OLYS MPPT15060 User manual

MPPT15060
MPPT
330
232
50
205
87.5
Solar Charge Controller
USER MANUAL
Thank you very much for buying our product ,Please read
thoroughly before using the prouuct
Description of Functions
1. Suitable for charging 12V/24V/36V/48V lead-acid batteries, including GEL, Sealed, Flooded battery
2. Mainly suitable for off-grid solar power generation systems, such as: home solar power generation system, solar RV power generation,
boat, unattended base stations, outposts and so on.
3. MPPT charging technology, three-stage charging mode, constant current charge-constant voltage charge-floating charge,
effectively improve the battery charging efficiency. It is more portable than ordinary PWM charging.
4. Suitable for high voltage input, PV voltage up to 150 V (At the lowest temperature -25℃).
5. input two Channel solar panels at the same time.
6. This product adopts intelligent single-chip microcomputer design, and all workflows are controlled by software, which can achieve
high precision and high reliability.
7. The charging mode of high-efficiency MPPT is adopted to ensure that the battery works in the best state and greatly prolong the
service life of the battery.
8. It has full automatic control such as overcharge, overdischarge, overload protection, anti-reverse protection and so on
The charge regulator is intended for use in photovoltaic systems with 12V or 24V nominal voltages, It shall be used
with vented or sealed (VRLA) lead acid batteries only.
Safety Recommendations:
1.Batteries store a large amount of energy. Never short circuit a battery whatever.
2.Batteries can produce flammable gases. Avoid making sparks, using fire or any naked flame. Make sure that the battery
room is ventilated.
3.Avoid touching or short circuiting wires and terminals. Be aware that the voltages on specific terminals and wires can
be up to double of battery voltage. Use isolated tools. Stand on dry ground and keep your hands dry.
Installation
Attentions
Please installed in the room, avoiding direct-clearance,
do not install in the wet environment, when use it outdoor,
please install controller and batteries in the same place,
and the batteries installed in the same place, the controller
can measuring the battery temperature, charge
voltage regulation.
Attention:
1. Screws specifications M4
2. Make sure heat-location were not l blocke

Part name
1
2
3
45
6
789
10 111213
1
2
3
4
5
6
7
8
9
10
11
12
13
LCD
Φ5 Mounting hole
Load status（red）
Chrge status（green）
Input PV1
Battery terminal
Dry contact terminal
RS485 Communication
Attention
!
■Input solar panel matrix power
■Grounding operation.
Input PV2
Forward or Increase
Backward or Reduce
Setting or Enter
Load ON/OFF or Ese
1. the MPPT solar controller has the function of simultaneous input of two solar panels. In theory, the two solar panels can input
different open circuit voltages and different power, and both can work normally. however, in order to balance the overcurrent
inside the controller, it is strongly recommended that the solar panels of the same specification be used in both ways, which is
beneficial to the service life and efficiency of the controller.
2.The controller has a limited power function, and when the total power of the two solar panels or each input solar panel exceeds
the rated power, the controller will limit the charging power to the rated power, so it is strongly recommended not to connect to
solar panels that exceed the rated power.
■Connect the wire
1.For the specification of the connecting cable, refer to the installation instructions.
2.When the connection cable between the solar panel or controller and the battery is relatively far away, the use of a thicker cable
can reduce the voltage drop and increase charging efficiency
■Installation and connection
Warning: the danger of explosion!
Never install the controller and thebattery in the same airtight space! Nor should it be installed in an airtight battery where gas
may accumulate the place.
Warning: high pressure is dangerous!
PV arrays may generate high open-circuit voltages. Disconnect circuit breakers or safety before wiring, and be careful
during wiring.
Note: when installing the controller, make sure that enough air flows through the heat sink of the controller, and there is at least
150mm space above and below the controller to ensure natural convection and heat dissipation.
If installed. In a closed box, it is necessary to ensure reliable heat dissipation through the box.
MPPT15060 is a common positive design controller. The electrode of solar panel and battery can be grounded at the
same time, or any terminal can be grounded. In practical application, the terminal can also be grounded.
It is not necessary to ground separately, but the shell must be grounded during installation, which can prevent external
electromagnetic interference and shell electrification from causing damage to the human body.
positive
positive
■Temperature compensation
Note: when the remote temperature sensor is not connected, the controller will charge or discharge the battery at 25 ℃ by
default, without temperature compensation.
■Modification of battery charging parameters
Note: when selecting the default battery type, the charging parameters cannot be modified. If you want to modify the charging
parameters, the battery type must select "Custom".
■Overheat protection
When the internal temperature of the controller is more than 80 ℃, the controller stops working. When the temperature drops
to 60 ℃, the controller resumes charging. If the overtemperature protection is repeated three times, the charge will be stopped
completely. which needs to be reset manually or can be recharged the next day.
1 4
14 Temperature sensor

Installation instructions
Battery connection
Solar panel connection
System expansion
！Warning
+
-
Relay
Load
2
FUSE
+ -
+-+-+-
Pv1 P V 2
+ -
+-+-+-
+ -
+-+-+-
1.The wiring order must be in the prescribed order, first connect the
battery, and then connect the solar panel. when you disconnect the controller
you must first disconnect the solar panel. then disconnect the battery, and the
two groups of solar panels are in no order.
2. Batteries and solar panels must be connected to fuses or circuit breakers.
Recommended fuse specification: Battery:120A, Solar panels per channel: 60A
3. In the process of operation and installation, the phenomenon of short circuit
of storage battery or solar panel is strictly prohibited.
Battery type: controller can only use lead-acid batteries, lithium battery can not use
Battery voltage: it can automatically adapt to 12V , 24V , 48V battery, if you need to
use 36V battery, you must set the battery voltage to 36V on the display screen.
Batteries in series and in parallel: if batteries need to be connected in series and
parallel, ensure the capacity of each battery the voltage is basically the same.
Mixed use of batteries of different specifications is not recommended, which can easily
lead to uneven charging of individual batteries, aging and damage ahead of time.
Wiring method: it is recommended to first connect the fuse or circuit breaker to the connection line,
then fix the controller end, and finally connect to the battery to ensure that the battery is not allowed
to short circuit in the whole process, otherwise it may cause serious safety accidents.
Connection cable: the connection cable between the controller and the battery is as short as possible,
which can effectively reduce the cable loss and reduce the voltage difference.
Recommended cable specifications: length < 4m: 8mm , length > 4m: 10mm
2
1. The controller has two solar panel input ports, each with a maximum charging current of 30A
It can be connected arbitrarily, and the controller can work normally if only any one of the solar panels is connected.
2. For details of the maximum open-circuit voltage and power of the solar panel, see the parameter table below.
3. The battery must be connected before connecting the solar panel.
4. The size of solar panel cable is more than that of 4mm.
Load connection
1.The controller does not have a load output port directly, but it has a dry contact port,
user can control the external relay or the controller signal as the external load
through the dry node.
2.The output voltage of the dry contact port is the voltage of the battery and the output
current is 2A.
3. Verify that the working voltage of the externally connected relay or load control signal
is consistent with the output voltage of the dry contact port.
3. There are five modes of dry contact signal output: manual mode, pure light control mode,
light control on + time control off. Single-period real-time time control, dual-period
real-time time control
1. Multiple controllers are connected in parallel to share a battery pack. But each controller must be connected to a
separate solar panel matrix.
2.In the expansion system, it is recommended that the specifications of each controller and the solar panel matrix be the same,
which is conducive to charge equalization.
FUSE
FUSE
Pv1 P V 2Pv1 P V 2
f u s e
+ -
+-+-+-
PV1P V 2
f u s e
fuse

K1K2K3K4
Parameter browsing
K1
K1
K2
K1
K2
K1
K2
K1
K2
K1
K2
K1K2
K1
K2
SET Esc
SET
Esc
Real time
K1
K2
Battery voltage
K3K1
K2
Boost voltage
K1
K2
Floating charge
K1
K2
LVD
K1
K2
Load work mode
K1K2
Real time
K1
K2
K1
K2
K1
K2
Light control
voltage
K1
K2
K 4
Icon description
Solar panel voltage > light control voltage, which means daytime.
Operation instruction
Key function
Forward or Increase
Backward or Reduce
Setting or Enter
Load ON/OFF or Ese
K2
K3
K4
Solar panel voltage > light control voltage, which means at night
Charging, horizontal stripes rolling up dynamically
Load ON
Load OFF
Press K1 or K2 to cycle forward or backward to browse the current working parameters or set working status.
Battery voltage PV1 voltage PV2 voltage Charge current PV power
Ambient temperature
Charging capacity
(AH)
Charging capacity
(WH)
Parameter setting browsing
In the battery voltage display interface, press the K3 button for 5 seconds to enter the interface of the parameters you need to set,
press K1 or K2 to cycle to display the specific parameters you need to set, press K4 or after 10 seconds of no operation, you can
exit the parameter settings browsing interface.
Battery type Load r
voltage
econnect
Communication
address
Battery voltage
No operation
for 10 seconds
Press for
5 seconds

Set boost charge voltage
K3K1
K2
K1
K2
value range: 12V battery: 14-15V , 24V battery: 28-30V, 36V battery: 42-45V, 48V battery: 56-60V
K1
K2
value range : 12V battery: 13-14V, 24V battery: 26-28V, 36V battery: 39-42V,48V battery: 42-56V
K3
K1
K2
Vale range: 12V battery: 10.5-11.5V, 24V battery: 21.0V-23.0V, 36V battery: 31.5V-34.5V , 48V battery: 42.0V-46.0V
K3
K1
K2
K1
K2
K1
K2
K1
K2
K1
K2
Value range: 12V battery: 11.5V-12.5V , 24V battery: 23.0V-25.0V, 36V battery: 34.5V-37.5V , 48V battery: 46.0V-49.0V
K3K1
K2
K1
K2
K2
K1
K2
Sealed battery Flooded battery
K1
K2
Custom definition
K3K1
K2
GEL battery
K1
Parameter setting operation
In the battery voltage display interface, press the K3 button for 5 seconds to enter the parameter setting browsing interface
(see < Parameter Settings Interface Browse >), and press K1 or K2 to cycle to the parameter interface you want to set.
Short press K3 button (SET), display "SET" font flashes to indicate that you can start to change the current parameter, press
K1 or K2 to modify the parameter value, and then press K3 button (set button) save the current settings, and the word "SET" will
stop flashing, and so on, you can set other parameters. Press K4 key to directly exit the current parameter setting interface.
Setting battery type
Set a precision of 0.1V, which increases or decreases 0.1V every time you press K1 or K2.
Indicates that the font "SET" flashes
Set floating charge voltage
Set a precision of 0.1V, which increases or decreases 0.1V every time you press K1 or K2.
Se low voltage protection voltage of battery
Set a precision of 0.1V, which increases or decreases 0.1V every time you press K1 or K2.
Set load reconnection voltage
Set a precision of 0.1V, which increases or decreases 0.1V every time you press K1 or K2.

load work mode 1:manual mode
K3K1
K2
3：
K1
K2
K1
K2
K1
K2
Single period real time control：
Set load working mode
There are 5 load working modes:
1: manual mode: press the K4 button to turn the load output on or off.
2: pure light control mode: the voltage of the solar panel is detected automatically, the load is turned on at dark and the load is
turned off at dawn.
3: light control + time control mode: the load starts the light control, and the load closing time is set by the user.
4: single real time control: Users can set real-time time to enable and close the load.
5: double-time real time control : , users can set two real-time periods to output and turn off the load of the controller, such as
8: 00 a.m. to 10:00 and 2: 00 p.m. to 4: 00 p.m.
Set operation instructions:
Manual mode and pure light control mode do not need to set the time, and the other three modes need to set the working time.
The operation are as follows:
Light control + time control: Turn the page to the load working mode to light control + time control interface (mode 3), press K3 key,
"SET" and "H" font flash, press K1 or K2 key to set the number of hours, the setting is finished.
Then press K3 key, "SET" and "M" font flash, press K1 or K2 key to set the number of minutes, after setting, press K3 key again,
“SET" and "M" stop flashing, save finished
Turn the page of the load working mode to the single real time control interface (mode 4)
1.Press K3 key, "H" flashing, "ON" on, short press K1 or K2 key to cycle change hours: 0- - 23.
2. Press K3 again, "H" stops flashing, "M" flashes, press K1 or K2 to change the number of minutes: 0--59.
3. Press the K3 key again, when the load time is set, the “ON” icon is off; the “OFF” icon is on, the “M” icon stops flashing, the
“H” icon is flashing, and press K1 or K2 key to modify the cycle number of hours: 0--23.
4. Press the K3 key again, the “H” icon stops flashing, the “M” icon flashes, press K1 or K2 key to change the number of minutes in a
cycle: 0--59.
5. Press the K3 key again, the SET and M icons stop flashing, the load time is set, and save the settings.
Dual-period real-time control mode
Turn the page of the load working mode to the dual-period real time control interface (mode 5)
1. Press the K3 key, the “H” icon flashes, the “ON1” icon is on, press K1 or K2 key to modify the cycle number of hours: 0--23.
2. Press the K3 key again, the “H” icon stops flashing, the “M” icon flashes, press K1 or K2 key to change the number of minutes
in a cycle: 0--59.
3. Press the K3 key again, when the load time 1 is set, the” ON1” icon is off, the “OFF1” icon is on, the “M” icon stops flashing,
the” H” icon flashes, and press K1 or K2 key to modify the cycle number of hours: 0--r23.
4. Press the K3 key again, the” H” icon stops flashing, the “M” icon flashes, press K1 or K2 key to change the number of minutes
in a cycle: 0--59.
5. Press the K3 key again, the “M” icon stops flashing, the load time 1 is set up, the “H” icon flashes, the “ON2” icon is om, press
the K1 or K2 key to modify the cycle number of hours: 0--23.
6. Press the K3 key again, the “H” icon stops flashing, the “M” icon flashes, press K1 or K2 key to change the number of minutes
in a cycle: 0--59.
7. Press the K3 key again, when the load time 2 is set, the “ON2” icon is off, the “OFF2” icon ison, the “M” icon stops flashing, the
“H” icon flashes, press K1 or K2 key to modify the cycle number of hours: 0--23.
8. Press the K3 key again, the “H” icon stops flashing, the “M” icon flashes, press K1 or K2 key to change the number of minutes
in a cycle: 0-- 59.
9. Press the K3 key again, the “SET” and” M” icons will stop flashing, and the load time 2 will be set up. Save the settings.
2:pure light mode Light control +
time control
4: Single period
real time control
5: Dual-period
real-time control
mode
ON OFF
Load OFF
K4K4
短按
Load ON
Manually turn on and off the load
When the load mode is manual mode 1 and is not in the "alarm function" period, short press the K4 button to turn on the load,
while in ot her modes, the K4 button is invalid

night detection
voltage 6V
K3
range： 12V: 6-11V, 24V:12-23V, 36V: 18V-35V, 48V: 24V-47V, Precision:1V
K1
K2
K1
K2
K1
K2
7V8V11 V
K3
Wh set zero
K3
Battery temperature
K3
Charge current
K3
Communication
address
“SET”flashing
K3K1
K2
K1
K2
K1
K2
K3
12V
K1
K2
K1
K2
K1
K2
K1
K2
24V 36V 48V
COM 4
Range： C01-C247
Set real-time time
K3K1K3K1K3
Real-time "SET","H"flash set hours
K2K2
Real-time time can be stored inside the controller, which can be kept consistent with the real time even if the controller is powered off,
using load single-period control and dual-period control mode must be set to the correct real-time time.
"SET","M"flash set minute icon stops flashing
Set Communication address
COM 5 COM 247
Set battery voltage
If you use 12V battery, 24V battery, or 48V battery, you don't need to set it. The controller can automatically identify the battery
voltage. If the battery is 36V, you must set the battery voltage here, otherwise. The controller will report an error and the controller
will not work
Battery voltage Automatic
identification
Set night detection voltage
The night detection voltage is the voltage of the solar panel ,when the load is turned on and output. it needs to be used
when the load working mode is set to pure light-control or light-control + time control
Charging capacity set to 0 (AH,WH)
At the interface of AH number or WH number, press the K3 key (SET) for 5 seconds, and the charge capacity WHs and
AH numbers are cleared to zero at the same time.
charge capacity
Press for 5
seconds Wh set zero
Press for 5
seconds
charge capacity
AH
Internal temperature and ambient temperature cycle display
You need to press the K3 key for 5 seconds . %: indicates the internal temperature of the controller.
ambient temperature
Press for 5
seconds
Restore factory settings
At the charging current interface, press the K3 key for 5 seconds to display "GO". When "GO" disappears,
all parameters of the controller return to the factory default values.
Press for 5
seconds
Restore factory
settings

Error code Buzzer Error reason
E01 Ring every 3 seconds for one minute system voltage error
E02 Over-temperature turn-off charging
E03 The buzzer rings once a second,
and the sun icon blinks. Solar panel overvoltage off charging
E04 Battery overvoltage turn off load
E05 Battery overvoltage turn off charging
E06 rings once every 3 seconds, and the empty
battery icon flashes.
E07
E08
RS485 Communication
A1
A2
A3
A4
A5
A6
A7
A8-A9
A10
A11
A12
A13
A14
battery type
charge current
PV1 voltage
PV2 voltage
PV power
total charge capacity AH
Daily charging capacityWH
Total capacity WH
PV status
battery status
Controller temperature
Load status
charge status
set load work mode
1
set battery type
2
set battery voltage
3
set night detection voltage
4
set communication address
5
Restore factory settings
6
The charging capacity is clear
7
Charging on and off
8
Get battery charging parameters
9
Modify battery charging parameters
10
Error code
When the following error occurs in the controller, the E01-E08 error code is displayed, and the buzzer alarms synchronously,
and the alarm continues until the error is corrected. Press K4 to exit the wrong generation interface, return to the main interface
and turn off the buzzer. Start timing. If the error persists after 10s, the alarm will continue.
Ring every 0.5 seconds for one minute
rings once in 0.5 seconds,
and the full battery icon flashes
rings once in 0.5 seconds,
and the full battery icon flashes
Battery low voltage shut-off load
--
-- - -
--
Through the standard RS485 communication protocol, the controller
can send the operating parameters of the controller to the the terminal
equipment, the terminal equipment can also send instructions to modify
the working parameters of a part of the controller.
Communication protocol continuous sales staff
Parameters that can be read by terminal equipment
The parameters that can be modified by the terminal
device are as follows
charge status (green)
load status(red)
OFF：Load off
Charge status（green）
ON： Charging
OFF：no charging
fasht flash：Charging at constant voltage
slow flash： Floating charging
Load status LED（Red）
ON： Load on
LED status
1 2 3 4 5 6 7 8
RJ4 5 Pin definition
PIN
1
2
3
4
5
6
7
8
12V
RXD
TXD
GND
B
GND
A
NC
Definition

Parameter
Note: the parameters in the following table are 12V, 24V, 36V, 48V need to be multiplied by multiple.
Model MPPT15060
System voltage 12V/24V/36V/48V
Max.charge current 60A, 30A per channel
Max. input power of solar panel 12V:780W, 24V: 1560W, 36V: 2340W, 48V:3120W
Max. input voltage of solar panel 150V(At the lowest temperature), 138V(25℃)
Battery type GEL Sealed Flooded user
Overvoltage shut-off load 16V
Overvoltage shut-off charging 15.5V
Overvoltage recovery voltage 13.7V
Equalization charge 14.6Vno 14.8V Boost voltage+0.2V
Boost charge 14.4V14.3V 14.7V 14-15V
Float charge 13.5V13.8V 13.5V 13-14V
Boost charge recovery 13.2V
Low voltage recovery load output 12.5V 11.5V-12.5V
Low voltage protection （shut-off load）11V 10.5V-11.5V
Equalization charge time 120min
Temperature compensation -3mv/℃/2V
Load work mode manual,light control+time contorl, Real-time timing control
Night detection voltage 6V
Dry contact terminal output voltage Same as battery voltage, current up to 2A
Display mode LCD+LED
Communication mode RS485，RJ45 interface
Temperature sensor(optional)3m
Working temperature -20℃-55℃
Demension 330mm×232mm 87.5mm×
Weight 5kg
SHENZHEN OLYS COMPANY LIMITED
Tel: [phone]
E-mail: [e-mail]
Address: 5 floor, B building of Sheng De Industrial Park,Lang Kou, Da Lang, Long
Hua New district, Shenzhen City, China
