Omega DP18-AC1 User manual



An OMEGA Te chn olo gie s Co m p an y







M2105/1294
INSTRUCTION
SHEET
DP18 Series
Models DP18-AC1 / -AC2 / -AC3 / -AC4
AC Milliammeter
CCD1294APC2BA
DISPLAYS. . . . . . . . . . . . . . . . . . . . . . 3 digits, 7 segment, red LED
HEIGHT . . . . . . . . . . . . . . . . . . . . . . . . 0.56" (14.2 mm.)
SYMBOLS. . . . . . . . . . . . . . . . . . . . . . 1.8.8.8
DECIMALPOINTS . . . . . . . . . . . . . . . . Selectable by jumpers
OVERRANGEINDICATION . . . . . . . . . Display flashing 1999
INPUTCONFIGURATION . . . . . . . . . . . Bipolar single
ZERO . . . . . . . . . . . . . . . . . . . . . . . . . Automatic
SPANADJUSTMENT. . . . . . . . . . . . . . ± 5 %
CONVERTER . . . . . . . . . . . . . . . . . . . . Dual-slope, average value
SIGNALINTEGRATIONPERIOD . . . . . 80 ms.
READRATE . . . . . . . . . . . . . . . . . . . . 3.12 / sec.
RANGES . . . . . . . . . . . . . . . . . . . . . . . See table selection
HOLD . . . . . . . . . . . . . . . . . . . . . . . . . Optional
NOISEREJECTIONNMR . . . . . . . . . . . 50 dB. 50/60 Hz.
ACCURACY . . . . . . . . . . . . . . . . . . . . 0.2 % ± 1 count
WARMUPTORATEDACCURACY . . . 2 minutes
SPANTEMPCO . . . . . . . . . . . . . . . . . . 150 ppm.
ZEROTEMPCO . . . . . . . . . . . . . . . . . . 2.5 µV/°C.
OPERATINGTEMPERATURE . . . . . . . 0 to 50 °C (32 to 122 °F)
STORAGETEMPERATURE . . . . . . . . . -40 to 80 °C (-40 to 176 °F)
WEIGHT . . . . . . . . . . . . . . . . . . . . . . . . 310 gr. (0.68 lb)
CASEMATERIAL . . . . . . . . . . . . . . . . ABS, DIN 43700, black color
STANDARDPOWER . . . . . . . . . . . . . . 115 Vac. ± 10 %, 50/60 Hz.
POWERCONSUMPTION . . . . . . . . . . . 5.5 VA for AC.
ELECTRICALCONNECTIONS . . . . . . . Push-in cable connectors
BURN-IN . . . . . . . . . . . . . . . . . . . . . . . 24 h.
SPAN OFFSET
1
10
D
C
B
A
+
-
REARVIEW
Setpoint R1
(option)
Setpoint R2
(option)
FRONTVIEW
FIG. 2
FIG. 1
SIGNAL
INPUT
SPAN:ADJUSTTHEMAXIMUMREADING.
OFFSET:NOTINSERVICE
SPAN ADJUSTMENT IS ACCESSIBLE BEHIND THE LOW DOOR.
Isolated digital output
(option)
HOLD,latchthereading
display, while these pins
are linked
ANALOG OUTPUT
(OPTION)
POWERSUPPLY
see instrument label
½
2
20
200
1.999
19.99
199.9
DISPLAY
READING
DP18-AC1
DP18-AC2
DP18-AC3
DP18-AC4
RANGE
mAac.
MODEL
2000 1999
DECIMALPOINT
CLOSEJUMPER
FIG.5 mA.
RESOLUTION IMPEDANCE
RS in Ω
D3
D2
D1
-----
221 Ω
22.1 Ω
2.21 Ω
0.187Ω
0.001
0.01
0.1
1
1650 Ω
R4 value
in Ω
1580 Ω
RANGESELECTION
FIG. 3
SIGNALCONDITIONER
PT1
C
B
A
RS
R4
GROSSSPANADJUSTMENT
COMPONENTSVIEW
SIGNALINPUT
mAac
SELECTTHEDESIREDRANGE,MODIFIYNGTHE RESISTANCEVALUERsANDR4,TOGETTHEREADINGDESIRED,
ACCORDINGTOTHEVALUESSHOWNINTHETABLE.
ACCURRENTINSTRUMENT,3½DIGITS,WITHFOURRANGESSELECTABLEONTHESIGNALCONDITIONERBYONLYMODIFIYNGTHE
VALUEOFTWORESISTORS(SEETABLEONFIG.3).THEREADINGCANNOTBEMODIFIEDINENGINEERINGUNITSUNLESSTHEVALUES
OFRSANDR4ARECHANGED.THEREFOREUSINGTHESTANDARDVALUESTHEDISPLAYWILLSHOWEXACTLYTHEVALUEPRESENT
ATTHEINPUTSIGNAL.
SPECIFICATIONS



























DP18 Series
96
(3.78)
44.5
(1.75)
48
(1.89)
MECHANICALDIMENSIONSmm (in)
D3 = 1.XXX
D2 = 1X.XX
D1 = 1XX.X
DECIMALPOINTSSELECTOR
D3 D1D2
INSTALL THE JUMPER IN
THE INDICATED PLACE,
ACCORDING TO THE
RANGESELECTED.
SIGNAL
CONDITIONER
(solderside)
MOTHERBOARD
COMPONENTS
SIDE
POWER SUPPLY
CONNECTOR
FIG.6
FIG.4
FIG.5
SELECTIONOF:DECIMALPOINTSANDSPECIALOPTIONS
OPTIONSANDPOWER SUPPLIESAVAILABLEFOR DP18Series
BCD PARALLELBCD,OPTOISOLATED A01 ANALOGOUTPUT,mA SINK
R1 SINGLESETPOINT,3Amp.Relay A02 ANALOG OUTPUT, mA SOURCE
R2 DUALSETPOINT,3Amp:Relays A03 ANALOGOUTPUT,VOLTAGE
APH1 ANALOGPEAKHOLD APH2 ANALOGPEAKHOLD
232 ISOLATEDSERIALOUTPUTRS-232
OPTION DESCRIPTION OPTION DESCRIPTION OPTION POWER OPTION POWER
CONTROLOUTPUT/COMMUNICATIONSOPTIONS
Select a maximum of one option from each column POWERSUPPLYOPTIONS
115
115
230
AL
J1
J2
JUMPERS SELECTION FOR SPECIAL OPTIONS
AL:OPEN ONLY WHEN ALARMSETPOINTCARDOPTION IS ADDED
J1: OPENTOELIMINATETHELEAST-SIGNIFICANTDIGIT(LSD)
J2: OPENTO ELIMINATE THE INDICATION±
PANELCUTOUT
CONNECTOR FOR ANALOG OUTPUT
(OPTIONAL)
13
(0.51)
102
(4.02) 15
(0.59)
5 max. (0.20)
92.5
(3.64)
230 230Vac 50/60Hz
STD 115 Vac 50/60 Hz 15/30Vdc 15...30Vdc.-10%(3.5W)
24 24Vac 50/60Hz 24/65Vdc 24...65 Vdc(4W) isolated
48 48Vac 50/60Hz
isolated
MOTHERBOARD
SOLDERSIDE

