Donut Fryer

Model CE-CN-1700-F

Item 44522

Instruction Manual

2

Page

--------------------------------------------------------------------------- 3 - 4

--------------------------------------------------------------------------- 4 - 6

-------------------------------------------------------------------------- 6

------------------------------------------------------------------------ 7

----------------------------------------------------------------------------------------- 8

------------------------------------------------------------------------------------- 8

----------------------------------------------------------------------------- 9 - 10

---------------------------------------------------------------------------- 11

------------------------------------------------------------------------------------------- 12 - 14

---------------------------------------------------------------------------- 15

Table of Contents

Section

General Information

Safety and Warranty

Technical Specications

Installation and Operation

Maintenance

Troubleshooting

Parts Breakdown

Electrical Schematics

Notes

Warranty Registration

Model CE-CN-1700-F

3

General Information

Omcan Manufacturing and Distributing Company Inc., Food Machinery of America, Inc. dba Omcan

and Omcan Inc. are not responsible for any harm or injury caused due to any person’s improper or

negligent use of this equipment. The product shall only be operated by someone over the age of 18, of

sound mind, and not under the inuence of any drugs or alcohol, who has been trained in the correct

operation of this machine, and is wearing authorized, proper safety clothing. Any modication to the

machine voids any warranty, and may cause harm to individuals using the machine or in the vicinity of

the machine while in operation.

CHECK PACKAGE UPON ARRIVAL

Upon receipt of an Omcan shipment please inspect for external damage. If no damage is evident on the

external packaging, open carton to ensure all ordered items are within the box, and there is no concealed

damage to the machine. If the package has su󰀨ered rough handling, bumps or damage (visible or concealed),

please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may

initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be

lled out within three days, from the delivery date shown in the shipping documents. Omcan has no recourse

for damaged products that were shipped collect or third party.

Before operating any equipment, always read and familiarize yourself with all operation and safety

instructions.

Omcan would like to thank you for purchasing this machine. It’s of the utmost importance to save

these instructions for future reference. Also save the original box and packaging for shipping the

equipment if servicing or returning of the machine is required.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Fabrication et distribution Companie Limité et Food Machinery d’Amerique, dba Omcan et

Omcan Inc. ne sont pas responsables de tout dommage ou blessure causé du fait que toute personne

ait utilisé cet équipement de façon irrégulière. Le produit ne doit être exploité que par quelqu’un de

plus de 18 ans, saine d’esprit, et pas sous l’inuence d’une drogue ou d’acohol, qui a été formé pour

utiliser cette machine correctement, et est vêtu de vêtements de sécurité approprié. Toute modication

de la machine annule toute garantie, et peut causer un préjudice à des personnes utilisant la machine

ou des personnes à proximité de la machine pendant son fonctionnement.

VÉRIFIEZ LE COLIS DÈS RÉCEPTION

Dès réception d’une expédition d’Omcan veuillez inspecter pour dommages externes. Si aucun dommage

n’est visible sur l’emballage externe, ouvrez le carton an de s’assurer que tous les éléments commandés

sont dans la boîte, et il n’y a aucun dommage dissimulé à la machine. Si le colis n’a subi aucune mauvaises

manipulations, de bosses ou de dommages (visible ou cachée), notez-le sur le bond de livraison avant

d’accepter la livraison et contactez Omcan dans les 24 heures qui suivent, pour que nous puissions engager

une réclamation auprès du transporteur. Un rapport détaillé sur l’étendue des dommages causés à la machine

doit être rempli dans un délai de trois jours, à compter de la date de livraison indiquée dans les documents

d’expédition. Omcan n’a aucun droit de recours pour les produits endommagés qui ont été expédiées ou cueilli

par un tiers transporteur.

4

Safety and Warranty

General Information

WARNING!

ANY REFITTING OR WRONG INSTALLATION, ADJUSTMENT AND MAINTENANCE CAN CAUSE

PROPERTY DAMAGE AND HARM. PLEASE CONTACT OMCAN IF YOU NEED TO ADJUST OR MAINTAIN

IT AND ONLY AUTHORIZED PERSONS MAY MAKE THE ADJUSTMENTS.

WARNING!

DO NOT PUT FLAMMABLE LIQUID, GAS OR OTHER OBJECTS AROUND THE PRODUCT FOR YOUR

Avant d’utiliser n’importe quel équipement, toujours lire et vous familiariser avec toutes les opérations

et les consignes de sécurité.

Omcan voudrais vous remercier d’avoir choisi cette machine. Il est primordial de conserver ces

instructions pour une référence ultérieure. Également conservez la boîte originale et l’emballage pour

l’expédition de l’équipement si l’entretien ou le retour de la machine est nécessaire.

---------------------------------------------------------------------------------------------------------------------------------------------------

Omcan Empresa De Fabricacion Y Distribucion Inc. Y Maquinaria De Alimentos De America, Inc. dba

Omcan y Omcan Inc. no son responsables de ningun daño o perjuicío causado por cualquier persona

inadecuada o el uso descuidado de este equipo. El producto solo podra ser operado por una persona

mayor de 18 años, en su sano juicio y no bajo alguna inuencia de droga o alcohol, y que este ha sido

entrenado en el correcto funcionamiento de esta máquina, y ésta usando ropa apropiada y autorizada.

Cualquier modicación a la máquina anúla la garantía y puede causar daños a las personas usando la

máquina mientras esta en el funcionamiento.

REVISE EL PAQUETE A SU LLEGADA

Tras la recepcion de un envio Omcan favor inspeccionar daños externos. Si no hay daños evidentes en el

empaque exterior, Habra el carton para asegurararse que todos los articulos solicitados ésten dentro de la

caja y no encuentre daños ocultos en la máquina. Si el paquete ha sufrido un manejo de poco cuidado, golpes

o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro

de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. Un informe detallado sobre

los daños causados a la máquina debe ser llenado en el plazo de tres días, desde la fecha de entrega que se

muestra en los documentos de envío. Omcan no tiene ningun recurso por productos dañados que se enviaron

a recoger por terceros.

Antes de utilizar cualquier equipo, siempre lea y familiarizarse con todas las instrucciones de

funcionamiento y seguridad.

Omcan le gustaría darle las gracias por la compra de esta máquina. Es de la mayor importancia para

salvar estas instrucciones para futuras consultas. Además, guarda la caja original y el embalaje para el

envío del equipo si servicio técnico o devolución de la máquina que se requiere.

5

Safety and Warranty

SAFETY.

WARNING!

THE PRODUCT IS NOT SUITABLE FOR PEOPLE WHO HAVE NOT BEEN TRAINED IN IT’S USE, OR

PEOPLE WHO ARE INEXPERIENCE (INCLUDING CHILDREN).

NOTES FOR INSTALLATION

1. The supplied voltage for this equipment must be coordinated with the voltage in nameplate.

2. User should install a suitable power switch and breaker switch near the fryer.

3. At the back of the equipment is the earth bolt. Please connect the earth wire in compliance with the safety

regulations reliably with copper cable of no less that 1.5mm².

4. The environment temperature should not be more than 300°C/572°F in the event of hot oil splashing and

causing the re.

5. The installation of this equipment must be done by professionals.

6. Using old oil will be easy to cause over boiling, and if the food too wet or too much, also the same problem

will happen.

WARNING!

If the oil level is less than the “MIN” level marked on the tank, there will be a risk of catching re.

NOTICE

• This equipment must be operated by trained cooks or professionals.

• Do not ret it! Retment of this product will cause serious injury.

• Do not clean the product with a water jet or soak the electric box into water while cleaning. Water can

conduct electricity so the product may cause electric-shock accident by electric leakage.

• High temperatures can and will scald. When the unit is in use and before or after being used, do not touch

any of the following directly because of it’s high temperature; body of trunk and chamber of top trunk.

• Do not use another power supply with di󰀨erent voltage. Do not use a main switch that is not coordinated

with safety regulations.

• When there is thunder and lighting in the area, the user should shut o󰀨 the main switch to avoid appliance

being damaged by a power surge.

• Do not use hard and sharp objects to clean the surface of oven body and the surface of oil pot.

• After using, please shut o󰀨 the main switch.

• The installation and maintenance of electric circuits must be done by professionals.

• If the power cord is damaged, to prevent a hazard, the user should contact Omcan to request a

replacement.

WARNING!

• Daily check of the product is needed. It can prevent the accidents.

• If a problem is found with the electric circuit or the temperature rising is abnormal, please stop using the

equipment immediately. And inform the professional technician to check and maintain as soon as possible.

1 YEAR PART AND LABOUR BENCH WARRANTY

6

Safety and Warranty

Technical Specications

Within the warranty period, contact Omcan Inc. at 1-800-465-0234 to schedule a drop o󰀨 to either

an Omcan authorized service depot in the area, or to an Omcan Service warehouse to repair the

equipment.

Unauthorized maintenance will void the warranty. Warranty covers electrical and part failures, not

improper use.

Please see https://omcan.com/disclaimer for complete info.

WARNING:

The packaging components (cardboard, polyethylene, and others) are classied as normal solid urban waste

and can therefore be disposed of without di󰀩culty.

In any case, for suitable recycling, we suggest disposing of the products separately (di󰀨erentiated

waste) according to the current norms.

DO NOT DISCARD ANY PACKAGING MATERIALS IN THE ENVIRONMENT!

Model CE-CN-1700-F

Power 1.7 kW

Volume of Oil 25 lbs. / 11.3 kgs.

Adjustable Temperature 93.3° - 187.8°C / 200° - 370°F

Electrical 120V / 60Hz / 1

Current 14.5A

Cooking Area 17.7” x 17.7” x 6” / 450 x 450 x 152mm

Screen Capacity 1

Screen Dimensions 15” x 14” / 379 x 355mm

Dimensions 18” x 24” x 14” / 460 x 616 x 355mm

Weight 37.5 lbs. / 17 kgs.

Packaging Weight 165 lbs. / 75 kgs.

Item Number 44522

7

Installation and Operation

1. Ensure the unit is plugged in correctly, and make sure the supplied voltage is the same as the voltage on

the rating plate.

2. Turn over the tank cover, and place it securely beside the fryer.

3. There is an oil level mark in the internal tank, when using the fryer the quantity of oil in tank should be kept

in certain level. “MAX” shows the maximum volume of oil, “MIN” shows the minimum volume of oil. When

using, the user can adjust the volume of oil between those points if needed.

4. - Plug in the machine, the green indicator will turn on. The machine is powered and ready to be used.

- Rotate the temperature controller clockwise to the desired temperature. At this point, the yellow indicator

will turn on and the green indicator will turn o󰀨. It shows that the unit is heating the oil in the tank.

5. - When the temperature of oil rises to the desired temperature, the temperature controller will cut o󰀨 power

automatically. At the same time, the yellow indicator will turn o󰀨 and heater will turn o󰀨.

- When temperature of the oil gets too low, the temperature controller will automatically turn on again. The

yellow indicator will turn on, and the heater will begin raising the oils temperature again.

- This process repeats until the unit is switched o󰀨.

6. The enclosed frying baskets are for frying donuts. Using one basket at a time, soak the basket in the oil

when frying. After the frying is nished, lift the basket and place it on the tank cover to lter the excess oil.

The user can continue to fry the food by using the other basket at this time.

7. After work is completed, please rotate the temperature controller counter-clockwise to the o󰀨 and cut o󰀨 the

power for safety.

8. - Please pour the old oil out of the tank when the temperature of the oil lowers room temperature.

- First, cut o󰀨 the power, then take the partition board for the oil out of tank, and then take the electric box

out of the back notch in bottom box. The electric heating tube and electric box are separated from the tank,

then take out the oil tank to clean.

9. In order to make sure the stove is safe and durable. The user should clean the oil tank and the electric

heating tube in order to maintain consistent and hygienic quality when frying.

10. The partition board of the oil tank is designed for protecting the electric heating tube. Put the partition board

into the oil tank when frying food.

11. - There is a temperature limiter in the electric box. When the oil temperature gets too hot, the temperature

limiter will automatically turn the unit o󰀨.

- There is “reset button for over heating” on the back side of electric box. When the temperature limiter

turns on, the reset button must be pressed before operation can resume.

TRANSPORTATION AND STORAGE

During transportation, the machine should be carefully handled. The packaged machine should not be stored

outdoors. It should be put in a well ventilated indoor location without any corrosive gases in the same space. It

should not be placed upside down.

8

Maintenance

Troubleshooting

• Cut o󰀨 the power supply before cleaning in case of accident.

• Do not use a wet towel with a non-corrosive cleanser to clean the module plate, the surface of the

equipment and power cord. Do not was directly with water.

• If the unit is not in use at any time, please turn o󰀨 temperature controller and main switch.

• Please store the equipment in a ventilated storehouse without corrosive gas after cleaning when stopping

its work for a long time.

Problem Possible Cause Solution

The machine is plugged in, but the

indicator does not turn on.

Plug is not inserted well. Plug the unit in correctly.

Micro-switch is not making contact. Ensure the micro-switch is making

contact.

The heating indicator is not on and

the temperature is not rising.

Connection of the electric heating

tube is loose.

Firmly connect the two sides of the

electric heating tube and screw.

Replace the electric heating tube.

The power indicator is on but the

set temperature is not rising.

The temperature controller is burnt

out.

Replace the temperature controller.

The temperature controller is

normal but the indicator is not on.

The indicator is burnt out. Replace the indicator.

The heater stops working after a

circuit break.

The temperature limiter was

activated.

Press the reset “over heating

protecting button”.

The temperature gets too hot. The temperature limiter is faulty. Replace the temperature limiter.

The aforementioned problems are just for reference. If any additional problems occur, please stop using the

unit, and contact an Omcan technician at 1-800-465-0234.

NOTE: If the power cord damaged, please replace it with soft oil-proof cable jacket (GB/T 5013.1 (IEC

60245, IDT) Mid No. 57) or the power cord from the manufacture or service center. This must be done

by a certied Omcan technician.

9

Parts Breakdown

Model CE-CN-1700-F 44522

10

Model CE-CN-1700-F 44522

Item No. Description Position Item No. Description Position Item No. Description Position

AE161 Bezel for Thermostat Knob for EF-DF 1 AE178 Rear Cover for Electric Box for EF-DF 17 AE194 Decoration Ring for Drainage Valve

for EF-DF 34

AE162 Ф41 Knob for Thermostat for EF-DF 2 AE179 Right Side Board for Electric Box 18 AE195 Self-Plugging Rivet for EF-DF 35

AE163 EGO Thermostat 200°C for EF-DF 2a AE180 Left Side Board for Electric Box for EF-DF 19 AE196 Nut GB/T 6170 M4 A2 for EF-DF 36

AE164 Oil Pan Coaming for EF-DF 3 AE181 Safeguard for Heater for EF-DF 20 AE197 Nut GB/T 6170 M5 A2 for EF-DF 37

AE165 Oil Pan for EF-DF 4 AE182 Top Board for Heater for EF-DF 21 AE198 G12 Hex Nut for EF-DF 38

AE166 Right Supporting Plate for EF-DF 5 AE183 Clamp for Probe for EF-DF 22 AE199 Screw GB/T 818 M4x10 A2 for EF-DF 39

AE167 Left Supporting Plate for EF-DF 6 AE184 Top Plate Holder for EF-DF 23 AE200 Screw GB/T 818 M4x16 A2 for EF-DF 40

AE168 Body for EF-DF 7 AE185 Supporting Rod for EF-DF 24 AE201 Screw GB/T 818 M4x6 A2 for EF-DF 41

AE169 Connecting Plate for EF-DF 8 AE186 Rotor Shaft for EF-DF 25 AE202 Screw GB/T 818 M5x16 A2 for EF-DF 42

AE170 Supporting Plate for Foot for EF-DF 9 AE187 Limiting Shaft for Electric Box for EF-DF 26 AE203 Indicator/Green for EF-DF 43

AE171 Cover for Oil Pan for EF-DF 10 AE188 Heater for EF-DF 27 AE204 Indicator/Yellow for EF-DF 44

AE172 Connecting Plate for EF-DF 11 AE189 Grid for EF-DF 28 AE205 Foot for EF-DF 45

AE173 Pressure Plate for Supporting Bar for

EF-DF 12 AE190 Frying Basket for EF-DF 29 AE206 Joint of Drainage Valve for EF-DF 46

AE174 Front Limiting Plate for EF-DF 13 AE191 Elbow for EF-DF 30 AE207 Connection Strap for Heater for EF-DF

AE175 Left Limiting Plate for EF-DF 14 AE192 Supporting Rod for Basket for EF-DF 31 AE208 Cover Assembly for Oil Pan for EF-DF

AE176 Right Limiting Plate for EF-DF 15 AD712 Power Switch for EF-DF 32

AE177 Holder for Electric Box for EF-DF 16 AE193 Drainage Valve for EF-DF 33

Parts Breakdown

11

Electrical Schematics

Model CE-CN-1700-F 44522

12

Notes

________________________________________________________________________________________

13

Notes

________________________________________________________________________________________

14

Notes

________________________________________________________________________________________

15

Warranty Registration

Gracias por comprar un producto Omcan usted. Para registrar su garantía para este producto, complete la información a continuación,

cortar la tarjeta en la perforación y luego enviarlo a la dirección indicada a continuación. También puede registrarse en línea en:

Merci d’avoir acheté un produit Omcan. Pour enregistrer votre garantie pour ce produit, complétez les informations ci-dessous, détachez la

carte au niveau de la perforation, puis l’envoyer à l’adresse spécié ci-dessous. Vous pouvez également vous inscrire en ligne en visitant:

Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear o󰀨 the card at

the perforation and then send to the address specied below. You can also register online by visiting:

OMCAN

PRODUCT WARRANTY REGISTRATION

3115 Pepper Mill Court,

Mississauga, Ontario

Canada, L5L 4X5

https://omcan.com/warranty-registration/

or email to: [email protected]

Purchaser’s Information

Name: Company Name:

Address:

Telephone:

City: Province or State: Postal or Zip: Email Address:

Country: Type of Company:

Restaurant Bakery Deli

Dealer from which Purchased: Butcher Supermarket Caterer

Dealer City: Dealer Province or State: Institution (specify):

Invoice: Other (specify):

Model Name: Model Number: Serial Number:

Machine Description:

Date of Purchase (MM/DD/YYYY): Date of Installation (MM/DD/YYYY):

Would you like to extend the warranty? Yes No



Por correo en Canadá

Pour postale au Canada

For mailing in Canada

Por correo en los EE.UU.

Pour di󰀨usion aux États-Unis

For mailing in the US

OMCAN

PRODUCT WARRANTY REGISTRATION

4450 Witmer Industrial Estates, Unit 4,

Niagara Falls, New York

USA, 14305

Thank you for choosing Omcan | Merci d’avoir choisi Omcan | Gracias por elegir Omcan

Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North

American food service industry. Our success over these many years can be attributed to our commitment

to strengthen and develop new and existing relationships with our valued customers and manufacturers.

Today with partners in North America, Europe, Asia and South America, we continually work to improve

and grow the company. We strive to offer customers exceptional value through our qualied local sales

and service representatives who provide convenient access to over 5,000 globally sourced products.

Depuis 1951 Omcan a grandi pour devenir un des “leaders” de la distribution des équipements et

matériel pour l’industrie des services alimentaires en Amérique du Nord. Notre succès au cours de ces

nombreuses années peut être attribué à notre engagement à renforcer et à développer de nouvelles

et existantes relations avec nos clients et les fabricants de valeur. Aujourd’hui avec des partenaires en

Amérique du Nord, Europe, Asie et Amérique du Sud, nous travaillons continuellement à améliorer et

développer l’entreprise. Nous nous efforçons d’offrir à nos clients une valeur exceptionnelle grâce à

nos ventes locales qualiées et des représentants de service qui offrent un accès facile à plus de 5000

produits provenant du monde entier.

Desde 1951 Omcan ha crecido hasta convertirse en un líder en la distribución de equipos y suministros

de alimentos en América del Norte industria de servicios. Nuestro éxito en estos años se puede atribuir

a nuestro compromiso de fortalecer y desarrollar nuevas relaciones existentes con nuestros valiosos

clientes y fabricantes. Hoy con socios de América del Norte, Europa, Asia y América del Sur, que trabajan

continuamente para mejorar y crecer la empresa. Nos esforzamos por ofrecer a nuestros clientes valor

excepcional a través de nuestro local de ventas y representantes de los servicios que proporcionan un

fácil acceso a más de 5,000 productos con origen a nivel mundial.

Omcan CE-CN-1700-F User manual

Popular Fryer manuals by other brands
