Omnimount PANA103PRO Guide

DOCUMENTNO:IA‐PANA103PRO_REV.A1
INSTALLATIONANDASSEMBLY INSTRUCTIONS
ALLDIMENSIONS‐MM(INCH)
MODEL:PANA103PRO
MAXLOADCAPACITY:500LB(227KG)

DOCUMENTNO:IA‐PANA103PRO_REV.A1
INSTALLATIONANDASSEMBLY INSTRUCTIONS
ALLDIMENSIONS‐MM(INCH)
MODEL:PANA103PRO
MAXLOADCAPACITY:500LB(227KG)
NOTE:READENTIREINSTRUCTIONSHEETBEFOREYOUSTARTINSTALLATIONANDASSEMBLY

WARNING

•DonotbegintoinstallyourPanasonicproductuntilyouhavereadandunderstandallinstructionsand
warningscontainedinthisInstallationSheet.Ifyouhaveanyquestionsregardinganyinstructions
and/orwarningspleasecallPanasonicCustomerSupport.
•Thisproductshouldonlybeinstalledbyaqualifiedprofessional.
•Makesurethatthesupportsurfacewillsafelysupportthecombinedloadoftheequipmentandall
attachedhardwareandcomponents.
•NeverexceedtheMaximumLoadCapacityofthismount:500lbs(227kg)
•Alwaysuseanassistantormechanicalliftingequipmenttosafelyliftandpositionequipment
•Tightenscrewsfirmly,butdonotovertighten.Overtighteningcandamageitems,greatlyreducing
theirabilitytohold.


PARTSLIST
ItemDescriptionQtyPart#
ABRACKET,WALL(RIGHT)11100222‐08
BBRACKET,WALL(LEFT)11100222‐02
CBRACKET,PANEL21100222‐07
DROD,HANGING41100222‐901(PARTOFBRACKET,PANEL)
EBOLT,HANGINGROD(HF0.5‐13X3.5)492965A716(MC)
FWASHER,FLAT(1/2ID,13/8OD)1698029A033(MC)
GNUT,HANGINGROD(1/2)891581A385(MC)
HSCREW,HEXHEADLAG(1/2X3‐1/2)1691478A726(MC)
IWASHER,FLAT(16MM)498035A109(MC)
JWASHER,LOCKING(16MM)491190A590(MC)



















J
H
I

DOCUMENTNO:IA‐PANA103PRO_REV.A1
INSTALLATIONANDASSEMBLY INSTRUCTIONS
ALLDIMENSIONS‐MM(INCH)
MODEL:PANA103PRO
MAXLOADCAPACITY:500LB(227KG)

INSTALLATIONTOTHEWALL

WARNING

•Installermustverifythatthesupportingsurfacewillsafelysupportfour(4)timesthecombinedweight
ofallattachedequipment(wallmount)andhardwarealongwithpanel.
•Mountisonlymeantforsurfacemountingtoawall.Forrecessedmountingoranyothermounting
pleasecontactOmnimountCustomerService.



•Use½”x3½”HexHeadLagScrews(H)and½”FlatWashers(F)toattachWallBrackets(A&B)towall
ineight(8)placesperWallBracket.

•DistancebetweeninsideedgesofWallBracketsmustbe46"(1167mm)andWallBracketsmustbe
levelandsquaretooneanother.





CAUTION

•IfWallBracketsarenotlevelandsquare,mountmaynotfunctionproperly.
•IfusingcustomfastenerstoattachWallBracketstowallbesurethatfastenerscansupportthe
combinedweightofallattachedequipmentincludingwallmountandpanel.


INSTALLATIONTOTHEPANEL


DOCUMENTNO:IA‐PANA103PRO_REV.A1
INSTALLATIONANDASSEMBLY INSTRUCTIONS
ALLDIMENSIONS‐MM(INCH)
MODEL:PANA103PRO
MAXLOADCAPACITY:500LB(227KG)

•Removespacersfromrearofscreen.Retainfour(4)16MMscrewsforinstallationofPanelBrackets.

•SecurePanelBrackets(C)torearofscreenbyusingtheoriginal16MMscrewsalongwithfour(4)Flat
Washers(I)andfour(4)LockingWashers(J).



CAUTION

•Ensurethateachfasteneristightandsecurepriortopreparingpaneltoliftandhanginposition.





































SETTINGANDADJUSTINGTILTPOSITION(S)/VERTICALANDLATERALADJUSTMENT

DOCUMENTNO:IA‐PANA103PRO_REV.A1
INSTALLATIONANDASSEMBLY INSTRUCTIONS
ALLDIMENSIONS‐MM(INCH)
MODEL:PANA103PRO
MAXLOADCAPACITY:500LB(227KG)

WARNING

•Ensurethatalladjustmentsaremadewithpropersupportofthepanelatalltimes.Noadjustments
shouldbemadeunlessdonebyaqualifiedinstallationprofessional.



TILTADJUSTMENT

•RemovethelowerboltshowninFig.1(Factoryinstallationissetat0°tilt)
•NOTE:Retainallhardwareforinstallationaftertiltpositionisselected.
•Selecttheproperholebasedonthedesiredtiltrequirement.
•Inserttheboltbackintoposition‐ensurethatthetubefromthepanelbrackethasremainedinthe
wallbracketandhasnotmovedfromtheinstallationposition.
•Secureallhardware.

Fig.1

DOCUMENTNO:IA‐PANA103PRO_REV.A1
INSTALLATIONANDASSEMBLY INSTRUCTIONS
ALLDIMENSIONS‐MM(INCH)
MODEL:PANA103PRO
MAXLOADCAPACITY:500LB(227KG)

LATERALADJUSTMENT

•Ensurethatthepanelisproperlysupportedduringlateraladjustment.
•LiftthepanelperPanasonicliftingrequirementstoremovetheloadfromtheinstalledcomponents.
•Thepanelmaybeshiftedfromsidetosideforfinalpositioningandthensetbackintotheretaining
slotsofthewallbracket.

VERTICALADJUSTMENT

•NOTE:Verticaladjustmentshouldonlybedonebyaqualifiedinstallationprofessional.
•NOTE:Factoryinstallationispresettothelowest(bottom)position.
•Verticaladjustmentisintendedtosupportthefinallevelingprocessoftheinstallationandshouldnot
beusedinanyotherinstallationmanner.
•LocatetheverticaladjustmentfastenerontopofeachinstallationwallbracketasshowninFig.2
•Theboltmaybeusedtoeitherraiseand/orlowertheverticalpositionforeachwallbracketasneeded
tolevel.





 





