be carefully
inspected to ensure that it can perform its’
intended function correctly. If in doubt, the
part should be renewed. Damage to
moving parts or major components should
be Inspected by a qualified technician
before operating the machine. Contact
your local dealer for advice.
19. DO NOT STAND ON THE MACHINE.
Serious injury could occur if the machine is
tipped over. Do not store materials above
or near the machine such that it is
necessary to stand on the machine to get
to them.
20. NEVER operate a machine when under the
influence of alcohol, drugs or medication.
WARNING
As with all machinery, there are certain hazards involved with their operation and use. Exercising
respect and caution will considerably lessen the risk of personal injury. However, if normal safety
precautions are overlooked, or ignored, personal injury to the operator may result.
4

1. IMPORTANT: You should not operate this
machine unless you are thoroughly familiar
with wood turning lathes and wood turning
techniques. If there is any doubt
whatsoever, you should consult a qualified
person.
2. Do not operate the machine until it is
completely assembled, and this entire
manual, has been read and understood.
3. Ensure the proper electrical regulations are
followed. The machine must be properly
earthed.
4. Before switching the machine ON, ALWAYS:-
a . Clear the lathe bed of ALL objects
(tools, scraps of wood etc.).
b . Examine the setup carefully, ensuring
nothing could possibly interfere with
the rotating workpiece. eg. The tool
rest is secure and not liable to swing
into the workpiece. Rotate workpiece
by hand to check.
c . Ensure the tool rest is adjusted to the
correct height, and is as close to the
workpiece as possible.
d . Ensure all clamps are properly secured.
e. Ensure your clothing is properly
adjusted.
f. Ensure the workpiece is centralised.
5. Make all adjustments with the power OFF.
6. ALWAYS use the slowest speed when
starting a new workpiece, and cut at
correct speed for material and shape.
7. ALWAYS remove the tool rest when sanding
or polishing.
8. When turning between centres, always
ensure that the tailstock centre is snug
against the workpiece, with the spindle
locked, AND the Tailstock securely locked
to the bed. NEVER loosen the tailstock
spindle OR the tailstock with the workpiece
turning.
NOTE: The centre should be lubricated
(unless it is a ball bearing type).
9. DO NOT drive the workpiece into the
centre when the centre is installed in the
headstock. Always set the workpiece into
the centre with a soft mallet first, and then
mount the Centre with workpiece attached
into headstock spindle.
10. When using the Faceplate, ensure the
workpiece is securely fastened to it and
the appropriate size faceplate is used to
correctly support the workpiece. Ensure
the securing screws cannot interfere with
the turning tool at the finished dimension.
11. ALWAYS rough cut the workpiece as close
as possible to the finished shape before
mounting on to a faceplate.
12. ALWAYS examine the workpiece for flaws.
Do not use wood which is split or has knots.
Test glued joints before mounting on to
lathe to ensure they have completely set.
13. When roughing off, DO NOT jam tool into
workpiece or take too big a cut.
14. NEVER attempt to remount a faceplate
turning to the faceplate for any reason.
Never attempt to remount a between-
centres turning if the original centres in the
turning have been altered or removed.
15. ALWAYS clean the machine at the end of a
working session. Remove centres from the
headstock AND tailstock and store them.
Ensure the work area is cleaned before
leaving the machine.
16. Should any part of the lathe be missing,
damaged, or fail in any way, or any
electrical component fail to perform
properly, shut OFF the machine and
disconnect from the power supply. Replace
missing, damaged or failed parts before
resuming operation. If in doubt, consult
your local dealer. Always disconnect from
power supply when carrying our repairs.
17. Be particularly careful with your clothing
when operating a lathe. Always wear
safety glasses. Long hair should be
contained. See General Safety Instructions
- Apparel.
18. Do not exceed recommended speeds.
Refer to chart on page 12.
ADDITIONALSAFETYRULESFOR WOOD LATHES
5

ELECTRICAL CONNECTIONS
Connect the mains lead to a standard 230 volt (50Hz) electrical supply using a 13 amp BS1363 plug
fitted with a 13 amp fuse. or a suitably fused isolator switch.
WARNING :THIS APPLIANCE MUST BE EARTHED.
IMPORTANT : The wires in the mains lead are coloured in accordance with the following code :
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the flexible cord of this appliance may not correspond with the coloured markings
identifying terminals in your plug, proceed as follows :-
Connect GREEN & YELLOW coloured cord to plug terminal marked with a letter “E” or Earth
symbol ‘ ’ or coloured GREEN or GREEN & YELLOW.
Connect BROWN coloured cord to plug terminal marked letter “L” or coloured RED.
Connect BLUE coloured cord to plug terminal marked letter “N” or coloured BLACK.
We recommend that this unit is fitted with a Residual Current Device (RCD)
f this appliance is fitted with a plug which is moulded onto the electric cable (i.e. non-rewirable)
please note:
1. The plug must be thrown away if it is cut from the electric cable. There is a danger of electric
shock if it is subsequently inserted into a socket outlet.
2. Never use the plug without the fuse cover fitted.
3. Should you wish to replace a detachable fuse carrier, ensure that the correct replacement is
used (as indicated by marking or colour code).
4. Replacement fuse covers can be obtained from your local dealer or most electrical stockists.
5. The fuse in the plug must be replaced with one of the same rating (13 amps) and this
replacement must be ASTA approved to BS1362.
We recommend that this machine is connected to the mains supply through a Residual Current
Device (RCD).
If in doubt, consult a qualified electrician. Do not attempt any electrical repairs yourself.
FUSERATING
The fuse in the plug for this appliance must be rated at 13 amps
MOTOR SPECIFICATIONS
The four speed pulley system of this lathe is designed to use a 1725 RPM, 370W motor. Rotation is
clockwise as viewed from the pulley end of the shaft. It is wired for 230 Volt, 50Hz.
Caution: Do not any other type of motor as their use may be hazardous .
6
The machines’ ON and OFF buttons are marked “I” for ON and “O” for OFF.
Should the power fail whilst the machine is in use, the NO VOLT RELAY will operate. This is a safety
feature which prevents the machine from starting up automatically when the power is restored. It
will be necessary to press the ON button to continue operations.

Please check the carton contents carefully, if any parts are missing or damaged in any way, contact your
Clarke dealer immediately.
Ensure the lathe is secured firmly to a firm level surface...a sturdy workbench for example, or, if necessary, a
piece of 1/2” ply may be used, and this in turn should be clamped to a strong work surface when the lathe is
in use. The lathe may then be moved to a more convenient location for storage purposes. This is handy if
workspace is limited.
If a piece of ply is used, ensure the mounting screws are countersunk into the underside of the ply, so that the
bearing surface is completely flat.
UNPACKING AND CHECKING CONTENTS OF CARTON
7
OPTIONAL ACCESSORIES
A full range of optional accessories (detailed below) are available from your local dealer.
Accessory Part No
Cup Turning Chuck 6500641
Screw Chuck 6500642
4 Jaw Independent Lathe Chuck 6500645
6" Face Plat (Right Hand) 6500646
8 Piece Chisel Set 6500649
1. Tailstock Spindle
2. Toolrest Clamp Assembly
3. Tailstock
4 Faceplate
5. Tool Rest
6. Tailstock Advancing Handle
7. Drive Centre
8. Tailstock Clamp Assembly
9. Packet - 4 Nuts, bolts & Washers
10. Spanner
Not Shown - 3-Piece Chisel Set
CARTON CONTENTS
Fig.1

1. Headstock
2. ON/OFF switches
3. Drive Centre
4 Bed
5. Tailstock
6. Tailstock Advancing Handle
7. Tailstock Revolving Centre
8. Tool Rest
9. Pulley Observation Window
10. Faceplate
11. 3-Piece Chisel Set
MAIN COMPONENTS
Fig.2
1. Bolt the two halves of
the bed together, using
the four nuts, bolts and
washers supplied,
ensuring the two halves
are perfectly aligned
so that the assembly
lies flat on the work
surface.
ASSEMBLY
2. Place the Tailstock on the bed.
Disassemble the Tailstock Clamp assembly (8, Fig.1)
and reassemble to the Tailstock with the bolt
through the hole in the Tailstock, throught the
Clamping Plate and into the Lever.
Note the orientation of the Clamping Plate and Lever
- Clamping Plate with raised edges uppermost and
sitting between the bed rails, and the Lever angled
downwards (Fig.4a).
Screw in the bolt and nip up using the lever.
Note the position of the Lever, when fully tightened
should be towards the operator as shown in Fig.4. This
is achieved by slackening off the lever, and turning
the bolt head until the appropriate position is attained
when the lever is tightened again.
Fig.3
Fig.4a
Fig.4
8

3. Screw in the Tailstock threaded shaft, screw
on the locking nut, and attach the Handle to
the flats on thre end of the shaft. Secure the
Handle by tightening the grub screw.
Fig.5
4. Disassemble the Tool Support Bracket, and
reassemble to the machine in the manner
shown in Fig.6. The Clamping Bracket and
Lever should be oriented in the same manner
as for the Tailstock.
The Tool Rest (5, Fig.1) is simply dropped into
the hole in the bracket and secured using the
knob provided.
Fig.6
5. Screw the machine to a workbench using the eight holes
provided in the base. Two of these holes are concealed
behind plastic end caps, as shown in Fig.7.
Alternatively, bolt the machine to a piece of board, of at
least 25mm in thickness and having a dimension of at
least 1500x500mm.
Use countersunk screws from beneath the board so that
the complete assembly lies flat.
The board, with Lathe attached, may then be firmly
clamped to a workbench when required for use.
Fig.5Fig.7
6. Before use, the
appropriate workpiece
securing device must be
attached - either the
fixed Centre or the Face
Plate.
These are simply
screwed into place, the
spindle being held using
the spanner provided
on the flats on the
spindle.
Fig.8
Your Lathe is now fully assembled and ready for use.
9

SPINDLESPEEDS
A chart showing spindle speeds and recommended turning speeds is mounted on the Head cowl
and for convenience, is duplicated as follows:
CAUTION : MAKE SURE THE POWER CORD IS
REMOVEDFROMTHEOUTLETBEFORE
ATTEMPTINGTO CHANGETHE BELT POSITION.
Changing speeds
1. Undo the two screws securing the Pulley
Access Panel.
2. Slacken the four Motor securing bolts -
2 are arrowed in Fig. 9.
3. Pull up the lower - motor pulley to relieve
belt tension.
4. Move belt to appropriate pulley’s.
5. Push down on the lower pulley to tension
the belt. It should be firm - 1/2” total
movement at the middle of the run.
6. Retighten Motor securing bolts and replace
Pulley Access Cover.
10
SPINDLE SPEEDS
RECOMMENDED GENERAL SPEEDS
SPINDLE TURNING
SQUARE LENGTH ROUGHING FINISHING
1” (25mm) 12” (305mm) 1750 2510
2” (50mm) 16” (406mm) 1250 2510
3” (75mm) 20” (508mm) 850 2510
4” (100mm) 20” (508mm) 850 2510
DIAMETER THICKNESS ROUGHING FINISHING
9” (228mm) 4” (100mm)Max. 850 2510
8” (205mm) 4” (100mm)Max. 1250 2510
6” (150mm) 4” (100mm)Max. 1750 2510
FACE PLATE TURNING
Fig.9 shows the belt positioned on the second
step from the outside edge of the pulley. This
produces a spindle speed of 1250 RPM. (Refer
to the chart above).
If you wish to run at a higher speed, say 2510
RPM, you must shift the belt inwards, 2 steps.
Fig.9

1. SPINDLE TURNING
If you are not experienced at the art of wood
turning, we suggest that you practice using the
various wood turning tools, starting with turning
a small spindle.
1.8 Place the wood between the centres and
advance the tailstock so that the rotating
centre is forced into the spindle at the exact
centre mark, rotating the spindle as you do
so.
1.9 Adjust the tool rest approx. 3mm away
from the corners of the wood and 3mm
above the centre line. Note the angled
position of the tool rest base.
11
1.1 Select a piece of wood 50x50x305mm.
1.2 Draw diagonal lines on each end to locate
the centres.
1.3 On one end, make a saw cut approximately
2mm deep on each diagonal line. This is
for the spur centre.
You may also remove the drive centre from
the spindle, as described on p.10
‘Faceplate Turning’, and place the
point of the centre on the wood where the
diagonal lines cross.
Drive the centre into the wood. Use a
wooden mallet or a plastic hammer, but put
a piece of wood on the end of the centre
to protect it.
1.6 Replace the Drive Centre, ensuring it is tight.
Positioning theTailstock
1.7 Position the tailstock at the appropriate
distance for the job in hand. To move the
tailstock, slacken the securing nut located
underneath. Always allowing a little
room for the advancement of the rotating
centre.
Wooden Mallet
or
Plastic Hammer
Fig. 4
Fig. 6
Fig. 5
1.10 Check to ensure there are no spanners/
wrenches/pieces of wood or other debris
in the area, and that your clothing is
properly adjusted before pushing the ON
button.
The procedure for cutting and the use of
woodworking chisels is described under
“Using Woodworking Chisels, starting on
page 12.
Fig. 7
Lock the trool rest base and the tool rest
IMPORTANT. ALWAYS rotate the wood by hand
to guarantee that the corners do not strike the
tool rest..
BASIC WOOD TURNING TECHNIQUES

12
Fig. 9
2. FACEPLATETURNING
Turning which cannot be worked through
centres, must be mounted on a faceplate, or
other work-holding device. (Some jobs may
require the use of special chucks).
To attach the face plate, first remove the Drive
Centreas follows:
Removing the Drive Centre
Hold the spindle with the spanner provided, on
the flats machined on the spindle.
Using a suitable spanner on the Drive centre, turn
it anticlockwise whilst holding the drive centre
steady - See Fig 8.
The Face Plate is removed in a similasr manner
All face plate work is done by scraping. Any
attempt to use a cutting technique on edge
grain, will result in hogging or gouging, which
may tear the tool out of your hands.
For Faceplate turning, the work (suitably
trimmed so that it is as near to its final
dimension as possible), should be firmly
mounted on to the faceplate, using screws
as appropriate (see fig. 9).
The complete assembly is then screwed on to
the headstock spindle, and tightened
securely, by holding the faceplate, and
turning the spindle nut using a spanner, to lock
it up against the faceplate boss.
The screws used in securing the work to the
face plate, must not be of sufficient length as
to interfere with the tool at the final dimension.
It may be necessary to screw the work to a
backing piece, depending upon design, or
where screws are not permissible at all, the
work may be glued to a backing piece, fitting
a piece of paper at the joint, which will allow
for later separation without damaging the
wood.
Fig. 8
The following pages are examples of woodworking operations and
illustrations of some of the techniques which are generally used.
This is by no means exhaustive, and we strongly recommend that
if you are inexperienced in the use of wood lathes, you should
read as much as possible on the subject and perhaps subscribe
to a good woodworkers periodical.

Better chisels have handles approximately 10"
(250mm) long, to provide plenty of grip and
leverage. Sharp tools are essential for clean,
easy work. Buy tools that will take and hold keen
edges.
An 8 piece chisel set is available from your
CLARKE dealer, part no. 6500649
2. THEORY OFTURNING
There are two classes of chisel; these are :
a. Chisels intended primarily for cutting, and
b. Chisels used only for scraping.
The cutting chisels are the gouge, skew and
parting tool. These are most commonly used.
They are sharpened to a razor edge by honing
on both sides.
The scraping chisels are the flat nose, round nose
and spear point. These are not honed on the
flat sides, the wire edges produced by grinding
are left on to aid in the scraping process.
must faster, especially the razor sharp cutting
chisels.
Cutting is faster than scraping and produces a
smoother finish which requires less sanding.
However, it is far more difficult to master.
Scraping, on the other hand, is far more precise
and easier to control.
13
USING WOODWORKING CHISELS
THE SIX MOST COMMONLY USED CHISELTYPES
2.1 Cutting and Scraping
To cut, the chisel is held so that the sharp edge
actually digs into the revolving work to peel off
a shaving.
To scrape, the chisel is held at a right angle to
the work surface as shown in fig. 12, and
removes fine particles instead of shavings.
Many operations require that the cutting chisels
be used for scraping, but scraping chisels are
never used for cutting. Scraping dulls a chisel
Cutting Chisel Scraping Chisel
2.2 When You Can Cut and When You
Must Scrape.
There are two different types of cut to consider
when turning.
One is cutting at the circumference of the
workpiece (for example, turning down the outer
surface of a cylinder or the inner wall of a hollow
round box, as shown in fig. 13). In this approach
the surface being turned travels under the chisel
edge like an endless belt.
The second type is cutting at the diameter of a
workpiece (as when turning the face of
faceplate turning or the side of a large shoulder
on a spindle turning, as shown in fig. 13). In this
approach the surface being turned rotates like
a disc under the chisel edge. Sometimes the
approach will be a combination of both.
Fig. 10
Fig. 12
Fig. 11
Fig. 13
1. SELECTION OF CHISELS

Either a cutting or scraping action can be used
when cutting at the circumference. The shaving
is removed like a peeling from a potato.
Scraping only, is used when cutting at the
diameter. The reason is obvious when you
consider that faceplate turning always requires
removal of wood across the grain. Wood does
not peel easily across the grain, and attempts
to use a cutting method will result in damage to
the work and throwing of the chisel by the work.
It follows that a cutting action is used for the
majority of spindle turning operations, whilst the
majority faceplate turning is done by the
scraping method.
When a combination approach is to be used,
you will have to judge, by the feel of the work,
when to stop cutting and start scraping.
Never try to cut when it becomes difficult to hold
the chisel against the roughness of the wood
grain.
2.3 HowTo Position TheTool Rest for
Circumference Cutting
When cutting, the object is to pierce the outer
skin of wood to a certain desired depth, then to
hold the chisel steady, with the bevel edge
parallel to the work circumference, so that it will
peel off a shaving at this desired depth.
The only sure method of holding the chisel
steady is to rest the bevel against the work, as
shown in sketch 1.
When the tool rest is at
the proper height , the
chisel can be held with
the bevel pressed
against the work, and
the tool rest will act as a
fulcrum to support the
chisel against the
downward force of the
revolving work.
If the rest is placed too
low, so that the chisel is
held with the bevel out
from the work (Sketch
2), the cutting edge will
continue to dig deeper
into the work. It will dig
in until the “bite”
becomes so deep that
your hands have
difficulty holding the
14
chisel, then the
improperly supported
chisel will begin to
bounce, or chatter,
against the workpiece.
If the rest is placed too
low, the chisel must be
held extremely high to
position the bevel
against the work
(Sketch 3). Then the rest
loses most of its value as
a fulcrum, and the
downward force of the
revolving workpiece
tends to kick the chisel
back out of your hands.
If the rest is placed too
high, (Sketch 4) and the
chisel is correctly
positioned for cutting, it
strikes the workpiece
near the top where the
direction of force
exerted by the
workpiece is nearly
horizontal, and
kickback will again
result.
If the rest is placed too
far out from the work
surface (Sketch 5) then,
when correctly held,
the chisel is again too
high on the work. Also,
you have less leverage
on your side of the tool
rest, and it is even more
difficult to hold the
chisel.
With large diameter
work (Sketch 6), the tool
rest can be above the
workpiece centre line,
and somewhat out from
the work surface.
With small diameter
work (Sketch 7), the rest
should not be far from
the work surface. As
work grows smaller, the
rest should be
repositioned.

2.4 How to PositionTool Rest for
Circumference Scraping
In scraping operations, the tool rest position is
not as critical as it is for cutting operations. The
chisel generally is held horizontally, though it can
be held at an angle to reach into tight places.
Considering that the wire edge of the chisel
does the scraping, sketches 9 and 10 show the
results of too low or too high a position for the
rest, and sketch 8 shows the chisel action with
the rest correctly positioned.
3. USING THE GOUGE
15
2.5 How to Position Chisel and Rest for
Diameter Scraping
When scraping on the diameter, that portion of
surface to the right of centre is moving upwards
(Sketch 11). If the chisel is placed in this area, it
will simply be carried up off the rest and out of
your hands. All diameter scraping operations
must be done at the left of centre.
Three different chisel contact points are shown
in Sketch 12. It will be noted that, when the chisel
is above the workpiece centre, or below it, the
work surface sweeps past the chisels’ edge at
an angle and tends to carry the chisel in one
direction or the other along the rest. Only when
the chisel contacts the work on the centre line
does the work surface pass squarely under the
chisels edge. This then, is the position in which it
is easiest to hold the chisel steady. To obtain
this position, place the rest approximately 1/8"
(3mm) - thickness of chisel, below the centre.
Three gouges the 1/4”, 1/2”, and 3/4” are ample
for general DIY turning, but other sizes from 1/8”
to 2” can be purchased.
The main use of the gouge is for rough
circumference cutting of raw stock down to a
cylinder of working size. it is the best tool to use
for rapidly cutting away large areas of the
workpiece, but when so used does not produce
a smooth surface. With practice, it can be used
for cutting coves and the shaping of long cuts.
It is also useful for scraping.
When used for cutting, the gouge is always held
with the convex side down. It should be rolled
approximately 30°to 45°in the direction in which
it is being advanced along the rest, and the
cutting edge will be a little in advance of the
handle.
4. USING THE SKEW
Two skews, the 1/2 and 3/4” sizes, are all that
are needed for general use. Other sizes are
available. This tool is nearly always used to make
finished cuts, to cut vees and beads, and to
square shoulders. Properly used, it produces the
best finish that can be obtained with a chisel. it
should not be used for scraping, as this quickly
dulls it.
For finish cutting, the skew is held with the cutting
edge considerably in advance of the handle,
Fig. 15
Fig. 14

bevel side down, keep the base of the bevel
against the work. Good practice is to place
the skew well over the work, pull it back until
the edge begins to cut, then swing the handle
into position to advance the cut. Both the toe
and the heel of the skew can be used for taking
light cuts, but do not penetrate the wood too
deeply without cutting clearances, as there is
danger of burning the tip of the tool.
5. USINGTHE PARTINGTOOL
scraping, when cutting methods cannot be
employed.
The spear point is used for fine scraping and
delicate operations, such as the forming of
beads, parallel grooves and shallow vees.
Edges and bowl contours can be rounded with
the round nose chisel. Any flat surface can be
scraped with the flat nose chisel.
7. USING SHAPER/MOULDING KNIVES
The parting tool has just one primary purpose to
cut straight into the workpiece as deep as
desired, or all the way through to make a cut-
off, it is therefore a very narrow tool. 1/8 inch
wide and shaped to cut its own clearance so
that the edge will not be burned. When used
for scraping, however, it should be backed off
regularly to prevent overheating.
Unlike the gouge and skew, the parting tool is
seldom held with the bevel against the work.
As the amount of stock removed is small, a
support for the bevel is not necessary. The tool
is simply fed into the work at an angle (for
cutting), or pointed at the workpiece centre (for
scraping) it can be held easily in one hand.
6. USING THESCRAPING CHISELS
A 1/2” wide spear point chisel, a 1/2” wide round
nose chisel and a 1” wide flat nose chisel
complete the list of tools ordinarily used by home
craftsmen. Each of these scraping chisels can
be purchased in various other sizes for special
purposes. All are very useful for diameter
scraping operations and for circumference
An old chisel can be made to serve as a holder
for ‘shaper’ or ‘moulding’ knives. Such knives
make it possible to scrape many interesting
shapes in the workpiece surface in one or two
operations instead of the many operations
required with standard chisels. It is generally not
practical to use cutting methods with special
shape tools, scraping methods should be used.
The holder should provide a shoulder against
which the butt end of the knife can be firmly
seated, and the knife must be securely
mounted, either by means of a screw threaded
into the holder, or be compressing it between
two prongs bolted together.
8. USING A BLOCK PLANE
Clear glass smooth finishes (especially on soft
woods) can be obtained by using a block plane
set to take a fine shaving. The tool rest should
be raised up approximately to the top of the
workpiece, and the plane should be horizontal,
but turned slightly in the direction of travel so
that it will take a shearing cut. Two tool rests,
one in front and the other behind the work, can
be used to advantage in positioning the plane
so as to exactly limit the depth of cut (and
finished size of the workpiece).
16
Fig. 17
Fig. 19
Fig. 18
Fig. 16

9. USING WOOD RASPS AND FILES 10.2 Finish Cutting
A wood rasp will remove stock quickly when
held against the revolving workpiece. Care
should be taken to support the rasp firmly
against the tool rest however, as it can tear the
hands painfully if caught by a rough edge of
the workpiece and kicked back. The rasp will
leave a very rough finish.
Finer finishes (similar to those produced by
scraping), can be obtained by using files in the
same manner. Various shape files can be used
for shaping vees, beads, coves etc. If pressed
into the wood too hard, however, a file can burn
the workpiece surface. Keep the file clean to
keep it cutting uniformly. Files work best on hard
woods.
10. HAND POSITIONS
When handling a chisel, the hand takes a
natural position, being nearer or farther from the
end depending upon the amount of leverage
required. The position of the tool rest hand is a
matter of individual liking, but there are three
generally accepted positions, each best for
certain types of operations.
10.1 Roughing Off
Roughing off and other heavy work requires a
firm grip and solid positioning of the chisel
against the rest. This is best obtained by the tool
rest hand position as illustrated. The wrist is
dropped down so that the heel of the hand
below the little finger acts as a sliding guide
against the rest. The handle hand controls chisel
position.
Finish cutting requires more control with less
force and is better done with the palm of the
tool rest hand turned up. The wrist is still held
down, and the side of the index finger acts as a
guide along the rest. In this position, control of
the chisel is shared by both hands, the fingers
of the tool rest hand being free to assist in
positioning the tool.
10.3 Intricate Cutting
Intricate, delicate cutting requires extreme
control, with practically no force. This is best
accomplished by guiding the chisel with the
fingers of the tool rest hand. The hand is held
palm up, with the wrist high, and the little finger
placed against the rest to steady the hand. The
chisel does not touch the rest and the handle
hand is completely secondary to the tool rest
hand.
The first and second positions are equally good
for scraping operations, but the third position is
never used for scraping.
11. CUTTING TO DEPTH
Many scraping operations and cutting to depth
with the parting tool can be easily done with
one hand. The chisel is grasped firmly with the
index finger on top, to press it down against the
rest, and is thrust straight into the work. Holding
the tool thus leaves the other hand free to hold
a pattern , callipers etc., to check work progress.
17
Fig. 21
Fig. 23
Fig. 20
Fig. 24
Fig. 22

MAKING STANDARD CUTS
1. THE ROUGHING OFF-CUT
Reducing a square or odd shaped workpiece
down to a cylinder of approximate size for finish
turning is called roughing-off. Faceplate
turnings and large diameter spindles should
first be partly reduced by sawing , but small
spindles are easily turned down entirely with the
large (3/4”) gouge.
Start the first cut about 50mm from tailstock and
then run it toward the tailstock and off the end
of the workpiece.
Next, start another cut 50mm nearer the
headstock and run it also toward tailstock to
merge with first cut.
Continue in this manner until 50mm to 100mm
from the headstock end, then reverse the
direction of tool travel and work one or two cuts
in succession toward the headstock and off this
end of the workpiece.
Never start a cut directly at the end. If the chisel
catches the end, it will damage the workpiece.
Never take long cuts while corners remain on
the work, as this tends to tear long slivers from
the corners.
The first series of cuts should not be too deep. It
is better to partially reduce the work to a cylinder
along its complete length, then start a second
series of cuts to reduce it to a cylinder. Once a
cylinder has been formed, step the lathe up to
its next fastest speed. Further reductions in size
can now be carried out by cutting as deeply
18
as desired at any spot along the work.
At this stage long cuts from the centre of either
end can also be taken. Roughing-off generally
is continued until the cylinder is approximately
3mm larger than the desired finished size.
Roundness can be tested by laying the gouge
on top of the work - it will not ride up and down
when cylinder is perfectly round.
2. ROUGH-CUTTING TO SIZE
Fig. 26
Fig. 27
Fig. 25
The roughing-off cut can be made to
accurately size the cylinder to a given diameter.
Another method is to make a number of sizing
cuts at intervals along the work, then use the
gouge to reduce the whole cylinder down to
the diameter indicated by these cuts.
3. MAKING SIZING CUTS
Sizing cuts are useful to establish approximate
finish-size diameters at various points along a
workpiece. The work can then be turned down
to the diameters indicated and be ready for
finishing.
Diameters for sizing cuts should be planned to
be about 3mm greater than the desired finished
diameters.
A sizing cut is made with the parting tool.
Hold the tool in one hand and use the other
hand to hold an outside calliper, preset to the
desired sizing-cut diameter.
As the cut nears completion, lower the chisel
point more and more into a scraping position.
When the callipers slip over the workpiece at
the cut, the cut is finished.
4.SMOOTHING A CYLINDER
The final 3mm can be removed in two ways.
Either use the 3/4” skew, working from the centre
toward both ends and taking lighter and lighter
cuts until finished.

Use the gouge to remove any waste stock
outside of shoulder, and smooth this section up
to within 3mm of the shoulder in the usual
manner. Finishing of the shoulder unless it is more
than 25mm high is best done with the 1/2” skew.
First, the toe of the skew is used to remove
shavings from the side of the shoulder, down to
finish size. Hold the skew so the bottom edge of
the bevel, next to shoulder, will be very nearly
parallel to side of shoulder, but with the cutting
edge turned away at the top, so that only the
extreme toe will do the cutting.
If the cutting edge is flat against the shoulder,
the chisel will run. Start with the handle low, and
raise handle to advance toe into the work.
Cut down to finished diameter of outside area,
then clean out the corner by advancing the
heel of the skew into it along the surface of the
outside area.
Tilt the cutting edge with handle raised up, so
that only the extreme heel does this cutting. If
the shoulder is at the end of work, the process is
called squaring the end. In this case, reduce
outer portion to a diameter about 6mm larger
than tool centre diameter, then later saw off the
waste stock.
6. CUTTING VEES
Vee grooves can be cut with either the toe or
heel of the skew. When the toe is used, the
cutting action is exactly the same as in trimming
a shoulder, except that the skew is tilted to cut
at the required bevel. Light cuts should be taken
first on one side then the other, gradually
enlarging the vee to the required depth and
width.
When the heel is used, the skew is rotated down
into the work, using the rest as a pivot.
Otherwise, the cutting position and sequence
of cuts is the same.
As when using the toe, it is important that cutting
be done only by extreme end of cutting edge.
If deep vees are planned, it is quicker to start
them by making a sizing cut at the centre of
each vee. Vees can also be scraped with the
spear point chisel or a three-sided file.
7. CUTTING BEADS
This requires considerable practice.
First, make pencil line to locate the tops (highest
points) of two or more adjoining beads. Then
make a vee groove at the exact centre
between two lines, and down to the desired
depth of the separation between the beads.
Be careful not to make the groove too wide or
you will remove portions of the desired beads.
The sides of the two adjoining beads are now
cut with the heel of the skew, preferably 1/2”
size, unless beads are quite large. Place the
skew at right angles to the work axis, flat against
the surface and well up near the top. The
extreme heel should be just inside the pencil line
that marks the top of the bead.
19
5. CUTTING A SHOULDER
A shoulder can be the side of a square portion
left in the workpiece, the side of a turned section
or the end of the workpiece. Most shoulders are
perpendicular to the work axis, but a shoulder
can be at any angle desired.
First, mark position of the shoulder with a pencil
held to the revolving workpiece. Then make a
sizing cut with the parting tool, placing this cut
about 2mm outside the shoulder position and
cutting to within about 3mm of the depth
desired for the area outside of the shoulder.
If shoulder is shallow, the toe of the skew can
be used to make the sizing cut, but do not go in
deeper that 3mm with the skew unless wider and
wider vees are cut to provide clearance for this
tool. Fig. 29
Fig. 30
Fig. 28

Now draw the skew straight back whilst raising
the handle slowly, until the edge of the heel at
the pencil line starts to cut.
As the edge begins to cut, roll the skew in the
direction of the vee, so that the exact portion
of the edge, when started cutting, will travel in
a 90° arc down to the bottom of the vee.
Upon reaching the bottom of the vee, the skew
should be on edge. Reverse the movements to
cut the side of the adjacent bead.
It is important that only the extreme heel should
do the cutting. This means that the bottom edge
of the bevel, next to the vee, must at all times
be tangent to the arc of the bead being
formed.
Easier beads can be shaped with a spear point
chisel. Use pencil marks and sizing cuts as
before. Push the chisel straight into each cut
and rotate it horizontally to round off the
adjacent edges. It must be moved slightly in
the direction of rotation at the same time, to
keep the point from digging into the adjacent
bead.
8. CUTTING COVES (CONCLAVES)
This is the most difficult single cut to master, but
one of the most important in good wood turning.
First, use pencil marks to indicate the edges.
Then rough-it out to within about 3mm of the
desired finish surface by scraping with the
gouge or round nose chisel. If the cove is to be
very wide, sizing cuts can be made to plot the
roughing out.
Once it is roughed out, the cove can be finished
in two cuts, one from each side to the bottom
centre.
At the start of either cut, the gouge is held with
handle high and the two sides of blade held
between the thumb and forefinger of tool rest
hand, just behind the bevel.
Position the fingers ready to roll the blade into
cove. Hold the blade so that bevel is at a 90°
angle to the work axis, with the point touching
the pencil line and pointing into work axis.
From here, depress the tip slightly to start the
cut, then continue to move tip down in an arc
toward the bottom centre cove, at the same
time rolling chisel uniformly so that at the end of
the cut it will be flat at the bottom of the cove.
The object is to keep the extreme tip of the
gouge doing the cutting from start to finish.
Reverse movements to cut the opposite side.
Coves can be scraped to finish using the round
nose chisel or a file, but these methods do not
generally produce perfectly curved coves.
9. MAKING A LONG CONVEX CUTS
First turn work down to approximate size, using
sizing cuts (as required) to determine various
diameters. Finish cut can then be made with
either skew or gouge.
If the skew is used, the principles of operation
are the same as those employed in cutting a
bead, except that the curve is longer and may
be irregular. Use the extreme heel throughout.
Start at the longer end of the curve (if curve is
irregular) and progress toward the steeper end.
If a gouge is used, make the cut in the same
direction. Start with the handle well back from
the point, swinging it in the direction of tool travel
to overtake the point, if necessary, when the
steep part of the curve is reached. The object is
to keep the extreme point doing the cutting
throughout, with the bevel at a tangent to the
curve as much as possible.
10. MAKING LONGTAPER CUTS
Long taper cuts are made like long convex cuts,
with the skew or gouge. However, the angle
between the cutting edge and handle is kept
constant during the entire cut. The handle is
not swung around. Always cut downhill. Do not
cut too deeply at the centre of the taper.
20
Fig. 34
Fig. 33
Fig. 32
Fig. 31
