Omron STC-OSB250CL Installation instructions

No.18S075-00
1/48
STC-OSB250CL
Product Specifications and User’s Guide
Camera Link
Monochrome CMOS Camera
STC-OSB250CL (25M / Monochrome)
Product Specifications and User’s Guide

No.18S075-00
2/48
STC-OSB250CL
Product Specifications and User’s Guide
Table of Contents
1Product Precautions........................................................................................................................................................ 5
2Warranty ........................................................................................................................................................................... 5
3Overview........................................................................................................................................................................... 6
4Features............................................................................................................................................................................ 6
5Specifications .................................................................................................................................................................. 7
5.1 Electronic Specifications............................................................................................................................................. 7
5.2 Spectral Sensitivity Characteristics ............................................................................................................................ 9
5.3 Mechanical specifications.........................................................................................................................................10
5.4 Environmental specifications.................................................................................................................................... 10
5.5 Connector specifications ...........................................................................................................................................11
5.5.1Camera Link Connectors ...................................................................................................................................11
5.5.2 Power/IO Connector.......................................................................................................................................... 12
5.5.3 Input signal circuit.............................................................................................................................................. 13
5.5.4 Output signal circuit...........................................................................................................................................13
6Dimensions .................................................................................................................................................................... 14
6.1 STC-OSB250CL....................................................................................................................................................... 14
6.2 STC-OSB250CL-F....................................................................................................................................................15
7Sensor Information........................................................................................................................................................ 16
7.1 Pixel Transferring Image........................................................................................................................................... 16
8Camera Function Modes............................................................................................................................................... 17
8.1 Free-run / Continuous mode .................................................................................................................................... 17
8.2 Pulse width trigger mode.......................................................................................................................................... 18
8.2.1 The exposure time with positive polarity........................................................................................................... 18
8.3 Edge preset trigger mode.........................................................................................................................................19
8.3.1 The exposure timing with positive polarity ........................................................................................................ 19
9Camera Output Timing Charts...................................................................................................................................... 20
9.1 Horizontal timing: Full scanning ...............................................................................................................................20
9.1.1 8TAP (1X8-1Y) / Horizontal: 5,120 pixels..........................................................................................................20
9.1.2 10TAP (1X10-1Y) / Horizontal: 5,120 pixels......................................................................................................21
9.2 Vertical timing ...........................................................................................................................................................23
10 Scanning Mode........................................................................................................................................................... 24
10.1 ROI Output Timing....................................................................................................................................................24
11 Camera Functions...................................................................................................................................................... 25
11.1 Flat Field Correction Control (FFC function) ............................................................................................................25
11.1.1 FFC Setting Procedure ..................................................................................................................................... 25
12 Communication Protocol specifications ................................................................................................................. 26
12.1 Communication method............................................................................................................................................ 26
12.2 Communication settings...........................................................................................................................................26
12.3 Communication format ............................................................................................................................................. 27
12.4 Camera control commands ......................................................................................................................................28
12.4.1 Camera commands list ..................................................................................................................................... 28
12.4.2 The Description of camera control commands ................................................................................................. 31
12.4.1 Camera Control Command List (Device Code:3AH) ........................................................................................ 39
12.4.2 Command sequence for data saves to EEPROM.............................................................................................46
13 Revision History......................................................................................................................................................... 47

No.18S075-00
3/48
STC-OSB250CL
Product Specifications and User’s Guide
Precautions for safe use
Please read carefully this “Precautions for safe use” before use the camera. Then the camera uses correctly with
agreeing with below notes.
In this “Precautions for safe use”, notes divides into “Warning” and “Caution” to use the camera safety and prevent to
harm and damage.
Warning
This shows, assumption for possibility of serious accident leading death or
serious injury if ignore this note and camera uses incorrectly.
Caution
This shows, assumption for possibility of bear the damage or physical
damage if ignore this note and camera uses incorrectly.
About Graphic
symbols
This symbol shows general prohibition.
This symbol shows completion or instruction.
[Environment / condition]
Warning
Do not use flammable or explosiveness
atmospheres.
This will cause of personal injury or fire.
Do not use for “safety for human body” related
usage.
This camera is designed for use “do not harm
human body immediately” if by any chance the
camera has malfunction.
Caution
Use and store under specified environmental
conditions (Vibration, shock, temperature,
humidity) in the specifications for this camera.
This will cause of fire or damage the camera.
[Installation and cable wiring]
Warning
Do not use with out of power voltage range
that is specified in the specifications for this
camera.
This will cause of fire, electrification or
malfunction.
Do not wrong wiring.
This will cause of fire or malfunction.
Caution
Do not grounding DC power (+) of all devices
that are connect to the camera.
The camera housing is connecting to 0 V line of
camera inside circuit.
There is a risk of short circuit between camera
inside ciurcuit and frame ground.
This will cause of malfunction.
It is necessary to wiring and mounting that is
specified in the specifications for this camera.
This will cause of fire or malfunction.
It is necessary to wiring with turn off the camera.
This will cause of electrification or malfunction.
It is necessary to mounting the camera without
stress for the cable.
This will case of electrification or fire.
Do not use Camera Link un-supported cable
and board.
There is a risk of malfunction if the camera
connects with wrong environment and turn on
the camera.

No.18S075-00
4/48
STC-OSB250CL
Product Specifications and User’s Guide
[Usage instruction]
Warning
Do not touch the terminal and PCB board
While turn on the camera.
This will cause of electrification or accident
caused by malfunction.
Do not put combustibles near the camera.
This will cause of fire.
Do not use without usage that is specified in
the specifications for this camera.
This will cause of personal injury or malfunction.
Do not push metals including screw driver into
radiation holes.
This will cause of electrification or malfunction.
Do not touch the camera housing while or
afterusing the camera.
There is a risk of get burned.
Caution
Do not push contamination into opening of
the camera.
This will cause of electrification or malfunction.
Do not block the radiation holes.
This will cause of fire due to increase the
camera inside temperature.
[Maintenance]
Caution
Do not disassemble or repair the camera.
This will cause of fire, electrification or
malfunction.
It is turn off the camera when maintaining or
inspecting the camera.
This will cause of electrification.
[Disposal]
Caution
It is necessary to dispose as industrial waste.
]

No.18S075-00
5/48
STC-OSB250CL
Product Specifications and User’s Guide
1 Product Precautions
Do not give shock to the camera.
Do not haul or damage the camera cable.
Do not wrap the camera with any material while using the camera. This will cause the internal camera
temperature to increase.
When the camera moving or using the place that temperature difference is extreme, countermeasure for dew
condensation (heat removal / cold removal) is necessary.
While the camera is not using, keep the lens cap on the camera to prevent dust or contamination from getting
in the sensor or filter and scratching or damaging it.
Do not keep the camera under the following conditions.
In wet, moist, high humidity or dusty place
Under direct sunlight
In extreme high or low temperature place
Near an object that releases a strong magnetic or electric filed
Place with strong vibrations
Apply the power that satisfies the specified in specifications for the camera.
The defective pixels may appear due to the sensor characteristics.
Use below recommend materials (or equivalent materials) to clean the surface of glass.
Air dust: Non Freon air duster (NAKABAYASHI Co., LTD.)
Alcohol: Propan-2-ol (SAN’EI KAKO Co., LTD.)
Non-woven: nikowipe clean room (NKB)
Use a soft cloth to clean the camera.
2 Warranty
■Warranty period
One year after delivery (However, the camera had malfunction with camera uses correctly)
In below case for a fee even within warranty period.
・The malfunction caused by incorrect usage, incorrect modify or repair.
・The malfunction caused by external shock including the camera dropping after delivery the camera.
・The malfunction caused by fire, earthquake, flood disaster, thunderbolt struck, other natural disaster or
wrong voltage.
■Warranty coverage
Exchange or repair the malfunction camera if the malfunction is occurred by our responsibility.
“Warranty” mean is warranty for the delivered camera itself. Please accept the induction damage by the
camera malfunction is not included.

No.18S075-00
6/48
STC-OSB250CL
Product Specifications and User’s Guide
3 Overview
This camera is 26 Mega pixels global shutter CMOS sensor with Camera Link interface camera.
This camera has external trigger function to obtain fast moving target image for machine vision usage.
4 Features
High resolution
The camera has ON Semiconductor 25 Mega pixels global shutter CMOS sensor to achieve maximum 31.8 fps at
10TAP 8bits output.
Camera Link standard compliance
The camera is compliance with Camera Link Deca configuration (10TAP 8bits and 8TAP 10bits), Full configuration
(8TAP 8bits).
Global shutter
The camera has ON Semiconductor 25 Mega pixels global shutter CMOS sensor to support obtaining fast moving
target image.
Fast exposure time
The minimum 21 μseconds exposure time is supported for free-run / continuous mode and edge preset trigger mode.
Trigger operation
Expose and obtain image by external trigger signal through CC1 on Camera Link or 2pin on Power/IO connector.
Selectable Camera Link clock speed
The Camera Link clock speed can be selectable from 85 Hz or 66.11 MHz.
Please select the optimum Camera Link clock speed if long length Camera Link cable is required.
Heat dissipation design
The heat of electronics components inside of camera is dissipated to camera housing with mechanical design, which
is minimized thermal resistance between components and housing.
Please manage camera housing temperature when camera using in environment exceeding ambient temperature
specified in this specifications.

No.18S075-00
7/48
STC-OSB250CL
Product Specifications and User’s Guide
5 Specifications
5.1 Electronic Specifications
Model Number
STC-OSB250CL
Image Sensor
APS-H 26M Progressive Monochrome CMOS (ON Semiconductor: PYTHON 25K)
Shutter Type
Global shutter
Active Picture Elements
5,120 (H) x 5,120 (V)
Cell Size
4.5 (H) x 4.5 (V) µm
Scanning Mode
Full scanning (Full resolution) / ROI
Maximum
Frame Rate
(at full
resolution) (*1)
10TAP output
31.84 fps (@ 85 MHz) / 24.67 fps (@ 66.11 MHz)
8TAP output
25.38 fps (@ 85 MHz) / 19.91 fps (66.11 MHz)
ADC Bits
10 bits
Video Output
8bits / 10bits output
Camera Link Data Output (*2)
Deca / Full Configuration
Camera Link TAP Configuration
10TAP / 8TAP
Camera Link
Clock Speed
(*3)
10AP output
85 / 66.11 MHz
8TAP output
Noise Level
(Gain 0 dB)
8bits Output
Less than 3 digits
10bits Output
Less than 12 digits
Sensitivity (*5)
390 Lux
Exposure Time (All TAP common)
1 µseconds to 16.777 seconds (Default: 1,000 µseconds)
Gain
Analog Gain
x1 (Fixed)
Digital Gain
X1 to x5 (Default: x1)
Black Level
(*4)
8bits Output
0 to 63 digits
10bits Output
0 to 252 digits
White Balance Gain
N/A
ROI
Size
Horizontal
10TAP: 10 to 5,120 pixels (Adjustable steps: 10 pixels)
8TAP: 8 to 5,120 pixels (Adjustable steps: 8 pixels) (Default: 5,120)
Vertical
2 to 5,120 lines (Adjustable steps: 1 line) (Default: 5,120)
Position
Horizontal
10TAP: 0 to 5,056 pixels (Adjustable steps: 1 pixel)
8TAP: 0 to 5,112 pixels (Adjustable steps: 1 pixel)
Vertical
0 to 5,119 lines (Adjustable steps: 1 line)
Multi ROIs
Maximum eight regions (Horizontal size for all regions are common)
Gamma
N/A
Binning
N/A
Decimation
N/A
Flip Image
Horizontal / Vertical / Horizontal and Vertical / Off
Defective Pixel Correction
Up to 1,024 points
Auto Image
Control
Auto Exposure
N/A
Auto Gain
N/A
Auto White Balance
N/A
Operational Mode
Edge preset Trigger / Pulse width Trigger / Free run
User Setting Storage
Support
Default: Bold

No.18S075-00
8/48
STC-OSB250CL
Product Specifications and User’s Guide
Model Number
STC-OSB250CL
Input / Output
4 GPIOs
Power
Input Voltage
+10.8 to +26.4 Vdc
Consumption
Max: 9.7 W, Typical: 9.2 W
Precautions
(*1) The selected image output bit does not make any influence for maximum frame rate.
(*2) Camera Link data output formats (TAP configuration and output bits) are listed in below table:
10TAP
8TAP
8bits
Deca configuration
Full configuration
10bits
N/A
Deca configuration
(*3) Please select the optimum Camera Link clock speed if long length Camera Link cable is required.
(*4) Selected TAP configuration does not make any influence for nose level and black level.
(*5) The sensitivity is measured light source illumination for 100 % white under below conditions:
Camera Setting
Environment
Parameter
Setting
Parameter
Setting
Gain Up
0 dB
Light Source
Light Box (White)
AGC
Off
Color temperature
5,100K
White Balance
Optimum
Lens
Electrical Shutter
1/30 seconds
F on Lens
F5.6
Black Level
Optimum
Target Luminance
IM-600 (Topcon)
Gamma
Factory Setting

No.18S075-00
9/48
STC-OSB250CL
Product Specifications and User’s Guide
5.2 Spectral Sensitivity Characteristics

No.18S075-00
10/48
STC-OSB250CL
Product Specifications and User’s Guide
5.3 Mechanical specifications
Model Number
STC-OSB250CL
Dimensions
75 (W) x 75 (H) x 40 (D) mm
Optical Filter
No Optical Filter
Optical CenterAccuracy
Positional accuracy in Horizontal and Vertical directions: +/- 0.35 mm
Rotational accuracy of Horizontal and Vertical directions: +/- 1.3 deg.
Material
Aluminum alloy (AC)
Lens Mount
M42 Mount
Interface Connectors
Camera Link connector: SDR connector x 2
Power/IO connector: HR10A-7R-6PB (Hirose) or equivalent x 1
Camera Mounting
M4 screw holes (Four on top, bottom and both side plates)
Weight
Approximately 400 g
(*1) Excluding the connectors
5.4 Environmental specifications
Model Number
STC-OSB250CL
Operational Temperature / Humidity
Environmental Temperature: 0 to +50 deg. C,
Environmental Humidity: 0 to 85 %RH (No condensation)
Storage Temperature / Humidity
Environmental Temperature: 0 to +80 deg. C,
Environmental Humidity: 0 to 90 %RH (No condensation)
Vibration
20 Hz to 200 Hz to 20 Hz (5 min. / cycle), acceleration 10 G, XYZ 3 directions 30 min. each
Shock
Acceleration 38 G, half amplitude 6 mseconds, XYZ 3 directions 3 times each
Standard compliancy
EMS: EN61000-6-2, EMI: 55011 Group1 Class A
RoHS
Compliant

No.18S075-00
11/48
STC-OSB250CL
Product Specifications and User’s Guide
5.5 Connector specifications
5.5.1 Camera Link Connectors
SDR (3M) or equivalent x 2
This camera is None PoCL Camera Link camera.
Camera Link Connector pin assignment
Base Camera Link Connector Medium / Full Camera Link Connector
Pin No.
Signal Name
Pin No.
Signal Name
Pin No.
Signal Name
Pin No.
Signal Name
1
GND
14
GND
1
GND
14
GND
2
X0-
15
X0+
2
Y0-
15
Y0+
3
X1-
16
X1+
3
Y1-
16
Y1+
4
X2-
17
X2+
4
Y2-
17
Y2+
5
Xclk-
18
Xclk+
5
Yclk-
18
Yclk+
6
X3-
19
X3+
6
Y3-
19
Y3+
7
SerTC+
20
SerTC-
7
100Ω
20
100Ω
8
SerTFG-
21
SerTFG+
8
Z0-
21
Z0+
9
CC1- (TRG)
22
CC1+ (TRG)
9
Z1-
22
Z1+
10
CC2+
23
CC2-
10
Z2-
23
Z2+
11
CC3-
24
CC3+
11
Zclk-
24
Zclk+
12
CC4+
25
CC4-
12
Z3-
25
Z3+
13
GND
26
GND
13
GND
26
GND
Power/IO Connector
Camera Link Connector
(26pin SDR Connector Camera Link: Base)
Camera Link Connector
(26pin SDR Connector Camera Link: Full)

No.18S075-00
12/48
STC-OSB250CL
Product Specifications and User’s Guide
5.5.2 Power/IO Connector
HR10A-7R-6PB (Hirose) or equivalent connector x 1
This connector is for external power (+12 to 24 Vdc) input and input and output signals.
Please use HR10A-7P-6S (Hirose) or equivalent connector for connecting cable.
Power/IO connector pin assignment
Pin No.
Signal Name
IN /
OUT
Voltage
Consumption
Low voltage
High voltage
1
GND
IN
0 V
2
GPIO3
IN /
OUT
IN
Less than
+0.8 V
+2.4 to +3.6 V
5 μA (typ.) (*1)
OUT
0 to +0.7 V
+2.3 to +3.3 V
12 mA (Max.) (*2)
3
GPIO2
IN /
OUT
IN
Less than
+0.8 V
+2.4 to +3.6 V
5 μA (typ.) (*1)
OUT
0 to +0.7 V
+2.3 to +3.3 V
12 mA (Max.) (*2)
4
GPIO1
IN /
OUT
IN
Less than
+0.8 V
+2.4 to +3.6 V
5 μA (typ.) (*1)
OUT
0 to +0.7 V
+2.3 to +3.3 V
12 mA (Max.) (*2)
5
GPIO0
IN /
OUT
IN
Less than
+1.00 V
+2.4 to +3.6 V
5 μA (typ.) (*1)
OUT
0 to +0.7 V
+2.3 to +3.3 V
12 mA (Max.) (*2)
6
Power In
IN
+10.8 to +26.4 V
The trigger signal input connector is selectable from below two connectors by camera control
command.
Camera Link connector: CC1
Power/IO connector: 2pin
(*1) The power consumption when high voltage trigger signal input to input port.
(*2) The power consumption for output port has to be managed less than 12 mA.

No.18S075-00
13/48
STC-OSB250CL
Product Specifications and User’s Guide
5.5.3 Input signal circuit
+3.3V
10kΩ100Ω
SN74AVC4T774
Camera Input
(to FPGA)
GND
User Input
Pin 2
2
1
6Pin Conector
Camera
5.5.4 Output signal circuit
+3.3V
SN74AVC4T774
100Ω10kΩ
3,4,5
1
6Pin Conector
Camera Output
(from FPGA)
GND
Pin 3 or 4 or 5
User Output
Voltage 0 to +3.3 DC
Camera

No.18S075-00
14/48
STC-OSB250CL
Product Specifications and User’s Guide
6 Dimensions
6.1 STC-OSB250CL
Unit: mm

No.18S075-00
15/48
STC-OSB250CL
Product Specifications and User’s Guide
6.2 STC-OSB250CL-F
Unit: mm

No.18S075-00
16/48
STC-OSB250CL
Product Specifications and User’s Guide
7 Sensor Information
7.1 Pixel Transferring Image
Pixel (n) of Data: nth pixel being transferred
Pixel1 of
Data Pixel2 of
Data

No.18S075-00
17/48
STC-OSB250CL
Product Specifications and User’s Guide
8 Camera Function Modes
8.1 Free-run / Continuous mode
This mode can be outputted camera image signal continuously.
Exposure Time
Image Out
Exposure
Time
Internal VD
* Note: The exposure time sets by preset exposure time.
When setting shorter than 21 μseconds for exposure time, 21 μseconds set to exposure time
automatically.

No.18S075-00
18/48
STC-OSB250CL
Product Specifications and User’s Guide
8.2 Pulse width trigger mode
The camera exposure starts by trigger signal.
In this trigger mode with positive trigger polarity, camera exposure starts at rising edge of trigger signal and stops
at falling edge of trigger signal. The exposure time is active pulse duration (high state) of trigger signal.
In this trigger mode with negative trigger polarity, camera exposure starts at falling edge of trigger signal and stops
at rising edge of trigger signal. The exposure time is active pulse duration (low state) of trigger signal.
The exposure start will be delay about 22.1 μseconds by filtering system on camera.
8.2.1 The exposure time with positive polarity
Exposure Time
Image Out
Trigger Signal
(Positive)
FVAL
* Note.1: The exposure time sets by active pulse duration of trigger signal.
There is no FVAL output without exposing by trigger signal.
* Note.2: When active pulse duration of trigger signal is shorter than 21 μseconds, trigger signal is discard
by filtering system on camera.
It is necessary to supply more than 21 μseconds active pulse duration of trigger signal to camera.
* Note.3: The trigger signal is discard when trigger signal supplies shorter than below minimum frame
interval time from previous supplied trigger signal.
Minimum frame interval:
10TAP, 85.00 MHz: 31.397 mseconds
10TAP, 66.11 MHz: 40.515 mseconds
8TAP, 85.00 MHz: 39.377 mseconds
8TAP, 66.11 MHz: 50.206 mseconds
* Note.3: The trigger signal is discard when trigger signal supplies shorter than below minimum horizontal
blanking period from falling edge of previous supplied trigger signal with positive polarity
Minimum vertical blanking period:
10TAP, 85.00 MHz: 250.88 μseconds
10TAP, 66.11 MHz: 266.24 μseconds
8TAP, 8bits, 85.00 MHz: 266.24 μseconds
8TAP, 8bits, 66.11 MHz: 286.72 μseconds
8TAP, 10bits, 85.00 MHz: 266.24 μseconds
8TAP, 10bits, 66.11 MHz: 286.72 μseconds

No.18S075-00
19/48
STC-OSB250CL
Product Specifications and User’s Guide
8.3 Edge preset trigger mode
The camera exposure starts by trigger signal.
In this trigger mode with positive trigger polarity, camera exposure starts at rising edge of trigger signal.
The exposure time sets by preset exposure time.
In this trigger mode with negative trigger polarity, camera exposure starts at falling edge of trigger signal.
The exposure time sets by preset exposure time.
The exposure start will be delay about 1.1 μseconds by filtering system on camera.
8.3.1 The exposure timing with positive polarity
Exposure Time
Image Out
Trigger Signal
(Positive)
FVAL
* Note.1
Exposure
TIme
* Note.1: The exposure time sets by preset exposure time.
When setting shorter than 21 μseconds for exposure time, 21 μseconds set to exposure time
automatically.
* Note.2: When active pulse duration of trigger signal is shorter than 1.1 μseconds, trigger signal is discard
by filtering system on camera.
It is necessary to supply more than 1.1 μseconds active pulse duration of trigger signal to
camera.
* Note.3: The trigger signal is discard when trigger signal supplies shorter than below minimum frame
interval time from previous supplied trigger signal.
Minimum frame interval:
10TAP, 85.00 MHz: 31.397 mseconds
10TAP, 66.11 MHz: 40.515 mseconds
8TAP, 85.00 MHz: 39.377 mseconds
8TAP, 66.11 MHz: 50.206 mseconds
However, when detecting signal state change from low to high (for positive polarity) at minimum
frame interval passed from previous trigger signal, exposing by trigger signal starts.

No.18S075-00
20/48
STC-OSB250CL
Product Specifications and User’s Guide
9 Camera Output Timing Charts
9.1 Horizontal timing: Full scanning
9.1.1 8TAP (1X8-1Y) / Horizontal: 5,120 pixels
Image out
(Tap1: DA)
LVAL
Horizontal
blanking
1H
640 CLK
Image output
Image out
(Tap2: DB)
Image out
(Tap4: DD)
Image out
(Tap3: DC)
Image out
(Tap5: DE)
Image out
(Tap6: DF)
Image out
(Tap7: DG)
Image out
(Tap8: DH)
5103 5111 5119
5100 5108 5116
5102 5110 5118
5101 5109 5117
5104 5112 5120
5099 5107 5115
5098 5106 5114
5097 5105 5113
5
13 21
6
14 22
8
16 24
7
15 23
4
12 20
3
11 19
1 9
17
2
10 18
Camera settings
Horizontal period
(μsecond)
Horizontal
Blanking period
(CLK)
Camera Link
Clock (MHz)
Camera Link
output format
85.00
8bits / 10bits
7.6389
222
66.11
8bits / 10bits
9.7500
372
