Overview
This document provides installation and service instructions for the External Return Bin (ERB)
on the G3 cabinets, the G3 cabinets with the G4 electronics box, and the G4 cabinets.
The ERB is used to collect unused medication after it has been issued to a patient. Only one return
bin is supported per cabinet.
The ERB can be mounted to:
OmniRx Color Touch cabinets
OmniTT Color Touch cabinets
Half-Cell Color Touch cabinets
One-, two-, and three-cell Color Touch cabinets
Anesthesia Workstations
Walls
Table tops
The ERB comes built with a standard 4-foot cable mounted on the right side of the bin.
Software Requirements
The cabinet to which the ERB is attached must be running Color Touch 5.3 or higher.
Software Configuration Options
Refer to the Color Touch user guide of the version on the cabinet for the options that support the
External Return Bin.
Tools
The following tools are needed to install or mount the External Return Bin:
Nut driver (5/16", 11/32", and 1/4")
Allen wrench (3/32", 9/64" and 5/32")
Crescent wrench
T8 Torx driver
T10 Torx driver
T15 Torx driver
T20 Torx driver
Phillips screwdriver #2 for the ERB handle

1-2 Overview
ERB Components
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
ERB Components
Figure 1-1 shows the components from the External Return Bin manufactured assembly. For a
listing of kits, components or spares, see “Appendix A: Parts” on page A-1.
Figure 1-1. ERB Mfg. Assembly #14-7030
Mounting Brackets
Kit #20-6021 contains various mounting brackets. The mounting part numbers and type are
stamped into the metal.
OmniRx
Figure 1-2. OmniRx brackets
Return
Door
Access Door
key #2204 key #2202
Foam Pad
Metal
Retainer
Strain Relief
Plug Cover
4 ft. Cable
Assy
Molex
Connector
3-Pin
Header
6-Pin
Header
AUX Connector
4-Pin
Header

© 2011 Omnicell, Inc. External Return Bin Installation and Service Guide/67-2038 Rev D
Overview 1-3
ERB Components
OmniTT
Figure 1-3. OmniTT brackets
Half-Cell Cabinet
Figure 1-4. Half-cell cabinet brackets
One-, Two-, and Three-Cell Cabinet
Figure 1-5. One-, two-, and three-cell cabinet brackets

1-4 Overview
ERB Components
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
Anesthesia Workstation (AWS) G3
Figure 1-6. AWS G3 bracket
Anesthesia Workstation (AWS) G4
Figure 1-7. AWS G4 bracket

© 2011 Omnicell, Inc. External Return Bin Installation and Service Guide/67-2038 Rev D
Overview 1-5
ERB Components
Wall and Table Templates
Drill templates are available for mounting an ERB to a wall or table.
Figure 1-8. Wall and table mount templates #60-0052

1-6 Overview
ERB Components
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.

© 2011 Omnicell, Inc. External Return Bin Installation and Service Guide/67-2038 Rev D
2-1
Installation Instructions
Setup
Before installing the ERB, change the cabling configuration if necessary, and perform cabinet
preparation.
Cable Assembly Configuration
If the ERB is to be installed on the right side of the cabinet, skip to “Cabinet Preparation” on
page 2-10.
If the ERB is to be installed on the left side of the cabinet, continue in this section to change the
cabling configuration.
1. Place the ERB on a flat clean surface.
2. Open the access door using both keys. Key #2204 unlocks the access door. Key #2202 overrides
the solenoid.
Figure 2-1. Unlock the access door
Important: The ERB cable assembly is configured to be installed on the right side of cabinets with the
cables leading to the back. If the ERB is to be installed on the left side of the cabinet, the cable assembly
must be switched to the left side. This avoids having to bend cables back across the ERB to reach the
back of the cabinet.

2-2 Installation Instructions
Setup
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
3. Lay the ERB down as shown in Figure 2-2, and unscrew the two 4-40 flat head fasteners from
under the ERB.
Figure 2-2. Unscrewing the fasteners
4. Turn the ERB upright and lift out both I/O cover plates.
Figure 2-3. Removing the I/O cover plates
5. Remove the PCB/solenoid metal mount.
a. Open the return door.
b. Push the pawl of the solenoid to the left.
Figure 2-4. Pushing the pawl

© 2011 Omnicell, Inc. External Return Bin Installation and Service Guide/67-2038 Rev D
Installation Instructions 2-3
Setup
c. Loosen, but do not remove, the two nuts on either side of the PCB/solenoid plate with a
5/16" nut driver.
Figure 2-5. Loosening the nuts on both sides of the PCB/solenoid plate
d. Maneuver the PCB/solenoid mount around the sheet metal tabs and nuts. Remove the
lower rim first.
Figure 2-6. Removing the PCB/solenoid mount
Under the PCB/solenoid mount is an internal cover to reduce the radiated emissions level.
6. Remove the RFI cover that is under the PCB/solenoid mount.
a. Loosen the two hex nuts on either side of the internal cover using a 5/16” nut driver or
socket.
Figure 2-7. Loosening hex nuts

2-4 Installation Instructions
Setup
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
b. Disconnect the yellow solenoid cable for convenience.
Figure 2-8. Disconnecting solenoid cable
c. Lift the RFI cover off the two studs. Slide the wiring rubber grommets down the two
keyhole slots and remove the RFI cover completely.
Figure 2-9. PC board with RFI cover removed
7. Unplug the PowerCom cable from J1 on the PC board.
Figure 2-10. J1 location on the PC board

© 2011 Omnicell, Inc. External Return Bin Installation and Service Guide/67-2038 Rev D
Installation Instructions 2-5
Setup
8. Remove the gray PowerCom cable from the right side of the ERB and set it aside.
Figure 2-11. Removing the PowerCom cable
9. Squeeze and pull the black grommet to remove it from the opening.
10. Remove the black plug cover by pushing against the groove from the inside with a screwdriver.
Figure 2-12. Removing the plug cover
11. Thread the PowerCom cable through the rear cutout on the opposite side of the ERB. The
correct orientation of the cable assembly exiting from the left side of the ERB is shown in the
figure below.
Figure 2-13. PowerCom cable routing

2-6 Installation Instructions
Setup
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
12. Cover the gray PowerCom cable with the black grommet taken off in step 9. Squeeze the
grommet together and push through the double D cutout on the left side.
Figure 2-14. Securing the grommet around the PowerCom cable
13. Snap the plug cover into the left-side D cutout adjacent to the cable assembly. The plug covers
the opening which will be used for future hardware developments.
Figure 2-15. Snapping in the plug
14. Rotate the lower plates. The open side of the left lower plate should face left. The open side of
the right lower plate should face down. This allows the left cover plate to protect the cables
being routed out of the ERB. The right cover plates will seal the cable openings on the right
side of the ERB.
Figure 2-16. Orientation for left cover plates

© 2011 Omnicell, Inc. External Return Bin Installation and Service Guide/67-2038 Rev D
Installation Instructions 2-7
Setup
15. Install the left I/O cover plates. Take care not to pinch any wires.
Figure 2-17. Left I/O cover plate
16. Re-insert the PowerCom cable into J1 on the PC board. Make sure all 6 pins on the cable
connector are inserted.
Figure 2-18. J1 location
17. Secure the left I/O cover with the 4-40 flat head fastener removed in step 3 on page 2-2.
Figure 2-19. Replacing the fasteners
Note: The 6-pin white connector is not used.
6-pin
connector

2-8 Installation Instructions
Setup
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
18. Reinstall the RFI cover.
a. Slide the two grommets back into the keyhole openings on the top and bottom of the RFI
cover. Hold the RFI cover over the studs against the rear wall. Make sure wires are not
pinched.
Figure 2-20. RFI rubber grommet
b. Reconnect the 2 position yellow wire solenoid cable, and slide the internal cover over the
studs.
Figure 2-21. Sliding RFI over studs
c. Retighten the two hex nuts. Tighten using the 5/16” nut driver or socket.
19. Reinstall the PCB/solenoid mount with the solenoid inserted first into the ERB housing,
clearing the return door. Keep the external return door open while reinstalling the mount
plate.
Figure 2-22. Installing the PCB/solenoid mount

© 2011 Omnicell, Inc. External Return Bin Installation and Service Guide/67-2038 Rev D
Installation Instructions 2-9
Setup
20. Maneuver the plate onto the two studs behind the nuts and position the bottom rim behind the
sheet metal tabs. Be careful not to pinch the wires behind the plate.
21. Tighten the two loose nuts with a 5/16" nut driver.
Figure 2-23. Tightening the nuts
22. Install the right I/O cover plates.
23. Secure the right I/O cover plates with the 4-40 flat head fastener removed in step 3 on
page 2-2. The side that does not have the cable installed has the two D cutouts covered by the
I/O cover.
Figure 2-24. Covered cutouts
24. Close the return door.
25. Check that the solenoid lock mechanism is latching correctly.
Figure 2-25. Complete assembly

2-10 Installation Instructions
Installation on G3 Cabinets
External Return Bin Installation and Service Guide/67-2038 Rev D © 2011 Omnicell, Inc.
Cabinet Preparation
1. Perform a graceful shutdown on the cabinet that is to have an ERB mounted.
2. Unplug the power cable.
3. Refer to the Omnicell Drug Handling Policy and Procedures for information regarding the
removal of drugs from the internal return bin drawer.
4. Empty the contents of the internal return bin drawer if it exists.
Installation on G3 Cabinets
This section contains ERB installation instructions for various G3 cabinet types. For installation
on G3 cabinets that have the new G4 E-box, see “Installation on G3 Cabinets with G4 Console
Upgrade” on page 2-40. For installation on G4 cabinets, see “Installation on G4 Cabinets” on
page 2-45.
This section describes installation procedures for the following:
“OmniTT” on page 2-10
“OmniRx” on page 2-17
“Half-Cell” on page 2-19
“One-, Two-, and Three-Cell Cabinets” on page 2-21
“Anesthesia Workstation (AWS) G3” on page 2-26
OmniTT
Attaching the ERB to the OmniTT
1. Remove the two screws securing the transport handle on the right side of the OmniTT Color
Touch cabinet, then remove the original transport handle.
Figure 2-26. Removing the original transport handle
Caution: The pharmacist must be present when servicing any drawers where medication is present.
Important: Once the ERB is enabled, the internal return bin is no longer accessible.
