ROLLATOR USER MANUAL

Dear Customer
Thank you for your purchase of our Treka rollator.
Please find the following instrutions for use and product specifications.
We wish you all the best with your new rollator.
Product Specifications
The Treka rollator has been designed to assist the user to walk, rest and carry small items
of shopping for both indoor and outdoor use on flat surfaces by a single individual with
limited mobility with a maximum weight as shown below.
It is important that the user reads and understands the safety advice given within this
manual before attempting to operate the product to avoid possible injury to the user or
bystanders and avoid damage to the wheeled walker or surrounding property.
SUMMARY
The Treka rollator has been manufactured from high quality materials including the
aluminum frame, padded seat and locking brakes. The handles are adjustable in height
and the wheeled walker folds easily for transport or storage.
The Treka rollator has been designed to assist the user to walk, rest and carry small items
of shopping for both indoor and outdoor use on flat surfaces by a single individual with
limited mobility with a maximum weight as shown below.
The Treka rollator has been tested according to BS ENISO 11199-2:2005

Treka Specifications
Treka 480
Treka 540
Treka 610
User Weight
21.5 st. (136 kg)
21.5 st. (136 kg)
21.5 st. (136 kg)
Total Weight
6.1 kg
6.2 kg
6.3 kg
Seat Width
480 mm (18.9 in.)
480 mm (18.9 in.)
480 mm (18.9 in.)
Seat Depth
200 mm (8 in.)
200 mm (8 in.)
200 mm (8 in.)
Seat Height
480 mm (18.9 in.)
540 mm (21 in.)
610 mm (24 in.)
Handle Height
765 –855 mm
795 –885 mm
875 –995 mm
Overall Width
650 mm (25.5 in.)
650 mm (25.5 in.)
650 mm (25.5 in.)
Folded Width
290 mm (11.5 in.)
290 mm (11.5 in.)
290 mm (11.5 in.)
Wheel
200 mm (8 in.)
200 mm (8 in.)
200 mm (8 in.)
Parts Description
1.
Hand Grip
2.
Back Rest
3.
Brake Lever
4.
Pull Strap For Folding
5.
Seat
6.
Handle Height Adjuster Lever
7.
Retaining Clip
8.
Rollator Bag
9.
Rear Wheel
10.
Front Wheel

Assembly & User Instructions
WARNING!
Ensure that all bolts are securely fastened before using this rollator!
Brakes must be in the parked /locked position before sitting on the rollator!
1. Remove all packaging and set-out parts.
2. Un-folding the rollator:
To open the rollator, un-hook the RED retaining clip as shown by lifting upwards.
Push down on either side of the cross bars as shown below.
WARNING!
Be carefull not to trap fingers when pushing down seat.
To open rollator push down seat on
either side of cross bars.

3. Folding the rollator:
To fold the rollator first unlock the RED retaining clip by lifting it upwards as shown
below. Then lift the strap in the centre of the seat and continue to lift upwards to
fold as shown. Once folded the RED retainging clip can be re-locked to hold the
rollator in the folded postion for storage etc.
4. Installing the handles:
Holding the ‘RED’ release lever in the open position as shown below, insert the
handles making sure the rectangular slots are facing inwards. Adjust the handles
to the required height. Re-adjust the handle height if necessary by
releasing the red lever and either lifting or pushing down the handle.
Set to the desired height and close the ‘RED’release lever. The release lever
should click when locked into the closed position.
WARNING!
Never use the rollator without making sure the RED release lever is fully locked
in the closed postion.
Clip in locked
position.
Lift clip upwards
to unlock.
Lift strap upwards
to fold.

5. Installing the backrest:
Slide the back strap into the backrest connector making sure the padded side of
the back strap is facing to the inside of the rollator.
Secure the back strap into position by tightening the screw and nut.
6. Installing the shopping bag:
Slide the hooks located either side of the bag onto the brackets positioned under
the seat at the front.
Loop the Velcro strap around the frame and insert through the tab.
WARNING!
Never overload the shopping bag’s 5kg Max Load.

7. Braking:
For braking while moving, pull both brake levers upwards as shown and always
brake slowly and steadily. Lifting the brake also releases the brake from locked
position.
8. Locking the Brakes (Parking Position):
Press both brake levers down to apply and lock the brakes while the rollator is
stationary.
WARNING! Regulary Test The Brakes

9. Sitting on Rollator:
Before sitting lock the brakes into the parking position and make sure the rollator is
on an even and firm surface and will not slide or topple over. Sit straight up and
never lean backwards.
Do not support your weight on the handle attempting to sit. Use the handles to
stabilize your body as you carefully turn around. Keeps your hand on the handles
and slowly lower your weight onto the seat.
WARNING! NEVER MOVE ROLLATOR WHILE SEATED
WARNING! ALWAYS APPLY PARKING BRAKES BEFORE SITTING
Maintenance and other
1. Do not use strong corrosive cleaners to clean or polish surface. This could damage
rollator.
2. Store in dry location.
3. Be careful when folding and unfolding rollator to avoid injury by mechanism.
4. Always apply brakes when in stationary position or when seated on rollator.
5. Do not hang bags or other items from handles –this will add stress to the rollator and
could also make it un-stable.
Manufacture: One Rehab Ltd
