Omega Lift MagicLift 32066 User manual

MagicLift™ Jack Stands
Model
32066
32126
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
SFA Companies
Capacity per pair
6 Ton
12 Ton
Model 32066
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
!
!WARNING
To avoid crushing and related injuries:
NEVER work on, under or around a
load supported only by a hydraulic jack.
ALWAYS use adequately rated jack
stands.
Model 32126
Patent Pending

2
SPECIFICATIONS
Figure 1 - Models 32066 & 32126 Components (model 32126 shown)
Model Capacity (per pair) Base Size Min. Height Max. Height
32066 6 Ton 11” x 9-3/4” 15-3/4” 24-3/8”
32126 12 Ton 14-3/4” x 12-3/4” 19-3/4” 30-1/4”
SAFETY AND GENERAL INFORMATION
Save these instructions. For your safety read, understand, and follow the information provided with and on this
pair of jack stands before using. The owner and operator of this equipment shall have an understanding of the jack
stands and safe operating procedures before attempting to use. The owner and operator shall be aware that use of
this product may require special skills and knowledge. Instructions and safety information shall be conveyed in the
operator's native language before use of these jack stands is authorized. If any doubt exists as to the safe and proper
use of these jack stands, remove from service immediately.
Inspect before each use. Do not use if broken, bent, cracked, or damaged parts (including labels) are noted. Any
jack stand that appears damaged in any way, operates abnormally or is missing parts, shall be removed from service
immediately. If you suspect that the jack stand was subjected to a shock load (a load dropped suddenly, unexpectedly
upon it), immediately discontinue use until the stand has been checked by a factory authorized service center (contact
distributor or manufacturer for list of Authorized Service Centers). It is recommended that an annual inspection be
done by qualied personnel. Labels and owner’s manuals are available from manufacturer.
PRODUCT DESCRIPTION
Omega "MagicLift™" Jack Stands are designed to support rated capacity, partial vehicle loads consisting of one end
of a vehicle. Your Omega Jack Stands have a special Magic-Lift feature which allows the ratchet bar to automatically
adjust till it makes contact. Use as a matched pair to support one end of a vehicle only.
WARNING: Never use automotive jack stands to support both ends or one side of a vehicle! Use only one (1)
pair per vehicle. Rated capacity is per pair only!
WARNING: The "Magic Lift" adjustment function of this jack stand is not designed to support a load. The
Locking Pawl must be properly engaged for the jack stand to support weight.
!
!
Ratchet Bar
Locking Handle
Locking Pawl
Base Frame
Ratchet Bar Collar
Air Spring
Ratchet Bar
Locking Pin
Spring

3
PREPARATION
1. Verify the product and your application are compatible.
2. Read this manual completely,examine the jack
stands and familiarize yourself with the components.
Recognize the hazards associated with its improper
use before using the product.
3. Refer to the vehicle owner's or service manual for
location of proper lift and support points.
4. Remove the Ratchet Bar Locking Pin to release the
Ratchet Bar. The purpose of the Locking Pin is to
avoid inadvertent removal of the Ratchet Bar from the
collar. Reinstall the Locking Pin when transporting
the jack stands.
OPERATION
Supporting Load
WARNING: Use only to support areas of the
vehicleasspeciedbythevehiclemanufacturer.
Useonlyon vehicleswhosesupportpointsare compatible
with the saddle of the jack stand. Incompatibility or
improper placement may result in structural damage
to the vehicle and/or jack stand. Structural damage to
either may result in sudden and unexpected loss of load
height!
WARNING: Do not use attachments and/or
adapters with this product.
1. Inspect your stands before each use. If any part is
missing or damaged, do not attempt to use the jack
stands and Contact Omega Technical Service.
2. Raise the locking handle and manually adjust the
ratchet bar to allow placement under vehicle.
3. After raising vehicle, carefully position the jack
stands so that the load will be centered on the
ratchet bar saddle. Raise the locking handle until
the ratchet bar saddle engages the load. Jack
stands should be at same height.
4. The Locking Handles on your Omega MagicLift™Jack
Stands are spring loaded to help secure the Ratchet
Bar in desired position. After adjusting the jack
stand, release the Locking Handle and pull down on
the Ratchet Bar to conrm the pawl and ratchet are
engaged. The bar should maintain height.
5. Slowly lower the vehicle onto the stands while
monitoring load distribution and jack stand height.
6. Verify the vehicle is secure before working on,
around or under.
Lowering load
WARNING: Be sure that all tools and personnel
are clear before lowering load.
1. Using a suitable jack, raise vehicle clear of stands.
2. Carefully remove jack stands, and lower vehicle
with lift device.
MAINTENANCE
Periodically inspect each stand. Ensure all parts move
freely. Do not apply oil or grease to any portion of this
product. Do not allow dirt to accumulate on Air Spring.
If rust appears, sand affected area and cover with a
suitable utility paint.
Storage
Store stands in upright position and in a clean, dry
area.
REPLACEMENT PARTS
Not all components of the jack are replacement items,
but are illustrated as a convenient reference of location
and position in the assembly sequence. When ordering
parts, please give the Model number, part number and
parts description.
• Study, understand, and follow all instructions
provided with and on this device before use.
•Rated capacity is PER PAIR! DO NOT exceed
rated capacity.
• Use as a matched pair to support one end of a
vehicle only. Use only ONE (1) PAIR per vehicle.
• Use only on hard, level surface. Properly secure
vehicle before using jack stands.
• Center load on ratchet bar saddle.
• Jack stands are not to be used to simultaneously
support both ends or one side of a vehicle.
• No alterations shall be made to this device.
• Failure to heed these markings may result in
personal injury and/or property damage.
!WARNING
!
!
!

4
REPLACEMENT PARTS
Individual replacement parts are not available for this product. Jack stands are sold as a matched
pair.
ONE YEAR LIMITED WARRANTY
For a period of one (1) year from date of purchase, SFA Companies will repair or replace, at its
option, without charge, any of its products, which fails due to a defect in material or workmanship under normal
usage. This limited warranty is a consumer's exclusive remedy.
Except where such limitations and exclusions are specifically prohibited by applicable law, (1) THE
CONSUMER'S SOLE AND EXCLUSIVE REMEDY SHALL BE THE REPAIR OR REPLACEMENT OF
DEFECTIVE PRODUCTS AS DESCRIBED ABOVE. (2) SFA Companies SHALL NOT BE LIABLE FOR ANY
CONSEQUENTIAL OR INCIDENTAL DAMAGE OR LOSS WHATSOEVER. (3) ANY IMPLIED WARRANTIES,
INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO ONE YEAR, OTHERWISE THE REPAIR,
REPLACEMENT OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED. (4) ANY MODIFICATION, ALTERATION, ABUSE, UNAUTHORIZED SERVICE OR
ORNAMENTAL DESIGN VOIDS THIS WARRANTY AND IS NOT COVERED BY THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not
apply to you. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights, which vary from state to state.
