Omcan FP-IT-0003 User manual

Bowl Cutter
Model FP-IT-0003
Item 10830
Instruction Manual
Revised - 12/02/2016
Toll Free: 1-800-465-0234
Fax: [phone]
Email: [email protected]
www.omcan.com

2
Page
--------------------------------------------------------------------------- 3 - 4
--------------------------------------------------------------------------- 4 - 5
---------------------------------------------------------------------- 5 - 6
-------------------------------------------------------------------------------------------- 6
--------------------------------------------------------------------------------------------- 6
------------------------------------------------------------------------------------ 6 - 7
------------------------------------------------------------------------------- 8 - 9
---------------------------------------------------------------------------- 10
---------------------------------------------------------------------------- 11
Table of Contents
Section
General Information
Safety and Warranty
Technical Specications
Installation
Operation
Maintenance
Parts Breakdown
Electrical Schematics
Warranty Registration
Model FP-IT-0003

3
General Information
Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan
and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or
negligent use of this equipment. The product shall only be operated by someone over the age of 18, of
sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct
operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the
machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of
the machine while in operation.
CHECK PACKAGE UPON ARRIVAL
Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the
external packaging, open carton to ensure all ordered items are within the box, and there is no concealed
damage to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),
please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may
initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be
lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse
for damaged products that were shipped collect or third party.
Before operating any equipment, always read and familiarize yourself with all operation and safety
instructions.
Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save
these instructions for future reference. Also save the original box and packaging for shipping the
equipment if servicing or returning of the machine is required.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et
Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne
ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de
plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour
utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication
de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine
ou des personnes à proximité de la machine pendant son fonctionnement.
VÉRIFIEZ LE COLIS DÈS RÉCEPTION
Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage
n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés
sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises
manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant
d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager
une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine
doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents
d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli
par un tiers transporteur.

4
General Information
Safety and Warranty
Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations
et les consignes de sécurité.
Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces
instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour
l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.
---------------------------------------------------------------------------------------------------------------------------------------------------
Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba
Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona
inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona
mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido
entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.
Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la
máquina mientras esta en el funcionamiento.
REVISE EL PAQUETE A SU LLEGADA
Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el
empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la
caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes
o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro
de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre
los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se
muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron
a recoger por terceros.
Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de
funcionamiento y seguridad.
Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para
salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el
envío del equipo si servicio técnico o devolución de la máquina que se requiere.
The following mechanical safety devices have been applied:
• Protection of transparent plastic material.
The following electrical safety devices have been applied:
• Start up with start/stop button that must be pressed again to restart the machine after an outage;
• Magnetic cutout on the transparent lid preventing machine startup when the lid is open;
• Cutout switch below the vessel preventing machine from starting without positioning the vessel.

5
Technical Specications
This machine is composed by a base supporting a vessel containing two rotary blades secured to a spindle.
The products are minced or mashed according to the length of time the blades are allowed to rotate.
All the components of this machine are made from polished and anodized aluminum, from stainless steel and
from food-compatible plastic material.
The blades are driven by an electric motor which is ventilated, while movement transmission is entrusted to a
longitudinally grooved belt.
Safety and Warranty
Correct functioning and full compliance to the intended service depends on the correct application of the
instructions contained in this manual. The manufacturer waives any liability, either direct or indirect; deriving
from:
• Failure to observe the instructions contained herein;
• Entrusting the machine to non-trained personnel;
• Failure to use this machine in according to the norms currently in force in the country of installation;
• Unauthorized alterations or repair;
• Use of non original accessories and spare parts.
1 YEAR PARTS AND LABOUR BENCH WARRANTY
Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop off to either
an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the
equipment.
Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not
improper use.
WARNING:
The packaging components are classied as normal solid urban waste and can therefore be disposed of
without difculty.
In any case, for suitable recycling, we suggest disposing of the products separately (differentiated
waste) according to the current norms.
DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

6
Technical Specications
The cutter is started and stopped by means of a button connected to an auxiliary control circuit preventing
accidental startup after an outage.
Model FP-IT-0003
Horsepower 0.4 HP
Capacity 2.8 L / 3 QT
Electrical 110V/60/1
Weight 28 lbs. / 12.7 kgs.
Dimensions 21” x 10” x 11.5” / 533 x 254 x 292mm
Item Number 10830
Maintenance
For good mincing performances, the blades must be sharp. If necessary, have them sharpened by a
specialized person. This machine does not require any further lubrication. Should the machine make any
unusual noise after a certain period of time, this may be due to a loosening of the belt. Screw the belt-tightener
on the side of the motor under the base.
Installation
Operation
Place the machine on a suitably plane, smooth and dry surface sufciently strong to support the machine
weight. Install near an outlet complying to local regulations.
Before completing the connections, check that the mains correspond to the data shown on the plate.
• To start the machine, press the green button.
• Insert the food to mince through the special opening on the lid.
• Take into account that prolonged use will mash the products.
• After completion, open the lid by turning the knob on the horizontal bar by ¼ turn to the left, and pull up the
bar.
• Take the blade holding pin away then remove the vessel from its seat.

7
Maintenance
CLEANING THE CUTTER
The cutter must be carefully cleaned at least once a day or more often as necessary. Always wear scratch
proof protection gloves. To clean the machine use only a cloth soaked in water and non-lathery detergent for
dishes with pH at 7-8 and at least at + 30° C.
REASSEMBLING THE CUTTER
Insert the vessel by inserting its small pin in the relevant seat. (ref. 44). Insert the blade holder pin in its seat.
Pull down the lever by turning the knob (ref. 35) by ¼ turn to the right to secure the lid to the vessel.
REFERENCE
Item Number Model Number Description Manufacturer Model Number
10830 FP-IT-0003 Bowl Cutter 3 L / 3 QT 2800 RPM
0.4 HP / 298 W 110V/60/1 C1

8
Parts Breakdown
Model FP-IT-0003 10830

9
Parts Breakdown
Model FP-IT-0003 10830
Item No. Description Position Item No. Description Position Item No. Description Position
38932 Foot for C1 1 38961 Screw for C1 30 38990 Set Screw for C1 59
38933 Bottom for C1 2 38962 Washer for C1 31 38991 Screw for C1 60
38934
18740 Belt for C1 3 38963 Hinge Pin for C1 32 38992 Washer for C1 61
38935 Plate for C1 4 38964 Hinge Support for C1 33 38993 Capacitor & Bracket for C1 62 - 63
38936 Screw for C1 5 38965 Lever for C1 34 38994 Screw for C1 64
38937 Cable for C1 6 38966 Thumb Knob for Lever for C1 35 38995 Block Magnet for C1 65
38938 Washer for C1 7 38967 Washer for C1 36 38996 Magnet for C1 66
38939 Screw for C1 8 38968
15217 Lock Knob for C1 37 38997 Shaft for C1 67
38940 Washer for C1 9 38969 Lever Handle for C1 38 38998
15223 Lid for C1 68
38941 Screw for C1 10 38970 Threaded Shaft for C1 39 38999 Plug for C1 69
38942 Screw for C1 11 38971 Shaft Pin for C1 40 39000 Screw for C1 70
38943 Screw for C1 12 38972 Clip for C1 41 39001 Blade Support for C1 71
38944 Nut for C1 13 38973 Locking Pin for C1 42 39002 Plug for C1 72
38945 Washer for C1 14 38974 Nut for C1 43 39003 Blade for C1 73
38946 Screw for C1 15 38975 Driving Pot for C1 44 39004 Spacer for C1 74
38947 Motor Plate for C1 16 38976 Screw for C1 45 39005 Screws for C1 75
38948 Cam Belt for C1 17 38977
15220 Micro Switch Pin for C1 46 39006 Blade for C1 76
38949 Nut for C1 18 38978 Screw for C1 47 39007 Pot for C1 77
38950 Motor Pulley for C1 19 38979 Micro Switch for C1 48 39008 Strain Relief for C1 78
38951 Set Screw for C1 20 38980 Set Screw for C1 49 39009 Bracket for C1 79
38952 Plug for C1 21 38981 O-Ring for C1 50 39010 Screw for C1 80
38953 Screw for C1 22 38982 Bearing and Shaft for C1 51 39011 Screw for C1 81
38954
15213 Motor for C1 23 38983 Pulley for C1 52 39012 Pin for C1 82
38955 Terminal Clamp for C1 24 38984 O-Ring for C1 53 39013 Complete Assy. for C1 83
38956 On / Off Switch for C1 25 38985 Bearing for C1 54 39014 Nut for C1 84
38957 Switch Assembly for C1 26 38986 Spacer for C1 55 39015 Micro Switch for C1 85
14859 Power Cord for C1 27 38987 Clip for C1 56 39016 Terminal Clamp for C1 86
38959 Housing for C1 28 38988 Clip for C1 57 39017 Screw for C1 87
38960 Magnetic Microswitch for C1 29 38989 Pulley for C1 58 39018 Hallow Cable for C1 88

10
Electrical Schematics
Model FP-IT-0003 10830

11
Warranty Registration
Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,
cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:
Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la
carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:
Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at
the perforation and then send to the address specied below. You can also register online by visiting:
OMCAN
PRODUCT WARRANTY REGISTRATION
3115 Pepper Mill Court,
Mississauga, Ontario
Canada, L5L 4X5
www.omcan.com/warrantyregistration.html
or email to: [email protected]
Purchaser’s Information
Name: Company Name:
Address:
Telephone:
City: Province or State: Postal or Zip: Email Address:
Country: Type of Company:
Restaurant Bakery Deli
Dealer from which Purchased: Butcher Supermarket Caterer
Dealer City: Dealer Province or State: Institution (specify):
Invoice: Other (specify):
Model Name: Model Number: Serial Number:
Machine Description:
Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):
Would you like to extend the warranty? Yes No

Por correo en Canadá
Pour postale au Canada
For mailing in Canada
Por correo en los EE.UU.
Pour diffusion aux États-Unis
For mailing in the US
OMCAN
PRODUCT WARRANTY REGISTRATION
4450 Witmer Industrial Estates, Unit 4,
Niagara Falls, New York
USA, 14305
Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Over the last 60 years, Omcan has grown to become a leading supplier to the food
service industry in Canada and the USA. Our success over these many years is
directly attributed to our established relationships with all of our valued customers
and through providing them with Diverse, Dependable and Proven products.
Omcan continues to help our customers remain competitive.
With associates in North America, Europe, and Asia, our global footprint continues
to expand as we hold to the principle that clients benet from the accessibility
and familiarity of our sales team. In 2013 as our geography and brand recognition
continued to grow, we changed to one name Omcan Food Machinery.
In over 200,000 sq ft of warehouse space we stock over 2,500 quality food
equipment and supplies for the food preparation market.
