Instruction Manual
Model: MC-HF645

Product Introduction
Dear customer,
Thank you for purchasing the ceramic cooker hob.
Our product can serve you many years to your satisfaction.
Please read this instructions manual carefully before using and installation.
Keep it in a good place after reading for future reference.
Thank you again for your purchase of the ceramic cooker hob, and wish
you to enjoy the pleasure brought about by it.
The microcomputer ceramic cooker hob can meet different kinds of
cuisine demands because of resistance wire heating, micro-
computerized control and multi-power selection, really the optimal choice
for modern families.
The ceramic cooker hob centers on customers and adopts personalized
design. The hob has safe and reliable performances, making your life
comfortable and enabling to fully enjoy the pleasure from life.
This hob was specially designed for domestic use.
In its constant search to improve its products,we reserves the right to modify
any technical,programme or aesthetic aspects of the appliance at any time.
Safety
High temperature protection
The temperature sensor mounted on the heating element monitor the temp-
erature inside the cooker from time to time,When an excessive temperature
is detected,the heating element will be stop power output.
Residual heat warning
When the hob has been operating for some time,there will be some residual
heat.The leteer “H”appears to warn you to keep away from it.
Auto shutdown
Another safety feature of the hob is auto shutdown.This occurs whenever
you forget to switch off a cooking zone.The default shutdown times are shown
in the table below:
Power level
Default working
timer(hour)
1
8 8 8 4 4 4 2 2 2
2 3 4 5 6 7 8 9
1

2
Installation
Selection of installation equipment
Drill holes on the table surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 5 cm space shall be
preserved around the hole.
Be sure the thickness of the table surface is at least 30mm. Please select
heat-resistant table material to avoid larger deformation caused by the heat
radiation from the hotplate.
As shown in Figure (1)
Air intake
Figure (2)
mini 5 cm
mini 760mm
mini 2 cm
Under any circumstances, make sure the ceramic cooker hob is well
ventilated and the air inlet and outlet are not blocked.Ensure the ceramic
cooker hob is in good work state. As shown in Figure (2)
Air exit
mini 5 mm

3
Note: The safety distance between the ceramic hob and the cupboard above
the hotplate should be at least 760mm.
Fix the hob on the table by screw four brackets on the bottom of hob (see picture)
after installation. Adjust the bracket position to suit for different table top thickness.
w
e
r
c
s
t
e
k
c
a
r
b
e
s
a
b
e
l
o
h
w
e
r
c
s
Cautions
1. The ceramic cooker hob must be installed by qualified personnel or
technicians. We have professionals at your service. Please never
conduct the operation by yourself.
2. The ceramic cooker hob shall not be mounted to cooling equipment,
dishwashers and rotary dryers.
3. The ceramic cooker hob shall be installed such that better heat radiation can
be ensured to enhance its reliability.
4. The wall and induced heating zone above the table surface shall
withstand heat.
5. To avoid any damage, the sandwich layer and adhesive must be
resistant to heat.
6. A steam cleaner is not to be used.
7. A board is must to be installed underneath the hob.
The socket should be connected in compliance with the relevant standard,or
a single-pole circuit breaker.the method of connection is shown in Figure (3)
Connection to power supply

4
Figure (3)
eul
b
wolley-
n
eerg
N2 N1 L2 L1
ye
rg
nwor
b
kca
l
b
220-240V
220-240V
e
u
lb
w
o
ll
ey-nee
r
g
N L
y
e
rg
n
wo
rb
kc
a
l
b
220-240V
PE
PE
connect to the main power supply connect to the main power supply
220-240V 2+2N~ 220-240V~
1. If the cable is damaged or needs replacing, this should be done by an
after-sales technician using the proper tools, so as to avoid any accidents.
2. If the appliance is being connected directly to the mains supply, an omnipolar
circuit breaker must be installed with a minimum gap of 3mm between the
contacts.
3. The installer must ensure that the correct electrical connection has been made
and that it complies with safety regulations.
4. The cable must not be bent or compressed.
5. The cable must be checked regularly and only replaced by a properly qualified
person.
The ceramic cooker hob appearance
ON/OFF
Glass plate
Control panel
1
23
4

5
Schematic diagram of the control panel
Instructions for Use
Power regulating key
Timer regulating key
Double zone
On/OffLock
Preparation before using
When the power is switch on,the buzzer will sound once and all the indicators
will come on for one second and go out.The hob is now in standy mode.
Place the pan in the centre of the cooking zone.
Note:
1. When the “ ” key is pressed,the hob returns to standby mode if no other
operation is carried out within one minute.
2. Every cooking zone is independent of each other.
Double zone function
The hob is fitted with double zone
Active the double zone
If you want to use bigger heating zone, press the “ ” when the hob is in
working mode .
Press the “ ” key to turn on the hob,then the power indicators show “-” and
the timer indicators shows “--”,the hob is now ready for heating.Then press
the “ ”or “ ” key for the corresponding cooking zone where there is a pan
on it,the relevant hotplate start heating.Its corresponding cooking zone indicator
flashe “5” five seconds,when the other indicators show “-”. Select the power
level by pressing the “ ” or “ ” key for the relevant hotplate.
Deactive the bouble zone
Press the “ ” when the hob is working with double zone.
Note:
1. This function is available only in the right back heating zone.
2. You can select the function from level 1 to level 9.

6
3. When the heating zone is in double loop working mode,the bouble loop
indicator shows ”P”.
4. You can select the size of the heating zone according to the size of the pot.
Lock Function
To ensure the safety of children,the hob is fitted with an lock device
Active the lock function
Press the “ ”,the hob then goes into lock mode, the timer shows “ ” and
the rest of the keys are disabled except the ON/OFF keys .
Deactiving the lock function
Hold down the“ ”for several seconds and the hob will return to normal working.
The power of each heating zone are shown as follow:
1 2
1200W 1800W 1000W 2200W
4
3
Heating zone
Power
Inner double
1200W
Timer function
Cooking timer
First select the cooking zone by press the “-” or “+”of the relevant heating
zone,then the cooking zone display flashing.Then adjust timer by pressing “-”
or “+” of timer,the timer is confirmed after the timer indicator flashing 5 seconds,
a red dot display at corresponding cooking zone indicator ,it reminds you a
cooking timer have been setted on this cooking zone .When cooking timer
expires,the corresponding cooking zone will be switch off automatically.
Note:Cooking timer only works for one cooking zone at the same time.
Minute reminder
Timer can be used as a minute reminder.
Press “+”or “-”of timer, the timer indicator flashes “00”,adjust timer by pressing
“+”or “-”of timer. When the time is setted, the timer indicator will stop flahing
after 5 seconds, minutes reminder starts. Buzzer will bips for 30 seconds and
the timer indicator shows “--”when the setting time finished , the work state will
not be affected by the minute reminder.
Timing cancellation
Press “+” and “-”of timer simultaneously, the timer cancelled automatically,and
the timer indicator shows “--”

7
Never wash the induction
cooker with water directly to
avoid danger.
Keep electrical appliance out
of reach from children or
inform person. Do not let them
use the appliances without
supervision.
Safety Reminding and Maintenance
After being used for a long
time, the corresponding
heating zone of the ceramic
cooker hob is till hot. Never
touch the ceramic surface to
avoid burning.
If the supply cord is damaged
, it must be replaced by the
manufacturer, its service agent
or similarly qualified persons
in order to avoid a hazard.
Never have the ceramic
cooker hob to work without
food inside, otherwise its
operational performance may
be affected and danger may
happen.
A dedicated power protection
air swith protection air switch
must be incorporated in the
fixed wiring in accordance
with the wiring rules.
Never use the ceramic cooker
hob in high temperature
environments such as near a
gas stove or kerosene stove.
For sealed foods such as
canned goods, please do not
heat them before opening their
covers so as to avoid any
dangers of explosion due to
heating expansion.
If the surface is cracked, swith
off the appliance to avoid the
possibility of electric shock.
Do not place rough or uneven
appliances, which may
damage the ceramic surface.
Do not put any detergents or
flammable materials in the
equipment installed under the
ceramic cooker hob.
Metallic objects such as
knives, forks,spoons and lids
should not be placed on the
hotplate since they can get
hot.

8
DISPOSAL: Do not dispose this
product as unsorted municipal
waste. Collection of such waste
separately for special treatment
is necessary.
Clean the ceramic cooker hob
on a regular basis to prevent
foreign matters from entering
the fan thus influencing the
normal operation.
Indoor use only.
Cleanness and Maintenance
You can easily clean the surface of the ceramic cooker hob if following the
methods given in the table.
Children should be supervised to ensure that they do not play with the appliance.
3. A steam cleaner is not to be used.
1. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
2. If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
5. The appliance is not intended to be operated by means of an external timer or
separate remote-control system.
4. After use, switch off the hob element by its control and do not rely on the pan
detector.

Maintenance Service Warranty
For any failure of the product, please contact the special
maintenance department or the customer service center.
1. There is a year’s guarantee with this the brand ceramic cooker
hob.
2. The period of warranty shall start from the date on which the invoice
is issued.
3. Any one of the following cases is without the warranty:
Damages caused by improper use, storage and maintenance of
the consumer.
Damages caused by unauthorized disassembly and repair in the
maintenance department not designated by the company.
Model of invoice and model of product maintained are not in
conformity or are altered.
Valid invoice can not be presented.
Damages caused by force majeure.
Using the ceramic cooker hob for commercial purposes.
9
Light Clean with hot water and
damp sponge Cleaning sponge
Accumulation
of dirt
Clean with hot water and
abrasive sponge
Special cleaning sponge for
ceramic glass
Hint: please disconnect power before the cleaning.
Type of
contamination Method of cleaning Articles used for cleaning
Rings and lime
crumbles
Apply white vinegar to the
polluted zone, then wipe it
dry with soft cloth or a
special article available in
local markets
Special adhesive for ceramic
glass
Sweetmeat,
melt aluminum
or plastics
Use a scraper suitable for
ceramic glass (to protect
glass, a silicon product is
preferred) to remove
residuals
Special adhesive for ceramic
glass
