Omcan Fw-cn-0010 User manual

Food Warmer

Model FW-CN-0010

Instruction Manual

Revised - 9/8/2014

Toll Free: 1-800-465-0234

Fax: 905-607-0234

Email: [email protected]

www.omcan.com

2

Page

-------------------------------------------------------------------------------- 3

-------------------------------------------------------------------------- 3

-------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------------- 5

----------------------------------------------------------------------------- 6 - 8

-------------------------------------------------------------------------------------------- 9 - 10

---------------------------------------------------------------------------- 11

Table of Contents

Section

General Information

Technical Specications

Operation & Maintenance

French Instructions

Parts Breakdowns

Notes

Warranty Registration

Model FW-CN-0010

3

General Information

Technical Specications

Operation & Maintenance

Omcan Manufacturing and Distributing Company Inc. and Food Machinery Of America, Inc. dba Omcan

are not responsible for any harm or injury caused due to any person’s improper or negligent use of

this equipment. The product shall only be operated by someone over the age of 18, of sound mind, and

not under the inuence of any drugs or alcohol, who has been trained in the correct operation of this

machine, and is wearing authorized, proper safety clothing. Any modication to the machine voids any

warranty, and may cause harm to individuals using the machine or in the vicinity of the machine while

in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the

external packaging, open carton to ensure all ordered items are within the box, and there is no concealed

damaged to the machine. If the package has suffered rough handling, bumps or damage (visible or concealed),

please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may

initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Capacity: 12 QT / 11.4 L.

Voltage: 220V-240V AC

Power: 400W-475W

Weight: 4.5 Kg. / 9.9 lbs.

Dimensions: 34.5cm Dia. x 36cm High / 13.6” Dia. x 14.2” High.

• Plug unit into correct electrical socket.

• Use with WET HEAT ONLY. Add 0.6L/2.5 cups of water between the stainless steel liner and internal

aluminum container. Never overll with water and under no circumstances should the stainless steel liner

oat up, even when empty. Remove any excess water immediately.

• The temperature control should be set between 1 and 8 and always operate the kettle at the lowest setting

to maintain correct serving temperature. Hold at high temperature when setting between 8 and 12.

• A neon light will glow when the unit is turned on. Turn the dial to 0 to switch off. Unplug from the wall socket

for storage.

• Always keep the removable hinged lid attached and in the closed position when not serving.

• Never move or carry the kettle when unit is switched on, or containing hot food.

• Spilled food should be removed immediately from all exterior surfaces. The stainless steel bain marie and

4

Operation & Maintenance

lid are machine washable. The painted exterior and top collar should be wiped over with a damp soapy

cloth.

• Ensure unit is unplugged when not in use, when lling and when being cleaned.

• The kettle must not be cleaned with a high pressure jet.

• Unit should never run dry.

IMPORTANT: Maintain water level between minimum and maximum level indicator.

IMPORTANT - NEVER IMMERSE KETTLE IN WATER AS DAMAGE TO THE UNIT WILL

RESULT AND THE WARRANTY WILL BE VOIDED.

WARNING - THIS APPLIANCE MUST BE CONNECTED TO A GROUNDED OUTLET.

DO NOT OPERATE KETTLE EMPTY.

ASSEMBLY DIAGRAM

5

French Instructions

SPECIFICATION

Capacite: 12 QT / 11.4 L.

Tension: 220V-240V AC

Poids: 4.5 Kg. / 9.9 lbs.

Dimension: 36cm Hauteur 34.5 cm Dia. / 14.2” Hauteur 13.6” Dia.

EXPLOITATION ET DE MAINTENANCE

• De branchez le module de che dans la prise électrique.

• Utiliser la chaleur humide et ajoute que non plus de 0.6L/2.5 tasses d’eau entre le revêtement en acier

inoxydable et le récipient interne en aluminium. Ne jamais trop remplir avec de l’eau et sous aucun

circonstances devrait le gaine en acier inoxydable otter, même lorsqu’il est vide. Retirer l’excès d’eau

immédiatement.

• Le contrôle de la température doit être réglée entre 1 et 8 et toujours fonctionner la bouilloire à la

température minimum pour maintenir la température correcte de service. Tenir à haute température lors de

la mise entre 8 et12.

• Un néon s’allume lorsque l’appareil est allumé. Tournez la molette à 0 pour fermer. Débranchez de la prise

murale pour le stockage.

• Garde toujours le couverture à charnière xé et en position fermée lorsqu’il n’est pas de service.

• Ne déplace jamais ou transporter L’unité de bouilloire est sous tension s’il contient de la nourriture chaude.

• Les alimentaire qui sont renversées doit être immédiatement retiré de toutes les surfaces extérieures. Le

bain marie en acier inoxydable et le couverture sont lavables en machine, le collier extérieur et la peinture

supérieure doit être essuyé avec un chiffon barrage savonneuse.

• Assure que l’appareil est débranché quand ont ne l’utilise pas, lors du remplissage et surtout lorsqu’on

nettoie.

• La bouilloire doit être nettoyé avec un jet à haute pression.

IMPORTANCE - NE JAMAIS PLONGER LA BOUILLOIRE DANS L’EAU, COMME

DES DOMMAGES À L’UNITE DU PRODUIT ENTRAÎNERA ET LA GARANTIE SERA

ANNULÉE.

ATTENTION - CETTE APPAREIL DOIT ÊTRE MIS À LA TERRE NE FONCTIONNENT PAS

DE BOUILLOIRE VIDE

SCHÉMA DE MONTAGE

6

Parts Breakdown

FW-CN-0010 19073

Description Position Description Position Description Position

Top cover 1 Bushing Block of Slewing Axis 18 Indicator Light 35

Screw Support Chip 2 Slewing Axis Base 19 Large Hand Wheels 36

Gear 3 Nut Clip 20 Mounting Plate of Heater 37

Backboard 4 Stationary Shaft of Gear 21 Heater Bracket 38

Synchronous Chain 5 Back Support Chip 22 Heater 39

Thermal Bafe 6 Synchronizing Gear 23 E-Box Cover 40

Side Board 7 Tensioning Gear 24 Filter Oil Box 41

Thermostat 8 Retainer Ring 25 Bull Stick 42

Indicator Light 9 Long Bolt 26 Stator of Probe Head 43

Thermostat Knob 10 MB Screw 27 Slide Way 44

Power Cord 11 Bearing Holder 28 Commutator Silicon Briquets 45

Strain Relief Clamp for Cord 12 M Nut 29 Transformer 46

Drive Chain 13 32 Bearing 30 Wire Connecting Terminal 47

Gearwheel 14 Shaft Nut 31 Reinforcement Plate 48

Pinion Wheel 15 Locating Sleeve 32 Location Bushing Block for

Bull Stick 49

Slewing Axis 16 Plastic Feet 33 Coping Screw 50

Plane Bearing 17 Rocker Switch 34 Screw Cover 51

7

Parts Breakdown

FW-CN-0010 19073

8

Parts Breakdown

FW-CN-0010 19073

Description Position Description Position Description Position

Complete Lid 1-1 to 1-3 Neon Light Set 10, 11, 24, 25 Plug 21

Aluminum Collar 3 Plastic Red Dot 12 Strain Relief for Power Cord 22

Silicon Washer for Insert Pan 4 Knob (0-12) 13 Aluminum Cover 23

Stud for Insert Pan 5 EGO Switch Controller Set 14, 26 to 28 Fuse 29

Stainless Steel Food Insert 6 Screw for Switch 15 Screw for Cover 34

Aluminum Food Insert 7 Screw for Ground Terminal 16 Wiring for Ground 35

Body 8, 33 Leg Complete 17 to 19 Thermostat 36

Heating Element 9, 30 to 32 Star Washer for Ground Terminal 20

9

Notes

________________________________________________________________________________________

10

Notes

________________________________________________________________________________________

11

Warranty Registration

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at

the perforation and then send to the address specied below. You can also register online by visiting:

OMCAN INC.

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

www.omcan.com/warrantyregistration.html

Thank you for choosing Omcan

Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):



For mailing in Canada For mailing in the US

OMCAN

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

Niagara Falls, New York

USA, 14305
