Omnimount 37FB-T Manual

800.MOUNT.IT (800.668.6848)
12132010
Product Specifications
Fits most: 23” - 42” flat panels
Supports up to: 80 lbs (36.3 kg)
Tilt: -5º to +15º
Mounting profile: 1.9” (49mm)
Universal & VESA compliant: 100x100 to 300x400
Mounting: Double-stud
UL listed: Yes
Warranty: 5 years
Color: Black
Product Benefits
• Tilt -5° to +15° to reduce glare
• Universal rails for greater panel compatibility
• Lift n’ Lock™for quick installation
• Tension adjustment for variable tilt
• Sliding lateral on-wall adjustment
• Open architecture for easy trim out
• Locking bar secures panel to mount
• Includes complete Grade 5 hardware kit
Dedicated to being a one-stop shop for professional products,
OmniMount remains on the cutting edge of product innovation.
That’s why we’re the natural choice for any professional,
industrial or commercial application. The Fastback Series
offers both fixed and tilt universal mounting solutions that are
designed for quick and easy installs. The 37FB-T is
ideal for budget-conscious customers or high-volume
jobs requiring a dependable medium tilt mount.
Series
37FB-T product information sheet
37FB-T
37FB-F
54FB-F
54FB-T
63FB-F
Keeping ease-of-installation in
mind, the 37FB-T was designed to
be installed in a few simple steps

800.MOUNT.IT (800.668.6848)12132010
Dimensions WxDxH Inches (mm) Wt lbs (kg) Qty
Box 11.2 x 21.1 x 2.8 (285x535x70) 7.2 (3.3) NA
MC 11.8 x 22.8 x 5.5 (300x580x140) 21 (9.5) 2
Color Stock Code Packaging UPC MC UPC
Americas Black 1002885PRO 728901015052 728901708350
International Black NA NA NA
Product Specifications
Fits most: 23” - 42” flat panels
Supports up to: 80 lbs (36.3 kg)
Tilt: -5º to +15º
Mounting profile: 1.9” (49mm)
Universal & VESA compliant: 100x100 to 300x400
Mounting: Double-stud
UL listed: Yes
Warranty: 5 years
Color: Black
Product Benefits
• Tilt -5° to +15° to reduce glare
• Universal rails for greater panel compatibility
• Lift n’ Lock™for quick installation
• Tension adjustment for variable tilt
• Sliding lateral on-wall adjustment
• Open architecture for easy trim out
• Locking bar secures panel to mount
• Includes complete Grade 5 hardware kit
Dedicated to being a one-stop shop for professional
products, OmniMount remains on the cutting edge
of product innovation. That’s why we’re the natural
choice for any professional, industrial or commercial
application. The Fastback Series offers both fixed and
tilt universal mounting solutions that are designed
for quick and easy installs. The 37FB-T is ideal for
budget-conscious customers or high-volume jobs
requiring a dependable medium tilt mount.
37FB-T technical data sheet
Box Contents Qty
Wall plate 1
Tilt rail 2
Locking bar 1
Complete mount installation hardware kit 1
Box Contents Qty
Complete panel attachment hardware kit 1
Instruction manual 1
Flat panel compatibility chart 1

Architects Specifications
800.MOUNT.IT (800.668.6848)
inches (mm)
12132010
The flat panel wall shall be an OmniMount model 37FB-T and shall be located where indicated on the plans. It shall be constructed of sheet
metal with -5º/+15º adjustable forward tilt. Assembly and installation shall be done according to instructions provided by the manufacturer.
WALL MOUNTING
FRONT VIEW
MOUNTING PROFILE
PANEL ATTACHMENT -
VESA COMPATABILITY (mm)
18.9
(479)
18.7
(475)
8
(203)
9.7
(245)
17
(432)
(100 - 400)
(338)
14.5
(368)
2.2
(57)
R .2
(4)
.75
(19)
1.2
(30)
Ø (9)
(30)
10.2
(260)
-5˚ to +15˚
37FB-T line drawing
