Omron E5AR-T User manual

USER’S MANUAL
Programmable
Digital Controller
E5AR-T
E5ER-T
Cat. No. H201-E1-01

I
Introduction
OMRON products are manufactured for use according to proper procedures by a qualified operator and
only for the purposes described in this manual.
This manual describes the functions, performance, and application methods needed for optimum use of
the E5AR-T/ER-T Programmable Digital Controllers.
Please observe the following items when using the E5AR-T/ER-T Programmable Digital Controllers.
• This product is designed for use by qualified personnel with a knowledge of electrical systems.
• Read this manual carefully and make sure you understand it well to ensure that you are using the
E5AR-T/ER-T Programmable Digital Controllers correctly.
• Keep this manual in a safe location so that it is available for reference when required.
Before using the Controller under the following conditions, make sure that the ratings and performance
characteristics of the Controller are sufficient for the systems, machines, and equipment, and be sure to
provide the systems, machines, and equipment with double safety mechanisms, and also consult your
OMRON representative.
• Using the Controller under conditions which are not described in the manual
• Applying the Controller to nuclear control systems, railroad systems, aviation systems, vehicles,
combustion systems, medical equipment, amusement machines, safety equipment, and other systems,
machines, and equipment
• Applying the Controller to systems, machines, and equipment that may have a serious influence on lives
and property if used improperly, and especially require safety
Precautions on Using the Product
Notice
(1) All rights reserved. No part of this manual may be reprinted or copied without the prior written
permission of OMRON.
(2) The specifications and other information in this manual are subject to change without notice for purposes
of improvement.
(3) Considerable care has been taken in the preparation of this manual; however, OMRON assumes no
responsibility or liability for any errors or inaccuracies that may appear. In the event that a problem is
discovered, please contact one of the OMRON offices or agents listed at the end of the manual, and
provide the catalogue number shown on the cover of the manual.

II
Read and Understand this Manual
Please read and understand this manual before using the product. Please consult your OMRON
representative if you have any questions or comments.
Warranty and Limitations of Liability
WARRANTY
OMRON's exclusive warranty is that the products are free from defects in materials and workmanship
for a period of one year (or other period if specified) from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING
NON-INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE
PRODUCTS. ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS
DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR
INTENDED USE. OMRON DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL
DAMAGES, LOSS OF PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE
PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR
STRICT LIABILITY.
In no event shall the responsibility of OMRON for any act exceed the individual price of the product on
which liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS
REGARDING THE PRODUCTS UNLESS OMRON'S ANALYSIS CONFIRMS THAT THE PRODUCTS
WERE PROPERLY HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO
CONTAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.
Application Considerations
SUITABILITY FOR USE
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to
the combination of products in the customer's application or use of the products.
At the customer's request, OMRON will provide applicable third party certification documents identifying
ratings and limitations of use that apply to the products. This information by itself is not sufficient for a
complete determination of the suitability of the products in combination with the end product, machine,
system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not
intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the
uses listed may be suitable for the products.
•Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions
or uses not described in this manual.
•Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical
equipment, amusement machines, vehicles, safety equipment, and installations subject to separate
industry or government regulations.
•Systems, machines, and equipment that could present a risk to life or property.
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO
ADDRESS THE RISKS, AND THAT THE OMRON PRODUCTS ARE PROPERLY RATED AND
INSTALLED FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user's programming of a programmable product, or any
consequence thereof.

III
Disclaimers
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other
reasons.
It is our practice to change model numbers when published ratings or features are changed, or when
significant construction changes are made. However, some specifications of the products may be
changed without any notice. When in doubt, special model numbers may be assigned to fix or establish
key specifications for your application on your request. Please consult with your OMRON representative
at any time to confirm actual specifications of purchased products.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when
tolerances are shown.
PERFORMANCE DATA
Performance data given in this manual is provided as a guide for the user in determining suitability and
does not constitute a warranty. It may represent the result of OMRON's test conditions, and the users
must correlate it to actual application requirements. Actual performance is subject to the OMRON
Warranty and Limitations of Liability.
ERRORS AND OMISSIONS
The information in this document has been carefully checked and is believed to be accurate; however,
no responsibility is assumed for clerical, typographical, or proofreading errors, or omissions.

IV
Definition of Safety Notices and Information
The following notation is used in this manual to provide precautions required to
ensure safe usage of the product.
The safety precautions that are provided are extremely important to safety. Always
read and heed the information provided in all safety precautions.
The following notation is used.
●Symbols
Precautions
Caution
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury or in
property damage.
Symbol Meaning
Caution
General Caution
Indicates non-specific general cautions, warn-
ings, and dangers.
Electrical Shock Caution
Indicates possibility of electric shock under spe-
cific conditions.
Prohibition General Prohibition
Indicates non-specific general prohibitions.
Mandatory
Caution
General Caution
Indicates non-specific general cautions, warn-
ings, and dangers.

V
●Precautions
CAUTION
Do not touch the terminals while power is being supplied.
Doing so may occasionally result in minor injury due to electric
shock.
Do not touch the terminals or the electronic components or pat-
terns on the PCB within 1 minute after turning OFF the power sup-
ply. Doing so may occasionally result in minor injury due to electric
shock.
Do not allow pieces of metal, wire clippings, or fine metallic shav-
ings or filings from installation to enter the product. Doing so may
occasionally result in electric shock, fire, or malfunction.
Do not use the product in locations where flammable or explosive
gases are present. Doing so may occasionally result in minor or
moderate explosion, causing minor or moderate injury, or property
damage.
Do Not disassemble, modify, or repair the product or touch any of
the internal parts. Minor electric shock, fire, or malfunction may
occasionally occur.
Tighten the screws on the terminal block to the following specified
torque. Loose screws may occasionally cause fire, resulting in
minor or moderate injury, or damage to the equipment.
Terminal block screws: 0.40 to 0.56 N·m
Perform correct setting of the product according to the application.
Failure to do so may occasionally cause unexpected operation,
resulting in minor or moderate injury, or damage to the equipment.
A malfunction in the Product may occasionally make control oper-
ations impossible or prevent alarm outputs, occasionally resulting
in property damage to the system or equipment connected to the
Product. To maintain safety in the event of malfunction of the
Product, take appropriate safety measures, such as installing a
monitoring device in a separate system.
Do not use the equipment for measurements within measurement
categories II, III, or IV (according to IEC61010-1). Doing so may
occasionally cause unexpected operation, resulting in minor or
moderate injury, or damage to the equipment. Use the equipment
for measurements only within the measurement categories for
which the product is designed.
The service life of the output relays depends on the switching
capacity and switching conditions. Consider the actual application
conditions and use the product within the rated load and electrical
service life. Using the product beyond its service life may occa-
sionally result in contact welding or burning.

VI
(1) Use and store the Digital Controller in the range of specifications for ambient
temperature and humidity. The service life will decrease due to increased
internal temperature if multiple Digital Controllers are mounted closely side by
side or one on top of the other. If this type of mounting is used, use forced
cooling, e.g., use a fan to blow air onto the Digital Controllers.
(2) Do not prevent heat dissipation by obstructing the periphery of the Digital
Controller. Do not block the vents on the Digital Controller unit.
(3) The supplied power voltage and load must be within the rated and specified
ranges.
(4) Be sure to confirm the name and polarity for each terminal before wiring the
terminal block.
(5) Do not connect anything to unused terminals.
(6) Use the specified size of crimp terminals (M3, width: 5.8 mm max.) to wire the
terminal block. When connecting bare wires, use copper stranded or solid
wires, and use AWG22 (cross-sectional area of 0.326 mm2) to AWG14 (cross-
sectional area of 2.081 mm2) for the power supply terminals and AWG28
(cross-sectional area of 0.081 mm2) to AWG16 (cross-sectional area of 1.309
mm2) for other terminals. (Length of exposed wire: 6 to 8 mm)
(7) Ensure that the rated voltage is attained within 2 seconds after turning ON the
power.
(8) Turn OFF the power first when you need to draw out the Digital Controller. Do
Not touch the terminals or the electronic components, or subject them to
physical shock. When inserting the Digital Controller, do not allow the
electronic components to contact the case.
(9) Do not remove the inner circuit board.
(10) The output may turn OFF when shifting to certain levels. Take this into consid-
eration when performing control.
(11) Allow a warm-up time of at least 30 minutes.
(12) To prevent inductive noise, separate the Digital Controller terminal block wiring
from power lines that carry high voltages or high currents. Also, do not wire
power lines together with or parallel to the Digital Controller wiring. Using
shielded cables and separate conduits or ducts is recommended.
Attach a surge suppressor or noise filter to peripheral devices that generate
noise (in particular, motors, transformers, solenoids, magnetic coils, or other
equipment that has an inductive component). When a noise filter is used at the
power supply, first check the voltage or current, and attach the noise filter as
close as possible to the product. Allow as much space as possible between the
product and devices that generate powerful high frequencies (e.g., high-
frequency welders, high-frequency sewing machines) or surge.
(13) Install a switch or circuit breaker that allows the operator to immediately turn
OFF the power, and label suitably.
(14) The product is designed for indoor use only.
Do not use the product outdoors or in any of the following locations.
· Locations where dust or corrosive gas is present (in particular, sulfur or
ammonia gases)
· Locations where condensation or ice may form
· Locations directly exposed to sunlight
· Locations subject to strong shocks or vibration
· Locations where water or oil may splatter on the Digital Controller
· Locations directly exposed to radiant heat from heating equipment
· Locations subject to sudden or extreme changes of temperature
(15) Do not use paint thinner or similar chemical to clean with. Use standard grade
alcohol.
Precautions for Safe Use

VII
●Service Life
Use the product within the following temperature and humidity ranges:
Temperature: −10 to 55°C (no icing or condensation)
Humidity: 25% to 85%
When the product is installed inside a control panel, make sure that the temperature
around the product, not the temperature around the control panel, does not exceed
55°C.
The service life of this product and similar electronic devices is determined not only
by the number of switching operations of relays but also by the service life of
internal electronic components. Component service life is affected by the ambient
temperature: the higher the temperature becomes, the shorter the service life
becomes and, the lower the temperature becomes, the longer the service life
becomes. Therefore, the service life can be extended by lowering the temperature
of the product.
Be sure to install the product according to the specified conditions. Otherwise, the
heat generated by the product will cause the internal temperature to rise, short-
ening the service life. If necessary, cool the product using fans or other means of air
ventilation.
When providing forced cooling, however, be careful not to cool down the terminals
sections alone to avoid measurement errors.
●Noise Countermeasures
To prevent inductive noise, separate the wiring for the product's terminal block and
connector from high-voltage, high-current power lines. Do not run the wiring parallel
to or in the same cable as power lines. The influence of noise can also be reduced
by using separate wiring ducts or shield lines.
Install surge absorbers or noise filters in devices near the product that generate
noise (in particular, devices with an inductance component, such as motors, trans-
formers, solenoids, and magnetic coils).
If a noise filter is used for the power supply, check the voltage and current, and
install the noise filter as close as possible to the product.
Separate the product as far as possible from devices generating strong high-
frequency noise (e.g., high-frequency welders and high-frequency sewing
machines) or surges.
●Measurement Accuracy
When extending the thermocouple lead wire, be sure to use a compensating wire
that matches the thermocouple type.
When extending the lead wire of the platinum resistance thermometer, be sure to
use wires that have low resistance, and make sure that the resistances of the three
lead wires are the same.
If the measurement accuracy is low, check whether the input shift is set correctly.
●Waterproofing
The degree of protection is as shown below.
Precautions for Correct Use
Front panel NEMA 4x indoor use
Rear case IP20
Terminals IP00

VIII
About this Manual
●How to use the manual
Purpose Related section Contents
General explanation
of the E5AR-T/ER-T
Section 1 Overview Explains the features, part names,
and main functions of the E5AR-T/
ER-T.
Setup Section 2 Preparations
Section 3 Typical Control Examples
Explains how to set up the E5AR-T/
ER-T for operation (including mount-
ing, wiring, and initial settings).
Basic operation of
the E5AR-T/ER-T
Section 4 Settings Required for
Basic Control
Section 8 Parameters
Explains the basic functions of the
E5AR-T/ER-T.
Advanced functions
of the E5AR-T/ER-T
Section 5 Functions and Opera-
tions
Section 8 Parameters
Explains the operating methods
required to get the most out of the
E5AR-T/ER-T, such as functions
related to programmed operation.
Communication
functions
Section 6 CompoWay/F Communi-
cations
Section 7 Modbus Communica-
tions
Explains how to use communication-
based functions.
User calibration Section 9 User Calibration Explains calibration procedures that
can be performed by the user.
Troubleshooting Section 10 Troubleshooting Explains what to do when you
encounter a problem.
Appendix Provides product specifications and
lists of parameters.
Can be used to make a copy of your
parameter settings.

IX
●Special Notation
(1) Important
“Important” appears where incorrect settings or operation will prevent a function from
achieving the expected result.
(2) Hint
“Hint” gives useful hints, advice, and other supplemental information.
(3) Notation used to indicate various information on parameters (“Function,” “Setting,”
“Monitor,” and “Reference”) are explained in Section 8 Parameters.
●Abbreviations
Abbreviations used in the parameters, illustrations, and text are listed in the
following table.
* Data after scaling is shown in engineering units such as °C, m, and g. “EU” is used
to indicate the minimum increment of such a quantity. For example, the minimum
increment of 50.02 m is 0.01 m, and thus 1 EU would be equal to 0.01 m.
●Notation Used for Settings
Letters, numbers, and abbreviations in settings that appear on the E5AR-T/ER-T
display are as follows:
Set the input type before setting the scaling value.
If the input type is changed after setting the scaling value, the scal-
ing value will be automatically initialized.
Important
Overshooting can be adjusted using the external interference over-
shoot adjustment function when there is excessive overshooting in
temperature control (i.e., in response to external interference).
Hint
Abbreviation Meaning Abbreviation Meaning
PV Present value ch Channel
SP Set point CH Channel
SV Set value PSP Program SP
AT Auto-tuning RSP Remote SP
EU Engineering units* FSP Fixed SP
abcdefghijklm
ABCDEFGH I JKLM
nopqrstuvwxyz
NOPQRS TUVWXYZ
0123456789 -
0123456789-1(Mostsignif-
icant digit)
1

X
●Revision History
The revision code of this manual is given at the end of the catalog number at the
bottom left of the back cover. The following table outlines the changes made to the
manual during each revision. Page numbers refer to the previous version.
Cat. No. H201-E1-01
Revision code Date Pages and changes
01 September 2006 Original production

XI
TABLE OF CONTENTS
Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - -I
Precautions on Using the Product - - - - - - - - - - - -I
Read and Understand this Manual - - - - - - - - - - II
Warranty and Limitations of Liability - - - - - - - - - II
Application Considerations - - - - - - - - - - - - - - - - II
Disclaimers - - - - - - - - - - - - - - - - - - - - - - - - - - - III
Precautions - - - - - - - - - - - - - - - - - - - - - - - - - -IV
Precautions for Safe Use - - - - - - - - - - - - - - - - -VI
Precautions for Correct Use - - - - - - - - - - - - - - VII
About this Manual - - - - - - - - - - - - - - - - - - - - -VIII
Section 1 Overview
1.1 Main Features of the E5AR-T and E5ER-T ................................................ 1-2
Inputs .................................................................................................. 1-2
Controller ............................................................................................ 1-2
Outputs ............................................................................................... 1-3
1.2 Part Names and Functions ......................................................................... 1-4
Front Panel ......................................................................................... 1-4
Interpreting the Display ....................................................................... 1-5
Using the Keys .................................................................................... 1-7
1.3 I/O and Main Functions .............................................................................. 1-8
I/O Configuration ................................................................................. 1-8
Main Functions .................................................................................... 1-9
Model Number Structure ................................................................... 1-13
Section 2 Preparations
2.1 Installation .................................................................................................. 2-2
Dimensions ......................................................................................... 2-2
Installation ........................................................................................... 2-2
2.2 Using the Terminals ................................................................................... 2-4
Terminal Arrangements ...................................................................... 2-4
Precautions when Wiring .................................................................... 2-9
Wiring ................................................................................................ 2-10
Section 3 Typical Control Examples
3.1 Standard Control ........................................................................................ 3-2
Application .......................................................................................... 3-2
Wiring .................................................................................................. 3-3
Settings ............................................................................................... 3-3
Program Settings ................................................................................ 3-5
Adjustment .......................................................................................... 3-6
3.2 Coordinated Electric Oven Operation ........................................................ 3-7
Application .......................................................................................... 3-7
Wiring .................................................................................................. 3-7
Settings ............................................................................................... 3-8

XII
Section 4 Settings Required for Basic Control
4.1 Setting Levels and Key Operations ............................................................ 4-2
Changing Parameters ......................................................................... 4-4
Saving Parameter Settings ................................................................. 4-4
4.2 Set Values .................................................................................................. 4-6
4.3 Initial Setting Example ................................................................................ 4-7
4.4 Setting the Input Type .............................................................................. 4-10
Input Type ......................................................................................... 4-10
Scaling .............................................................................................. 4-11
4.5 Selecting the Temperature Unit ................................................................ 4-14
4.6 Selecting the Control Mode ...................................................................... 4-15
Standard Control ............................................................................... 4-15
Heating/Cooling Control .................................................................... 4-15
Standard Control with Remote SP .................................................... 4-16
Heating/Cooling Control with Remote SP ......................................... 4-16
Proportional Control .......................................................................... 4-16
Cascade Standard Control ................................................................ 4-17
Cascade Heating/Cooling Control ..................................................... 4-17
Position-proportional Control ............................................................ 4-18
4.7 Setting Output Parameters ....................................................................... 4-20
Control Period ................................................................................... 4-20
Direct Operation (Cooling)/Reverse Operation (Heating) ................. 4-20
Output Type ...................................................................................... 4-21
Output Assignments .......................................................................... 4-21
4.8 Program Settings ..................................................................................... 4-23
Outline of Program Functions ........................................................... 4-23
Program Parameters ......................................................................... 4-23
Program Setting Example ................................................................. 4-25
4.9 Performing ON/OFF Control ..................................................................... 4-31
ON/OFF Control ................................................................................ 4-31
Settings ............................................................................................. 4-32
4.10 Determining the PID Constants (AT or Manual Settings) ......................... 4-33
Auto-tuning (AT) ................................................................................ 4-33
Limit Cycle ........................................................................................ 4-35
Manual Settings ................................................................................ 4-36
4.11 Using Auxiliary Outputs ............................................................................ 4-37
Auxiliary Output Assignments ........................................................... 4-37
Alarm Types ...................................................................................... 4-38
Alarm Values ..................................................................................... 4-39
Alarm Sets ........................................................................................ 4-39
Settings ............................................................................................. 4-39
4.12 Starting and Stopping Operation .............................................................. 4-41
Starting Operation (Run) and Stopping Operation (Reset) ............... 4-41
Other ................................................................................................. 4-45
Settings ............................................................................................. 4-46
4.13 Manual Operation ..................................................................................... 4-47
Manual Mode .................................................................................... 4-47
4.14 Changing Channels .................................................................................. 4-50
Changing Channels .......................................................................... 4-50
4.15 Adjusting Programs .................................................................................. 4-51
Changing the SP ............................................................................... 4-51
Changing the Time ............................................................................ 4-51
4.16 Operating Precautions ............................................................................. 4-52

XIII
Section 5 Functions and Operations
5.1 Input Adjustment Functions ....................................................................... 5-2
Input Correction .................................................................................. 5-2
First Order Lag Operation ................................................................... 5-5
Moving Average .................................................................................. 5-5
Broken-line Approximation .................................................................. 5-6
Extraction of Square Root ................................................................... 5-7
Other Input Adjustments ..................................................................... 5-7
5.2 Control Functions ....................................................................................... 5-8
Alarm Sets .......................................................................................... 5-8
SP Limits ............................................................................................. 5-9
PID Sets ............................................................................................ 5-10
Operating Programs Using Multiple Channels .................................. 5-11
Disturbance Overshoot Adjustment .................................................. 5-13
5.3 Output Adjustment Functions ................................................................... 5-15
MV Limits .......................................................................................... 5-15
MV Change Rate Limit ...................................................................... 5-16
MV at Reset ...................................................................................... 5-17
MV at PV Error .................................................................................. 5-17
5.4 Display and Key Adjustment Functions .................................................... 5-18
Display Scan ..................................................................................... 5-18
PF Settings (Function Keys) ............................................................. 5-20
Other Display and Key Adjustment Functions .................................. 5-22
5.5 Protecting Settings ................................................................................... 5-23
Protection .......................................................................................... 5-23
5.6 Alarm Adjustment Functions .................................................................... 5-25
Alarm Hysteresis ............................................................................... 5-25
Standby Sequence ............................................................................ 5-25
Alarm Latch ....................................................................................... 5-26
Close in Alarm/Open in Alarm ........................................................... 5-26
Alarm SP Selection ........................................................................... 5-26
5.7 Program Operation Functions .................................................................. 5-28
Rate of Rise Programming ................................................................ 5-28
Program Operations .......................................................................... 5-30
SP Modes ......................................................................................... 5-31
Wait ................................................................................................... 5-32
Time Signal ....................................................................................... 5-33
Segment Outputs .............................................................................. 5-34
Program Status Outputs ................................................................... 5-36
Operation at Program Start ............................................................... 5-37
End Condition ................................................................................... 5-38
5.8 Using Event Inputs ................................................................................... 5-39
Event Input Assignments .................................................................. 5-39
5.9 Using a Transfer Output ........................................................................... 5-47
Transfer Output Settings ................................................................... 5-47
5.10 Using Communications ............................................................................ 5-49
Setting Communications Parameters ............................................... 5-49
Communications Writing ................................................................... 5-50
Section 6 CompoWay/F Communications
6.1 Communications Method ........................................................................... 6-2
CompoWay/F Communications .......................................................... 6-2
Communications Specifications .......................................................... 6-2
Transfer Protocol ................................................................................ 6-3

XIV
6.2 Frames ....................................................................................................... 6-4
Command Frames .............................................................................. 6-4
Response Frames ............................................................................... 6-5
6.3 FINS-mini Text ............................................................................................ 6-6
6.4 Variable Areas ............................................................................................ 6-7
Variable Types .................................................................................... 6-7
Addresses ........................................................................................... 6-8
Number of Elements ........................................................................... 6-9
Set Values ........................................................................................... 6-9
6.5 Read from Variable Area .......................................................................... 6-10
6.6 Write to Variable Area .............................................................................. 6-11
6.7 Operation Commands .............................................................................. 6-13
6.8 Setting Areas ............................................................................................ 6-15
6.9 Commands and Responses ..................................................................... 6-17
Reading Monitor Values .................................................................... 6-17
Reading Set Values .......................................................................... 6-18
Composite Read from Variable Area ................................................ 6-19
Writing Set Values in Protect Level .................................................. 6-21
Writing Set Values ........................................................................... 6-21
Set Value Compound Write .............................................................. 6-23
Composite Read Registration ........................................................... 6-24
Composite Read Registration Confirmation ...................................... 6-25
Composite Registration Read ........................................................... 6-25
Communications Writing ................................................................... 6-26
Run/Reset ......................................................................................... 6-26
AT Execute ....................................................................................... 6-27
AT Cancel ......................................................................................... 6-28
Write Mode ........................................................................................ 6-28
Save RAM Data ................................................................................ 6-30
Software Reset ................................................................................. 6-30
Move to Setting Area 1 ..................................................................... 6-30
Move to Protect Level ....................................................................... 6-31
Auto/Manual ...................................................................................... 6-31
Parameter Initialization ..................................................................... 6-32
Alarm Latch Cancel ........................................................................... 6-33
SP Mode ........................................................................................... 6-33
Hold ................................................................................................... 6-34
Advance ............................................................................................ 6-35
Back .................................................................................................. 6-36
Controller Attribute Read .................................................................. 6-36
Controller Status Read ...................................................................... 6-38
Echoback Test .................................................................................. 6-39
6.10 Program Example .................................................................................... 6-40
N88Basic ........................................................................................... 6-40
Section 7 Modbus Communications
7.1 Communications Method ........................................................................... 7-2
Modbus Communications ................................................................... 7-2
Communications Specifications .......................................................... 7-2
Transfer Protocol ................................................................................ 7-3
7.2 Frames ....................................................................................................... 7-4
Command Frames .............................................................................. 7-4
Response Frames ............................................................................... 7-5
7.3 List of Functions ......................................................................................... 7-7
7.4 Variable Areas ............................................................................................ 7-8

XV
Addresses ........................................................................................... 7-8
Number of Elements ........................................................................... 7-9
Set Values ......................................................................................... 7-10
7.5 Read from Variable Area .......................................................................... 7-11
7.6 Write to Variable Area .............................................................................. 7-13
7.7 Operation Commands .............................................................................. 7-15
7.8 Setting Areas ........................................................................................... 7-18
7.9 Commands and Responses ..................................................................... 7-20
Reading Monitor Values .................................................................... 7-20
Reading Set Values ......................................................................... 7-21
Writing Set Values in Protect Level ................................................... 7-22
Writing Set Values ........................................................................... 7-23
Communications Writing ................................................................... 7-24
Run/Reset ......................................................................................... 7-25
AT Execute ....................................................................................... 7-26
AT Cancel ......................................................................................... 7-27
Write Mode ........................................................................................ 7-27
Save RAM Data ................................................................................ 7-28
Software Reset ................................................................................. 7-29
Move to Setting Area 1 ..................................................................... 7-29
Move to Protect Level ....................................................................... 7-30
Auto/Manual ...................................................................................... 7-30
Parameter Initialization ..................................................................... 7-31
Alarm Latch Cancel ........................................................................... 7-32
SP Mode ........................................................................................... 7-32
Hold ................................................................................................... 7-33
Advance ............................................................................................ 7-34
Back .................................................................................................. 7-35
Echoback Test .................................................................................. 7-35
Section 8 Parameters
8.1 Using this Section ...................................................................................... 8-2
8.2 Protect Level (l.prt) .................................................................................. 8-3
8.3 Operation Level ( ) .................................................................................... 8-6
8.4 Program Setting Level ( ) ........................................................................ 8-16
8.5 Adjustment Level (l.adj) ......................................................................... 8-22
8.6 Adjustment 2 Level (l.ad2) ...................................................................... 8-33
8.7 Alarm Set Setting Level (l.alm) ............................................................... 8-36
8.8 PID Setting Level (l.pid) ......................................................................... 8-39
8.9 Time Signal Setting Level ( ) ................................................................... 8-43
8.10 Approximation Setting Level (l.tec) ........................................................ 8-46
8.11 Input Initial Setting Level (l.0) .................................................................. 8-49
8.12 Control Initial Setting Level (l.1) .............................................................. 8-55
8.13 Control Initial Setting 2 Level (l.2) ........................................................... 8-63
8.14 Alarm Setting Level (l.3) .......................................................................... 8-74
8.15 Display Adjustment Level (l.4) ................................................................ 8-80
8.16 Communications Setting Level (l.5) ........................................................ 8-84
8.17 Advanced Function Setting Level (l.adf) ................................................ 8-88
8.18 Expansion Control Setting Level (l.exc) ................................................. 8-94
Section 9 User Calibration
9.1 Parameters for User Calibration ................................................................. 9-2
Output Calibration Parameters ........................................................... 9-2
9.2 User Calibration ......................................................................................... 9-4

XVI
Input Calibration .................................................................................. 9-4
Output Calibration ............................................................................... 9-4
Registering Calibration Data ............................................................... 9-4
9.3 Thermocouple Input Calibration ................................................................. 9-5
Preparations ........................................................................................ 9-5
9.4 Analog Input Calibration ............................................................................. 9-8
9.5 Resistance Thermometer Calibration ....................................................... 9-10
9.6 Output Calibration .................................................................................... 9-12
9.7 Inspecting Indicator Accuracy .................................................................. 9-14
Thermocouples ................................................................................. 9-14
Resistance Thermometers ................................................................ 9-14
Analog Inputs .................................................................................... 9-15
Section 10 Troubleshooting
10.1 Troubleshooting Checklist ........................................................................ 10-2
10.2 Error Messages ........................................................................................ 10-3
10.3 Inferring Causes from Conditions: Abnormal Measured Values .............. 10-4
The Measured Value Is Abnormal or Measurement Is Not Possible 10-4
10.4 Inferring Causes from Conditions: Abnormal Control ............................... 10-6
The PV Does Not Increase ............................................................... 10-6
The Measured Value Increases Above the SP ................................. 10-6
Overshooting or Undershooting Occurs ............................................ 10-7
Hunting Occurs ................................................................................. 10-7
SP Does Not Change as Programmed ............................................. 10-8
The Segment Does Not Advance ..................................................... 10-8
The Program Is Reset in the Middle ................................................. 10-8
10.5 Inferring Causes from Conditions: Abnormal Outputs .............................. 10-9
No Control Output or No Alarm Output ............................................. 10-9
10.6 Inferring Causes from Conditions: Communications Problems .............. 10-10
Cannot Communicate or No Response .......................................... 10-10
10.7 Inferring Causes from Conditions: Reset Operation ............................... 10-11
Outputs Are Made While Resetting (Operation Will Not Stop) ........ 10-11
Appendix
Specifications .......................................................................................................A-2
Unit Ratings ........................................................................................A-2
Controller Performance Specifications ................................................A-3
Sensor Input Setting Ranges and Display/Control Ranges ..................................A-4
ASCII Table ..........................................................................................................A-5
Setting Lists ..........................................................................................................A-6
E5@R-T Status (Communications) .....................................................A-8
E5@R-T Program Status (Communications) .....................................A-10
Initialization Due to Changing Parameter Settings ...........................A-44
Parameter Charts ...............................................................................................A-48
Index

1-1
Overview
Section 1 Overview
1.1 Main Features of the E5AR-T and E5ER-T ....................... 1-2
1.2 Part Names and Functions ................................................ 1-4
1.3 I/O and Main Functions ..................................................... 1-8

Section 1 Overview
1-2
Overview
1.1 Main Features of the E5AR-T and E5ER-T
The E5AR-T/ER-T is an advanced Programmable Digital Controller that features high-precision control.
The E5AR-T/ER-T has the following features.
■Inputs
●High-speed
Sampling
• Sampling period: 50 ms
●High Accuracy and
High Resolution
• Indication accuracy
Thermocouple: (Larger of ±0.1% PV or ±1°C) ± 1 digit max.
Platinum resistance thermometer:
(Larger of ±0.1% PV or ±0.5°C) ± 1 digit max.
Analog input: (±0.1% FS) ± 1 digit max
(For non-standard specifications, refer to Appendix Specifications
(P. A-2))
• Input resolution: 1/100°C
(Pt100: A range of −150.00 to 150.00°C with a resolution of 0.01°C
is provided.)
• High-speed sampling is achieved simultaneously with high accuracy
and high resolution. This provides high-accuracy, high-speed control
to match your application.
●Multi-input
Function
• A wide range of temperature inputs and analog inputs is supported.
Temperature inputs:
Thermocouples: K, J, T, E, L, U, N, R, S, B, W
Platinum resistance thermometers: Pt100
Analog inputs:
Current inputs: 4 to 20 mA or 0 to 20 mA
Voltage inputs: 1 to 5 V, 0 to 5 V, or 0 to 10 V
●Multiple Inputs • The E5AR-T is available with either 2 input or 4 input channels.
The E5ER-T comes with 2 inputs.
■Controller
●Programs • Up to 32 programs can be created containing set points, times, PID
set numbers, alarm set numbers, wait upper/lower limits, segment
outputs, program repetitions, and program links. The set point,
times, wait function, and segment outputs can be set for each
segment. Outputs can be set for each segment or outputs can be
set based on the time from the start of the segment.
●PID Sets • Up to 8 PID sets can be created to store settings (PID constants,
MV limits, and automatic selection range upper limits) for PID
control.

1.1 Main Features of the E5AR-T and E5ER-T
1-3
Overview
• PID sets can be selected not only by directly specifying the PID set
number in a program, but they can also be selected automatically
according to the present value, deviation, or set point.
●A wide Variety of
Control Modes and
Functions
• Coordinated operation is possible with one Digital Controller for
models with 2 or 4 input channels, eliminating the need for slave
adjusters.
• Position-proportional Control Models support floating control or
closed control. Floating control allows position-proportional control
without a potentiometer.
■Outputs
●Multi-output
Function
• Multi-outputs enable using either current outputs or voltage outputs
(pulses).
●High Resolution • Resolution of Current Outputs
0 to 20 mA: Approx. 54,000
4 to 20 mA: Approx. 43,000
●Control Period • The control period can be set as short as 0.2 seconds, allowing
precise time-proportioning control for voltage output pulses.
