Omega ODW600S User manual

Dishwasher
Instruction Manual
12 place settings

Thank you for introducing our family to yours
At Omega, we understand that cooking, cleaning and washing may not be your
favourite things in the world. That's why we created a range of no-nonsense, reliable
products that always get the job done for you. With the features you need and
nothing you don't. What's more, they're made to fit perfectly into your home life and
your wallet.
We aim to simplify any further appliance purchases. When researching our products
you will find a range of icons that visually represent our products key features. Visit
our website to learn more about these icons and the features and benefits of our
products.
You are welcoming an Omega appliance into your place and you can be sure it'll
always serve you well.
For important information about your Omega such as warranty registration, online
manuals, specifications and catalogues, please visit
www.omegaappliances.com.au/customer (if you are in Australia) or
www.omegaappliances.co.nz/customer (if you are in New Zealand).
Make sure you activate your product warranty on our websites on the links above.
If you want to know more about promotions, to receive cool tips and tailor made
content, like us on www.facebook.com/omegaappliances and follow us on
www.instagram.com/omegaappliances_aus.
We hope you love this product as much as we do!
www.omegaappliances.com.au / www.omegaappliances.co.nz
omegaappliances
omegaappliances_aus

Quick Operation Guide
1
3
3
3
4
4
5
6
6
8
9
9
9
10
11
11
12
13
13
13
14
15
16
16
17
18
10
2

Compartment A:Compartment A:
For each wash cycle.
Compartment B:B:
For programs with pre-wash only.
(Follow the user instructions)
Mechanical indicator C.Mechanical indicator C.
Electric indicator on control panel (if provided).
Check the rinse aid level
Load the baskets
Select a programme
Running the dishwasher
Switch off the appliance
Turn off the water tap,
unload the baskets
Fill the detergent dispenser
Warning: wait a few minutes (about 15 minutes) before unloading the dishwasher to avoid scald,as
the dishes and utensils are still hot and more susceptible to break.
They could also dry better.Unload the appliance, starting from the lower basket.
Changing the programme
Add forgotten dishes in the
dishwasher.
Scrape off any large food particles. Soften remnants of burnt food in pans,
then load the baskets. Refer to the dishwasher loading instructions.
When the working cycle is finished, the buzzer of the
dishwasher will sound 8 times, then stop.
Turn off the appliance using the On/Off Button.
If the appiance was under standby mode, it will be power off automaticly after 30 minutes without any operation.
If the appliance is switched
off during a wash cycle.
Open the doorcarefully.
Hot steam mayescape
when the dooris opened!
WARNING!
If the appliance is switched off during a wash cycle, when switched
on again, please re-select the washing cycle and operate the dishwasher
according to the original Power-on state ).
Switch on the appliance
Quick Operation GuideQuick Operation Guide
For detailed operating method read the corresponding content on the instruction manual.
Open the door, press the On/Off button to switch on the appliance.
T urn on the water tap and press the Start/Pause Button. The machine will start working
after about 10 seconds.
Close the door,press the Program Button until the selected program lights up.
( See the section entitled Operation instruction )
1. A running cycle can only be modified if it has been running for a short time. Otherwise the detergent
may have already been released and the water already drained. If in this case, the detergent
dispenser must be refilled.
2. Press the Start/Pause button, the machine will be in standby state, press the program
button more than 3 seconds then you can change the program to the desired cycle setting.
3. Press the Start/Pause Button, the dishwasher will run after 10 seconds.
1.Press the Start/Pause Button to stop the washing.
2.Open the door a little.
3.After the spray arms stop working, you can open the door
completely.
4.Add forgotten dishes.
5.Close the door.
6.Press the Start/Pause Button, the dishwasher will run
after 10 seconds.
AB
C
2

2.Operation Instruction2.Operation Instruction
Dishwasher FeaturesDishwasher Features
before using it for the first time.
To get the best performance from your dishwasher, read all operating instructions
IMPORTANTIMPORTANT
Control PanelControl Panel
8
Back View
Front view
Dispenser
Cup Shelf
Spray arms
Filter assembly
Inlet pipe connector
Drain pipe
Lower Basket
Inner pipe
Upper Basket
1
5
6
7
8
9
3
2
4
9
11.Start/Pause: To start the selected washing program or
pause the washing program when the machine is working.
1.On/Off Button: To turn on/off the power supply.
2.Delay Button : To the button to add the
delay time.
press
10.Program Button :To the button toselect the
appropriate Program.
press
5.Delay indicators: To show the delay time.
9.Half load functionsButton: To select Halfload functions.
(With this Half load function you can only use it when you
have only about or less than 6 place setting dish ware,
and you will see less water and energy consumption ,
90 min .)
8.Program ending lights: To be on when the washing
program is finished.
4.Power indicator :To be on when the power on.
3.Extra drying Button : To select Extra drying
function. Extra drying function Only be used
6.Extra drying indicators: To be on when selected
the Extra drying function.
7.Rinse Aid indicator: To be on when the dispenser
needs to be refilled.
12.Halfload indicator: To be on when selected the
Halfload function.
13. Program indicators:To be onwhen the program that you have
chose;
1133
4466
99
77
55
1010
22
1212
1111
1313
88
5
6
7
1
2
3
4
3
with Intensive, Heavy, Normal, Glassand 90min.)
can only be used with Intensive, Heavy, Normal,Glass and

3.Prior to using for the first time3.Prior to using for the first time
Before using your dishwasher for the first time:
A. Fill the rinse aid dispenser
B. Fill in detergent
A. Rinse Aid DispenserA. Rinse Aid Dispenser
The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can
leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is
designed to use liquid rinse aids. The rinse aid dispenser is located inside the door next to the detergent dispenser.
To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely
black. The volume of the rinse aid container is about 110ml.
Rinse AidDispenser
Function of Rinse Aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.
Attention!
Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance.
As the rinse aid diminishes, the size of the black dot
on the rinse aid level indicator changes, as illustrated below.
Full
3 / 4 full
1 / 2 full
1 / 4 full - Should refill to eliminate spotting
Empty
If there is no rinse-aid warning light in the control panel, you can judge the amount of rinse-aid by the color of the
optical level indicator "C" located next to the cap. When the rinse-aid container is full, the whole indicator will be
dark .As the rinse-aid diminishes, the size of the dark dot decreases. You should never let the rinse aid get below
1 / 4 full.
When to Refill the Rinse Aid Dispenser
How to fill the Rinse Aid Dispenser
To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
Pour the rinse aid into the dispenser, being careful not to overfill.
Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow.
Be careful not to overfill the dispenser, because this could cause over sudsing. Wipe away any spills
with a damp cloth. Don't forget to replace the cap before you close dishwasher door.
Attention!
Clean up any rinse aid spill during filling with an absorbent cloth to avoid excess foaming during the next wash.
1
2
3
C (Rinse-Aid indicator)C
4

Adjusting Rinse Aid Dispenser
The rinse aid dispenser has six or four settings. Always start with the dispenser
set on "4". If spots and poor drying are a problem, increase the amount of rinse
aid dispensed by removing the dispenser lid and rotating the dial to "5". If the
dishes still are not drying properly or are show spots, adjust the dial to the next
higher lever until your dishes are spot-free. The recommended setting is "4".
(Factory value is "4".)
Increase the dose if there are drops of water or lime spots on the dishes after washing.
Reduce it if there are sticky whitish stains on your dishes or a bluish film on glassware or
knife blades.
Adjust lever
(Rinse)
Adjust lever
(Rinse)
during the next wash. Don't forget to replace the cap before you close dishwasher door.
Clean up any rinse aid spilled while during filling with an absorbent cloth to avoid excessive foaming
NOTE:NOTE:
NOTE:NOTE:
Detergents have chemical ingredients that are necessary to remove dirt, crush dirt and transport it out of the dishwasher.
Most of the commercial quality detergents are suitable for this purpose.
B. DetergentB. Detergent
Detergents
There are 3sorts of detergents
1.With phosphate and with chlorine
2.With phosphate andwithout chlorine
3.Without phosphate and without chlorine
MAXMAX
Based on theirchemical composition, detergents can be splitin two basic types:
The use of normal washing programs incombination with concentrated detergents
reduces pollution and is good for your dishes; these wash programs are specifically matched
to the dirt-dissolving properties ofthe enzymes ofthe concentrated detergent. For this reason
normal wash programs in which concentrated detergents are used can achieve the same
results that can otherwise onlybe achieved using intensive programs.
Detergent tablets ofdifferent brands dissolve at different speeds. For this reason some
detergent tablets cannotdissolve and develop their full cleaningpower during short
programs. Therefore please use long programs when usingdetergent tablets, to
ensure the completeremoval of detergent residuals.
The dispenser mustbe refilled before the start ofeach wash cycle following the instructions
provided in the wash cycle table . Your dishwasher uses less detergent and rinse aid than
Conventional dishwasher. Generally, only one tablespoon of detergent is needed for
a normal wash load. More heavily soiled items need more detergent. Always add the
detergent just before starting the dishwasher, otherwise it could get damp and will not
dissolve properly.
Concentrated Detergent
Detergent Tablets
Detergent Dispenser
Conventional, alkaline detergents with caustic components
Low alkaline concentrated detergents with natural enzymes
Normally new pulveriseddetergent is without phosphate. Thus the water softener function of
phosphate is notgiven. If detergents without phosphate areused in the case of hard water
often white spotsappear on dishes and glasses. Inthis case please add more detergent to reach
better results. Detergentswithout chlorine do only bleach alittle. Strong and coloured spots will not
be removed completely. In this case pleasechoose a program with a highertemperature.
5

Adding detergent to dispenser
Proper Use of Detergent
Use only detergentspecifically made for the use indishwashers. Keep yourdetergent fresh and dry.
Don't put powdereddetergent into the dispenser until you'reready to washdishes.
Dishwasher detergent is corrosive!
Take care to keep it out of reach of children.
WARNING!WARNING!
Always add the detergent just before starting each wash cycle.
Only use branded detergent and rinse aid for dishwasher.
If the lid is closed: push the latch to open.
NOTE:NOTE:
Fill the detergentdispenser with detergent.
The marking indicates the dosing levels , as
illustrated on theright:
For main washdetergent.
For pre-wash detergent.
Please observe the manufacturers dosing and storage
Recommendations as stated on the detergent packaging.
Close the lid and press until it locks in place.
If the dishes are heavily soiled, place an additional
detergent dose inthe pre-wash detergent chamber. This detergent willtake effect during the pre-wash phase.
A
B
Fill in Detergent
You see information about the amount of detergent for the single programme on .page 8.
Please be awarethat soiling levels and water hardness can effect wash results.
Please observe themanufacturer's recommendations on the detergent packaging.
Push latch to openPush latch to open
AABB
6

4.Loading the Dishwasher Baskets4.Loading the Dishwasher Baskets
Suitability of use in the dishwasherSuitability of use in the dishwasher
Cutlery with wooden, horn china or
mother-of-pearl handles.
Plastic items thatare not heat resistant.
Older cutlery with glued parts that are not
temperature resistant.
Bonded cutlery itemsor dishes.
Pewter or cooperitems.
Crystal glass.
Steel items subject to rusting.
Wooden platters.
Items made from synthetic fibres.
Some types ofglasses can become
dull after alarge number of washes.
Silver and aluminumparts have a
tendency to discolour during washing.
Glazed patterns may fade if machine
washed frequently.
Not suitable for use Limited suitability
Dishes and items of cutlery must not lie inside one another, or cover each other.
To avoid damage to glasses, they must not be touched.
Load large itemswhich are most difficult to clean into thelower basket.
The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee
and tea cups.
Long bladed knives stored in an upright position are a potential hazard!
Long and/or sharp items of cutlery such as carving knives must be positioned
horizontally in theupper basket.
Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
Load hollow itemssuch as cups, glasses, pans etc. With the openingfacing downwards sothat
water cannot collect in the container or a deep base.
RecommendationRecommendation
Consider buying utensilswhich are identified as dishwasher-proof.
Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further
information from thedetergent manufacturers.
For particular items, select a program with as low temperature as possible.
To prevent damage, do not take glass and cutlery out of the dishwasher immediately
after the program has ended.
(For the best performance ofthe dishwasher,follow these loading guidelines.
Features and appearanceof baskets and cutlery baskets mayvary from your model.)
Scrape off any large food particles. Soften remnants of burnt food in pans.
It is not necessary to rinse the dishes under running water.
Place objects inthe dishwasher in following way:
1.Items such as cups,glasses, pots/pans, etc. are faced downwards.
2.Curved items,or ones with recesses, should beloaded aslant so that water can run off.
3.All utensils are stacked securely and can not tip over.
4.All utensilsare placed in the way that the spray arms can rotate freely duringwashing.
NOTE:NOTE:
Very smallitems should not be washed inthe dishwasher as they could easily fall out ofthe basket.
Attention before or after loading the Dishwasher BasketsAttention before or after loading the Dishwasher Baskets
Toprevent water dripping from the upper basket into the lower basket,we recommend thatyou
empty the lowerbasket first and then the upperbasket.
Removing the DishesRemoving the Dishes
7
