BINOCULAR TUBE _I

CH3-Bl45

REPAIR MANUAL

OLYMPUS 5

01.10.1997

CH3-B145

CONTENTS

OUTLINE OF PRODUCT

/‘

f^“

1. Outline............................................................................................................................... A-l

2. Features

...................................................................i.........................................................

A-l

3. UsingConditions ...................................*..........................................................................

A-l

4. Specifications.................................................................................................................... A-2

5. Dimensions........................................................................................................................ A-3

DESCRIPTION OF MECHANISM

1. Light PathDiagram ........................................................................................................... B-l

2. JentshandSiedentopf ....................................................................................................... B-2

3. Interpupillary DistanceAdjustmentMechanism ,

.............................................................. B-3

4. OpticalAdjustmentMechanism .......i....................I......‘........:........i.................................. B-4

INSPECTION STANDARD

1. CheckItemsandMethods %

................................................................................................. C-l

-. Useof JigsandTools ........................................................................................................

, c-2

DISASSEMBLY AND ASSEMBLY PROCEDURES

1. EntireDisassemblyandAssembly.................................................................................... D-l

2. Division“PlateAssemblyProcedure

.................................................................................. D-4

REPAIR PROCEDURE ’

1. OpticalAdjustmentProcedure....-......................................................................................

E-l

-. Adjustmentof theInterpupillary Distance

Working Force ................................................ E-17

JIGS AND TOOLS

1. List of JigsandTools ......................................................................................................... F-l

LUBRICANTS 2&D CHEMICALS

1. List of Lubricants .............................................................................................................. G-l

2. List of Chemicals.............................................................................................................. G-l

01.10.1997

CH3-B145 A. OUTLINE OF PRODUCT

1. Outline

CH3-BI45 is a Siedentopf type binocular tube with inclined at a viewing angle of 45” (fixed), and

combinedwith thesystemmicroscopeCH30 or CH40for educationandlaboratory, etc.,

2. Features

(1) One-sidehelicoid ring enablestheleft/right diopter difference compensation,

(2) The siedentopf type observationtube preventsthe optical path length from varying with

theinterpupillary.distance,andenhancesthedustproof andfungusproof performance.

f ‘

(3) It is possible to observein wide range of field number 20. (Conventional field number

was18.)

(4) The interpupillary distanceis adjustablefrom 48 mm to 75 mm, applicable to various

observer’seyes.(Conventionalrangewas53 mm to 72 mm.)

(5) The eyepieceis antitheft asit canbefixed with the clampingscrew.

3. Using Conditions

(1) Applicable frame: CH30-F,CH40-F

(2) Applicable eyepiece: WHKlOX, CWHKlOX

(3) Applicable objective: EDAch, DA+ series

(4) Usingenvironment: Temperature 0 to 40°C

Humidity 30 to 90

(5) Others: Fixableat anarbitrary position in anangleof 360”

(horizontal direction) only when,the interbupillary distanceis at

themaximum.

A-l 01.10.1997

CH3-Bl45 A. OUTLINE OF PRODUCT

4. Specifications

Bern

1 Type

2 Field number

Specifications

Siedentopf

20 (when usingWHKlOX)

18(when usingCWHKlOX)

(Eyepiecesleevediameter423.2 mm)

Remarks

3 Inclination 45” fixed

4 InterpupiBu-y distance 48 to 75 mm

adjustmendrange

5 Magnification lx

6 Imagedirection Inverted image

7 Left/right diopter difference Helicoid ring for adjustmentprovided in

compensation theleft sleeve

(Diopter range:2 5 diopters)

8 Mounting on theframe

9 Eyepoint ttight

Circular dovetail (Ip34 mm, depth6 mm)

93.4mm (when usingCWHKlOX) At standard

(Arm mounting surfaceto eyepoint) interpupillary

distance(62 mm)

10 Weight

11 Dimensions

Approx. 0.5 kg

Seethe next page.

A-2

CH3-Bl45 A. OUTLINE OF PRODUCT

Dimensions

103.6

Unit: mm

A-3

01.10.1997

CH3-5145 8. DESCRIPTION OF MECHANISM

1. Light Path Diagram

path

From objective

CH3-Bl45 B. DESCRIPTION OF MECHANISM

2. Jentsh and Siedentopf

Binocular tube has the mechanismto adjust the distancebetween left and ri@ optical axesto meet

the observer’s eyes. This mechanismis availablein two typical types: Jentshwhich changesthe

distancein astraight line andSiedentopfwhich changesthe distancein anarc. Eachtype hasmerits

anddemerits. The featuresof eachtypeareasshownbelow.

Jentsh Siedentopf

i_:i .: ’

Li$rt

path

diagram

k??dl

L&i57

- The center prism is fixed. The * The left and right prisms havethe function

interpupillary distance is adjusted by of a center prism. The interpupillary

mo\-ing the left andright prismsin parallel distance is adjusted by moving these

to eachother. prisms in an arc centering the optical axis

* Less possibility of optical axis displace- going up from theobjective.

ment causedby changingtheinterpupillary * The tube length is not changedevenif the

distance. interpupillary distanceis adjusted.

Features - The reticle glassin the eyepiecedoesnot * The interpupillary distance does not

incline evenif theinterpupillary distanceis change even if the eyepiece is pushed

adjusted. during observation.

. The tube length changesasa result of the * The reticle glass in the eyepiece inclines

change in the optical path length when the when the interpupillary distance is

interpupillary distanceisadjusted. adjusted.

* Conpact design.

B-3

CH3-Bl45 B. DESCRIPTION OF MECHANISM

3. lnterpupillary Distance Adjustment Mechanism

3-l Working force

The interpupillary distance

working force is adjusted

by screwingthispart.

B-3 01.10.1997

CH3-Bl45 B. DESCRIPTION OF MECHANISM

4. Optical Adjustment Mechanism

4-1 Optical axis .a Absolute optical axis(center of standard

f- objective) with theBI unit installed

Revolving axis and

left/right optical axis

with sleeveinstalled

Adjust the optical axisat theabovetwo points. The internal prism position is adjustment-free

in principle.

Adjustment 0:

Adjust the revolving axisin theri$t sleeve. (“Revolving axis” meansthemechanicalrotation

center upon interpupillary distanceadjustmentand the phenomenonwhich occurs when the

optical axis is displaced. The optical axismentionedhere is the center of the sleeve. Ali@

the optica! axis with themechanicalrotation centerby changing the sleeveposition so that the

imagein the field of view doesnot moveuponobservation.)

The left sleeve is usedto adjustonly the left/right optical axis. (Align the right sleevecenter

with a point of a specimenbeforehand,then match the left sleevecenter with the point of a

specimen.)

Adjustment 0:

Almost the sameasthe adjustmentmethodperformed for installation of the BI unit of the U-

BI30.

Mount the standardobjectiveon therevolving nosepieceof adjustedframe. Mount theBI unit

with the srandard eyepieceinserted into the right sleeve on the frame. Changethe BI unit

mounting position so that the crosscenter of a specimen in the standardobjective coincides

with thecross hairs cerrterof thestandardeyepiece.

B-3

CH3-Bl45 B. DESCRIPTION OF MECHANISM

4-2 Tube length

Left sleeve Right sleeve

/-- ,

, \

Adjust “0” position of helicoid scaleto the The tube length canbe changedby adjustingthis

index. sleeve-Rvertically.

f-\

B-5 01.10.1997

CH3-Bl45 C. INSPECTION STANDARD

1. Check items and Methods

/-‘

f-‘,

Item Standard Method

Interpupillary Adjustment 48mm or lessatmin. -

distance Settheobservationstate,insertathin paperwith

range 75mm or moreatmax.

adjustment graduationsattheeyepoint positionandmeasure

theinterpupillary>distance.

Working

force 500to 1200g Tie astring aroundthesleeveperipheryand

measuretheinterpupillarydistanceworking force

with atensiongauge.

Diopter Adjustment -c5 dioptersmin.

difference Turnthescalering andcheckthat thescalegoes

range overthelimit.

:ompensation

Dpticalaxis Left/right Ontheimagesurface:

OPtica1axis Settheobservationstate,usethestandardeyepiece

Max. 0.2mm in the KNOO48andobserveaspecimenwhosecentercan

difference vertical direction beidentified (e.g.,anconcentriccircle).Align the

IMax.0.2mmin the1 centersof thespecimenandthevisualfield taking

outwarddirection theright sleeveasastandard,thencheckthe

Max. 0.4mm in the centersdisplacementin theleft sleeveby reading

inwarddirection thereticle scale(1graduation= 0.1mm)of

KNOO48.

Absolute 0.25mm or lessonthe Settheinterpupillarydistanceto about62mm,

optical axis imagesurfacewhenthe combinethestandardeyepiece(KNOO48),the

(right sleeve interpupillarydistanceis microscopeframe(product),andthestandard

only) 62mm objective(KNOO15).Thencheckthedisplacement

betweenthecentersof thespecimenandthevisual

field in theright sleeveby readingthereticlescale

(1graduation= 0.1mm) of KNOO48.

Exit pupil

center Within 20 %of the

objective’sexit pupil

diameter

Settheinterpupillarydistanceto about62mm,

combinethecenteringtelescope(KXOO29)plusthe

KNOO48accessoryadapter-2,themicroscopeframe

(product),andtheobjective(4x or 10x).Then

checkthe displacementbetweenthecenterof the

objective’sexit pupil diameterandthecrosshairs

centerof thecenteringtelescope.

‘ubelength Parfocality t 0.25mm Settheinterpupillarydistanceto about62mm

(referto theaboveitemfor theinterpupillary

distanceadjustment),combinethestandard

eyepiece(KNOO38t FT-36),themicroscopeframe

(product),andthestandardobjective(KiiOO16).

Thenchecktheparfocality displacementin theleft

andright sleevesby readingthehelicoidscaleof

K?JOO48.

Difference lessthan1mm Setthescalering at “0”. Putarigid flat plateacross

betweenleft theleft andright sleeveendface,inserta 1mm

andright thicknessgaugebetweentheflat plateandthetube

tubelength surface.If theclearanceisgreaterthan1mm, the

unit

out

specifications.

CH3-B145 C. INSPECTION STANDARD

2. Use of Jigs and Tools

Measurirrclthe interpupillary distanceworking force Tensiongauge

Pull in

the closestate.

Tie astrkg around the sleeve

periphery and pull with the

tensiongauge.

Checkino,the left/right optical axis I

/-KN0048

Objective (4x or 10x)

Crossmicrometer or

Test plate

(Note) Whenusingthetensiongaugeto

measureintheopenstate,add

about1OOgtothemeasurement

value(inthecaseof a3kg

tensiongauge).

Pull in the openstate.

(Checking the absoluteoptical axis1

(j/100 mm concentric circles)

c-2

CH3-Bl45 C. INSPECTION STANDARD

FT-36

[Checking the tubelength

Checking the exit pupil center ’

Use theIWO048

accessoryadapter-tupsidedown.

Objective (4x or 10x)

c-3

01.10.1997

CH3-B145 D. DISASSEMBLY AND ASSEMBLY PROCEDURES

1. Entire Disassembly and Assembly

2 +

(^“,

-m\

‘* 6

D-l

01.10.1997

CH3-Bl45 D. DISASSEMBLY AND ASSEMBLY PROCEDURES

No. Partsname

o COVER-R

@ COVER-L

@ COVER-H

@ DIVISION PLATE

@ HELICOID ASS’Y

@ SCALERNG

0 HELICOID

Screw Grease Adhesive Remarks

3PUTS2X4SB(‘l) 3 PCS.

3PUTS2X4SB(*2) 3 PCS.

CUTB3XlOSA(*3) 1pc.

Refer to D-4 for the

assemblyprocedure.

CUK3X6SB(*4) 2 PCS. Refer to E-8 for the

repair procedure.

ACU3X3SA(*5) ,2PCS. Refer to E-15 for the

repair procedure.

@ SLEEVE-R ASS’Y CUK3X6SB(*6) 2 PCS. Refer to E-5 for the

repair procedure.

@ SLEEVE-R ACU3X3SA(*7) 2 PCS. Refer to E-14 for the

repair procedure.

t@ OC MOUKI’-R

0 PRISM-R ASS’Y CUK3X6SA(*s) 2 PCS. To bepushedall the

way in the arrow

direction

D PRISM-L ZS’Y CUK3X6SA(*9) 2 PCS. To bepushedall the

way in the arrow

direction

B ADJ.SCREW ACU3XSSA(* 10) 2 PCS. Refer to E-17 for the

repair procedure.

@ SPRING W-ASHER

D WASHER

B FIXNGRKG

D C-RING

@ PRISM MOUNT-R

@ WASHER

OT1595

D-2

CH3-BIG D. DISASSEMBLY AND ASSEMBLY PROCEDURES

f-‘ \

No. Partsname

@ PRISM MOUNT-L

Screw Grease Adhesive , Remarks

@iI C-RING

@ SHAFT

@ FIXNGPLATE

@ PRISM

@ DIAPHRAGM

@ PRISM

OT1595

CUK3X6SA( *11) 4 PCS. Refer to E-10 for the

repair procedure.

CUTS3X6SA( *12) 1pc.

OT1873 To bepushedall the

way in the arrow

direction.

Refer to E-12 for the

repair procedure.

3PUTS2X4SB(* 13)2 PCS.

@ DUSTPROTECT’OR .

@ BODY ’

(“

D-3

CH3-Bl45 D. DISASSEMBLY AND ASSEMBLY PROCEDURES

2. Division Plate Assembly Procedure

2-1 Stick the DIVISION PLATE 0 in the following procedure.

(1) lMiGmize the interpupillary distance.

(2) Stick the DIVISION PIATE~so that the ROUND PROJECTION@ of the sleeve-R

assembly and the ROUND PROJECTION @ of the helicoid ring assemblyreadthe same

graduation of the division plate.

3 /

d I \

( 3

yz?J

f@y \

I Lo --p

! !

f-@ \

Minimum

* I

D-4

CH3-Bl45 E. REPAIR PROCEDURE

1. Optical Adjustment Procedure

OPTICAL ADJUSTMENT REQUIRED FOR CH3-BI45

...........................y. ...........................................................................................................................................................................................................

3UTLNE I

..........................2 [Leftsleeve) fEGj

Changethe mount&g position to adjust the

Changethe mounting position to adjust the absolute optical axis (center of standard

left/right optical axis.

revolving axis.

Adjust the tubelength

(Rightsleeve:movethesleeve-Rvertically.) 1

(Left sleeve:changethehelicoidscaleposition.)

...................................I...............................................................................................-......................................................................................................

‘ROCEDURE ; .

...................~...............f

1 Adjust the revolving axis by changingthe right sleeveposition. f Refer to E-2.

2 Adjust the left/right optical axis by changingthe left sleeveposition. i Refer to E-7.

3 Adjust the absoluteoptical axis by changingthe BI unit mounting position. i

iRefer to E-10.

4 Checkthe exit pupil center. [Refer to E-12.

5 Adjust the tubelength in the left andright sleevesrespectively. i Refer to E-13.

E-l

01.10.1997

CH3-B145 E. REPAIR PROCEDURE

1-l Adjusting the revolving axis

PREPARATIOS i

,...._............................-.: :................

................................

............................

X Insert thestandardeyepieceinto the

rig,ht

sleeve.

! X Change the interpupillary

f distance by fully opening the

i right sleeve (seethe illustration).

Objective(4x or 10x)

Test plate(3100 mmconcentriccircles

Align the specimen center with the cross hairs center of the

standardeyepieceby turning thecontrol knob of the stage.

Before adjustment After adjustment

Specimencenter

Cros hairscenterof standardeyepiece

COntrol.knob-,

E-2

CH3-B145 E. REPAIR PROCEDURE

3ARCHING FORTHE REVOLVING AXIS CEINTER i

.......................-........l...............................................................................................2

) Checking the optical axis displacementby the revolving axis.

Work Imageseenthrough thestandardeyepiece

Ikadually reduce the interpupillary distance i The centersare aligned at

vhile observing through the standard

:yepiece. / first. . The centers are displaced a?

shown below. i

:ion

) Searchingfor the revolving axis center from the optical axis displacement amount and direcl

checkedin (1) above.

le revolving axis ten

shown below When the interpupillary distance is

reduced, the concentric circles center

moves from B to A.

The revolving axis center “0” is located (

the left-hand side of the moving direction

(When the interpupillary distance is

increas’ed,the revolving axis center “0” i:

located on the right-hand side of the

moving direction.)

The triangle formed by A, B and 0 is

always constant in shape.

- Revolving axis triangle

The revolving axis center can be found

simply by adopting this triangle.

...............................,........................................o Revolving axis trianpJe _......._........,.....................................................................

Revolving

axis center

n -1

Remember this triangle shape and

use it when finding the revolving axis

center after the step (1).

AB:AO = 1:1.3

i_.__.._____..__..._:.___.....

Reference ~.__..__._____._____.__......I

OAB = 65”

‘.....................................................................................:

Cross hairs center f3 “ Specimen

of standard evepiece center

..............................I......................................................................................................._......................................................................................

..:

E-3

01.10.1997
