One Forall URC 5065 User manual

Feature Function
CH+
CH—
VOL VOL
M
REC
ENTER TV/VCR
MENU —
PREV CH
FAV CH
MENU
L
MENU
R
PAUSE
SETUP POWER
TVCBL/SAT VCR/LD
AUDIO 2AUDIO 1
MENU
MENU +
SLEEP
AUDIO
PLAY
REW FF
STOP
S
E
L
E
C
T
The Red Light (LED) flashes red to show that
the remote is working.
The SETUP key is used to program your One
For All
®
Easy 5 .
The Glow Keys: VOL +/- (Volume Up/
Down),CH +/- (Channel Up/Down),M
(Mute),POWER,TV/VCR,ENTER and the
Digit Keys (0-9) operate the same as on
your original remote. These keys are
made of a phosphorescent material that
Glows-in-the-dark. To activate the“Glow”
Feature,you must expose the Glow Keys
to bright light. The length of time the
Glow Keys remain illuminated will be
determined by the length of time the
remote is exposed to bright light.
The TV,VCR/LD,CBL/SAT,AUDIO 1, and
AUDIO 2 keys are used to select the home
entertainment component you want to
control.
The SLEEP key allows you to access the
sleep timer of your TV or Cable Box. If your
original TV or Cable Box remote control did
not have a SLEEP function,your
One For All
®
Easy 5 will automatically access its own
built-in sleep timer.
The AUDIO key allows you to turn "ON" the
audio components that are programmed
to the AUDIO 1 and AUDIO 2 keys with one
keystroke. This feature is set up as soon as
you program the AUDIO 1 and AUDIO 2
keys.
The MENU key operates the same as the
MENU or OSD (On Screen Display) key on
your original remote.When you press the
MENU key,your
One For All
®
5 Remote
Control enters the menu mode and
enables
the CH +/- and VOL +/- keys to
navigate through your menu.Pressing one
of the device keys will exit the remote
control’s menu mode and revert CH +/-
and VOL +/- to their original functions.If
your original remote control had a SELECT
key,for use in your menu,try M(Mute) or
ENTER.Please consult the original owners
manual of your home entertainment
component for more detailed instructions
on accessing and navigating your on-
screenmenus.
The FAV CH (Favorite Channel) key allows
you to program your
One For All
®
Easy 5
with up to 10 of your favorite channels.
The PREV CH (Previous Channel) key
operates the same as the LAST CHANNEL
or RECALL key on your original remote.
The REC (Record),PAUSE,REW (Rewind),
PLAY,FF (Fast Forward) and STOP keys
operate the same as the keys on your
original VCR and CD Player remote. As a
safety feature on the
One For All
®
Easy 5 ,
you must press the REC key twice.
SETUP
Features and Functions
The illustration below and chart immediately to
the right describe the features and functions of
the
One For All
®
Easy 5 universal remote control.
Use the drawing to locate each key on the
remote,then refer to the chart for a description of
the corresponding function each key performs.
Overview
The illustration below and the chart immediately
after describe the features and functions of the
One For All
®
Easy 5 universal remote control.Use
the drawing to locate each key on the remote,
then refer to the chart for a description of the
corresponding function each key performs.
MENU
Programming the One For All
®
Easy 5 to operate your TV:
Locate the brand name of your TV and then write it in
the space below.
TV Brand: _____________________________________________
Locate the brand name of your TV in the“SETUP CODES
FOR TVs”section.The brands are listed in alphabetical
order with the most popular codes listed first. You will
use one of these codes to program your
One For All
®
Easy 5 to operate your TV.
To program the One For All Easy 5 to operate your TV:
1Turn on your TV.
2Press TV and release. Press and hold SETUP
until the
One For All
®
Easy 5’s red light blinks
twice,then release SETUP.
3Enter the first three-digit TV code listed for your
brand in the“Looking Up Set-Up Codes forTVs”
section. If you perform this procedure
correctly,the red light will blink twice when you
enter the final digit of your code.
4Aim the
One For All
®
Easy 5 at your TV and
press POWER. Your TV should turn off. If your TV
does not respond,repeat Steps 2-4,trying
each code listed for your brand until you find
the one that operates your TV.
5Your
One For All
®
Easy 5 is now programmed
to operate your TV. Write your TV code in the
boxes to the left for future reference.
Remember,if you want to use your
One For All
®
Easy 5 to
operate your TV,press the TV key first.
POWER
TV SETUP
Setting Up Your Components
FAV CH
PREV CH
STOP
REW
PLAY
FF
Installing the Batteries
Your One For All
®
Easy 5 requires four (4) new AAA alkaline
batteries. To install the batteries:
On the back of the
One For All
®
Easy 5 ,
push down on the tab and lift the battery
cover off.
Match the +and -marks on the batteries to
the + and - marks in the battery case,then
insert the batteries.
Press the battery cover back into place.
Test the unit by pressing POWER. If the
batteries are inserted correctly,the red light
(LED) will blink once.
NOTE: Your One For All
®
Easy 5 includes an unlimited memory
backup,removing the batteries will not require you to
reprogram your remote.
1
2
3
4
TV VCR/LD
CBL/SAT
AUDIO 1 AUDIO 2
POWER
M
S
E
L
E
C
T
VOL
VOL
CH+
CH_
SLEEP
AUDIO
0-9
0
0- 9
AUDIO 1 AUDIO 2
DO NOT USE the MENU- key on your One For All
®
Easy 5 remote control with TVs manufac-
tured by Mitsubishi in 1996 or 1997,or on any TV manufactured in 1996 or 1997 using TV code
150.In 1996,Mitsubishi changed the frequency used to operate the menu down feature on
these TVs.Consequently,using the MENU- key on your
One For All
®
Easy 5 remote control with
these Mitsubishi TVs or with TVs using TV Code 150 will put your TV in a service mode.Universal
Electronics Inc.assumes no responsibility for this change in the manufacturer’s design or for
any damage to your TV or any other damages that you incur as a result of these changes.
Attention Consumers
STOP
Set-Up Codes for
TVs
A-Mark 003
Admiral 093,016, 180, 165,
179
Adventura 046
Aiko 092
Akai 030, 056, 145, 151
Alleron 179
Ambassador 177
Amstrad 171,177
Anam 180
Anam
National 055
AOC 030,019, 185, 137,
003,180,056
Archer 003
Audiovox 180,003
Belcor 019, 030
Bell &
Howell 016, 154, 179, 180
Blue Star 282
BPL 282
Bradford 180
Brockwood 019
Broksonic 236, 463, 003, 180
Candle 030, 056, 186, 046
Carver 054,187
Celebrity 000
Citizen 092,060,030,056,
280,186,046,039
Clairtone 185
Concerto 056
Contec 180, 185
Craig 180
Crown 180,039
Curtis Mathes 047,
060,054,154,030,
039
CXC 180
Daewoo 451,092, 019, 039
Daytron 019,056,092
Dumont 017, 019
Electroband 000,185
Electrohome 150,056,000,154,
185,039
Emerson 463, 236, 180, 177,
179,280,178,282,
154,019,039,185
Envision 030
Finlux 179
Fisher 154, 159
Fujitsu 179
Funai 171,179,180
Futuretech 180
GE 047,451,051,021,
027,282,178,135,
174
Gibralter 019, 030, 017
Goldstar 060, 056, 030, 019,
178
Goodmans 179
Granada 145,151, 178
Grandin 282,180
Grunpy 179,180
Hallmark 178, 179,236,019
Harvard 180,236, 178, 179
HCM 282
Hinari 179
Hisawa 282
Hitachi 151, 145, 056
POWER
STOP
SEE
BELOW
TV/VCR ENTER
REC
PAUSE
User Guide
URC 5065
Easy 5

Hypson 282
Ima 180
Infinity 054
Janeil 046
JBL 054, 046
JCB 000
JVC 053
Kaisui 282
KEC 180,060
Kenwood 030,019
Kloss 046, 024, 030
KTV 180, 030, 280,
185,039
Logik 016, 180, 236
Luxman 056
LXI 047, 054, 154,
178,156
Magnavox 054,096, 030,
186,187,024
Majestic 016, 017
Marantz 054,030,096,
187
Matsui 177, 039
Megatron 178,145,003,
151
MEI 185
Memorex 150,154,056,
016,178
MGA 150, 030, 019,
178
Midland 047,051,017,
135,039
Minutz 021, 027
Mitsubishi 150,019, 178,
093
Motorola 093,055,054,
150,051
MTC 060, 056, 030,
019,185
Multitech 180, 179
NAD 156, 166, 178,
019
NEC 030, 056, 019
Nesco 179
Nikko 092, 030, 178
NTC 092
Onwa 180
Optimus 166,154,150,
165
Optonica 093, 165
Orion 236,463,180,
179
Panasonic 250,051, 055,
054
Penney 047,051,060,
019,018,030,
156,021,027,
178,003,135,
039,250
Philco 054,096,030,
019,187
Philips 054,096,030,
019,187
Pilot 030,019, 039,
060,178,051
Pioneer 166
Portland 092,019,039
Priceclub 060
Prism 051,055
Proscan 047
Proton 466, 178, 003
Pulsar 017, 092, 019
Pulser 019, 017, 092
Quasar 250, 051, 055
RadioShack 180,165, 039,
056,047,030
RCA 047,018, 135,
090,019,
174,093
Realistic 154, 165, 056,
030,019,178,
180,039
Rhapsody 185
Runco 060,494, 030,
017
Saisho 177
Sampo 030, 039
Samsung 060,427,056,
030,019,178
Samsux 039
Sanyo 154,159, 146
Scimitsu 019
Scotch 178
Scott 236,019, 178,
180,179
Sears 047,054,154,
171,056,156,
178,179,146,
451
SEI 177
Sharp 093,491,165,
039
Shogun 019
Signature
2000 016, 047, 054,
019
Simpson 186, 187,030
Sinudyne 177
Sony 000,080
Soundesign 178,180, 179,
186
Spectricon 003,137,180,
030,019,056
Squareview 171
SSS 019, 180, 236
Starlite 180,236,019
Supra 039
Supre-Macy 046,039, 186
Supreme 000
Sylvania 054,096,030,
187,186
Symphonic 171,179,180
Tandy 093,165,039,
054,047
Tatung 055,003, 051
Technics 250, 051, 055
Technol Ace 179
Techwood 051, 056,003,
055,250
Teknika 092,054,060,
056,019,016,
180,179,186,
039
Tera 178
TMK 156, 177, 178,
236
Tomashi 282
Toshiba 156,154, 060
Tosonic 185
Totevision 039
Triumph 177
Universal 027,021,047
Vector
Research 030
Victor 053
Vidikron 054
Vidtech 019, 178
Viking 046
Wards 054,016, 096,
030,174,
056,165,019,
021,027,
020,178,179,
080
Yamaha 030,019
Zenith 017, 092, 016
Zonda 003
3Enter the first three-digit VCR or Laser Disc
code listed for your brand in the“Looking Up
Set-Up Codes for LD Players”section. If you
perform this procedure correctly,the red light
will blink twice when you enter the final digit of
your code.
4Aim the
One For All
®
Easy 5 at yourVCR or
Laser Disc Player and press POWER. Your
component should turn off. If your original VCR
or Laser Disc Player remote control did not
have a POWER key,press PLAY. Your
component should start to play. If your VCR or
Laser Disc Player does not respond,repeat
Steps 2-4,trying each code listed for your
brand until you find the one that operates your
VCR or Laser Disc Player.
5Your
One For All
®
Easy 5 is now programmed to
operate yourVCR or Laser Disc Player. Write
your code in the boxes to the left for future
reference.
Remember,if you want to use your
One For All
®
Easy 5 to
operate your VCR or Laser Disc Player,press the VCR/LD key
first.
Programming the
One For All
®
Easy 5 to operate yourVCR
or Laser Disc Player:
Locate the brand name of your VCR/Laser Disc Player
and then write it in the space below.
VCR/LD Brand: _______________________________________
Locate the brand name of yourVCR or Laser Disc Player
in the“SETUP CODES FOR VCRs”or“SETUP CODES FOR LD
PLAYERS”section.The brands are listed in alphabetical
order with the most popular codes listed first. You will use
one of these codes to program your One For All Easy 5 to
operate your VCR or Laser Disc Player.
To program the One For All Easy 5 to operate your VCR or
Laser Disc Player:
1Turn on your VCR and insert a tape. If you are
setting up a Laser Disc Player, turn on the Laser
Disc Player and insert a disc.
2Press VCR/LD and release. Press and hold
SETUP until the
One For All
®
Easy 5’s red light
blinkstwice,then release SETUP.
Set-Up Codes for
VCRs
Admiral 048
Action 317
Adventura 000
Aiko 278
Aiwa 000, 307, 406,
468
Akai 041, 061, 315
Akiba 072
Alba 020, 278
American
High 035,081
Amstrad 000, 325
Anitech 072
ASA 037, 081
Asha 240
Asuka 037
Audiovox 037,038
Baird 000, 041, 104
Basic Line 072,020,278
Beaumark 240
Bell &
Howell 104, 048, 046
Blaupunkt 162,034
Brandt Elec-
tronique 041
Broksonic 184, 121, 211,
295,361
Bush 072, 278
Calix 037
Candle 037, 038
Canon 035
Capehart 020
Carver 081
CCE 278, 072
CGE 000
Cimline 072
Citizen 037,278,240,
035,000
Clatronics 020
Colt 072
Condor 020
Craig 240,072, 037,
047,271
Crown 072,020,278
Curtis
Mathes 035, 060, 202,
041
Cybernex 240
Daewoo 278, 020, 045,
046
Dansai 072
Daytron 020, 278
De Graaf 042
Decca 081,000
Dual 041
Dumont 038, 240, 045
Dynatech 000
Electro-
home 037,240, 043
Electro-
phonic 037
Emerex 032
Emerson 278,184, 479,
000,002,121,
211,037,043,
061,208,295,
361
Ferguson 041
Fidelity 000
Finlandia 081,110,104
Finlux 000,042,104,
081
Firstline 072,043,045,
037
Fisher 104,046,047,
066,054
Frontech 020
Fuji 033,035, 032,
034
Funai 000,278,072,
325,240
GAB 072
Garrard 000,325
GE 060,202,035,
GEC 081
Go Video 232, 350,240
Goldstar 037,038, 278
Goodmans 278,000, 020,
072,037,062
Gradiente 000
Granada 048,035
Grandin 072,000,037
Grundig 081
Harley
Davidson 000
Harman/
Kardon 038
Harvard 072
Harwood 072
Head-
quarter 046
HI-Q 047
Hinari 072,240
Hitachi 042, 000, 041
Imperial 000
Interfunk 081
ITT 041, 104, 046,
240
Jensen 041, 067
JVC 067, 008, 041
Kaisui 072
KEC 037,278
Kenwood 067, 008, 041,
038
KLH 072
Kodak 035,037
Lloyd’s 000,208, 072,
038
Logik 072
Luxor 043,104, 046,
062
LXI 037,000
Magnavox 035,081, 039,
110,149
Magnin 240
Marantz 035, 081, 110
Marta 037
Matsushita 035,081
Matsui 208, 295
MEI 035
Memorex 000,035,048,
104,037,039,
240,047,046,
307
Metz 162,454
MGA 043,061
MGN
Technology 240
Minolta 042
Mitsubishi 043,061, 067,
008,173,
093
Motorola 035, 048
MTC 000, 240
Multitech 000, 072
NEC 038, 041, 067,
008,104
Nikko 037
Noblex 240
Nokia 104,240, 046,
041
Olympus 035
Optimus 048,037, 104
Optonica 062
Orion 184,278,479,
121,211,295,
208
Panasonic 162,035,077,
225,454
Penney 035,037,240,
042,038,162,
454
Pentax 042
Philco 035, 081
Philips 081,035,062,110
Pilot 037
Pioneer 067
Portland 020
Proline 000
Protec 072
Pulsar 039, 240, 278
Quarter 046
Quartz 046
Quasar 162, 035, 077
RadioShack 000,035, 037,
048
Radix 037
Randex 037
RCA 060,202, 042,
149,077,048
Realistic 000, 035, 048,
240,104,037,
046,047,066,
062
Ricoh 034,035
Runco 039
Samsung 240,045
Sanky 048,039
Sansui 041,067,072,
271
Sanyo 104,046,047,
240
Scott 184,043, 045,
211,121
Sears 104,035,037,
042,046,
047,066,054,
451
SEI 081
Sharp 048, 062
Shintom 072, 000, 240
Shogun 240
Singer 072,037,240
Sony 032,033,034,
035
STS 042
Sylvania 081,035,043,
110
Symphonic 000,325
Tatung 041,067, 000
TEAC 000,041
Technics 162,035
Teknika 035,000,037
TMK 240, 208
Toshiba 043,045,066
Totevision 240, 037
Triumph 208
Unitech 240
Vector 045
Vector
Research 038
Video
Concepts 045,061
Videosonic 240, 000, 072
Videotronic 035
Wards 048, 000,035,
047,060,
202,062,072,
240,149
XR-1000 072,000,035,
240
Yamaha 038
Zenith 039, 033, 034
Set-Up Codes for
TV/VCR Combos
American
High 035*
Brocksonic 002, 294, 479
Colt 072
Curtis
Mathes 035*
Daewoo 278
Emerson 002, 294, 479
Funai 000
GE 035*, 060*, 048*,
240
Hitach 035*, 000
HQ 000
Lloyds 000
MGA 240
Magnavox 000, 035*, 081*
Magnin 240
Memorex 037, 162*
Mitsubishi 048*
Orion 002, 294, 479
Panasonic 035*, 162*
Penney’s 035*, 240, 162*
Quasar 035*, 162*
RCA 060*, 035*, 048*
Sansui 000, 479
Sanyo 240
Sears 000, 037
Symphonic 000
Zenith 000
NOTE: If your TV/VCR is
working on one of the above codes highlighted with an
asterisk (*),you may need to program a separate TV
code in order to control the
volume. Check the list of codes below and follow the
instructions detailed in the“Programming the One For All
Easy 5 to Operate Your TV”section to program the
supplied TV code.
TV/VCRs working on VCR code 035 may require TV code
051 for volume control.
TV/VCRs working on VCR code 048 may require TV code
093 for volume control.
TV/VCRs working on VCR code 060 may require TV code
047 for volume control.
TV/VCRs working on VCR code 081 may require TV code
054 for volume control.
TV/VCRs working on VCR code 162 may require TV code
250 for volume control.
Set-Up Codes for
Laser Discs
Carver 194
Disco Vision 023
Hitachi 023
Magnavox 194
Marantz 194
Mitsubishi 059
NAD 059
Panasonic 204
Philips 194
Pioneer 059, 023
Quasar 204
Sega 023
Sony 201
Theta Digital 194
VCR/LD SETUP
POWER
PLAY

To program the One For All Easy 5 to operate your
Receiver/Amplifier/Tuner:
1Turn on your Receiver/Amplifier/Tuner.
2Press AUDIO 2 and release. Press and hold
SETUP until the
One For All
®
Easy 5’s red light
blinkstwice,then releaseSETUP.
3Enter the first three-digit Receiver/Amplifier/
Tuner code listed for your brand in the “Set-Up
Codes for Receivers/Tuners”or“Set-Up Codes
for Amplifiers”section. If you perform this
procedure correctly,the red light will blink
twice when you enter the final digit of your
code.
4Aim the
One For All
®
Easy 5 at your Receiver/
Amplifier/Tuner and press POWER. Your
Receiver/Amplifier/Tuner should turn off. If your
Receiver/Amplifier/Tuner does not respond,
repeat Steps 2-4,trying each code listed for
your brand until you find the one that operates
your Receiver/Amplifier/Tuner.
5Your
One For All
®
Easy 5 is now programmed to
operate your Receiver/Amplifier/Tuner. Write
your Receiver/Amplifier/Tuner code in the
boxes to the left for future reference.
Remember,if you want to use your
One For All
®
Easy 5 to
operate your Receiver/Amplifier/Tuner,press the AUDIO 2
key first.
Programming the
One For All
®
Easy 5 to operate your
Cable Converter or Satellite:
Locate the brand name of your Cable Converter or
Satellite and then write it in the space below.
Cable or Satellite Brand: ______________________________
Locate the brand name of your Cable Converter or
Satellite in the“SETUP CODES FOR CABLE CONVERTERS”or
“SETUP CODES FOR SATELLITES”section.The brands are
listed in alphabetical order with the most popular codes
listed first. You will use one of these codes to program
your One For All Easy 5 to operate your Cable
Converter or Satellite.
To program the One For All Easy 5 to operate your Cable
Converter or Satellite:
1Turn on your Cable Converter or Satellite.
2Press CBL/SAT and release. Press and hold
SETUP until the
One For All
®
Easy 5’s red light
blinkstwice,then release SETUP.
3Enter the first three-digit Cable Converter or
Satellite listed for your brand in the“Set-Up
Codes for Cable Converters”or“Set-Up Codes
for Satellites”section. If you perform this
procedure correctly,the red light will blink
twice when you enter the final digit of your
code.
4Aim the
One For All
®
Easy 5 at your Cable
Converter or Satellite and press POWER. Your
Cable Converter or Satellite should turn off. If
your Cable Converter or Satellite does not
respond,repeat Steps 2-4,trying each code
listed for your brand until you find the one that
operates your Cable Converter or Satellite.
5Your
One For All
®
Easy 5 is now programmed to
operate your Cable Converter or Satellite.
Write your Cable Converter or Satellite code in
the boxes to the left for future reference.
NOTE: If your original Cable Converter remote control did
not have an“ON”key,press CH+ on the
One For All
®
Easy 5
to turn your Cable Converter ON.
Remember,if you want to use your
One For All
®
Easy 5
to operate your Cable Converter or Satellite,press the
CBL/SAT key first.
Set-Up Codes for
Cable Converters
ABC 003, 014, 007, 008,
011, 017,
001,013
Antronix 022
Archer 153, 022
Belcor 056
Cable Star 056
Cabletenna 022
Cableview 022
Century 153,618
Citizen 153,315
Colour
Voice 025
Contec 019
Dae Ryung 008
Eagle Com-
tronics 040,008
Eastern 002
Everquest 015
Funai 153
Garrard 153
GC
Electronics 056
Gemini 015
General
Instrument 476,011, 003, 014
Goldstar 144,040, 533
Hamlin 259, 020, 009, 034
Hitachi 001
Hytex 007
Jasco 153,315
Jerrold 003,014, 476, 012,
011,015
Memorex 525
Movie Time 063, 015
Novaplex 618
Novavision 008,017,477
NSC 063, 156
Oak 019, 007
Omega 015
Panasonic 107,021,525
Paragon 525
Philips 153,025
Pioneer 533, 144
Popular
Mechanics 400
Pulsar 525,040
RCA 021
Regal 259,020
Regency 002,020
Rembrandt 011,153
Runco 525
Samsung 144, 040, 533
Scientific
Atlanta 008,477, 017
Sigma 019
Signal 015,040
Signature 011
SL Marx 040
Sprucer 021
Starcom 003, 015
Stargate 015, 040
Starquest 015
Sylvania 001
Tandy 258
Teleview 040,063
Texscan 001
Tocom 012, 013
Toshiba 525
Tusa 015
TV 86 063,040
Unika 153, 022
United
Artists 007
United
Cable 003
Universal 153, 056, 022
Videoway 250,525
Viewstar 063, 258
Walmart 400
Zenith 525
Zentek 400
Set-Up Codes for
Satellites
Channel
Master 018
Chaparral 053
Citoh 164
Drake 018,064
Echostar 280,269
General
Instrument 627,050, 038, 361
Home
Cable 238
IQ Prism 210
Janeil 152
Jerrold 627
Macom 050,018
Memorex 269
Panasonic 152
Primestar 627
RCA DSS 566
Realistic 052
Sony DBS 639
Star Trak 180,547
STS 210
Toshiba 082
Uniden 052, 074, 076, 238
US
Electronics 547
Zenith 064
Programming the One For All
®
Easy 5 to operate your CD
Player:
Locate the brand name of your CD Player and then write
it in the space below.
CD Player Brand: ______________________________________
Locate the brand name of your CD Player in the “SETUP
CODES FOR CD PLAYERS”section.The brands are listed in
alphabetical order with the most popular codes listed
first. You will use one of these codes to program your One
For All Easy 5 to operate your CD Player.
To program the One For All Easy 5 to operate your CD
Player:
1Turn on your CD Player and insert a compact
disc.
2Press AUDIO 1 and release. Press and hold
SETUP until the
One For All
®
Easy 5’s red light
blinkstwice,thenreleaseSETUP.
3Enter the first three-digit CD Player code listed
for your brand in the“Set-Up Codes for CD
Players”section. If you perform this procedure
correctly,the red light will blink twice when you
enter the final digit of your code.
4Aim the
One For All
®
Easy 5 at your CD Player
and press PLAY. Your CD Player should play
your disc. If your CD Player does not respond,
repeat Steps 2-4,trying each code listed for
your brand until you find the one that operates
your CD Player.
5Your
One For All
®
Easy 5 is now programmed to
operate your CD Player. Write your CD Player
code in the boxes to the left for future
reference.
Remember,if you want to use your One For All
®
Easy 5 to
operate your CD Player,press the AUDIO 1 key first.
Set-Up Codes for
CD Players
Aiwa 124,157
California
Audio Lab 029
Carver 157,179
Denon 003
DKK 000
Emerson 305
Fisher 048, 179, 088
Garrard 393
Genexxa 032,305
Goodmans 305
Grundig 157
Hitachi 032
JVC 072
Kenwood 028, 037, 048,
190
Krell 157
LXI 305
Magnavox 157
Marantz 157, 029
Matsui 157
MCS 029
Memorex 032, 305
Mission 157
NAD 000
NSM 157
Onkyo 101
Optimus 032,000, 468,
179,037,
305
Panasonic 029
Philips 157
Pioneer 032, 468
Proton 157
QED 157
Quasar 029
RCA 053
Realistic 179
Rotel 157
SAE 157
Sansui 157,305
Sanyo 179
Scott 305
Sears 305
Sharp 037
Sony 000, 185, 397,
490,604,
605
Soundesign 145
TEAC 393
Technics 029,303
Victor 072
Yamaha 036,187
To program your One For All
®
Easy 5 to operate your
Receiver/Amplifier/Tuner:
Locate the brand name of your Receiver/Amplifier/Tuner
and then write it in the space
below.
Receiver/Amplifier/Tuner Brand: _______________________
Locate the brand name of your Receiver/Amplifier/Tuner
in the“SETUP CODES FOR RECEIVERS/AMPLIFIERS/TUNERS”
section.The brands are listed in alphabetical order with
the most popular codes listed first. You will use one of
these codes to program your One For All Easy 5 to
operate your Receiver/Amplifier/Tuner.
Set-Up Codes for
Receivers/Tuners
Aiwa 121,158, 189
Carver 189, 008
Casio 195
Clarinette 195
Denon 004
Fisher 042
Garrard 463
Grundig 189
JVC 074
Kenwood 027,077, 186
Lloyd’s 195
Magnavox 189,195
Marantz 189,039
Matsui 195
MCS 039
Memorex 014
Modulaire 195
NAD 320
Onkyo 135
Optimus 014,080, 186
Panasonic 039,309
Penney 195
Philips 189
Pioneer 014, 080
Quasar 039
Realistic 195
Sansui 189
Sharp 186
Sherwood 502
Sony 158
TEAC 463
Technics 039,309
Victor 074
Wards 014, 189,158,
042,080
Yamaha 176, 186, 082
Yorx 195
Set-Up Codes for
Amplifiers
Carver 269
Denon 160
Genexxa 395
Grundig 269
Luxman 165
Magnavox 269
Marantz 269, 321
Nakamichi 321
Optimus 300, 013, 395
Panasonic 308
Philips 269
Pioneer 300, 013
Realistic 395
Sansui 321
Soundesign 211
Technics 308
Wards 013,211
Yamaha 133,354
There may be additional home entertainment or home
automation components that you want to control with
your
One For All
®
Easy 5 which do not have their own
designated device keys. The following components can
be set up under these device keys.
Home Entertainment Key to Program
Component
Miscellaneous Audio AUDIO 1
Audio Cassette Decks VCR/LD
Video Accessories CBL/SAT
To set up your additional components,simply follow the
programming instructions for Steps 2 and 3 in the“Setting
UpYour Components”section for the device key you are
programming.
Setting Up Additional Components
CBL/SAT
SETUP
POWER
AUDIO 1
SETUP
AUDIO 2
SETUP
PLAY
POWER
Set-Up Codes for
Miscellaneous
Audio
Aiwa 159,010
Fisher 052
Jerrold 520, 459
JVC 073
Scientific
Atlanta 460
Sony 159,010
Starcom 459
Set-Up Codes for
Audio Cassette
Decks
Aiwa 197
Carver 029
Denon 076
Garrard 308,309
JVC 273, 274
Kenwood 070,071
Magnavox 029
Marantz 029
Onkyo 136
Optimus 027,220
Philips 029
Pioneer 027, 220
Sansui 029
Sony 170, 243, 291
TEAC 308,309
Technics 229
Victor 273, 274
Wards 027
Yamaha 094,097
Set-Up Codes
forVideo
Accessories
Rabbit 081
TeleCaption 171

One For All®is a trademark of Universal Electronics Inc.
Copyright 1996 by Universal Electronics Inc. No part of this
publication may be reproduced,transmitted,transcribed,stored
in any retrieval system, or translated to any language,in any
form or by any means,electronic,mechanical,magnetic,
optical,manual,or otherwise,without the prior written permission
of Universal Electronics Inc.
URC-5065 - One For All®Easy 5W/Glow Keys
M4039 McK 2/98
Troubleshooting
Problem Solution
Red light not blinking
when you press a key?
The red light blinks
when you press a key
but you receive no
response from your
home entertainment
component ?
The
One For All
®
Easy
5
does not operate
your home
entertainment
component or is not
performing commands
properly.
Problems program-
ming a TV/VCR
combo?
VCR not recording?
No volume on a 2nd
TV?
Problems program-
ming the AUDIO 2 key?
Channel +/- and
RECALL not working for
your RCA TV?
Problems changing
channels?
Keypad scrambled?
Replace the batteries with four (4)
new AAA alkaline batteries.
Make sure you are aiming your
One For All
®
Easy 5 at your home
entertainment component and
that you are within 15 feet of the
component you are trying to
operate before using your remote.
Try all the codes listed for your
home entertainment component
in the "Set-Up Codes" section.
Many set-up codes may allow for
partial functionality,however,only
one set-up code will operate your
home entertainment component
properly. Make sure that all of the
components you are setting up
can be operated with an infrared
remote control.
Use the VCR set-up codes for your
brand. Some combo units may
require both a TV code to control
volume and aVCR code for full
operation.
As a safety feature on the
One For
All
®
Easy 5 ,you must press the REC
key twice.
Press and hold SETUP until the One
For All
®
Easy 5's red light blinks
twice. Release SETUP and enter 9-
9-3 followed by VOL +.
If the
One For All
®
Easy 5's red light
does not blink twice after entering
your Receiver/Amplifier/Tuner
code,press and hold SETUP until
the One For All
®
Easy 5's red light
blinks twice. Release SETUP and
press 9-9-2 followed by AUDIO 2
and then AUDIO 2 again.AUDIO 2
is now ready to accept Receiver/
Amplifier/Tuner codes.
Due to RCA design (1983-1987),
only the original remote control
will operate these functions.
However,using the FAV CH key will
allow you to run through a list of
up to 10 of your favorite channels.
If your original remote control
required a ENTER keystroke when
changing channels,press the
ENTER key on the
One For All
®
Easy
5
after you enter the channel
number.
Press and hold SETUP until the
One
For All
®
Easy 5's r ed light blinks
twice. Release SETUP and enter
9-6-9.
Your
One For All
®
Easy 5 is equipped with a favorite
channel key (FAV CH). You can set up the FAV CH key with
a list of up to 10 of your favorite channels for either your TV,
VCR,Cable Box,Satellite or DSS. Please note,the FAV CH
key can only be set up for one device key (TV,VCR/LD or
CBL/SAT) at a time. You cannot set up a favorite channel
list for another device key until you have cleared the FAV
CH key of your original list.
1Press the device key (TV,VCR/LD,or CBL/SAT) for the
home entertainment component that will contain your
favorite channel list.
2Press and hold SETUP until
One For All
®
Easy 5’s red light
blinks twice. Release SETUP and press 9-9-6.
3Enter the channel number of the first channel you
would like to add to your favorite channel list. Then
pressSETUP.
• If you are entering a single digit channel number, you
must press 0first.
• If you are entering a channel that is three digits long,
such as 103,you do not have topress SETUP after you
have entered the channel number.
• If your original remote control required you to use an
ENTER key to change channels,press ENTER instead of
SETUP after entering your channel number. For
example,if you want to addTV channel“4”to your
favorite channel list,you would: Press TV,then press and
hold SETUP until the
One For All
®
Easy 5’s red light
blinks twice,then release SETUP and press 9-9-6. Press
0-4, followed by ENTER. Then,add your second
Using the Favorite Channel Key
Using the Sleep Key
You can use the One For All
®
Easy 5 to operate a second
TV or a second VCR or any combination of five home
entertainment components. For example,you may want
your One For All
®
Easy 5 to control 1 TV,1 VCR and 3 audio
components; such as a CD Player,a Tuner and an Amplifier.
To accomplish this, you must reassign the CBL/SAT key to
operate the desired component,in this case,a third audio
component. The chart below shows you how to reassign a
particular device key and then set up your new
component.
TV to VCR/LD SETUP* + 992 + VCR/LD + TV + TV +
SETUP* + VCR or Laser Disc code.
TV to CBL/SAT SETUP* + 992 + CBL/SAT + TV + TV +
SETUP* + Cable or Satellite code.
TV to AUDIO 1 SETUP* + 992 + AUDIO 1 + TV + TV +
SETUP* + CD Player code.
TV to AUDIO 2 SETUP* + 992 + AUDIO 2 + TV + TV +
SETUP* + Receiver/Amplifier/Tuner
code.
VCR/LD to TV SETUP* + 992 + TV + VCR/LD + VCR/LD
+SETUP* + TV code.
VCR/LD to CBL/SAT SETUP* + 992 + CBL/SAT + VCR/LD +
VCR/LD + SETUP* + Cable or Satellite
code.
VCR/LD to AUDIO 1 SETUP* + 992 + AUDIO 1 + VCR/LD +
VCR/LD + SETUP* + CD Player code.
VCR/LD to AUDIO 2 SETUP* + 992 + AUDIO 2 + VCR/LD +
VCR/LD + SETUP* + Receiver/
Amplifier/Tuner code.
CBL/SAT to TV SETUP* + 992 + TV + CBL/SAT + CBL/
SAT + SETUP* + TV code.
CBL/SAT to VCR/LD SETUP* + 992 + VCR/LD + CBL/SAT +
CBL/SAT + SETUP* +VCR or Laser Disc
code.
CBL/SAT to AUDIO 1 SETUP* + 992 + AUDIO 1 + CBL/SAT +
CBL/SAT + SETUP* + CD Player code.
CBL/SAT to AUDIO 2 SETUP* + 992 + AUDIO 2 + CBL/SAT +
CBL/SAT + SETUP* + Receiver/
Amplifier/Tuner code.
AUDIO 1 to TV SETUP* + 992 + TV + AUDIO 1 + AUDIO
1+ SETUP* + TV code.
AUDIO 1 to VCR/LD SETUP* + 992 + VCR/LD + AUDIO 1 +
AUDIO 1 + SETUP* +VCR or Laser
Disc code.
AUDIO 1 to CBL/SAT SETUP* + 992 + CBL/SAT + AUDIO 1 +
AUDIO 1 + SETUP* + Cable or
Satellite code.
AUDIO 1 to AUDIO 2 SETUP* + 992 + AUDIO 2 + AUDIO 1 +
AUDIO 1 + SETUP* + Receiver/
Amplifier/Tuner code.
AUDIO 2 to TV SETUP* + 992 + TV + AUDIO 2 + AUDIO
2+ SETUP* + TV code.
AUDIO 2 to VCR/LD SETUP* + 992 + VCR/LD + AUDIO 2 +
AUDIO 2 + SETUP* +VCR or Laser
Disc code.
AUDIO 2 to CBL/SAT SETUP* + 992 + CBL/SAT + AUDIO 2 +
AUDIO 2 + SETUP* + Cable or
Satellite code.
AUDIO 2 to AUDIO 1 SETUP* + 992 + AUDIO 1 + AUDIO 2 +
AUDIO 2 + SETUP* + CD Player code.
*NOTE: Here you must hold SETUP until the
One For All
®
Easy
5
’s red light blinks twice.
Reassigning Device Keys channel,followed by ENTER,and continue adding your
favorite channels until you have added the 10
channels you desire in your favorite channel list.
4Continue adding your favorite channels, up to 10
channels. Once you have finished,press and hold SETUP
until the
One For All
®
Easy 5’s red light blinks twice.
5To scan through your favorite channel list,press FAV CH.
Your One For All
®
Easy 5 will automatically scan through
your favorite channel list,stopping at each channel for
three seconds.
6To stop at one of your favorite channels,press any key
on the
One For All
®
Easy 5 .
To clear an entire favorite channel list from the FAV CH key:
1Press and hold SETUP until the One For All
®
Easy 5’s red
lightblinks twice,then release SETUP.
2Press 9-9-6,then press and hold SETUP until the One For
All
®
Easy 5’s red light blinks twice.
The SLEEP key allows you to access the sleep timer of your
TV or Cable Box. Even if your original TV or Cable Box
remote control did not have a sleep timer,your
One For All
®
Easy 5 has its own built-in sleep timer. If your TV or Cable
Box has a sleep timer,press the SLEEP key to activate the
sleep timer. To activate the
One For All
®
Easy 5’s built-in
sleep timer:
1Press the desired device key (TV or CBL),then press the
SLEEP key once to set the built-in sleep timer for 15
minutes.
2Each additional press of the SLEEP key will add 15 more
minutes to the sleep timer,up to a maximum of 60
minutes.
NOTE: Once you have activated the
One For All
®
Easy 5’s
built-in sleep timer,you must keep the remote pointed
directly at the component.
3. To deactivate the built-in sleep timer,press any key
otherthanSLEEP.
This product is discontinued and is no longer
supported
