Introduction
Thank you for purchasing this machine.
This manual provides descriptions on the use of network printing and network scan-
ning functions used with the Internet or on an intranet.
Be sure to read this manual before performing any operations.
For precautions concerning the use and safety of the machine, refer to the User’s
Guide provided with the machine.
Store the CD-ROM and User’s Guides provided with the machine in a safe place.
