5x Optical Zoom It’s amazing to see 5x optical zoom in a digital camera
this thin. Plus, you get 5.6x digital zoom, for a total seamless zoom
capability of 28x.
Digital Image Stabilization Mode Capture crisp, clear pictures with
high ISO sensitivity and fast shutter speed even if your subject is
moving or if camera shake occurs.
All-Weather Shoot in rain or shine, at the beach or on the slopes.
Sealed and coated in all the right places, the Stylus®740 resists
water, snow and dust.
Bright Capture Technology Low light is no problem. Even when it’s
too dark for your eyes to see, you can preview your subject clearly on
the LCD, then capture an image that’s clear and bright without having
to use a flash. Plus, Bright Capture Movie lets you record the moments
in the dark even after the candles are blown out!
7.1 Megapixel CCD Capture subtle detail in high resolution and create
larger printed images without loss of clarity.
2.5” LCD Previewing, composing, shooting and sharing are so much
easier and more enjoyable with this bright, premium-sized LCD.
TruePic TURBOTM Image Processor With this exclusive technology,
you not only get truer colors – you also get quicker start-up and shutter
release times so you can shoot faster.
27 Shooting Modes including QuickTime®Movie with Sound Take
the best shots in any situation with advanced shooting options such as
Landscape, Portrait, Indoor, Night Scene and more.
Built-In Help Guide Abrief in-camera description helps you quickly
choose the ideal setting for each situation and purpose. An improved
Shooting Guide even sets the camera for you automatically.
One-Touch Easy Print Connect to any PictBridgeTM-enabled printer
and enjoy photo lab quality prints, fast. No computer needed.
Incredibly thin. Powerful zoom. Irresistible.
1.7
Megapixel
Effective Zoom
Optical
28 x
Optical & Digital
Total Zoom
5 x
Auto
Connect
All-Weather
Construction
5.2
Color
LCD
”
Digital
Image Stabilization
Movie
With Audio
Olympus combines the latest in zoom lens technology with a
sleek and stylish body to bring you an ultra-compact 5x optical
zoom digital camera.
Ultra-Compact 5x Zoom
SeeIt Before You Shoot It: See what you’re shooting even in the
dark. When you’re ready, just frame it and take the picture.
Bright Capture Technology
Capture Bright Images: Compose and shoot bright, clear photos
in dim light, and even record movies.
Digital Image Stabilization Mode lets you capture sharp images free
from the blur sometimes caused by camera shake or moving subjects.
Digital Image Stabilization
Stylus®740
5x
3x 5x
WithWithout
WithWithout
WithWithout

Olympus Digital StillCameras can be used with confidence wherever you go. They are backed by a one-
year repair warranty service that is available worldwide. Please contact our service center or check the
Authorized Distributors list for service and applicable areas of service. May not be available in all areas.
Specifications subject to change without notice or obligation on the part of the manufacturer.
©2006 Olympus Imaging America Inc. All rights reserved. Printed in the United States of America. Olympus and
Stylus are trademarks or registered trademarks of Olympus Corporation, Olympus Imaging America Inc. or their
affiliated entities. Alltrademarks and registered trademarks listed herein are the property of their respective holders.
D1346-0806
Available Accessories
Package Contents
Stylus 740 Digital Camera
LI-42BLi-Ion Rechargeable Battery and Charger
USB Cable, Audio/Video Cable
Wrist Strap
Manual
CD-ROM (OLYMPUS Master Software)
Warranty Card
getolympus.com
Imager: 7.1 Megapixel (effective), 7.4 Megapixel gross,
1/2.3” (1.10cm) CCD
Lens: 6.4 – 32.0 mm (36 – 180mm equivalent in 35mm photography),
6lenses in 4 groups, 4 aspherical lenses
Zoom: 5x Optical Zoom + 5.6x Digital Zoom (seamless to 28x)
Aperture Range: f3.3 – f5.0
LCD: 2.5” (6.4cm) Color LCD, approx. 215,000 pixels
Focus System: CCD Contrast Detection
Focus Range: Normal Mode: 27.6” – infinity (0.7m – infinity)
Macro Mode (Wide): 7.9” – infinity (0.2m – infinity)
Macro Mode (Tele): 23.6” – infinity (0.6m – infinity)
Super Macro Mode: 1.2” – 7.9” (3 – 20cm)
Focus Mode: iESP Auto, Spot AF
Shutter Speed: 1/1000 sec. – 1/2 sec. (up to 4 sec. in Night Scene mode)
ISO: Auto, 80, 100, 200, 400, 800, 1600*1(equivalent)
Metering Mode: Digital ESP Auto Multi-Pattern TTL, Spot Metering
White Balance: iESP2 Multi-Pattern Auto TTL, Pre-Set (Daylight, Overcast,
Tungsten, Fluorescent1, Fluorescent2, Fluorescent3)
Exposure Compensation: ±2 EV steps in 1/3 EV steps
Recording Modes: Still Image: JPEG
Movie: QuickTime®motion JPEG
Adjustment Resolutions: 3,072 x 2,304, SHQ / HQ
2,560 x 1,920, SQ1
2,304 x 1,728, SQ1
2,048 x 1,536, SQ1
1,600 x 1,200, SQ2
1,280 x 960, SQ2
1,024 x 768, SQ2
640 x 480, SQ2
Shooting Modes: 27 Shooting Modes: Auto, Program Auto, Scene Preset
(Portrait, Landscape, Landscape & Portrait, Night Scene,
Night & Portrait, Sport, Indoor*1,Candle*2,Self-Portrait,
Available Light Portrait*2,Sunset, Fireworks, Museum,
Cuisine, Behind Glass, Documents, Auction*3,Shoot &
Select1, Shoot & Select2, Beach & Snow, Under Water Wide1,
Under Water Wide2, Under Water Macro), Digital Image
Stabilization Mode*1,Movie
Panorama: Up to 10 frames automatically stitchable with OLYMPUS
Master Software when using Olympus brand xD-Picture Card™
Sequential Shooting: High speed: 3.5 frames per second up to 11 frames in SQ1
mode
Normal speed: 0.9 frames per second, 6 frames or more in
HQ mode
Shooting Assist Functions: Histogram, Frame Assist
Movie Mode: QuickTime®Movie with Sound: 640x480/15fps, SHQ;
320x240/15 fps, HQ; 160x120/15fps, SQ
Image Processing: TruePic TURBO™ Image Processor
Pixel Mapping: Automatic Pixel Mapping (APM) available via menu setting
Noise Reduction: Set automatically at shutter speeds of 0.5 seconds or longer
Image Playback: Still Image: Single, Index Display (4/9/16/25), Up to 10x
Enlargement, Slideshow, Rotation, Calendar, Album,
Histogram
Movie: Normal, Reverse, Frame-By-Frame
Playback Edit Effects: Still Image: Resize, Rotation, Red-Eye Fix, Black & White,
Sepia, Frame, Label, Calendar, Brightness, Saturation
Movie: Frame Index
Direct Printing Options: PictBridgeTMand DPOF
Flash: Built-in
Flash Modes: Auto (for low-light and backlit conditions), Red-Eye
Reduction, Fill-In, Off
Flash Working Range: Wide: 12.5 ft. (3.8m), Tele: 8.9 ft. (2.7m)
Self-Timer: 12 Seconds/Auto
Settings Memorization: On/Off (Hold changes/Reset to default settings)
Date/Time Calendar: Simultaneous recording into image data, Automatic
up to 2099
Memory: 17MB internal memory
Removable Media Card: xD-Picture Card™ (16, 32, 64, 128, 256, 512MB, 1GB or 2GB)
Outer Connectors: Multi-terminal (USB connecter, Audio/Video output,
DC input*) *Optional DC coupler (CB-MA1) is required.
Auto-Connect USB: 2.0 Full Speed (USB mass storage)
System Requirements: Auto-Connect USB: Windows®98SE/ME/2000PRO/XP with
USB Port, Mac OS®9.0-9.2x/OS X 10.1-10.4 with USB port
Software: Windows 98SE/ME/2000PRO/XP, Mac®10.2 and
higher
Operating Environment: Operation: 32° – 104°F (0° – 40°C), 30% – 90% humidity
Storage: -4° – 140°F (-20° – 60°C), 10% – 90% humidity
Power Supply: Li-Ion Rechargeable Battery (LI-42B), AC Adapter (D-7AC)
with the Optional DC Coupler (CB-MA1)
Size: 3.8” W x 2.1” H x 0.96” D (96mm x 54mm x 24.3mm)
Weight: 4.0 oz. (140g) without battery and media card
*1Works with Bright Capture. *2Works with Bright Capture. Image size is automatically changed to 2,048 x 1,536. *3Image
quality is limited to 640 x 480.
Olympus®Stylus 740 Specifications Stock No. 225845
Stylus®740
Available Accessories
202066 Neoprene Compact Camera Case
200496 Metal Neck Strap
200830 MAUSB-10 xD-Picture Card™/
SmartMedia™ USB Reader/Writer
202084 POL-34 O-ring for PT-034
200346 LI-40C Replacement Charger
200850 D-7AC AC Adapter
202053 CB-MA1 DC Coupler
(For Use With D-7AC)
200372 CB-USB6 Digital Camera USB Cable
(Replacement)
200347 CB-AVC3 Digital Camera A/V Cable
(Replacement)
202044 2-Year Extended Digital Warranty
202057 Stylus Digital Accessory Kit
Includes Case, Battery and Metal
Neck Strap
Olympus
xD-Picture CardTM
256MB
512MB
1GB
2GB
Leather Case
(Vertical,
Top-Loading)
200398
LI-42B
Lithium Ion Battery
202034
PT-034
Underwater Housing
202070
MAUSB-200
xD-Picture Card
USB Reader/Writer
202049
