Omron F3SG RE Series Operating and maintenance instructions

Safety Light Curtain
F3SG-□RE Series
© OMRON Corporation 2015-2023 All Rights Reserved.
Original instructions 8900153-0D
http://www.ia.omron.com/f3sg-r
Document Title Cat. No.
Safty Light Curtain F3SG-R Series User's Manual Z352-E1
1
EN
Quick Installation Manual

1F3SG-RE
Quick Installation Manual
Introduction
Thank you for purchasing the F3SG-RE Series Safety Light Curtain (hereinafter referred to as the "F3SG-
RE"). This document contains simple instructions to install the F3SG-RE.
Please download the F3SG-RE User's Manual for full contents of the instructions from our website at:
http://www.ia.omron.com/f3sg-r
Table of Contents
1. Precautions for Correct Use .............................................................................................................2
2. What is Included...............................................................................................................................3
3. System Components ........................................................................................................................3
4. LED Indicators..................................................................................................................................4
4-1. LED Indicator Status ................................................................................................................5
5. Ratings/Specifications ......................................................................................................................6
6. F3SG-RE Setup Procedure Example...............................................................................................9
7. F3SG-RE Setup Procedure Example...............................................................................................9
8.Wiring Examples .............................................................................................................................11
8-1. Long Mode .............................................................................................................................11
8-2. Short Mode.............................................................................................................................11
9. Safety Distance ..............................................................................................................................12
9-1. Safety Distance Formulas according to ISO 13855/EN ISO 13855 .......................................12
9-2. Safety Distance Formulas according to ANSI B11.19............................................................15
10. Mounting and Beam Alignment ....................................................................................................16
10-1. Mounting with Standard Fixed Brackets (F39-LGF).............................................................16
10-2. Mounting with Standard Adjustable Brackets (F39-LGA).....................................................18
11. Operation Check ..........................................................................................................................21
Suitability for Use/Contact Information ...............................................................................................21

2
F3SG-RE
Quick Installation Manual
1. Precautions for Correct Use
Observe the precautions described below to prevent operation failure, malfunctions, or undesirable effects on
product performance.
■Storage conditions and installation environment
• Do not install, use, or store the F3SG-R for a long time at a temperature or humidity out of the specified
range.
• This is a class A product. In residential areas it may cause radio interference, in which case the
Responsible Person may be required to take adequate measures to reduce interference.
■Wiring and installation
• Properly perform the wiring after confirming the signal names of all the terminals.
• Be sure that there is nothing in the detection zone and the stable-state indicator is turned ON after power is
turned ON.
• Do not operate the control system until 2 seconds or more after turning ON the power of the F3SG-R.
• When using a commercially available switching regulator power supply, make sure to ground the PE
terminal (protective earth terminal).
• Install the emitter and receiver to the same vertical direction.
Use brackets of specified quantities and locations according to the dimensions.
If the brackets described above are not used, ratings and performance cannot be met.
• Do not install the F3SG-R close to a device that generates high-frequency noise. Otherwise, take sufficient
blocking measures.
• Sharing the power supply with other devices may cause the F3SG-R to be affected by noise or voltage
drop. It is recommended that the F3SG-R use a power supply dedicated for safety components, not shared
with other devices.
■Cleaning
• Do not use thinner, benzene, or acetone for cleaning. They affect the product's resin parts and paint on the
housing.
• Use a soft cloth which is dry or wetted with clean water for cleaning. Do not use solvents.
■Object detection
• The F3SG-R cannot detect transparent and/or translucent objects.

3F3SG-RE
Quick Installation Manual
2. What is Included
For ratings/specifications, input/output circuit, LED indicator status and troubleshooting, refer to Safety Light Curtain F3SG-R
Series User's Manual.
3. System Components
Product Quantity
F3SG-RE main unit
Emitter x 1, Receiver x 1
Standard Fixed Bracket
The number of brackets included depends on protective height of the F3SG-RE.
Less than 1,280 mm: 2 sets
1,280 mm or longer and up to 2,270 mm: 3 sets
2,350 mm or longer and up to 2,510 mm: 4 sets
Troubleshooting Guide Sticker 1
Safety Precautions 4
Quick Installation Manual 3
Indicator
Beam
Emitter
Receiver
Power Cable
(Black)
Power Cable
(Gray)
Extension cable
Beam center-line mark
1. Top-beam-state indicator (Blue)
2. Operating range indicator (Green)
3. Power indicator (Green)
4. Lockout indicator (Red) 9. Internal error indicator (Red)
10. Lockout indicator (Red)
11. Stable-state indicator (Green)
12. ON/OFF indicator (Green/Red)
13. Communication indicator (Green)
14. Bottom-beam-state indicator (Blue)
<Emitter> <Receiver>

4
F3SG-RE
Quick Installation Manual
4. LED Indicators
1. Top-beam-state indicator (Blue)
2. Operating range indicator (Green)
3. Power indicator (Green)
4. Lockout indicator (Red) 9. Internal error indicator (Red)
10. Lockout indicator (Red)
11. Stable-state indicator (Green)
12. ON/OFF indicator (Green/Red)
13. Communication indicator (Green)
14. Bottom-beam-state indicator (Blue)
<Emitter> <Receiver>

5F3SG-RE
Quick Installation Manual
4-1. LED Indicator Status
Shown below are indication statuses of F3SG-R LED indicators of factory default.
Emitter
Receiver
*1.The EDM indicator is illuminated when the RESET input is in the ON state regardless of the use of the EDM function.
*2.Refer to F3SG-R Series User's Manual for more information of blinking patterns.
Location Name of Indicator Color Illuminated Blinking
2 Operating range LONG Green Long range mode is selected
Lockout state due to DIP Switch setting
error or Operating range selection setting
error
3 Power POWER Green Power is ON. Error due to noise
4 Lockout LOCKOUT Red - Lockout state due to error in emitter
Location Name of Indicator Color Illuminated Blinking
1 Top-beam-state TOP Blue The top beam is unblocked Muting/Override state, or Lockout state
due to Cap error or Other sensor error *3
5 Internal error INTERNAL Red -
Lockout state due to Internal error, or
error due to abnormal power supply or
noise
6 Lockout LOCKOUT Red - Lockout state due to error in receiver
7 Stable-state STB Green Incident light level is 170% or higher
of ON-threshold
Safety output is instantaneously turned
OFF due to ambient light or vibration
8 ON/OFF ON/OFF
Green Safety output is in ON state -
Red Safety output is in OFF state
Lockout state due to Safety Output error,
or error due to abnormal power supply or
noise
9 Communication COM Green Synchronization between emitter
and receiver is maintained
Lockout state due to Communication
error, or error due to abnormal power
supply or noise
10 Bottom-beam-state BTM Blue The bottom beam is unblocked Muting/Override state, or Lockout state
due to DIP Switch setting error *3

6
F3SG-RE
Quick Installation Manual
5. Ratings/Specifications
The  in the model names indicate the protective heights in millimeters.
F3SG-4RE14
F3SG-2RE14
F3SG-4RE30
F3SG-2RE30
Type of ESPE (IEC
61496-1)
Type 4 F3SG-4RE14/30
Type 2 F3SG-2RE14/30
Performance
Object Resolution (Detection Capability)
Opaque objects
14-mm dia. 30-mm dia.
Beam Gap 10 mm 20 mm
Number of Beams 15 to 207 8 to 124
Lens Size 5.2 × 3.4 (W × H) mm 7-mm dia.
Protective Height 160 to 2080 mm (6.3 to 81.9 inch) 190 to 2510 mm (7.3 to 98.7 inch)
Operating Range
Long 0.3 to 10.0 m (1 to 32 ft.) 0.3 to 20.0 m (1 to 65 ft.)
Short 0.3 to 3.0 m (1 to 10 ft.) 0.3 to 7.0 m (1 to 23 ft.)
Response Time
ON to OFF 5 to 15 ms
OFF to ON 25 to 75 ms
*1. Response time when used in one segment system or in cascaded connection.
Refer to F3SG-R Series User's Manual for more information.
*2. Selectable by Configuration Tool.
Effective Aperture
Angle (EAA) (IEC
61496-2)
Type 4 ±2.5° max., emitter and receiver at operating range of 3 m or greater
Type 2 ±5.0° max., emitter and receiver at operating range of 3 m or greater
Light Source Infrared LEDs, Wavelength: 870 nm
Startup Waiting Time 2 s max.
Electrical
Power Supply Voltage (Vs) SELV/PELV 24 VDC±20% (ripple p-p 10% max.)
Current Consumption Refer to F3SG-R Series User's Manual.
Safety Outputs (OSSD)
F3SG-REP: Two PNP transistor outputs
F3SG-REN: Two NPN transistor outputs
Load current of 300 mA max., Residual voltage of 2 V max. (except for voltage drop due
to cable extension), Capacitive load of 1 F max., Inductive load of 2.2 H max. *1
Leakage current of 1 mA max. (PNP), 2 mA max. (NPN) *2
*1. The load inductance is the maximum value when the safety output frequently repeats
ON and OFF. When you use the safety output at 4 Hz or less, the usable load
inductance becomes larger.
*2. These values must be taken into consideration when connecting elements including
a capacitive load such as a capacitor.
Output Operation
Mode Safety Output Light-ON (Safety output is enabled when the receiver receives an emitting signal.)

7F3SG-RE
Quick Installation Manual
Input Voltage
RESET (EDM) Operating Range Select Input:
Long: 9 V to Vs (short circuit current: approx. 2.5 mA)*
Short: 0 to 1.5 V (short circuit current: approx. 2.0 mA)
The F3SG-RE enters the Long Mode when the Operating Range Select Input line is
open.
MUTE A/B
TEST
* The Vs indicates a supply voltage value in your environment.
Overvoltage Category (IEC 60664-1) II
Indicators Refer to 4. LED Indicators
Protective Circuit Output short protection, Power supply reverse polarity protection
Insulation Resistance 20 M or higher (500 VDC megger)
Dielectric Strength 1,000 VAC, 50/60 Hz (1 min)
Functional
Mutual Interference Prevention
(Scan Code) Refer to F3SG-R Series User's Manual for more information.
Test Function Self-test (at power-on, and during operation)
Environmental
Ambient Temperature
Operating -10 to 55°C (14 to 131°F) (non-icing)
Storage -25 to 70°C (-13 to 158°F)
Ambient Humidity
Operating 35% to 85% (non-condensing)
Storage 35% to 95%
Ambient Illuminance Incandescent lamp: 3,000 Ix max. on receiver surface
Sunlight: 10,000 Ix max. on receiver surface
Degree of Protection (IEC 60529) IP65 and IP67
Vibration Resistance (IEC 61496-1)
Class 3M4 (IEC TR 60721-4-3)
Operation limit: 5~150 Hz, Multiple amplitude of 7 mm, Acceleration of 1G, 10 sweeps
each in X, Y, and Z directions (no delay at resonant frequencies)
Shock Resistance (IEC 61496-1)
Class 3M4 (IEC TR 60721-4-3)
Operation limit: Acceleration of 15G, Pulse duration of 6 ms, 100 shocks for each in X, Y,
and Z directions (600 shocks in total)
Pollution Degree (IEC 60664-1) Pollution Degree 3
Connections
Power cable
Type of
Connection
M12 connectors: 4-pin, IP67 rated when mated,
Cables prewired to the sensors
Number of Wires Emitter: 4, Receiver: 4
Cable Length 0.3 m
Cable Diameter 6 mm
Minimum Bending
Radius R5 mm
F3SG-4RE14
F3SG-2RE14
F3SG-4RE30
F3SG-2RE30

8
F3SG-RE
Quick Installation Manual
Extension cable
- Single-ended cable
- Double-ended cable
Type of
Connection
Use the XS5-D42 series cables.
Number of Wires
Cable Length
Cable Diameter
Minimum Bending
Radius
Extension of Power Cable 100 m max.(Emitter/Receiver)
Material
Material
Housing: Aluminium alloy
Cap: PBT resin
Front window: Acrylic resin
Cable: Oil resistant PVC resin
Standard Fixed Bracket (F39-LGF): Zinc alloy
FE plate: Stainless steel
Weight Refer to F3SG-R Series User's Manual.
Included Accessories
Safety Precautions, Quick Installation Manual, Standard Fixed Bracket*1,
Troubleshooting Guide Sticker, Warning Zone Label *2
*1. The quantity of Standard Fixed Brackets included varies depending on the protective
height.
[F3SG-RA-14]/F3SG-RE14]
- Protective height of 0160 to 1200: 2 sets
- Protective height of 1280 to 2080: 3 sets
[F3SG-RA-30]/F3SG-RE30]
- Protective height of 0190 to 1230: 2 sets
- Protective height of 1310 to 2270: 3 sets
- Protective height of 2350 to 2510: 4 sets
*2. Included in the F3SG-RA series.
Conformity
Conforming standards Refer to F3SG-R Series User's Manual.
Performance Level
(PL)/Safety category
Type 4 PL e/Category 4 (EN ISO 13849-1:2015)
Type 2 PL c/Category 2 (EN ISO 13849-1:2015)
PFHD9.1×10-9 (IEC 61508)
Proof test interval TMEvery 20 years (IEC 61508)
SFF 99% (IEC 61508)
HFT 1 (IEC 61508)
Classification Type B (IEC 61508-2)
F3SG-4RE14
F3SG-2RE14
F3SG-4RE30
F3SG-2RE30

9F3SG-RE
Quick Installation Manual
6. F3SG-RE Setup Procedure Example
7. F3SG-RE Setup Procedure Example
■PNP Output
Setup
Wiring
Mounting/Beam Alignment
Operation check
Done
. . . . . . page 11
. . . . . . page 16
. . . . . . page 21
1
4
3
2
+24 V
1
2
4
3
0 V
Operating Range
Select Input circuit
Brown
Black Not used
White
Blue
Brown
White OSSD 2
Black OSSD 1
Blue
Indicator
Emitter
Main Circuit
Receiver
Main Circuit 2
Receiver
Main Circuit 1
Indicator
Load
Load
Operating Range
Select Input

10
F3SG-RE
Quick Installation Manual
■NPN Output
1
4
3
2
+24 V
1
2
4
3
0 V
Brown
Black Not used
White
Blue
Brown
White OSSD 2
Black OSSD 1
Blue
Indicator
Emitter
Main Circuit
Receiver
Main Circuit 2
Receiver
Main Circuit 1
Indicator
Load
Load
Operating Range
Select Input circuit
Operating Range
Select Input

11 F3SG-RE
Quick Installation Manual
8.Wiring Examples
For input/output circuit and other examples than below, refer to Safety Light Curtain F3SG-R Series User's Manual.
8-1. Long Mode
8-2. Short Mode
IN1 IN2
+24 V
0 V
OSSD1 : Black OSSD2 : White Operating Range Select Input : White 24 VDC : Brown Not used : Black 24 VDC : Brown 0 VDC : Blue
Receiver
Emitter
0 VDC : Blue
DC
Power
Supply
Safety
Controller *1 *2
*1. Refer to F3SG-R Series User's Manual for more information.
*2. The safety controller and the F3SG-RE must share the
power supply or be connected to the common terminal of
the power supply.
+24 V
0 V
OSSD1 : Black OSSD2 : White Operating Range Select Input : White 24 VDC : Brown Not used : Black 24 VDC : Brown 0 VDC : Blue
Receiver
Emitter
0 VDC : Blue
DC
Power
Supply
Safety
Controller *1 *2
IN1 IN2
*1. Refer to F3SG-R Series User's Manual for more information.
*2. The safety controller and the F3SG-RE must share the
power supply or be connected to the common terminal of
the power supply.
Wiring Operation check
Mounting/Beam Alignment

12
F3SG-RE
Quick Installation Manual
9. Safety Distance
The safety distance is the distance that must be set between the F3SG-R and a machine's hazardous part to
stop the hazardous part before a person or object reaches it. The safety distance varies according to the
standards of each country and the individual specifications of each machine. Always refer to the relevant
standards.
The response time of a machine is the time period from when the machine receives a stop signal to when the machine's
hazardous part stops. Measure the response time on the actual system. Also, periodically check that the response time of the
machine has not changed.
9-1. Safety Distance Formulas according to ISO 13855/EN ISO 13855
Detection Zone Orthogonal to Direction of Approach
S = K x T + C . . . Formula (1)
• S: Safety distance
• K: Approach speed to the detection zone
• T: Total response time of the machine and F3SG-R
• C: Additional distance calculated by the detection capability (or
object resolution) of the F3SG-R
Calculation Example for Systems with a Detection Capability
of 40 mm or Less
Use K = 2,000 mm/s and C = 8 x (d - 14 mm) in formula (1) for the cal-
culation.
S = 2,000 mm/s x (Tm + Ts) + 8 x (d - 14 mm)
• S = Safety distance (mm)
• Tm = Machine's response time (s)
• Ts = Response time of the F3SG-R from ON to OFF (s)
• d = Detection capability (or object resolution) of the F3SG-R (mm)
[Calculation example]
When Tm = 0.05 s, Ts = 0.008 s, and d = 14 mm:
S=2,000 mm/s x (0.05 s + 0.008 s) + 8 x (14 mm - 14 mm)
= 116 mm . . . Formula (2)
If the result < 100 mm, use S = 100 mm.
If the result exceeds 500 mm, use the following expression where K = 1,600 mm/s.
S=1,600 mm/s x (Tm + Ts) + 8 x (d - 14 mm) . . . Formula (3)
If the result of this formula (3) < 500 mm, use S = 500 mm.
Calculation Example for Systems with Larger Detection Capability than 40 mm
Use K = 1,600mm/s and C = 850mm in formula (1) for calculation.
S = 1,600mm/s x (Tm + Ts) + 850 . . . Formula (4)
• S = Safety distance (mm)
• Tm = Machine's response time (s)
• Ts = Response time of the F3SG-R from ON to OFF (s)
[Calculation example]
When Tm = 0.05 s and Ts = 0.008 s:
S = 1,600mm/s x (0.05 s + 0.008 s) + 850mm
= 942.8 mm
Make sure to secure the safety distance (S) between the F3SG-R and the hazardous part. Other-
wise, the machine may not stop before a person reaches the hazardous part, resulting in serious
injury.
Hazard
Safety distance (S)

13 F3SG-RE
Quick Installation Manual
Possible Circumventing by Reaching Over the Detection Zone
If access to the hazardous zone by reaching over the detection zone of vertically mounted F3SG-R cannot be
excluded, the height and the safety distance, S, of the F3SG-R shall be determined. S shall be determined by
comparison of the calculated values in Detection Zone Orthogonal to Direction of Approach . The greater
value resulting from this comparison shall be applied.
S=(K × T) + Cro . . . Formula (5)
• S: Safety distance
• K: Approach speed to the detection zone
• T: Total response time of the machine and F3SG-R
• Cro: Approach distance based on the distance which personnel
can move towards the hazardous zone of a machine by reaching
over the detection zone. The distance is determined in the table
below based on the height of the hazardous zone, a, and the
height of the upper edge of the detection zone, b.
Note:Lower edge of the detection zone above 300 mm in relation to the reference
plane does not offer sufficient protection against crawling below.
First, use K = 2,000 mm/s in formula (5) for the calculation. If the
result of this calculation is less than 100 mm, use S = 100 mm.
If the result exceeds 500 mm, use K = 1,600 mm/s to recalculate it. If
the result of the recalculation is less than 500 mm, use S = 500 mm.
Note 1.Upper edge of the detection zone below 900 mm is not included since they do not offer sufficient protection against
circumventing or stepping over.
Note 2.When determining the values of this table, it shall not be interpolated. If the known values a, b or Cro are between two values of
this table, the greater safety distance shall be used.
[Calculation example]
• T: Tm + Ts (s)
• Tm: Machine's response time (s)
• Ts: Response time of the F3SG-R from ON to OFF (s)
• a: Height of machine hazardous zone (mm)
• b: Height of upper edge of detection zone (mm)
Height of
hazardous
zone, a
Height of upper edge of detection zone, b
900 1000 1100 1200 1300 1400 1600 1800 2000 2200 2400 2600
Additional distance to hazardous zone, Cro
2600000000000000
2500 400 400 350 300 300 300 300 300 250 150 100 0
2400 550 550 550 500 450 450 400 400 300 250 100 0
2200 800 750 750 700 650 650 600 550 400 250 0 0
2000 950 950 850 850 800 750 700 550 400 0 0 0
1800 1100 1100 950 950 850 800 750 550 0 0 0 0
1600 1150 1150 1100 1000 900 850 750 450 0 0 0 0
1400 1200 1200 1100 1000 900 850 650 0 0 0 0 0
1200 1200 1200 1100 1000 850 800 0 0 0 0 0 0
1000 1200 1150 1050 950 750 700 0 0 0 0 0 0
800 1150 1050 950 800 500 450 0 0 0 0 0 0
600 1050 950 750 550 0 0 0 0 0 0 0 0
400 900 700 0 0 0 0 0 0 0 0 0 0
20060000000000000
0 000000000000
Hazard Safety
distance (S)
Reference plane
a
b
300 mm max.

14
F3SG-RE
Quick Installation Manual
When Tm = 0.05 s, Ts = 0.008 s, a = 1,400 mm, b = 1,500 m:
From the table above, Cro = 850 mm. Since b is between 1,400 mm and 1,600 mm, b = 1,400 mm which has
the greater Cro value, shall be used.
S = 2,000 mm/s × (0.05 s + 0.008 s) + 850 mm
= 966 mm
Since 966 mm is greater than 500 mm, use K = 1,600 mm/s and recalculate it.
S = 1,600 m/s × (0.05 s + 0.008 s) + 850 mm
= 942.8 mm
Compare S = 942.8 mm with the calculation for Detection Zone Orthogonal to Direction of Approach, and
choose the larger value as the safety distance.
For the system with a detection capability of 40 mm max., the safety distance S is 942.8 mm since this is larger
than S = 116 mm calculated in the calculation example of Detection Zone Orthogonal to Direction of Approach.
For the system with a detection capability larger than 40 mm, the safety distance S is 942.8 mm since this is
the same value as S = 942.8 mm calculated in the calculation example of Detection Zone Orthogonal to
Direction of Approach.
Refer to Detection Zone Orthogonal to Direction of Approach under 9-1. Safety Distance Formulas according to ISO 13855/EN
ISO 13855 .
Detection Zone Parallel to Direction of Approach
Use K = 1,600 mm/s and C = (1200 - 0.4 x H) in formula
(1) for calculation. Note that C must not be less than 850 mm.
S = 1,600 mm/s x (Tm + Ts) + 1200 - 0.4 x H
• S = Safety distance (mm)
• Tm = Machine's response time (s)
• Ts = Response time of F3SG-R from ON to OFF (s)
• H = Installation height (mm)
Note that H must satisfy:
1000 ≥ H ≥ 15 (d - 50 mm) ≥ 0 mm
Also, you must include a hazardous condition under which
a person may go through under a detection zone if H
exceeds 300 mm (200 mm for other purpose than indus-
trial use) into risk assessment.
[Calculation example]
When Tm = 0.05 s, Ts = 0.008 s, and d = 14 mm:
S = 1,600 mm/s x (0.05 s + 0.008 s) + 1200 - 0.4 x 500 mm
= 1092.8 mm
When a warning zone is configured as in the figure, you must calculate L, a distance from an end of casing to
a detection zone, using a formula below:
L = (Total number of F3SG-R beams - number of warning
zone beams - 1) x P + 10
P: Beam Gap (mm)
F3SG-RA-14 . . . 10 mm
F3SG-RA-30 . . . 20 mm
Refer to F3SG-R Series User's Manual for total number of F3SG-
R beams.
+
Safety distance (S)
Hazard
H
Safety
distance (S)
Hazard
Distance L from casing end
to detection zone
Detection
zone
Warning
zone

15 F3SG-RE
Quick Installation Manual
9-2. Safety Distance Formulas according to ANSI B11.19
If a person approaches the detection zone of the F3SG-R orthogonally, calculate the safety distance as
shown below.
S = K x (Ts + Tc + Tr + Tbm) + Dpf
• S: Safety distance
• K: Approach speed to the detection zone (the value recommended by OSHA standard is 1,600 mm/s)
Approach speed K is not specified in the ANSI B.11.19 standard. To determine the value of K to apply, con-
sider all factors, including the operator's physical ability.
• Ts = Machine's stopping time (s)
• Tr = Response time of the F3SG-R from ON to OFF (s)
• Tc = Machine control circuit's maximum response time required to activate its brake (s)
• Tbm = Additional time (s)
If a machine has a brake monitor, "Tbm= Brake monitor setting time - (Ts + Tc)". If it has no brake monitor, we
recommend using 20% or more of (Ts + Tc) as additional time.
• Dpf = Additional distance
According to ANSI's formula, Dpf is calculated as shown below:
Dpf = 3.4 x (d - 7.0): Where d is the detection capability (or object resolution) of the F3SG-R (unit: mm)
[Calculation example]
When K = 1,600 mm/s, Ts + Tc = 0.06 s, brake monitor setting time = 0.1 s,
Tr = 0.008 s, and d = 14 mm:
Tbm = 0.1 - 0.06 = 0.04 s
Dpf = 3.4 x (14 - 7.0) = 23.8 mm
S = 1,600 x (0.06 + 0.008 + 0.04) + 23.8 = 196.6 mm

16
F3SG-RE
Quick Installation Manual
10. Mounting and Beam Alignment
10-1. Mounting with Standard Fixed Brackets (F39-LGF)
■Dimensions (Check position)
P
51
24.85
F
D C2 (Protective height for 14 mm)
F
A150 max
150 max
150 max150 max
25
15
24.85
6.4
9.2
51
66
35
C1 (Protective height for 30 mm)
A
51
2-M5 or M6
2-M5 or M6
35
40
Standard Fixed
Bracket
Standard Fixed
Bracket
(F39-LGF)
(F39-LGF)
50.35
F3SG-RE30 Series
Dimension A C1
Dimension C1 4-digit number of the type name
(Protective height)
Dimension D C1-50
Dimension P 20
Protective height
(C1)
Number of Standard
Fixed Brackets *1 Dimension F
0190 to 1230 2 *2 1000 mm max.
1310 to 2270 3 1000 mm max.
2350 to 2510 4 1000 mm max.
F3SG-RE14 Series
Dimension A C2+30
Dimension C2 4-digit number of the type name
(Protective height)
Dimension D C2-20
Dimension P 10
Protective height
(C2)
Number of Standard
Fixed Brackets *1 Dimension F
0160 to 1200 2 *2 1000 mm max.
1280 to 2080 3 1000 mm max.
[ Unit : mm ]
< Screw: M5 or M6 >
[Backside mounting]
*1. The number of brackets required to mount either one of emitter and receiver.
*2. Mounting an emitter or receiver with one bracket is possible for the models of protective height of 0160 to 0270. In this case, locate
this bracket at half the Dimension A (or at the center of the sensor length).
Refer to Safety Light Curtain F3SG-R Series User's Manual for dimensions of side mounting.
Wiring Operation check
Mounting/Beam Alignment
Check
position
Step1
Mount
Step2

17 F3SG-RE
Quick Installation Manual
■Mounting
Note: Although this chapter uses the figures of the F3SG-RA series safety light curtain, the mounting proce-
dure of the F3SG-RE series is the same as the F3SG-RA series.
1. Loosen the screw.
2. Lightely tighten the screw.
3. Adjust the mounting position and secure the bracket.
4. Secure the bracket to the wall.
Screws to mount the brackets to the wall are not included.
hook
Hexagon socket head
cap screw (M3 x 15) Fixed Bracket
<Backside mounting> <Side mounting>
Optical surface
of F3SG-RE Optical surface of F3SG-RE
Fixed Bracket Fixed Bracket
Slide the hook
in the groove
Slide the hook
in the groove
<Backside mounting> <Side mounting>
Adjust the bracket
to mounting position
Tightening torque:
2.0 N•m (recommended)
Adjust the bracket
to mounting position
<Backside mounting> <Side mounting>
Check
position
Step1
Mount
Step2
Wiring Operation check
Mounting/Beam Alignment

18
F3SG-RE
Quick Installation Manual
10-2. Mounting with Standard Adjustable Brackets (F39-LGA)
■Dimensions (Check position)
P
72
24.85
F
D C2 (Protective height for 14 mm)
F
A150 max
150 max
150 max 150 max
25
15
24.85
9.2
6.4
72
84
35
C1 (Protective height for 30 mm)
A
72
2-M5 or M6
2-M5 or M6
35
48.6
Standard Adjustable
Bracket
Standard Adjustable
Bracket
(F39-LGA)
(F39-LGA)
50.35
F3SG-RE30 Series
Dimension A C1
Dimension C1 4-digit number of the type name
(Protective height)
Dimension D C1-50
Dimension P 20
Protective height
(C1)
Number of Standard
Adjustable Brackets *1 Dimension F
0190 to 1230 2 *2 1000 mm max.
1310 to 2270 3 1000 mm max.
2350 to 2510 4 1000 mm max.
F3SG-RE14 Series
Dimension A C2+30
Dimension C2 4-digit number of the type name
(Protective height)
Dimension D C2-20
Dimension P 10
Protective height
(C2)
Number of Standard
Adjustable Brackets *1 Dimension F
0160 to 1200 2 *2 1000 mm max.
1280 to 2080 3 1000 mm max.
[ Unit : mm ]
< Screw: M5 or M6 >
[Backside mounting]
*1. The number of brackets required to mount either one of emitter and receiver.
*2. Mounting an emitter or receiver with one bracket is possible for the models of protective height of 0160 to 0270. In this case, locate
this bracket at half the Dimension A (or at the center of the sensor length).
Refer to Safety Light Curtain F3SG-R Series User's Manual for dimensions of side mounting.
Wiring Operation check
Mounting/Beam Alignment
Check
position
Step1
Mount
Step2
Align
beams
Step3

19 F3SG-RE
Quick Installation Manual
■Mounting and Beam Alignment
Note: Although this chapter uses the figures of the F3SG-RA series safety light curtain, the mounting proce-
dure of the F3SG-RE series is the same as the F3SG-RA series.
1. Loosen the screws and adjust the angle.
2. Lightely tighten the screw.
3. Adjust the mounting position and secure the bracket.
4. Secure the bracket to the wall.
Screws to mount the brackets to the wall are not included.
hexagon socket head
cap screw (M3 x 15)
hook
hexagon socket head
cap screw (M3 x 15)
<Backside mounting> <Side mounting>
Optical surface
of F3SG-RE Optical surface of F3SG-RE
Adjusta
Bracket
Adjustable
Bracket
Slide the hook
in the groove
Slide the hook
in the groove
Adjust the bracket
to mounting position
Tightening torque:
2.0 N•m (recommended)
Adjust the bracket
to mounting position
<Backside mounting> <Side mounting>
<Backside mounting> <Side mounting>
Wiring Operation check
Mounting/Beam Alignment
Check
position
Step1
Mount
Step2
Align
beams
Step3
