Omnitron Systems OmniConverter FPoE/SL User manual

OmniConverter®
FPoE/SL
User Manual
38 Tesla, Irvine, CA 92618 USA
Phone: [phone]; Fax: [phone]
General and Copyright Notice
This publication is protected by U.S. and international copyright laws. All rights
reserved. The whole or any part of this publication may not be reproduced, stored
in a retrieval system, translated, transcribed, or transmitted, in any form, or by
any means, manual, electric, electronic, electromagnetic, mechanical, chemical,
optical or otherwise, without prior explicit written permission of Omnitron Systems
Technology, Inc.
The following trademarks are owned by Omnitron Systems Technology, Inc.:
FlexPointTM, FlexSwitchTM, iConverter®, miConverterTM, NetOutlook®, OmniLight®,
OmniConverter®, RuggedNet®, Omnitron Systems Technology, Inc.TM, OSTTM and
the Omnitron logo.
All other company or product names may be trademarks of their respective owners.
The information contained in this publication is subject to change without notice.
Omnitron Systems Technology, Inc. is not responsible for any inadvertent errors.
Warranty
This product is warranted to the original purchaser (Buyer) against defects in
material and workmanship for a period of two (2) years from the date of shipment.
A lifetime warranty may be obtained by the original purchaser by registering this
product at www.omnitron-systems.com/support within ninety (90) days from the
date of shipment. During the warranty period, Omnitron will, at its option, repair or
replace a product which is proven to be defective with the same product or with a
product with at least the same functionality.
For warranty service, the product must be sent to an Omnitron designated facility,
at Buyer’s expense. Omnitron will pay the shipping charge to return the product to
Buyer’s designated US address using Omnitron’s standard shipping method.
Limitation of Warranty
The foregoing warranty shall not apply to product malfunctions resulting from
improper or inadequate use and/or maintenance of the equipment by Buyer, Buyer-
supplied equipment, Buyer-supplied interfacing, unauthorized modications or
tampering with equipment (including removal of equipment cover by personnel not
specically authorized and certied by Omnitron), or misuse, or operating outside
the environmental specication of the product (including but not limited to voltage,
ambient temperature, radiation, unusual dust, etc.), or improper site preparation
or maintenance.
No other warranty is expressed or implied. Omnitron specically disclaims the implied
warranties of merchantability and tness for any particular purpose.
The remedies provided herein are the Buyer’s sole and exclusive remedies. Omnitron
shall not be liable for any direct, indirect, special, incidental, or consequential
damages, whether based on contract, tort, or any legal theory.
Page 2

OmniConverter FPoE/SL
User Manual
Product Overview
The OmniConverter FPoE/SL media converters with multi-port options provide
10/100BASE-T copper to 100BASE-FX ber conversion and function as Power-
over-Ethernet (PoE) Power Sourcing Equipment (PSE). Port congurations are
available in single or dual RJ-45 and SFP ports.
OmniConveter FPoE/SL
Equipment that provides DC power over twisted-pair cable is known as Power
Sourcing Equipment (PSE). Equipment that is powered over twisted-pair cable is
known as a Powered Device (PD).
The FPoE/SL supports IEEE 802.3af PoE standard and provides up to 15.4W of
DC power to each PD.
Installation Procedure
1) Congure DIP-switches
2) Install the Module
3) Apply Power
4) Connect Cables
5) Verify Operation
1) Congure DIP-switches
DIP-switches are located on the side of the module. The DIP-switches are used to
congure ports, link modes and PoE/PSE options.
Page 4
Environmental Notices
The equipment covered by this manual must be disposed of or recycled in
accordance with the Waste Electrical and Electronic Equipment Directive (WEEE
Directive) of the European Community directive 2012/19/EU on waste electrical and
electronic equipment (WEEE) which, together with the RoHS Directive 2015/863/
EU, for electrical and electronic equipment sold in the EU after July 2019. Such
disposal must follow national legislation for IT and Telecommunication equipment
in accordance with the WEEE directive: (a) Do not dispose waste equipment with
unsorted municipal and household waste. (b) Collect equipment waste separately.
(c) Return equipment using collection method agreed with Omnitron.
The equipment is marked with the WEEE symbol shown to indicate that it
must be collected separately from other types of waste. In case of small items the
symbol may be printed only on the packaging or in the user manual. If you have
questions regarding the correct disposal of equipment go to www.omniton-systems.
com/support or e-mail to Omnitron at [email protected].
Safety Warnings and Cautions
ATTENTION: Observe precautions for handling electrostatic discharge
sensitive devices.
WARNING: Potential damage to equipment and personal injury.
WARNING: Risk of electrical shock.
Customer Support Information
If you encounter problems while installing this product, contact Omnitron Technical
Support:
Phone: [phone]
Fax: [phone]
Address: Omnitron Systems Technology, Inc.
38 Tesla
Irvine, CA 92618, USA
Email: [email protected]
URL: www.omnitron-systems.com
040-09340-001C 11/21
Page 3

DIP-switch Bank Locations
The table below provides a description of each DIP-switch position and function.
Switch 1 Fiber, 1 RJ-45 1 Fiber, 2 RJ-45 2 Fiber, 1 RJ-45 2 Fiber, 2 RJ-45
1 Port 1 Duplex Mode Port 1 Duplex Mode Port 1 Duplex Mode Port 1 Duplex Mode
2 N/A N/A Port 2 Duplex Mode Port 2 Duplex Mode
3Port 2 RJ-45
AUTO/MAN
Port 2 RJ-45
AUTO/MAN
Port 3 RJ-45
AUTO/MAN
Port 3 RJ-45
AUTO/MAN
4Port 2 RJ-45 Speed
(Only in MAN mode)
Port 2 RJ-45 Speed
(Only in MAN mode)
Port 3 RJ-45 Speed
(Only in MAN mode)
Port 3 RJ-45 Speed
(Only in MAN mode)
5Port 2 RJ-45 Duplex
(Only in MAN mode)
Port 2 RJ-45 Duplex
(Only in MAN mode)
Port 3 RJ-45 Duplex
(Only in MAN mode)
Port 3 RJ-45 Duplex
(Only in MAN mode)
6 Pause Capability Pause Capability Pause Capability Pause Capability
7 RJ-45 Port 2 PoE/PSE RJ-45 Port 2 PoE/PSE RJ-45 Port 3 PoE/PSE RJ-45 Port 3 PoE/PSE
8 N/A RJ-45 Port 3 PoE/PSE N/A RJ-45 Port 4 PoE/PSE
9RJ-45 Port 2 Alt A/B RJ-45 Port 2 Alt A/B RJ-45 Port 3 Alt A/B RJ-45 Port 3 Alt A/B
10 N/A RJ-45 Port 3 Alt A/B N/A RJ-45 Port 4 Alt A/B
11 Large Cap Detection Large Cap Detection Large Cap Detection Large Cap Detection
12 Link Mode Selection Link Mode Selection Link Mode Selection Link Mode Selection
13 Link Mode Selection Link Mode Selection Link Mode Selection Link Mode Selection
14 PSE Reset PSE Reset PSE Reset PSE Reset
15 N/A N/A Redundant Fiber Link Redundant Fiber Link
16 N/A N/A Return to Port 1 Return to Port 1
DIP-switch Denitions
SW1 and SW2: F/O Duplex “FDX/HDX” DIP-switch
The OmniConverter supports 100BASE-FX SFPs and xed ber transceivers.
These DIP-switches are used to congure the ber duplex mode. Setting these
DIP-switches to the Up “HDX” position facilitates a connection that supports
Half-Duplex. Setting these DIP-switches to the Down “FDX” position facilitates a
connection that supports Full-Duplex operation.
Page 5
SW3, SW4 and SW5 RJ-45 Conguration DIP-Switches
SW3
RJ-45
AN/MAN
SW4
RJ-45
100/10
SW5
RJ-45
FDX/HDX
RJ-45 Mode of Operation
AN 100 FDX The RJ-45 port is set to auto-negotiation with the following modes
advertised: 100FDX, 100HDX, 10FDX, 10HDX
AN 100 HDX The RJ-45 port is set to auto-negotiation with the following modes
advertised: 100HDX, 10FDX, 10HDX
AN 10 FDX The RJ-45 port is set to auto-negotiation with the following modes
advertised: 10FDX, 10HDX
AN 10 HDX The RJ-45 port is set to auto-negotiation advertising 10HDX.
MAN 100 FDX The RJ-45 port is set to manual negotiation and is forced to 100FDX.
MAN 100 HDX The RJ-45 port is set to manual negotiation and is forced to 100HDX.
MAN 10 FDX The RJ-45 port is set to manual negotiation and is forced to 10FDX.
MAN 10 HDX The RJ-45 port is set to manual negotiation and is forced to 10HDX.
RJ-45 Port Conguration Matrix
SW6 - Pause “On/Off” DIP-Switch
In auto-negotiation mode, setting this DIP-switch to the Up “On” position allows the
unit to advertise Symmetrical and Asymmetrical Pause capability. In auto-negotiation
mode, setting the DIP-switch to the Down “Off” position allows the unit to advertise
no Pause capability. In the manual mode, this DIP-switch determines the Pause
behavior.
SW7 - Power Sourcing Function, RJ-45 Port
The module automatically detects the attached PD and provides the equipment
with the necessary power.
This DIP-switch controls the power sourcing function for Port 2 on the single-ber
models and Port 3 on all other models (see DIP-switch Denition table on page
5). When this DIP-switch in the Down “On” position, the power sourcing function
is enabled. When the DIP-switch is in the Up “Off” position, the power sourcing
function is disabled.
Switch Position Description DOWN UP
7 RJ-45 Port 2 or 3 PoE/PSE Enabled (ON) Disabled (OFF)
8 RJ-45 Port 3 or 4 PoE/PSE Enabled (ON) Disabled (OFF)
Power Sourcing Function
SW8 - Power Sourcing Function, RJ-45 Port
This DIP-switch controls the power sourcing function for the 2nd RJ-45 port on
the 2 RJ-45 port models (see DIP-switch Denition table on page 5). When this
DIP-switch in the Down “On” position, the power sourcing function is enabled. When
the DIP-switch is in the “Off” UP position, the power sourcing function is disabled.
Page 6

SW9, SW10 and SW11 - Power Sourcing Modes
The RJ-45 ports can be congured to support different powering modes. The
powering modes include Alternative A (supporting power on pins 1,2 and 3,6),
Alternative B (supporting power on pins 4,5 and 7,8) and legacy Power Devices
(PDs) that use large capacitance for detection.
PoE Modes
SW9 SW10 SW11 1 Fiber 1 RJ-45 2 Fiber 1 RJ-45
Port 2 Port 3
DOWN N/A DOWN IEEE Alt A IEEE Alt A
UP N/A DOWN IEEE Alt B IEEE Alt B
DOWN N/A UP Large Capacitor Detection
+ Alt A
Large Capacitor Detection
+ Alt A
UP N/A UP Large Capacitor Detection
+ Alt B
Large Capacitor Detection
+ Alt B
Power Sourcing Modes for Models with 1 RJ-45 Port
PoE Modes
SW9 SW10 SW11 1 Fiber 2 RJ-45 2 Fiber 2 RJ-45
Port 2 Port 3 Port 3 Port 4
DOWN DOWN DOWN IEEE Alt A IEEE Alt A IEEE Alt A IEEE Alt A
UP DOWN DOWN IEEE Alt B EEE Alt A IEEE Alt B EEE Alt A
DOWN UP DOWN IEEE Alt A IEEE Alt B IEEE Alt A IEEE Alt B
UP UP DOWN IEEE Alt B IEEE Alt B IEEE Alt B IEEE Alt B
DOWN DOWN UP Large Capacitor
Detection + Alt A
Large Capacitor
Detection + Alt A
Large Capacitor
Detection + Alt A
Large Capacitor
Detection + Alt A
UP DOWN UP Large Capacitor
Detection + Alt B
Large Capacitor
Detection + Alt A
Large Capacitor
Detection + Alt B
Large Capacitor
Detection + Alt A
DOWN UP UP Large Capacitor
Detection + Alt A
Large Capacitor
Detection + Alt B
Large Capacitor
Detection + Alt A
Large Capacitor
Detection + Alt B
UP UP UP Large Capacitor
Detection + Alt B
Large Capacitor
Detection + Alt B
Large Capacitor
Detection + Alt B
Large Capacitor
Detection + Alt B
Power Sourcing Modes for Models with 2 RJ-45 Ports
On devices with two RJ-45 ports, SW11 enables large cap detection on BOTH ports
(see table above).
Page 7
RJ-45 Pinout PoE Modes
Alternative A Alternative B
1 Vport Positive
2 Vport Positive
3 Vport Negative
4 Vport Positive
5 Vport Positive
6 Vport Negative
7 Vport Negative
8 Vport Negative
Voltage Polarity for PoE Options
NOTE: Alternative A and Alternative B pinouts are compliant with IEEE802.3af
specication.
SW12 and SW13 - Link Modes
The OmniConverter supports Link Segment and Asymmetrical Link Propagate. See
Appendix A for Link Mode block diagrams.
Link Segment
In Link Segment mode, all ports operate independently. A loss of a receive link signal
will only affect the port detecting the loss of signal. All the other ports will continue
to generate a link signal. A loss of link on the RJ-45 port will only affect the RJ-45
port, and the other ports will remain unaffected.
Asymmetrical Link Propagate
In Asymmetrical Link Propagate mode, faults are propagated based on the port
notation. Port 1 to Port 2 notation indicates the direction the loss of link signal will
propagate. A loss of receive link on the ber optic Port 1 causes the RJ-45 Port 2 to
drop its link due to the propagated state (Port 1 to Port 2). The loss of link on the
RJ-45 Port 2 does not cause the loss of link to propagate. The loss only propagates
in the Port 1 to Port 2 direction. See Port Congurations on page 4.
NOTE: A loss of link or loss of signal is when the optical receiver on the media
converter can no longer detect the presence of an optical signal.
NOTE: On models with 2 ber ports or 2 RJ-45 ports, both ports of the same
media type must be in link fault condition before the fault will propagate.
Page 8

SW12 SW13 Function
DOWN DOWN Link Segment (LS)
UP DOWN
Asymmetrical Link Propagate Port 1 to Port 2 (1+1 - 2 Port models),
Port 1 to Port 2 and Port 3 (1+2 - 3 Port models),
Port 1 and Port 2 to Port 3 (2+1 - 3 Port models) and
Port 1 and Port 2 to Port 3 and Port 4 (2+2 - 4 Port models).
DOWN UP
Asymmetrical Link Propagate Port 2 to Port 1 (1+1 - 2 Port models),
Port 2 and Port 3 to Port 1 (1+2 - 3 Port models)
Port 3 to Port 1 and Port 2 (2+1 - 3 Port models)
and Port 3 and Port 4 to Port 1 and Port 2 (2+2 - 4 Port models)
UP UP Invalid Conguration
Link Modes
SW14 - Power Sourcing Reset
The OmniConverter can be congured to disable (reset) the PoE output power for 2
seconds after a loss of receive link on any ber port. This feature is typically used
to allow a PD to re-initialize after a failure on the incoming ber. When this DIP-
switch is in the Up “Lk Loss” position, the module will disable PoE output power for
2 seconds following a loss of receive link on any ber port. When this DIP-switch
is in the Down position, PoE output power does not reset on ber link loss.
SW15 and SW16 - Port Redundant Mode
SW15 and SW16 are valid on models with 2 ber ports only. Port redundancy is
available when connected to Omnitron and third party devices with 2 ber ports.
SW15 controls the port redundancy mode of the module. When SW15 is in the Down
“Off” (default) position, the ber ports operate in a non-redundant (independent)
mode. When SW15 is in the Up “On” position, the ber ports operate as redundant
links. A fault on the primary ber port (Port 1), will cause a fail over to the secondary
ber port (Port 2) within 50msec.
SW16 enables the module to return to the primary ber port (Port 1) after the ber
link has been restored for 6 seconds. When SW16 is in the Down “Off” position,
return to primary is disabled (inactive). When the SW16 is in the Up “On” position,
return to primary is enabled.
Switch 15
P1+P2 Redun
Switch 16
Rtn P1 Function
DOWN (Off) DOWN (Off) Non-redundant mode - normal mode
DOWN (Off) UP (On) Non-redundant mode - normal mode
UP (On) DOWN (Off) Redundant mode - no return to primary
UP (On) UP (On) Redundant mode - return to primary
Port Redundancy Modes
Page 9
2) Installing the Module
Wall Mounting
The wall mounting height of the module should be less than or equal to 2 meters
(6.6 feet) from the oor. Use the four mounting holes on the module to secure the
module to the wall. The module can accommodate #6 screws (not included).
Installation of the module should be such that the air ow in the front, back, side
and top vents of the switch are not compromised or restricted.
The accessory cables should have their own strain relief and do not pull down on
the module.
Rack Mounting
The module can be rack mounted using the optional Rack Mount Shelf (8260-0).
Refer to the Rack Mount Shelf user manual (040-08260-001x) for the proper
installation guidelines.
Follow the same guidelines above when rack mounting the module.
DIN-rail Mounting
The module can be DIN-rail mounted using the optional DIN-rail Mounting Bracket
(8250-0) or the optional DIN-rail Mounting Clip (8251-0). Refer to the user manuals
(040-08250-001x or 040-08251-001x) for the proper installation guidelines.
3) Apply Power
AC Power
Secure the ground wire to the NEBS grounding screw located on the back of the
module.
To power the unit using the AC/DC adapter, route the power cord through the
provided strain relief for additional support. Then connect the barrel connector
at the end of the wire on the AC/DC adapter to the 2.1mm DC barrel connector
(center-positive) on the unit. Connect the AC/DC adapter to the AC outlet. Conrm
that the module has powered up properly by checking the Power LED located on
the front of the installed module.
Installation of the equipment should be such that the air ow in the front, back, side
and top vents of the chassis are not compromised or restricted.
Page 10

WARNING: OnlyaDC power source that complies with
safety extra low voltage (SELV) requirements can be
connected to the DC-input power supply.
WARNING REGARDING EARTHING GROUND:
o
o
o
o
This equipment shall be connected to the DC supply
system earthing electrode conductor or to a bonding
jumper from an earthing terminal bar or bus to which the
DC supply system earthing electrode is connected.
This equipment shall be located in the same immediate
area (such as adjacent cabinets) as any other equipment
that has a connection between the earthed conductor of
the same DC supply circuit and the earthing conductor,
and also the point of earthing of the DC system. The DC
system shall not be earthed elsewhere.
The DC supply source is to be located within the same
premises as this equipment.
There shall be no switching or disconnecting devices in
the earthed circuit conductor between the DC source and
the earthing electrode conductor.
Locate the DC circuit breaker of the external power source, and switch the circuit
breaker to the OFF position.
Prepare a power cable using a three conductor insulated wire (not supplied) with
12AWG to 14AWG thickness. Cut the power cable to the length required.
Strip approximately 3/8 of an inch of insulation from the power cable wires.
Connect the ground wire to the NEBS grounding screws on the back of the module.
Route the power cables through the provided strain relief for additional support.
Connect the power cables to the module by fastening the stripped ends to the DC
power connector.
WARNING: Note the wire colors used in making the positive, negative and ground
connections. Use the same color assignment for the connection at the circuit breaker.
Connect the power wires to the circuit breaker and switch the circuit breaker ON.
If any module are installed, the Power LED will indicate the presence of power.
During the installation, ensure that the ground potentials are maintained throughout
the system connections. This includes but not limited to the power source ground
and any shielded cabling grounds.
Installation of the equipment should be such that the air ow in the front, back, side
and top vents of the chassis are not compromised or restricted.
Page 12
Rear View with AC Power Connector
NEVER ATTEMPT TO OPEN THE CHASSIS OR
SERVICE THE POWER SUPPLY. OPENING THE
CHASSIS MAY CAUSE SERIOUS INJURYOR DEATH.
THERE ARE NO USER REPLACEABLE OR
SERVICEABLE PARTS IN THIS UNIT.
WARNING!!!
DC Power
This module is intended for installation in restricted access areas. (“Les matériels
sont destinés à être installés dans des EMPLACEMENTS À ACCÈS RESTREINT”).
A restricted access area can be accessed only through the use of a special key, or
other means of security.
The over current protection for connection with centralized DC shall be provided in
the building installation, and shall be a UL listed circuit breaker rated 20 Amps, and
installed per the National Electrical Code, ANSI/NFPA-70.
Appropriate overloading protection should be provided on the DC power source
outlets utilized.
The module requires +46 to 57VDC @ 72mA max rated power. See specication
table for specic model requirements.
Description IEEE 802.3af PoE
Power Supply Voltage Range 46.0 to 57.0 VDC
Voltage Range at PSE port Output 44.0 to 56.0 VDC
Maximum Power from PoE/PSE port 15.4 watts
Minimum Voltage at PoE/PD port input* 37.0 VDC
Minimum Power at PoE/PD port* 12.95 watts
* at 100 meters using Cat5
Page 11

Rear View with DC Power Connector
NEVER ATTEMPT TO OPEN THE CHASSIS OR
SERVICE THE POWER SUPPLY. OPENING THE
CHASSIS MAY CAUSE SERIOUS INJURYOR DEATH.
THERE ARE NO USER REPLACEABLE OR
SERVICEABLE PARTS IN THIS UNIT.
WARNING!!!
4) Connect Cables
a. When using the SFP model, insert the SFP Fiber transceiver into the SFP
receptacle on the front of the module (see the SFP Data Sheet 091-17000-001
for supported Fast Ethernet transceivers).
NOTE: The release latch of the SFP Fiber transceiver must be in the closed
(up) position before insertion.
b. Connect an appropriate multimode or single-mode ber cable to the ber port
on the front of the module. It is important to ensure that the transmit (TX) is
attached to the receive side of the device at the other end and the receive
(RX) is attached to the transmit side. When using single-ber (SF) models, the
TX wavelength must match the RX wavelength at the other end and the RX
wavelength must match the TX wavelength at the other end.
c. Connect the Ethernet 10/100 RJ-45 port via a Category 5 or better cable to an
external 10BASE-T or 100BASE-TX Ethernet device.
Page 13
5) Verify Operation
Verify the Module is operational by viewing the LED indicators.
Power LED Indicators
Legend Indicator Description
Pwr
OFF Unit not powered
Green - ON Unit powered
Amber - ON Over temperature condition
Power LED Indicators
Fiber Port LED Indicators
Legend Indicator Description
P1
OFF No link
Green - ON Port linked at 100Mbps
Green - Blinking at 10Hz Port data activity at 100Mbps
Green - Blinking at 1Hz Port linked at 100Mbps and in redundant standby mode
Amber - Blinking at 1Hz Port linked at 100Mbps and receiving Far End Fault Indicator
(FEFI)
FDX OFF Port is in half-duplex
Green - ON Port is in full-duplex
Stat
OFF Transceiver does not support digital diagnostics or no
transceiver (SFP) is installed
Green - ON Transceiver (SFP) supports digital diagnostics and no alarm is
detected
Amber - ON Transceiver (SFP) supports digital diagnostics and alarms are
present
P2
OFF No link
Green - ON Port linked at 100Mbps
Green - Blinking at 10Hz Port data activity at 100Mbps
Green - Blinking at 1Hz Port linked at 100Mbps and in redundant standby mode
Amber - Blinking at 1Hz Port linked at 100Mbps and receiving Far End Fault Indicator
(FEFI)
FDX OFF Port is in half-duplex
Green - ON Port is in full-duplex
Stat
OFF Transceiver does not support digital diagnostics or no
transceiver (SFP) is installed
Green - ON Transceiver (SFP) supports digital diagnostics and no alarm is
detected
Amber - ON Transceiver (SFP) supports digital diagnostics and alarms are
present
Fiber LED Indicators
Page 14

RJ-45 Port Indicators
Legend Indicator Description
10
OFF No link
Green - ON Port linked at 10Mbps
Green - Blinking at 10Hz Port data activity at 10Mbps
Amber - Blinking at 1Hz Port linked at 10Mbps and receiving AN Remote Fault
100
OFF No link
Green - ON Port linked at 100Mbps
Green - Blinking at 10Hz Port data activity at 100Mbps
FDX
Green - ON Port is congured for full-duplex via DIP-switch or has
negotiated to full-duplex in AN mode
OFF
Port is congured for half-duplex via DIP-switches or Port 2 has
negotiated to half-duplex in AN mode or Port 2 in AN mode has
not established the correct connection
PSE
Green - ON Port PSE is active
Amber - ON Port PSE inactive
Amber - Blinking at 1Hz Port PSE inactive due to resistance too low (< 15k ohms) or
short circuit detected
Amber - Blinking at 10Hz Port PSE inactive due to resistance to high (33k to 500k ohms)
OFF Port PSE disabled
RJ-45 LED Indicators
Page 15 Page 16
Specications
Description
OmniConverter FPoE/SL
10/100BASE-T to 100BASE-X
Fiber Media Converter with PoE
Standard Compliances IEEE 802.3,
IEEE 802.3af (15.40 watts)
PoE Supported Modes
IEEE Alternate A (Alt A) and B (Alt B)
Cisco Legacy and High Cap
(Alt B, Legacy & High Cap requires 9143-6 cable)
Environmental REACH, RoHS and WEEE
Frame Size Up to 2,000 bytes
Port Types
Copper: 10/100BASE-T (RJ-45)
Fiber: 100BASE-X (ST, SC, SFP)
100BASE-BX (SC, SFP)
Cable Types
Copper: EIA/TIA 568A/B, Cat 5 UTP and higher
Fiber: Multimode: 50/125, 62.5/125µm
Single-mode: 9/125µm
AC Power Requirements
(Models with AC/DC Adapters)
1 RJ-45 Port:
100 - 240VAC/47 to 63Hz
0.17A @ 120VAC (typical)
2 RJ-45 Ports:
100 - 240VAC/50 - 60Hz
0.32A @ 120VAC (typical)
DC Power Requirements
(Models with DC Terminals)
1 RJ-45 Port:
+46 to +57VDC;
0.39A @ 48VDC
2 Pin Terminal (non-isolated)
2 RJ-45 Ports:
+46 to +57VDC;
0.72A @ 48VDC
2 Pin Terminal (non-isolated)
A minimum DC input voltage of 50VDC is required to guarantee 25.5
watts (for 802.3at) at the end of 100 meters on Cat 5 cable or better.
Dimensions (W x D X H) 4.5” x 6.0” x 1.0” (114.3 mm x 152.4 mm x 25.4 mm)
Weight Module: 1.1 lbs. (498.9 grams)
With AC/DC Adapter: 1.6 lbs. (725.7 grams)
Operating Temperature
Commercial: 0 to 50°C
Wide: -40 to 60°C (-20°C AC cold start)
Extended: -40 to 75°C (-20°C AC cold start)
Storage: -40 to 80°C
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4,000m
MTBF (hrs) Module: 430,000
AC/DC Adapter: 100,000
Warranty Lifetime warranty with 24/7/365 free Technical Support

Regulatory Compliances
(*Pending)
Safety: UL 62368-1*,
UL 60950-1,
IEC 62368-1*,
IEC 60950-1,
EN 62368-1*,
EN 60950-1,
CAN/CSA C22.2 No. 62368-1-14*,
CAN/CSA C22.2 No. 60950-1,
CE Mark
EMC: EN 55032/EN 55024 CE Emissions/Immunity
EMI: CISPR 32,
FCC 47 Part 15 Subpart B Class A
IP Rating: IP20 Protection
Appendix A: Link Modes
Page 17 Page 18

Page 19 Page 20
Page intentionally left blank
