One Rehab Zoom Plus User manual

ROLLATOR USER MANUAL

Thank you for your purchase of our Zoom Plus rollator.
Please find the following instrutions for use and product specifications.
We wish you all the best with your new rollator.
Dear Customer
Safety Guidelines 1
Product Specifications 2
Summary 3
Assembly and User Instructions 4
Maintenance and Other 10
Contents
Safety Guidelines
WARNING! Indicates a hazardous situation that could result in
serious injury or death if it is not avoided.
The symbols below are used throughout this owner’s manual to identify
warnings and important information. It is very important for you to read
them and understand them completeley.
CAUTION! Indicates a hazardous situation that could result in
minor or slight injury if it is not avoided.
1
IMPORTANT! Indicates a hazardous situation that could result
in damage to property or rollator if not avoided.

The Zoom Plus rollator has been designed to assist the user to walk, rest
and carry small items of shopping for both indoor and outdoor use on
flat surfaces by a single individual with limited mobility with a maximum
weight as in the below table.
It is important that the user reads and understands the safety advice
given within this manual before attempting to operate the product to
avoid possible injury to the user or bystanders and avoid damage to the
wheeled walker or surrounding property.
Product Specifications
Model Reference Zoom Plus - Small Zoom Plus - Medium Zoom Plus - Large
User Weight
(Max)
21 st. (136 kg) 21 st. (136 kg) 21 st. (136 kg)
Total Weight 5.55 kg 5.65 kg 5.75 kg
Handle Height 780-880 mm 810-910 mm 810-910 mm
Seat Width 470 mm 470 mm 520 mm
Seat Height 510 mm 560 mm 560 mm
Chassis Type Lightweight
Aluminium
Lightweight
Aluminium
Lightweight
Aluminium
Overall Width
Folded
250 mm 250 mm 250 mm
Overall Width
Open
625 mm 625 mm 675 mm
Overall Length 730 mm 730 mm 730 mm
Wheel EVA Soft Roll EVA Soft Roll EVA Soft Roll
Wheel Size 200 mm 200 mm 200 mm
Stick Holder Yes Yes Yes
Storage Bag Yes Yes Yes
Padded Backrest Yes Yes Yes
Locking Band Yes Yes Yes
2

Summary
The Zoom Plus Rollator has been manufactured from high quality materi-
als, aluminum frame, PP, nylon seat, Polyester bag and locking brake. The
handles are adjustable in height and the wheeled walker folds easily for
transport or storage.
The Zoom Plus Rollator has been designed to assist the user to walk, rest
and carry small items of shopping for both indoor and outdoor use on
flat surfaces by a single individual with limited mobility with a maximum
weight as shown opposite.
The Zoom Plus Rollator has been tested according to BS ENISO 11199-2:2005
1 Hand Grip 6 Handle Tightening Knob
2 Back Rest 7 Rollator Bag
3 Brake Lever 8 Rear Wheel
4 Pull Strap for Folding 9 Stick Holder
5 Seat 10 Front Wheels
2
4
7
10
9
1
6
5
3
8
3

Assembly and User Instructions
WARNING!
Ensure that all bolts are securely fastened before using this
rollator!
Brakes must be in the parked /locked position before
sitting on the rollator!
1. Remove all packaging and set out parts
5
1
3
4
2
98 7 6
4
1 Front Wheels 6 Handles
2Frame 7 Seat
3 Rear Wheels 8 Band
4 Rollator Bag 9 Tightening Knob
5 Back Rest Strap

3. Opening rollator
CAUTION!
Be careful not to trap your fingers when pushing down the
seat.
To open the rollator, push down
on either side of the cross bars
as shown. You should feel both
sides click into position.
2. Insert front and rear wheels
Install front and rear wheel sets
as shown. Put the wheel set
tube into the frame tube and
make sure the spring ball has
popped out. Do the same for all
four wheels.
5

4. Inserting the handles
Insert the handles as shown and
push down to the required height.
Use the tightening knobs provided
to secure in place at the desired
height.
5. Folding the rollator
To fold the rollator pull up the
strap in the middle of the seat
as shown.
Note: As shown, a band is
supplied to hold the rollator
together in folded postion
6

6. Rollator Bag
Attach the bag to the rollator by
placing the bag hoops over the
two bag hangers postioned at
the front of the seat as shown.
Place the two Velcro bag straps
around the rollator frame to
secure the lower section of the
bag.
CAUTION!
Never overload the bag’s 5kg MAX load.
7. Back Strap
Before using the rollator check
that the back strap frame bolts
are securely tightened and that
the velcro straps are secure.
7

9. Handle Height Adjustment
To adjust the handle height up
or down, undo the tightening
knob and adjust the height.
Tighten the knob back up mak-
ing sure the handles are secure
and level.
10. Braking
For braking while moving, pull
both brake levers upwards as
shown and always brake slowly
and steadily.
8. Stick Holder
Attatched to the rollator is a
stick holder. Place your stick into
the stick holder as shown and
secure stick by using the Velcro
strap attatched to the back rest.
8

12. Sitting on the Rollator
Before sitting down on the rollator ensure the brakes are in the parking
position and make sure the rollator is on an even surface and will not slide
or topple over. Sit up straight and never lean backwards.
Do not support your weight on the handle when attempting to sit. Use
the handle to stabilize your body as you carefully turn around. Keep your
hands on the handles and slowly lower your weight onto the seat.
WARNING!
Never move rollator while seated.
Always apply parking brakes before sitting.
11. Locking the Brakes (Parking Position)
Push both brake levers down to
apply and lock the brakes while
the rollator is stationary.
WARNING!
Test the brakes regulary
9

Maintenance and Other
10
IMPORTANT! Do not use strong corrosive cleaners to clean or
polish surface. This could damage the rollator.
IMPORTANT! Store in dry location.
CAUTION! Be careful when folding and unfolding the rollator to
avoid injury by the mechanism.
WARNING! Always apply brakes when in stationary position or
when seated on rollator.
WARNING! Do not hang bags or other items from handles - this
will add stress to the rollator and could also make it unstable.
Manufactured by
One Rehab Ltd
