CASCADING FOUNTAIN
Model 93442
ASSEMBLY AND OPERATING INSTRUCTIONS
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Distributed exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2005 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.

PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front cover.
Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate this product in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Electrically charged products
create sparks which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a this product.
Distractions can cause you to lose control. Protect others in the work area from
SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 2
debris such as chips and sparks. Provide barriers or shields as needed.
ELECTRICAL SAFETY
4. Grounded products must be plugged into an outlet properly installed and
Item Description
Electrical Requirements 120 VAC / 60Hz / 0.04 AMPs
Power Cord: 6’-3” / 18AWG x 3 C
Power Plug: 3-Prong
Water Pump Self-Priming with Intake Filter / 1/4” Outlet Nipple
Large Bowl Size 13-1/4” Diameter x 4-1/2” High
Small Bowl Size 6-1/4” Diameter x 2-7/8” High
Jug Size 4-7/8” Diameter x 6” High
Stand Frame Dimensions 11” Diameter x 16-3/4” High
Overall Dimensions 15-5/8” Long x 17” Wide x 21-1/2” High
Unit Weight 16.25 Pounds
REV 09c

grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify the plug in any way. Do not use any adapter
plugs. Check with a qualified electrician if you are in doubt as to whether
the outlet is properly grounded. If the product should electrically malfunction
or break down, grounding provides a low resistance path to carry electricity away
from the user.
5. Double insulated products are equipped with a polarized plug (one blade is
wider than the other). This plug will fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install a polarized outlet. Do not
change the plug in any way. Double insulation eliminates the need for the
three wire grounded power cord and grounded power supply system.
6. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if your
body is grounded.
7. Do not abuse the Power Cord. Never use the Power Cord to carry this
product or pull the Plug from an outlet. Keep the Power Cord away from
heat, oil, sharp edges, or moving parts. Replace damaged Power Cords
immediately. Damaged Power Cords increase the risk of electric shock.
8. When operating this product outside, use an outdoor extension cord
marked “W-A” or “W”. These extension cords are rated for outdoor use, and
reduce the risk of electric shock.
PERSONAL SAFETY
9. Stay alert. Watch what you are doing, and use common sense when
operating this product. Do not use the Fountain while tired or under the
influence of drugs, alcohol, or medication. A moment of inattention while
operating this product may result in serious personal injury.
10. Avoid accidental starting. Make sure the Power Cord remains unplugged from
its electrical outlet until this product is completely assembled, filled with water,
and ready to use.
SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 3
11. Do not overreach. Keep proper footing and balance at all times. Proper
footing and balance enables better control of this product in unexpected
situations.

12. Use safety equipment. Wear eye protection when assembling this product.
Non-skid safety shoes must be used for appropriate conditions.
TOOL USE AND CARE
13. Disconnect the Power Cord Plug from the power source before making any
adjustments, changing accessories, or storing the Fountain. Such
preventive safety measures reduce the risk of starting the unit accidentally.
14. Store idle equipment out of reach of children and other untrained persons.
Electrically powered products are dangerous in the hands of untrained users.
15. Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect this product’s operation. If damaged,
have the Fountain serviced before using. Many accidents are caused by
poorly maintained equipment.
SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 4
SERVICE
16. Service must be performed only by qualified repair personnel. Service
or maintenance performed by unqualified personnel could result in a risk of injury.
17. When servicing this product, use only identical replacement parts. Follow
instructions in the “Inspection, Maintenance, And Cleaning” section of this
manual. Use of unauthorized parts or failure to follow maintenance instructions
may create a risk of electric shock or injury.
SPECIFIC SAFETY RULES
1. Maintain labels and nameplates on the Fountain. Save this instruction
manual. These carry important information. If unreadable or missing, contact
Harbor Freight Tools for a replacement.
2. Wear ANSI approved safety impact eye goggles and heavy duty work
gloves when assembling the Fountain. Using personal safety devices
reduce the risk for injury. Safety impact eye goggles and heavy duty work
gloves are available from Harbor Freight Tools.

3. Maintain a safe environment. Keep the area well lit. Make sure there is ade-
quate surrounding space. Always keep the area free of obstructions, grease, oil,
trash, and other debris. Do not use an electrically powered product in areas near
flammable chemicals, dusts, and vapors.
SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 5
4. Never leave the Fountain unattended when it is plugged into an electrical
outlet. Turn off the Fountain before leaving.
5. Carefully inspect the condition of the Fountain before use, and check the
Fountain continually during use. If any damage is noted, stop immediately
and repair or replace the Fountain.
6. Make sure the Pump (9) is unplugged from its electrical outlet prior to
performing any inspection, maintenance, or cleaning procedures.
7. CAUTION! Excessive weight or pressure on any of the Fountain sections
may cause it to tip and/or fall. Keep children and pets away from any of the
Fountain sections and the Power Cord.
8. The ceramic Bowls (5, 6, 7) are fragile and can be easily damaged. Handle
with care.
9. This Fountain is designed for use with cold, clean water only. Do not use
water over 85 degrees Fahrenheit as it will damage the inner seals of the Pump
(9) may occur. Do not use this Fountain with any other liquids.
10. Make sure the water supply used for the Fountain is not dirty, sandy, and
does not contain any corrosive chemical products. Change the water when
necessary and rinse out the ceramic Bowls (5, 6, 7) frequently.
11. Running the Pump (9) without sufficient water can damage the Pump. This
Pump requires a minimum of 2 inches of water at all times.
12. If locating the Fountain on a ground surface, make sure the surface is flat,
level, and dry.
13. If locating the Fountain on a table, make sure the table is flat, level, dry,
and sturdy enough to support the weight of the Fountain and its water. Always
keep the Fountain out of reach of children.
14. Avoid accidental electric shock. Keep all electrically powered products
away from the Fountain. Disconnect the Pump (9) from its electrical outlet
before placing hands in a ceramic Bowl (5, 6, 7) filled with water. Make
sure to stand on a dry, insulated surface such as a rubber mat while using
the Fountain.

15. Always arrange a “drip loop” in the Power Cord connecting the Pump (9) to
a 120 volt, grounded, electrical outlet. A drip loop is that part of the Power
Cord below the level of the electrical outlet, or the connector if an
extension cord is used, to prevent water traveling along the Power Cord
and coming in contact with the outlet. If the Power Cord Plug or outlet
does get wet, do not unplug the Power Cord Plug. Disconnect the fuse or
circuit breaker that supplies power to the electrical outlet. Then, unplug
the Power Cord and examine for presence of water in the outlet.
(See Figure A.)
.
.
.
SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 6
16. WARNING! People with pacemakers should consult their physician(s) be-
fore using this product. Operation of electrical equipment in close proximity to a
heart pacemaker could cause interference or failure of the pacemaker.
17. WARNING! The warnings and cautions discussed in this manual cannot
cover all possible conditions and situations that may occur. It must be understood
by the operator that common sense and caution are factors which cannot be built
into this product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS
DRIP LOOP
(WATER)
120 VOLT, GROUNDED,
ELECTRICAL OUTLET
POWER CORD
FIGURE A

SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 7
GROUNDED TOOLS: TOOLS WITH THREE PRONG PLUGS
1. Tools marked with “Grounding Required” have a three wire cord and three prong
grounding plug. The plug must be connected to a properly grounded outlet. If the
tool should electrically malfunction or break down, grounding provides a low
resistance path to carry electricity away from the user, reducing the risk of electric
shock. (See Figure B.)
2. The grounding prong in the plug is connected through the green wire inside the
cord to the grounding system in the tool. The green wire in the cord must be the
only wire connected to the tool’s grounding system and must never be attached
to an electrically “live” terminal. (See Figure B.)
3. Your tool must be plugged into an appropriate outlet, properly installed and
grounded in accordance with all codes and ordinances. The plug and outlet
should look like those in the following illustration. (See Figure B.)
THIS PRODUCT USES A
3-PRONG
ELECTRICAL
PLUG
120 VOLT,
GROUNDED,
ELECTRICAL OUTLET
FIGURE B
DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS
4. Tools marked “Double Insulated” do not require grounding. They have a special
double insulation system which satisfies OSHA requirements and complies with
the applicable standards of Underwriters Laboratories, Inc., the Canadian
Standard Association, and the National Electrical Code. (See Figure C.)
5. Double insulated tools may be used in either of the 120 volt outlets shown in the
following illustration. (See Figure C.)
THIS PRODUCT
DOES NOT
USE A
2-PRONG
ELECTRICAL
PLUG
120 VOLT,
GROUNDED,
ELECTRICAL OUTLETS
FIGURE C

SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 8
EXTENSION CORDS
1. Grounded tools require a three wire extension cord. Double Insulated tools
can use either a two or three wire extension cord.
2. As the distance from the supply outlet increases, you must use a heavier gauge
extension cord. Using extension cords with inadequately sized wire causes a
serious drop in voltage, resulting in loss of power and possible tool damage.
(See Figure D.)
3. The smaller the gauge number of the wire, the greater the capacity of the cord.
For example, a 14 gauge cord can carry a higher current than a 16 gauge cord.
(See Figure D.)
4. When using more than one extension cord to make up the total length, make
sure each cord contains at least the minimum wire size required.
(See Figure D.)
5. If you are using one extension cord for more than one tool, add the nameplate
amperes and use the sum to determine the required minimum cord size.
(See Figure D.)
6. If you are using an extension cord outdoors, make sure it is marked with the suf-
fix “W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.
7. Make sure your extension cord is properly wired and in good electrical condition.
Always replace a damaged extension cord or have it repaired by a qualified elec-
trician before using it.
8. Protect your extension cords from sharp objects, excessive heat, and damp or
wet areas.
FIGURE D

SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 9
SYMBOLOGY
V ~
A
xxxx/min.
no
Double Insulated
Canadian Standards
Association
Underwriters
Laboratories, Inc.
Volts Alternating Current
Amperes
No Load Revolutions
per Minute (RPM) FIGURE E
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts List on page 13
are included. If any parts are missing or broken, please call Harbor Freight Tools at the
number shown on the cover of this manual as soon as possible.
ASSEMBLY AND OPERATING INSTRUCTIONS
NOTE:
For additional information regarding the parts listed in the
following pages, refer to the Assembly Diagram on page 13.
CAUTION! Always make sure the Pump (9) is disconnected from its
electrical outlet prior to assembling the Fountain, adding any water, or performing
service to the product.
Assembly Instructions:
1. NOTE: Assembly will require the assistance of another person.
2. Place the Bottom Stand (1) in the location where the Fountain is to be used.
(See Assy. Diagram.)
3. Attach the Vertical Stand (2) to the Bottom Stand (1). (See Assy. Diagram.)
4. Attach the Middle Stand (3) to the Vertical Stand (2) and Bottom Stand (1).
(See Assy. Diagram.)
WARNING: DROWNING HAZARD; KEEP OUT OF SMALL CHILDREN’S REACH.

SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 10
5. Attach the Top Stand (4) to the Vertical Stand (2) and Middle Stand (3).
(See Assy. Diagram.)
6. Carefully set the Large Bowl (5) on the Bottom Stand (1). (See Assy. Diagram.)
7. Carefully set three Small Bowls (6) on the Middle Stand (3) and Top Stand (4).
(See Assy. Diagram.)
8. Carefully set the Jug (7) on the Top Stand (4). (See Assy. Diagram.)
9. Route the Hose (8) downward into the Large Bowl (5). (See Assy. Diagram.)
10. Set the Pump (9) in the middle of the Large Bowl (5). (See Assy. Diagram.)
11. Connect the Hose (8) to the Pump (9). (See Assy. Diagram.)
12. Make sure the Fountain is unplugged from its electrical outlet. Then, move the
Flow Regulator of the Pump (9) towards the “+” position. NOTE: After running
the Fountain, it may be necessary to adjust the rate of water flow. If so,
disconnect the Pump from its electrical outlet. Moving the Flow Regulator
towards the “+” position increases the rate of flow. Moving the Flow Regulator
towards the “--” position decreases the rate of flow. (See Figure F.)
13. Fill the Large Bowl (5) with a minimum 2” of water. Do not overfill the Large
Bowl. (See Assy. Diagram and Figure F.)
PUMP (9)
FLOW
REGULATOR
MINIMUM WATER LEVEL
FOR BEST RESULTS,
COMPLETELY SUBMERGE THE PUMP.
FIGURE F

SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 11
Operating Instructions:
1. Plug the Power Cord of the Pump (9) into the nearest 120 volt, grounded,
electrical outlet, making sure to arrange a “drip loop” in the Cord. The Pump will
now run continuously until it is unplugged from its electrical outlet. (See Figure G.)
2. Allow sufficient time for the Pump (9) to move water upward into the Jug (7).
Once the Jug is filled to overflowing, the water will begin cascading downward
into the three Small Bowls (6) and into the Large Bowl where it will again be
pumped upward to repeat the process. (See Assy. Diagram.)
3. When finished using the Fountain, always unplug the Power Cord from the
electrical outlet. Drain the Fountain of all water.Then store the unit in a clean,
dry, safe location out of reach of children.
INSPECTION, MAINTENANCE, AND CLEANING
1. WARNING! Make sure the Power Cord of the Pump (9) is disconnected
from its electrical outlet prior to performing any inspection, maintenance, or
cleaning procedures.
2. Before each use, inspect the general condition of the Fountain. Check for
cracked or broken parts, damaged electrical wiring, and any other condition
that may affect safe operation. If abnormal noise or vibration occurs, have the
problem corrected before further use. Do not use damaged equipment.
3. To clean the Pump Filter: A clogged or dirty Pump Filter will greatly reduce
performance of the Fountain. To clean the Pump Filter, remove the Front Plate
of the Pump to expose the Filter. Use a stream of clean water to clean the Filter
and Impeller area inside the Pump. Then, replace the Front Plate.
4. Make sure the water supply used for the Fountain is not dirty, sandy, and
does not contain any corrosive chemical products. Change the water when
necessary and rinse out the ceramic Bowls (5, 6, 7) frequently.
DRIP LOOP
(WATER)
120 VOLT, GROUNDED,
ELECTRICAL OUTLET
POWER CORD
FIGURE G

SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 12
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER
AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS
SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER.
THE BUYER ASSUMES ALL RISKS AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE
ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER
INSTALLATION OF REPLACEMENT PARTS THERETO.
6. CAUTION! All maintenance, service, or repairs not mentioned in this
manual must only be performed by a qualified service technician.
5. When storing, make sure to store the Fountain in a clean, dry, safe location out
of reach of children.
GROUNDING
WARNING!
Improperly connecting the grounding wire can result in the risk of electric shock. Check
with a qualified electrician if you are in doubt as to whether the outlet is properly grounded.
Do not modify the power cord plug provided with the tool. Never remove the grounding
prong from the plug. Do not use the tool if the power cord or plug is damaged. If damaged,
have it repaired by a service facility before use. If the plug will not fit the outlet, have a
proper outlet installed by a qualified electrician.
TROUBLESHOOTING

PARTS LIST AND ASSEMBLY DIAGRAM
NOTE:
Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 13
1
2
3
4
5
6
6
6
7
8
9
Part # Description Qty. Part # Description Qty.
1 Bottom Stand 1 6 Small Bowl 3
2 Vertical Stand 1 7 Jug 1
3 Middle Stand 1 8 Hose 1
4 Top Stand 1 9 Pump 1
5 Large Bowl 1

SKU 93442 For technical questions, please call 1-800-444-3353 PAGE 14
REV 09c
